Overview
Door
3-door	3-door	3-door	3-door
Seats
2	2	2	1
Engine
190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)	190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)	190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)	195.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel) 285.0-hp, 5.3-liter, 8 Cylinder Engine(Gasoline Fuel)
Combined MPG
0	0	0	0
Size
" length, 75.0" height	" length, 75.2" height	" length, 75.0" height	" length, 82.0" height
Drivetrain
Rear Wheel Drive	Rear Wheel Drive	Rear Wheel Drive	Rear Wheel Drive

Wheels
Front Wheel Size
16 x 6.5 in	15.0 x 6.5 in	16 x 6.5 in	16 x -TBD- in
Front Wheel Material
Steel	Steel	Steel	Steel
Spare Wheel Size
N/A	16 x 4 in	N/A	16 x -TBD- in
Rear Wheel Size
16 x 6.5 in	15.0 x 6.5 in	16 x 6.5 in	16 x -TBD- in
Spare Wheel Material
Steel	Steel	Steel	Steel
Rear Wheel Material
Steel	Steel	Steel	Steel

Electrical
Maximum Alternator Capacity (amps)
105	105	105	105
Cold Cranking Amps @ 0° F (Primary)
600	600	600	600

Engine
SAE Net Horsepower @ RPM
190 @ 4400	190 @ 4400	190 @ 4400	195 @ 4600
Engine Oil Cooler
Yes	Yes	Yes	Yes
Engine Type
Gas V6	Gas V6	Gas V6	Gas V6
Displacement
4.3L/262	4.3L/262	4.3L/262	4.3L/262
SAE Net Torque @ RPM
250 @ 2800	250 @ 2800	250 @ 2800	260 @ 2800

Mileage
Cruising Range - Hwy
594.00 mi	594.00 mi	594.00 mi	0.00 mi
Fuel Economy Est-Combined
N/A	N/A	N/A	N/A
Cruising Range - City
432.00 mi	459.00 mi	432.00 mi	0.00 mi
Estimated Battery Range
N/A	N/A	N/A	N/A
EPA Fuel Economy Est - Hwy
22 MPG	22 MPG	22 MPG	-
EPA Fuel Economy Est - City
16 MPG	17 MPG	16 MPG	-

Suspension
Suspension Type - Front
Independent Coil	Independent Coil	Independent Coil	Independent Coil
Suspension Type - Rear
Single-Stage Spring	Single-Stage Spring	Single-Stage Spring	Hypoid Multi-Leaf
Axle Type - Front
Independent	Independent	Independent	Independent
Axle Type - Rear
Semi-floating	Semi-floating	Semi-floating	Semi-Floating

Brakes
Front Brake Rotor Diam x Thickness
12 x 1.1 in	11.86 x 1.04 in	12 x 1.1 in	12 x 1.14 in
Rear Brake Rotor Diam x Thickness
12.80 x 0.79 in	-	12.80 x 0.79 in	13 x 1.18 in
Disc - Front (Yes or )
Yes	Yes	Yes	Yes
Brake Type
Power	Power	Power	Pwr
Brake ABS System
4-Wheel	4-Wheel	4-Wheel	4-Wheel
Disc - Rear (Yes or )
Yes	-	Yes	Yes
Drum - Rear (Yes or )
-	Yes	-	-

Steering
Steering Type
Variable Power	Variable Power	Variable Power	Pwr-Assisted
Turning Diameter - Curb to Curb
40.5 ft	40.5 ft	40.5 ft	43.4 ft
Turning Diameter - Wall to Wall
N/A	44.2 ft	N/A	N/A
Steering Ratio (:1), Overall
N/A	N/A	N/A	N/A

Tires
Front Tire Size
P215/70R16	P215/75R15	P215/70R16	P235/75R16EL
Rear Tire Size
P215/70R16	P215/75R15	P215/70R16	P235/75R16EL
Spare Tire Size
N/A	T145/80D16	Compact	P235/75R16EL

Trailering
Dead Weight Hitch - Max Tongue Wt.
200 lbs	200 lbs	200 lbs	440 lbs
Wt Distributing Hitch - Max Trailer Wt.
5300 lbs	6000 lbs	5300 lbs	4400 lbs
Dead Weight Hitch - Max Trailer Wt.
2000 lbs	2000 lbs	2000 lbs	4400 lbs
Wt Distributing Hitch - Max Tongue Wt.
530 lbs	650 lbs	530 lbs	440 lbs
Maximum Trailering Capacity
N/A	N/A	N/A	N/A

Exterior color
Exterior color

Vehicle
Rear Door Type
Panel	Panel	Panel	Dual Swing-out

Frame
Frame Type
Integral body	Integral body	Integral body	Ladder

Doors
Side Door Type
Sliding	Sliding	Sliding	Swing-out

Weight Information
Gross Vehicle Weight Rating
5600.00 lbs	5600.00 lbs	5600.00 lbs	7200.00 lbs
Total Option Weight
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
Gross Axle Weight Rating
5900.00 lbs	5950.00 lbs	5900.00 lbs	7600.00 lbs
Option Weight - Rear
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
As Spec'd Payload
1747.00 lbs	1684.00 lbs	1747.00 lbs	2460.10 lbs
Base Curb Weight
N/A	N/A	N/A	N/A
Curb Weight - Rear
1584 lbs	1634 lbs	1584 lbs	2052.9 lbs
Gross Combined Wt Rating
9500 lbs	9000 lbs	9500 lbs	9500 lbs
Curb Weight
3853.00 lbs	3916.00 lbs	3853.00 lbs	4739.90 lbs
Curb Weight - Front
2269 lbs	2282 lbs	2269 lbs	2687 lbs
Option Weight - Front
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
As Spec'd Curb Weight
3853.00 lbs	3916.00 lbs	3853.00 lbs	4739.90 lbs
Maximum Payload Capacity
1747.00 lbs	1684.00 lbs	1747.00 lbs	2460.10 lbs

Dimensions
Width, Max w/o mirrors
77.5 in	77.5 in	77.5 in	79.4 in
Front Shoulder Room
64.0 in	64.0 in	64.0 in	68.8 in
Ground to Top of Load Floor
26.0 in	26.7 in	26.0 in	27.7 in
Second Head Room
N/A	N/A	N/A	N/A
Length, Overall w/rear bumper
189.8 in	189.8 in	189.8 in	224.1 in
Step Up Height - Side
21.5 in	20.7 in	21.5 in	20.9 in
Cargo Box Width @ Wheelhousings
51.6 in	51.6 in	51.6 in	52.7 in
Cargo Area Length @ Floor to Seat 1
98.6 in	98.6 in	98.6 in	127.8 in
Front Head Room
39.2 in	39.2 in	39.2 in	40.2 in
Passenger Capacity
2	2	2	2
Ground Clearance, Front
6.8 in	6.8 in	6.8 in	8.6 in
Front Hip Room
65.0 in	64.9 in	65.0 in	65.5 in
Ground Clearance, Rear
7.4 in	7.4 in	7.4 in	7.6 in
Cargo Area Width @ Beltline
N/A	57.2 in	N/A	N/A
Cargo Box Width @ Top, Rear
N/A	N/A	N/A	N/A
Side Door Opening Height
46.8 in	46.8 in	46.8 in	47.9 in
Ext'd Cab Cargo Volume
N/A	N/A	N/A	N/A
Rear Door Opening Height
42.0 in	42.0 in	42.0 in	49.4 in
Overhang, Front
32.5 in	32.5 in	32.5 in	N/A
Cargo Box (Area) Height
47.2 in	47.2 in	47.2 in	51.9 in
Side Door Opening Width
34.5 in	34.5 in	34.5 in	44.1 in
Overhang, Rear w/o bumper
N/A	N/A	N/A	N/A
Wheelbase
111.2 in	111.2 in	111.2 in	135 in
Cargo Volume
170.4 ft³	170.4 ft³	170.4 ft³	225.1 ft³
Step Up Height - Front
19.5 in	18.9 in	19.5 in	20.1 in
Front Leg Room
41.6 in	41.6 in	41.6 in	41.3 in
Length, Overall
N/A	N/A	N/A	N/A
Cab to End of Frame
N/A	N/A	N/A	N/A
Tailgate Width
N/A	N/A	N/A	N/A
Second Leg Room
N/A	N/A	N/A	N/A
Cargo Box Width @ Floor
N/A	N/A	N/A	N/A
Cargo Area Length @ Floor to Console
126.0 in	126.0 in	126.0 in	153.6 in
Second Shoulder Room
N/A	N/A	N/A	N/A
Second Hip Room
N/A	N/A	N/A	N/A
Rear Door Opening Width
57.2 in	57.2 in	57.2 in	57.0 in
Height, Overall
75.0 in	75.3 in	75.0 in	81.6 in
