Overview
Door
3-door	3-door	3-door	3-door
Seats
2	2	1	1
Engine
190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)	190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)	200.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel) 220.0-hp, 5.0-liter, 8 Cylinder Engine(Gasoline Fuel) 250.0-hp, 5.7-liter, 8 Cylinder Engine(Gasoline Fuel)	190.0-hp, 4.3-liter, V6 Cylinder Engine(Gasoline Fuel)
Combined MPG
0	0	0	0
Size
" length, 75.0" height	" length, 75.0" height	" length, 79.4" height	" length, 75.2" height
Drivetrain
Rear Wheel Drive	Rear Wheel Drive	Rear Wheel Drive	Rear Wheel Drive

Wheels
Rear Wheel Size
16 x 6.5 in	16 x 6.5 in	15 x 6.0 in	15.0 x 6.5 in
Front Wheel Material
Steel	Steel	Steel	Steel
Front Wheel Size
16 x 6.5 in	16 x 6.5 in	15 x 6.0 in	15.0 x 6.5 in
Spare Wheel Size
N/A	16 x 4 in	15 x 6.0 in	16 x 4 in
Spare Wheel Material
Steel	Steel	Steel	Steel
Rear Wheel Material
Steel	Steel	Steel	Steel

Electrical
Maximum Alternator Capacity (amps)
105	105	100	105
Cold Cranking Amps @ 0° F (Primary)
600	600	600	600

Engine
Engine Type
Gas V6	Gas V6	Gas V6	Gas V6
SAE Net Torque @ RPM
250 @ 2800	250 @ 2800	250 @ 2800	250 @ 2800
Displacement
4.3L/262	4.3L/262	4.3L/262	4.3L/262
SAE Net Horsepower @ RPM
190 @ 4400	190 @ 4400	200 @ 4400	190 @ 4400
Engine Oil Cooler
Yes	Yes	-	Yes

Mileage
EPA Fuel Economy Est - City
16 MPG	16 MPG	15 MPG	17 MPG
EPA Fuel Economy Est - Hwy
22 MPG	21 MPG	18 MPG	22 MPG
Cruising Range - Hwy
594.00 mi	567.00 mi	558.00 mi	594.00 mi
Estimated Battery Range
N/A	N/A	N/A	N/A
Fuel Economy Est-Combined
N/A	N/A	N/A	N/A
Cruising Range - City
432.00 mi	432.00 mi	465.00 mi	459.00 mi

Suspension
Suspension Type - Rear
Single-Stage Spring	Single-Stage Spring	2-Stage Multi-Leaf	Single-Stage Spring
Axle Type - Front
Independent	Independent	Independent	Independent
Axle Type - Rear
Semi-floating	Semi-floating	Semi-Floating	Semi-floating
Suspension Type - Front
Independent Coil	Independent Coil	Independent Coil	Independent Coil

Brakes
Drum - Rear (Yes or )
-	-	Yes	Yes
Brake Type
Power	Pwr	Power	Power
Disc - Front (Yes or )
Yes	Yes	Yes	Yes
Brake ABS System
4-Wheel	4-Wheel	4-Wheel	4-Wheel
Front Brake Rotor Diam x Thickness
12 x 1.1 in	12.00 x 1.14 in	11.57 x 1.25 in	11.86 x 1.04 in
Rear Brake Rotor Diam x Thickness
12.80 x 0.79 in	12.80 x 0.79 in	-	-
Disc - Rear (Yes or )
Yes	Yes	-	-

Steering
Turning Diameter - Curb to Curb
40.5 ft	40.5 ft	45.2 ft	40.5 ft
Steering Type
Variable Power	Pwr	Variable Power	Variable Power
Turning Diameter - Wall to Wall
N/A	44.2 ft	N/A	44.2 ft
Steering Ratio (:1), Overall
N/A	N/A	N/A	N/A

Tires
Rear Tire Size
P215/70R16	P215/70R16	P215/75R15	P215/75R15
Front Tire Size
P215/70R16	P215/70R16	P215/75R15	P215/75R15
Spare Tire Size
N/A	Compact	P215/75R15	T145/80D16

Trailering
Wt Distributing Hitch - Max Tongue Wt.
530 lbs	520 lbs	1000 lbs	750 lbs
Dead Weight Hitch - Max Trailer Wt.
2000 lbs	2000 lbs	4000 lbs	2000 lbs
Dead Weight Hitch - Max Tongue Wt.
200 lbs	200 lbs	400 lbs	200 lbs
Wt Distributing Hitch - Max Trailer Wt.
5300 lbs	5200 lbs	7300 lbs	6000 lbs
Maximum Trailering Capacity
N/A	N/A	N/A	N/A

Exterior color
Exterior color

Vehicle
Rear Door Type
Panel	Panel	Dual Swing-out	Panel

Frame
Frame Type
Integral body	Integral body	Ladder	Integral body

Doors
Side Door Type
Sliding	Sliding	Swing-out	Sliding

Weight Information
As Spec'd Curb Weight
3853.00 lbs	3853.00 lbs	4639.00 lbs	3916.00 lbs
Total Option Weight
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
Curb Weight - Front
2269 lbs	2269 lbs	2459 lbs	2282 lbs
Gross Vehicle Weight Rating
5600.00 lbs	5600.00 lbs	6100.00 lbs	5950.00 lbs
Gross Combined Wt Rating
9500 lbs	9500 lbs	9500 lbs	9000 lbs
Curb Weight
3853.00 lbs	3853.00 lbs	4639.00 lbs	3916.00 lbs
As Spec'd Payload
1747.00 lbs	1747.00 lbs	1461.00 lbs	2034.00 lbs
Maximum Payload Capacity
1747.00 lbs	1747.00 lbs	1461.00 lbs	2034.00 lbs
Base Curb Weight
N/A	N/A	N/A	N/A
Option Weight - Front
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
Curb Weight - Rear
1584 lbs	1584 lbs	2180 lbs	1634 lbs
Option Weight - Rear
0.00 lbs	0.00 lbs	0.00 lbs	0.00 lbs
Gross Axle Weight Rating
5900.00 lbs	5900.00 lbs	6335.00 lbs	5950.00 lbs

Dimensions
Tailgate Width
N/A	N/A	N/A	N/A
Front Leg Room
41.6 in	41.6 in	41.1 in	41.6 in
Second Shoulder Room
N/A	N/A	N/A	N/A
Width, Max w/o mirrors
77.5 in	77.5 in	79.4 in	77.5 in
Cargo Area Length @ Floor to Seat 1
98.6 in	98.6 in	127.3 in	98.6 in
Cargo Box Width @ Floor
N/A	N/A	N/A	N/A
Side Door Opening Height
46.8 in	46.8 in	49.1 in	46.8 in
Overhang, Front
32.5 in	32.5 in	33.8 in	32.5 in
Rear Door Opening Height
42.0 in	42.0 in	48.9 in	42.0 in
Ground Clearance, Rear
7.4 in	7.4 in	6.7 in	7.4 in
Cargo Area Length @ Floor to Console
126.0 in	126.0 in	155.9 in	126.0 in
Side Door Opening Width
34.5 in	34.5 in	46.7 in	34.5 in
Overhang, Rear w/o bumper
N/A	N/A	N/A	N/A
Cargo Area Width @ Beltline
N/A	57.2 in	75.5 in	57.2 in
Passenger Capacity
2	2	2	1
Length, Overall w/rear bumper
189.8 in	189.8 in	218.7 in	189.8 in
Front Hip Room
65.0 in	65.0 in	63.8 in	64.9 in
Rear Door Opening Width
57.2 in	57.2 in	56.9 in	57.2 in
Length, Overall
N/A	N/A	N/A	N/A
Cargo Volume
170.4 ft³	170.4 ft³	267.3 ft³	170.4 ft³
Cab to End of Frame
N/A	N/A	N/A	N/A
Ext'd Cab Cargo Volume
N/A	N/A	N/A	N/A
Cargo Box (Area) Height
47.2 in	47.2 in	53.8 in	47.2 in
Ground to Top of Load Floor
26.0 in	26.0 in	24.3 in	26.7 in
Height, Overall
75.0 in	75.0 in	79.4 in	75.3 in
Second Hip Room
N/A	N/A	N/A	N/A
Second Leg Room
N/A	N/A	N/A	N/A
Step Up Height - Front
19.5 in	19.5 in	16.5 in	18.9 in
Cargo Box Width @ Top, Rear
N/A	N/A	N/A	N/A
Front Shoulder Room
64.0 in	64.0 in	68.8 in	64.0 in
Front Head Room
39.2 in	39.2 in	40.6 in	39.2 in
Step Up Height - Side
21.5 in	21.5 in	15.5 in	20.7 in
Cargo Box Width @ Wheelhousings
51.6 in	51.6 in	52.6 in	51.6 in
Wheelbase
111.2 in	111.2 in	135.0 in	111.2 in
Second Head Room
N/A	N/A	N/A	N/A
Ground Clearance, Front
6.8 in	6.8 in	6.9 in	6.8 in
