1998 GMC Sierra 3500 specs & colors
Regular Cab Pickup
Change trim
MSRP
- Reg Cab 131.5" WB $19,189
- Reg Cab 131.5" WB 4WD $22,189
- 4dr 168.5" WB $22,319
- Ext Cab 155.5" WB DRW $22,612
- Ext Cab 155.5" WB 4WD DRW $25,423
- 4dr 168.5" WB 4WD $25,493
$19,189
Starting MSRP
Current listing price
Current listing price
Showing the 1998 GMC Sierra 3500 Reg Cab 131.5" WB
Shop NowKey specs
Color options
Interior
Taupe
Dark Ruby Red
Gray
Navy
Packages
$0
Starting MSRP
- SL decor
$1,337
Starting MSRP
- SL decor
- air cond,ETR AM/FM stereo w/cassette
- tilt wheel
$4,450
Starting MSRP
- SLT decor
- air cond
- tilt wheel
Specifications
| Front Wheel Size | 16 x 6.5 in |
| Rear Wheel Size | 16 x 6.5 in |
| Spare Wheel Size | 16 x 6.5 in |
| Front Wheel Material | Steel |
| Rear Wheel Material | Steel |
| Spare Wheel Material | Steel |
| Cold Cranking Amps @ 0° F (Primary) | 600 |
| Maximum Alternator Capacity (amps) | 100 |
| Engine Type | Gas V8 |
| Displacement | 5.7L/350 |
| SAE Net Horsepower @ RPM | 255 @ 4600 |
| SAE Net Torque @ RPM | 330 @ 2800 |
| Engine Oil Cooler | Yes |
| EPA Fuel Economy Est - Hwy | Not Available MPG |
| Cruising Range - City | 0.00 mi |
| EPA Fuel Economy Est - City | Not Available MPG |
| Fuel Economy Est-Combined | N/A MPG |
| Cruising Range - Hwy | 0.00 mi |
| Estimated Battery Range | N/A mi |
| Drivetrain | Rear Wheel Drive |
| Trans Type | 5 |
| Trans Description Cont. | HD Manual w/OD, |
| Trans Description Cont. Again | Deep Low |
| First Gear Ratio (:1) | 5.61 |
| Second Gear Ratio (:1) | 3.04 |
| Third Gear Ratio (:1) | 1.67 |
| Fourth Gear Ratio (:1) | 1.00 |
| Fifth Gear Ratio (:1) | 0.75 |
| Reverse Ratio (:1) | 5.61 |
| Trans Power Take Off | SAE 6-Bolt |
| Final Drive Axle Ratio (:1) | N/A |
| Transfer Case Model | Not Available |
| Transfer Case Gear Ratio (:1), High | Not Available |
| Transfer Case Gear Ratio (:1), Low | Not Available |
| Transfer Case Power Take Off | Not Available |
| Suspension Type - Front | Indep Coil Spring |
| Suspension Type - Rear | 2-Stage Multi-Leaf |
| Axle Type - Front | Not Available |
| Axle Type - Rear | Full-Floating |
| Frame Type | Ladder |
| Brake Type | Power |
| Brake ABS System | Four Wheel |
| Brake ABS System (Second Line) | Not Available |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Not Available |
| Front Brake Rotor Diam x Thickness | 12.50 x 1.26 in |
| Rear Brake Rotor Diam x Thickness | Not Available in |
| Drum - Rear (Yes or ) | Yes |
| Fuel Tank Capacity, Approx | 34 gal |
| Aux Fuel Tank Capacity, Approx | Not Available gal |
| Steering Type | Power |
| Steering Ratio (:1), Overall | N/A |
| Turning Diameter - Curb to Curb | 43.4 ft |
| Turning Diameter - Wall to Wall | 47.9 ft |
| Front Tire Size | LT245/75R16E |
| Rear Tire Size | LT245/75R16E |
| Spare Tire Size | LT245/75R16E |
| Dead Weight Hitch - Max Trailer Wt. | 5000 lbs |
| Dead Weight Hitch - Max Tongue Wt. | 500 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | 10,000 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 1000 lbs |
| Fifth Wheel Hitch - Max Trailer Wt. | Not Available lbs |
| Fifth Wheel Hitch - Max Tongue Wt. | Not Available lbs |
| Maximum Trailering Capacity | N/A lbs |
| Base Curb Weight | N/A lbs |
| Curb Weight - Front | 2841 lbs |
| Curb Weight - Rear | 2029 lbs |
| Option Weight - Front | 0.00 lbs |
| Option Weight - Rear | 0.00 lbs |
| As Spec'd Curb Weight | 4870.00 lbs |
| As Spec'd Payload | 4130.00 lbs |
| Maximum Payload Capacity | 4130.00 lbs |
| Gross Combined Wt Rating | 13,500 lbs |
| Gross Axle Weight Rating | 9684.00 lbs |
| Curb Weight | 4870.00 lbs |
| Total Option Weight | 0.00 lbs |
| Gross Vehicle Weight Rating | 9000.00 lbs |
| Passenger Capacity | 3 |
| Front Head Room | 40.0 in |
| Front Leg Room | 41.5 in |
| Front Shoulder Room | 65.0 in |
| Front Hip Room | 60.1 in |
| Second Head Room | N/A in |
| Second Leg Room | N/A in |
| Second Shoulder Room | N/A in |
| Second Hip Room | N/A in |
| Wheelbase | 131.5 in |
| Length, Overall w/o rear bumper | 213.4 in |
| Length, Overall w/rear bumper | N/A in |
| Length, Overall | N/A in |
| Width, Max w/o mirrors | 76.8 in |
| Height, Overall | 73.4 in |
| Overhang, Front | 35.4 in |
| Overhang, Rear w/o bumper | 46.5 in |
| Cab to End of Frame | Not Available in |
| Ground to Top of Load Floor | 35.3 in |
| Ground Clearance, Front | 8.4 in |
| Ground Clearance, Rear | 6.4 in |
| Cargo Box Length @ Floor | 97.6 in |
| Cargo Box Width @ Top, Rear | 60.2 in |
| Cargo Box Width @ Floor | 64.4 in |
| Cargo Box Width @ Wheelhousings | 49.1 in |
| Cargo Box (Area) Height | 19.2 in |
| Tailgate Width | 62.0 in |
| Cargo Volume | 69.1 ft³ |
| Ext'd Cab Cargo Volume | Not Available ft³ |
| Full-floating rear axle | Standard |
| Double-wall steel construction 8' pickup box w/extensive corrosion protection | Standard |
| Leaf spring rear suspension | Standard |
| Chrome front bumper | Standard |
| Passlock theft deterrent security system | Standard |
| Front outboard shoulder belt height adjusters | Standard |
| 5.7L (350) SFI V8 (Vortec) engine | Standard |
| Four-wheel anti-lock brake system | Standard |
| Cargo area lamp | Standard |
| Dual black foldaway mirrors | Standard |
| Single note horn | Standard |
| 9000# GVWR (3600 front/6084 rear), springs (3600 front/6084 rear), axles (3800 front/6084 rear) | Standard |
| Intermittent windshield wiper system | Standard |
| HD 5-speed manual transmission w/deep low, OD | Standard |
| Solid exterior paint | Standard |
| Manual lap safety belts, center seat position | Standard |
| Winch-type spare tire carrier (under rear frame) | Standard |
| Independent front suspension w/coil springs | Standard |
| Lighting-inc: dome, reading, ashtray, glove-box, illuminated entry feature, underhood | Standard |
| Scotchgard Fabric Protector on all cloth & carpet surfaces | Standard |
| 1.25" Front stabilizer bar | Standard |
| Heater/defogger w/side window defoggers | Standard |
| Single rectangular halogen headlamps | Standard |
| Color-keyed molded vinyl floor covering | Standard |
| 16" silver painted steel wheels w/black center cap-inc: spare wheel | Standard |
| Cigarette lighter | Standard |
| Molded plastic door trim panels w/dual padded armrests | Standard |
| Single rear wheels | Standard |
| Manual lap/shoulder safety belts, outboard seat positions | Standard |
| Argent painted grille | Standard |
| Daytime running lamps | Standard |
| Removable tailgate | Standard |
| Daytime running lamps | Standard |
| Dual cupholders on instrument panel | Standard |
| Rear wheel drive | Standard |
| Solar-Ray tinted glass (all windows) | Standard |
| Dual coat hooks | Standard |
| Lights-on warning buzzer | Standard |
| Energy-absorbing steering column/instrument panel | Standard |
| Head restraints, front seat | Standard |
| Aluminized stainless steel exhaust system | Standard |
| Passenger assist handle | Standard |
| Dual dash mounted power outlets | Standard |
| 100 amp alternator | Standard |
| Simulated leather steering wheel | Standard |
| Painted rear step bumper w/step pad | Standard |
| Mechanical jack & wheel wrench | Standard |
| Glove box w/latched door | Standard |
| Passenger side instrument panel storage bin | Standard |
| Single, two-sided key | Standard |
| Side door guard beams | Standard |
| Color-keyed cloth headliner | Standard |
| 3-passenger bench seat w/folding backrest | Standard |
| 600 CCA 12-volt battery | Standard |
| Speed-sensitive pwr steering | Standard |
| Gauges-inc: speedometer, tachometer, odometer, trip odometer, voltmeter, fuel level, engine temperature, oil pressure | Standard |
| Pwr front disc/rear drum brakes | Standard |
| (5) LT245/75R16E all-season SBR BSW tires | Standard |
| 8-lead trailering wire harness | Standard |
| Insulation under dash & floor covering | Standard |
| ETR AM/FM stereo-inc: seek-scan, digital clock, 4 speakers | Standard |
| Dual color-keyed padded cloth sunshades w/LH storage strap, RH vanity mirror | Standard |
| 34 gallon fuel tank | Standard |
| Four-wheel anti-lock brake system | Standard |
