Change trim
MSRP
- RWD 4dr X $23,065
- 4WD 4dr X $24,240
- RWD 4dr Sahara $27,770
- 4WD 4dr X RHD $27,870
- 4WD 4dr Sahara $28,945
- 4WD 4dr Rubicon $32,090
2009 Jeep Wrangler Unlimited Sahara specs & colors
Sport Utility
$27,770
Starting MSRP
Current listing price
Current listing price
Showing the 2009 Jeep Wrangler Unlimited RWD 4dr Sahara
Shop NowKey specs
Color options
Interior
Dark Khaki / Medium Khaki
Dark Slate Gray / Medium Slate Gray
Packages
$0
Starting MSRP
- 3.8L V6 engine
- 4-speed auto trans
Specifications
| EPA Classification | 2WD Sport Utility Vehicle |
| Front Wheel Size | 18 x 7.5 in |
| Rear Wheel Size | 18 x 7.5 in |
| Spare Wheel Size | 18 x 7.5 in |
| Front Wheel Material | Aluminum |
| Rear Wheel Material | Aluminum |
| Spare Wheel Material | Aluminum |
| Cold Cranking Amps @ 0° F (Primary) | 600 |
| Maximum Alternator Capacity (amps) | 140 |
| Engine Type | Gas V6 |
| Displacement | 3.8L/231 |
| SAE Net Horsepower @ RPM | 202 @ 5200 |
| SAE Net Torque @ RPM | 237 @ 4000 |
| EPA Fuel Economy Est - Hwy | 20 MPG |
| Cruising Range - City | 337.50 mi |
| EPA Fuel Economy Est - City | 15 MPG |
| Fuel Economy Est-Combined | 17 MPG |
| Cruising Range - Hwy | 450.00 mi |
| EPA MPG Equivalent - City | N/A |
| EPA MPG Equivalent - Hwy | N/A |
| EPA MPG Equivalent - Combined | N/A |
| Estimated Battery Range | N/A mi |
| Drivetrain | 2-Wheel Drive |
| Trans Type | 4 |
| Trans Description Cont. | Automatic |
| Trans Description Cont. Again | Not Available |
| First Gear Ratio (:1) | 2.84 |
| Second Gear Ratio (:1) | 1.57 |
| Third Gear Ratio (:1) | 1.00 |
| Fourth Gear Ratio (:1) | 0.69 |
| Reverse Ratio (:1) | 2.21 |
| Final Drive Axle Ratio (:1) | 3.73 |
| Transfer Case Gear Ratio (:1), High | Not Available |
| Transfer Case Gear Ratio (:1), Low | Not Available |
| Suspension Type - Front | Live Axle |
| Suspension Type - Rear | Live Axle |
| Suspension Type - Front (Cont.) | w/Coil Springs |
| Suspension Type - Rear (Cont.) | w/Coil Springs |
| Brake Type | Pwr |
| Brake ABS System | 4-wheel |
| Brake ABS System (Second Line) | N/A |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 11.9 x 1.1 in |
| Rear Brake Rotor Diam x Thickness | 12.4 x 0.5 in |
| Drum - Rear (Yes or ) | Not Available |
| Fuel Tank Capacity, Approx | 22.5 gal |
| Aux Fuel Tank Capacity, Approx | N/A gal |
| Steering Type | Pwr |
| Steering Ratio (:1), Overall | 14.7 |
| Lock to Lock Turns (Steering) | 3.5 |
| Turning Diameter - Curb to Curb | 41.2 ft |
| Turning Diameter - Wall to Wall | N/A ft |
| Front Tire Size | P255/70R18 |
| Rear Tire Size | P255/70R18 |
| Spare Tire Size | P255/70R18 |
| Dead Weight Hitch - Max Trailer Wt. | 3500 lbs |
| Dead Weight Hitch - Max Tongue Wt. | 350 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | 3500 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 525 lbs |
| Maximum Trailering Capacity | N/A lbs |
| Base Curb Weight | 4086 lbs |
| Curb Weight - Front | N/A lbs |
| Curb Weight - Rear | N/A lbs |
| Maximum Payload Capacity | N/A lbs |
| Curb Weight | N/A lbs |
| Total Option Weight | 0.00 lbs |
| Passenger Capacity | 5 |
| Passenger Volume | 103.9 ft³ |
| Front Head Room | 41.3 in |
| Front Leg Room | 41.0 in |
| Front Shoulder Room | 55.8 in |
| Front Hip Room | 55.6 in |
| Second Head Room | 40.4 in |
| Second Leg Room | 37.2 in |
| Second Shoulder Room | 56.8 in |
| Second Hip Room | 56.7 in |
| Wheelbase | 116.0 in |
| Length, Overall | 173.3 in |
| Width, Max w/o mirrors | 73.9 in |
| Height, Overall | N/A in |
| Track Width, Front | 61.9 in |
| Track Width, Rear | 61.9 in |
| Min Ground Clearance | 10.2 in |
| Rear Door Opening Height | 37.1 in |
| Rear Door Opening Width | 58.7 in |
| Cargo Area Length @ Floor to Seat 1 | N/A in |
| Cargo Area Length @ Floor to Seat 2 | N/A in |
| Cargo Area Length @ Floor to Seat 3 | Not Available in |
| Cargo Area Width @ Beltline | N/A in |
| Cargo Box Width @ Wheelhousings | 44.7 in |
| Cargo Box (Area) Height | N/A in |
| Liftover Height | 31.4 in |
| Cargo Volume to Seat 1 | 86.8 ft³ |
| Cargo Volume to Seat 2 | 46.4 ft³ |
| Cargo Volume to Seat 3 | Not Available ft³ |
| Rear wheel drive | Standard |
| 4-wheel disc brakes | Standard |
| Next generation Dana 44 HD rear axle | Standard |
| 4-speed automatic transmission | Standard |
| Hood insulation | Optional |
| Rear stabilizer bar | Standard |
| Black front frame overlay | Standard |
| Cargo compartment covered storage | Standard |
| (6) Infinity speakers w/subwoofer | Optional |
| Black/silver front bumper | Optional |
| Outside temp & compass gauge | Optional |
| Black/silver rear bumper | Optional |
| 600-CCA maintenance free battery | Standard |
| Sport bar w/full padding | Standard |
| Leather-wrapped steering wheel w/bright spokes | Optional |
| Front passenger sun visor | Standard |
| Driver height adjustment | Standard |
| Tire pressure monitoring warning lamp | Standard |
| HD suspension w/gas shocks | Optional |
| Full length floor console | Standard |
| 1-year SIRIUS subscription | Optional |
| Pwr windows w/driver & front-passenger one-touch down | Optional |
| (2) front/(1) rear tow hooks | Optional |
| Easy folding soft top | Standard |
| Child safety rear door locks | Standard |
| Remote keyless entry | Optional |
| Rear dome light w/on/off switch | Standard |
| Fog lamps | Optional |
| 3.8L OHV 12-valve SMPI V6 engine | Standard |
| Premium cloth seat trim | Optional |
| Swing-away mirrors | Standard |
| Front & rear floor mats | Optional |
| Bright interior accents | Optional |
| Halogen headlamps | Standard |
| Speed control | Optional |
| Stain & odor resistant anti-static seat fabric | Optional |
| Deep-tint sunscreen windows | Optional |
| Hydraulic assist brake boost | Standard |
| 4-wheel anti-lock brakes | Standard |
| Cargo tie down loops | Standard |
| Electronic stability program | Standard |
| Front tinted glass | Standard |
| Electronic roll mitigation | Standard |
| SIRIUS satellite radio *N/A in HI* | Optional |
| Outside tire carrier | Standard |
| 18" x 7.5" aluminum machined cast wheels | Optional |
| Tilt steering column | Standard |
| Matching spare wheel | Standard |
| Tip start | Standard |
| Body color grille | Standard |
| Air conditioning | Standard |
| Traction control | Standard |
| Security alarm | Optional |
| Front seatback map pockets | Optional |
| Reclining front seats | Standard |
| 3.73 axle ratio | Standard |
| Pwr door locks | Optional |
| Full size spare tire | Standard |
| Low back bucket seats | Standard |
| Tubular side steps | Optional |
| Sunrider soft top feature | Standard |
| Tinted windshield glass | Standard |
| Front stabilizer bar | Standard |
| Driver & front passenger advanced multi-stage frontal airbags | Standard |
| Sentry Key theft deterrent system | Standard |
| Hill start assist | Standard |
| Variable intermittent windshield wipers | Standard |
| 60/40 folding rear seat | Standard |
| AM/FM stereo w/CD/MP3 player -inc: aux input jack | Standard |
| 140-amp alternator | Standard |
| Driver sun visor | Standard |
| Premium instrumentation w/tachometer | Optional |
| Pwr steering | Standard |
| Fuel tank skid plate | Standard |
| Auxiliary 12-volt pwr outlet | Standard |
| P255/70R18 on/off-road OWL tires | Optional |
| Rear passenger assist handle kit | Optional |
