2021 GMC Canyon 2WD Elevation Standard specs & colors

Extended Cab Pickup

Change trim

MSRP

2WD Ext Cab 128" Elevation Standard $26,800
2WD Crew Cab 128" Elevation Standard $28,700
2WD Ext Cab 128" Elevation $30,300
4WD Ext Cab 128" Elevation Standard $32,200
2WD Crew Cab 128" Elevation $32,200
4WD Crew Cab 128" Elevation $37,300
4WD Crew Cab 141" Elevation $37,900
4WD Crew Cab 128" AT4 w/Cloth $38,400
4WD Crew Cab 141" AT4 w/Cloth $39,000
4WD Crew Cab 128" AT4 w/Leather $40,200
4WD Crew Cab 141" AT4 w/Leather $40,800
2WD Crew Cab 128" Denali $41,200
4WD Crew Cab 128" Denali $44,700
4WD Crew Cab 141" Denali $45,000

Change trim

$26,800

Starting MSRP
Current listing price

Showing the 2021 GMC Canyon 2WD Ext Cab 128" Elevation Standard

Shop Now

Color options

Exterior

Interior

Jet Black / Dark Ash

Packages

Elevation Standard Preferred Equipment Group

$0

Starting MSRP

includes standard equipment

Specifications

Front Wheel Size	18 x 8.5 in
Rear Wheel Material	Aluminum
Front Wheel Material	Aluminum
Spare Wheel Size	18 x 4.5 in
Spare Wheel Material	Aluminum
Rear Wheel Size	18 x 8.5 in

Estimated Battery Range	N/A mi
Fuel Economy Est-Combined	22 MPG
EPA Fuel Economy Est - Hwy	25 MPG
EPA Fuel Economy Est - City	19 MPG
Cruising Range - Hwy	525.00 mi
Cruising Range - City	399.00 mi

Transfer Case Power Take Off	N/A
Sixth Gear Ratio (:1)	0.67
Trans Description Cont. Again	N/A
Reverse Ratio (:1)	3.20
Final Drive Axle Ratio (:1)	N/A
Trans Power Take Off	N/A
Fourth Gear Ratio (:1)	1.16
Fifth Gear Ratio (:1)	0.85
Trans Type	6
Transfer Case Gear Ratio (:1), High	N/A
Second Gear Ratio (:1)	2.37
First Gear Ratio (:1)	4.06
Trans Description Cont.	Automatic
Drivetrain	Rear Wheel Drive
Transfer Case Model	N/A
Third Gear Ratio (:1)	1.55
Transfer Case Gear Ratio (:1), Low	N/A

Disc - Front (Yes or )	Yes
Disc - Rear (Yes or )	Yes
Brake Type	Pwr
Brake ABS System	4-Wheel
Brake ABS System (Second Line)	N/A
Front Brake Rotor Diam x Thickness	12.2 x -TBD- in
Rear Brake Rotor Diam x Thickness	12.75 x -TBD- in
Drum - Rear (Yes or )	N/A

Maximum Trailering Capacity	7000 lbs
Fifth Wheel Hitch - Max Trailer Wt.	N/A lbs
Wt Distributing Hitch - Max Tongue Wt.	350 lbs
Dead Weight Hitch - Max Tongue Wt.	350 lbs
Wt Distributing Hitch - Max Trailer Wt.	3500 lbs
Dead Weight Hitch - Max Trailer Wt.	3500 lbs
Fifth Wheel Hitch - Max Tongue Wt.	N/A lbs

Option Weight - Rear	0.00 lbs
Curb Weight - Front	2183 lbs
Maximum Payload Capacity	1558.00 lbs
As Spec'd Curb Weight	3847.00 lbs
Gross Vehicle Weight Rating	5400.00 lbs
Total Option Weight	0.00 lbs
Curb Weight - Rear	1659 lbs
Gross Combined Wt Rating	8500 lbs
Curb Weight	3842.00 lbs
Base Curb Weight	N/A lbs
Option Weight - Front	0.00 lbs
As Spec'd Payload	1553.00 lbs
Gross Axle Weight Rating	6200.00 lbs

Ground Clearance, Front	8.4 in
Ground to Top of Load Floor	N/A in
Ground Clearance, Rear	8.4 in
Cargo Box Width @ Floor	57.8 in
Cargo Box Width @ Wheelhousings	44.4 in
Cargo Box Length @ Floor	74 in
Ext'd Cab Cargo Volume	N/A ft³
Wheelbase	128.3 in
Second Leg Room	28.6 in
Height, Overall	70.4 in
Second Shoulder Room	57.3 in
Front Shoulder Room	57.5 in
Front Leg Room	45 in
Width, Max w/o mirrors	74.3 in
Cargo Box (Area) Height	N/A in
Tailgate Width	N/A in
Length, Overall w/o rear bumper	N/A in
Second Hip Room	52.2 in
Cargo Box Width @ Top, Rear	N/A in
Second Head Room	36.7 in
Cab to End of Frame	N/A in
Cargo Volume	49.9 ft³
Front Head Room	41.4 in
Passenger Capacity	4
Overhang, Rear w/o bumper	47.2 in
Length, Overall	212.4 in
Length, Overall w/rear bumper	N/A in
Overhang, Front	36.9 in
Front Hip Room	55 in

Audio system, GMC Infotainment System with 7" diagonal color touch-screen AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth streaming audio for music and select phones; featuring Android Auto and Apple CarPlay capability for compatible phones (STD)	Standard
Audio system feature, 6-speaker system	Standard
SiriusXM Radio enjoy an All Access trial subscription with over 150 channels including commercial-free music, plus sports, news and entertainment. Plus listening on the SiriusXM app, online and at home on compatible connected devices is included, so you'll hear the best SiriusXM has to offer, anywhere life takes you. Welcome to the world of SiriusXM. (IMPORTANT: The SiriusXM radio trial package is not provided on vehicles that are ordered for Fleet Daily Rental ("FDR") use. If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your chosen payment method at then-current rates. Fees and taxes apply. See the SiriusXM Customer Agreement at www.siriusxm.com for complete terms and how to cancel. All fees, content, features, and availability are subject to change.)	Standard

Mirrors, outside manual-folding, Black	Standard
Tires, 265/60R18 all-season, blackwall	Standard
CornerStep, rear bumper	Standard
Bumper, rear body-color	Standard
Headlamps, halogen projector-type with LED signature	Standard
Wheels, 18" x 8.5" (45.7 cm x 21.6 cm), Black painted aluminum	Standard
Door handles, Black	Standard
Tailgate handle, Black	Standard
Tailgate, locking (When (PCM) Convenience Package is ordered (EN5) locking tailgate is removed and replaced with (A91) Remote Locking Tailgate.)	Standard
Moldings, Black beltline	Standard
Tire, compact spare T175/90D18, blackwall (Included and only available with (LCV) 2.5L I4 engine.) (STD)	Standard
Wheel, compact spare, 18" x 4.5" (45.7 cm x 11.4 cm) Black cast aluminum (Included and only available with (LCV) 2.5L I4 engine.)	Standard
Lamps, cargo area, cab mounted with switch on center switch bank	Standard

Seat trim, Cloth	Standard
Lighting, interior, center dome	Standard
Seats, front bucket (STD)	Standard
Mirror, inside rearview manual day/night	Standard
Steering column, tilt, manual	Standard
Theft-deterrent system, immobilization	Standard
Floor mats, carpeted front (Deleted when (B38) full-length Black vinyl floor covering is ordered. Requires (B30) color-keyed carpeting floor covering. Removed when ordered with (PDH) Interior Protection Package, LPO, (VAV) All-weather floor mats, LPO or (RIA) All-weather Floor Liner, LPO.)	Standard
Handles, inside door release, front and rear, Jet Black	Standard
Console, floor, front compartment, custom	Standard
USB data ports, 2 includes auxiliary input jack, located on the front console	Standard
Seat adjuster, driver 4-way power with manual recline	Standard
Door locks, power	Standard
Display, driver instrument information enhanced, one color	Standard
Air conditioning, single-zone manual climate control	Standard
Windows, power with driver Express-Up and Down	Standard
Seats, dual rear with underseat storage (Extended Cab models only.)	Standard
Floor covering, color-keyed carpeting	Standard
Seat adjuster, passenger 2-way manual, fore/aft with manual recline	Standard
Visors, driver and front passenger with passenger vanity mirror	Standard
Steering wheel, urethane	Standard
Floor mats, carpeted rear (Requires (B30) color-keyed carpeting floor covering. Removed when ordered with (PDH) Interior Protection Package, LPO, (VAV) All-weather floor mats, LPO or (RIA) All-weather Floor Liner, LPO.)	Standard

Engine, 2.5L I4, DI, DOHC, VVT (200 hp [149.0 kW] @ 6300 rpm, 191 lb-ft of torque [259 N-m] @ 4400 rpm) (STD)	Standard
Pickup box	Standard
Transmission, 6-speed automatic (STD)	Standard
Rear wheel drive	Standard
Capless Fuel Fill (Requires a gas engine.)	Standard
Recovery hooks, front	Standard
Rear axle, 4.10 ratio	Standard
Steering, electric power-assist	Standard
Frame, fully-boxed	Standard
GVWR, 5400 lbs. (2449 kg) (Standard on Extended Cab models with (LCV) 2.5L I4 engine only.) (STD)	Standard
Brakes, 4-wheel antilock, 4-wheel disc	Standard

Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. It includes the Buckle-to-Drive feature which prevents the driver from shifting from Park for up to 20 seconds if the driver's seat belt is not buckled. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver	Standard
Tire Pressure Monitoring System (does not apply to spare tire)	Standard
Rear Vision Camera	Standard
Tire Fill Alert provides an audible and visual indication when tire pressure is added to a tire that is low. Aids to achieve optimal tire pressure	Standard
Daytime Running Lamps	Standard
Airbags, Dual-stage frontal airbags for driver and front passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)	Standard
Traction control, electronic	Standard
StabiliTrak, stability control system	Standard

Compare trims

Wondering which trim is right for you?

Our 2021 GMC Canyon trim comparison will help you decide.

SAE Net Torque @ RPM	191 @ 4400
Engine Oil Cooler	N/A
SAE Net Horsepower @ RPM	200 @ 6300
Displacement	2.5L/150
Engine Type	Gas I4

Suspension Type - Rear	2-Stage Multi-Leaf
Suspension Type - Front	Independent Coil
Axle Type - Front	Independent
Axle Type - Rear	Semi-Floating

Aux Fuel Tank Capacity, Approx	N/A gal
Fuel Tank Capacity, Approx	21 gal

Turning Diameter - Curb to Curb	41.3 ft
Turning Diameter - Wall to Wall	N/A ft
Steering Ratio (:1), Overall	N/A
Steering Type	Electric Rack & Pinion

Cold Cranking Amps @ 0° F (Primary)	N/A
Maximum Alternator Capacity (amps)	N/A

Spare Tire Size	T175/90D18
Front Tire Size	265/60R18
Rear Tire Size	265/60R18
