2012 GMC Sierra 3500 Work Truck specs & colors

Regular Cab Pickup

Change trim
$31,375
Starting MSRP
Current listing price
2012 GMC Sierra 3500 Work Truck

Showing the 2012 GMC Sierra 3500 2WD Reg Cab 133.7" Work Truck

Shop Now

Key specs

Color options

Interior

Dark Titanium

Packages

Specifications

Spare Wheel Material Steel
Front Wheel Material Steel
Rear Wheel Material Steel
Rear Wheel Size 17 x 6.5 in
Front Wheel Size 17 x 6.5 in
Spare Wheel Size 17 x 6.5 in
Cold Cranking Amps @ 0° F (Primary) 600
Maximum Alternator Capacity (amps) 125
SAE Net Horsepower @ RPM 322 @ 4400
SAE Net Torque @ RPM 380 @ 4200
Displacement 6.0L/366
Engine Oil Cooler Yes
Engine Type Gas/Ethanol V8
EPA Fuel Economy Est - Hwy Not Available MPG
Cruising Range - City 0.00 mi
EPA Fuel Economy Est - City Not Available MPG
Estimated Battery Range N/A mi
Fuel Economy Est-Combined Not Available MPG
Cruising Range - Hwy 0.00 mi
Reverse Ratio (:1) 3.06
Trans Description Cont. Again Not Available
Trans Type 6
Transfer Case Power Take Off Not Available
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.03
Final Drive Axle Ratio (:1) N/A
Sixth Gear Ratio (:1) 0.67
Second Gear Ratio (:1) 2.36
Drivetrain Rear Wheel Drive
Transfer Case Gear Ratio (:1), Low Not Available
Fourth Gear Ratio (:1) 1.15
Third Gear Ratio (:1) 1.53
Transfer Case Model Not Available
Trans Power Take Off Not Available
Fifth Gear Ratio (:1) 0.85
Transfer Case Gear Ratio (:1), High Not Available
Axle Type - Rear Full-Floating
Suspension Type - Front Independent
Axle Type - Front Independent
Suspension Type - Rear Multi-Leaf
Frame Type Hydroformed
Disc - Rear (Yes or ) Yes
Brake Type Pwr
Rear Brake Rotor Diam x Thickness 13.98 x 1.57 in
Drum - Rear (Yes or ) Not Available
Disc - Front (Yes or ) Yes
Brake ABS System 4-Wheel
Front Brake Rotor Diam x Thickness 13.98 x 1.57 in
Brake ABS System (Second Line) Not Available
Aux Fuel Tank Capacity, Approx Not Available gal
Fuel Tank Capacity, Approx 36 gal
Turning Diameter - Wall to Wall N/A ft
Steering Ratio (:1), Overall N/A
Steering Type Pwr Recirculating Ball
Turning Diameter - Curb to Curb 45.6 ft
Front Tire Size LT235/80R17E
Spare Tire Size Not Available
Rear Tire Size LT235/80R17E
Wt Distributing Hitch - Max Tongue Wt. 1440 lbs
Fifth Wheel Hitch - Max Trailer Wt. 9600 lbs
Maximum Trailering Capacity 14500 lbs
Wt Distributing Hitch - Max Trailer Wt. 9600 lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Fifth Wheel Hitch - Max Tongue Wt. 2400 lbs
Gross Combined Wt Rating 16000 lbs
As Spec'd Payload 7235.00 lbs
Option Weight - Front 0.00 lbs
As Spec'd Curb Weight 6165.00 lbs
Base Curb Weight N/A lbs
Curb Weight 6165.00 lbs
Curb Weight - Rear 2985 lbs
Gross Vehicle Weight Rating 13400.00 lbs
Gross Axle Weight Rating 14225.00 lbs
Total Option Weight 0.00 lbs
Maximum Payload Capacity 7235.00 lbs
Option Weight - Rear 0.00 lbs
Curb Weight - Front 3180 lbs
Cargo Box Length @ Floor 97.8 in
Length, Overall w/o rear bumper 225.0 in
Second Shoulder Room N/A in
Cargo Box Width @ Wheelhousings 50.6 in
Cargo Volume 75.5 ft³
Cargo Box (Area) Height 21.0 in
Wheelbase 133.7 in
Front Shoulder Room 65.2 in
Tailgate Width 61.6 in
Ground to Top of Load Floor 37.9 in
Second Head Room N/A in
Cargo Box Width @ Top, Rear N/A in
Ground Clearance, Rear 8.8 in
Passenger Capacity 3
Second Leg Room N/A in
Second Hip Room N/A in
Ext'd Cab Cargo Volume Not Available ft³
Overhang, Rear w/o bumper 52.6 in
Front Head Room 41.3 in
Length, Overall w/rear bumper N/A in
Front Hip Room 60.3 in
Front Leg Room 41.3 in
Length, Overall N/A in
Ground Clearance, Front 10.0 in
Overhang, Front 38.8 in
Cargo Box Width @ Floor 62.5 in
Width, Max w/o mirrors 95.9 in
Height, Overall 77.4 in
Cab to End of Frame N/A in
Rear axle, 3.73 ratio (Not available with (L96) Vortec 6.0L V8 SFI engine on TC30903 with Single Rear Wheels.) Standard
Grille, chrome surround Standard
Seats, front 40/20/40 split-bench, 3-passenger, driver and front passenger manual reclining with outboard head restraints and center fold-down armrest with storage Standard
Battery, heavy-duty 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power Standard
Differential, heavy-duty automatic locking rear Standard
Headliner, Opal Gray-colored cloth with matching retainer moldings Standard
Glass, Solar-Ray light-tinted, all windows Standard
SiriusXM Satellite Radio, delete Standard
OnStar, delete Standard
Bumper, front chrome includes body-color bumper top caps Standard
Recovery hooks, front, frame-mounted Standard
Exhaust, aluminized stainless-steel muffler and tailpipe Standard
Wheels, 17" (43.2 cm) painted steel includes painted center caps and a steel spare (spare wheel will not cosmetically match the other 6 wheels) Spare not included with (ZW9) pickup box delete unless a spare tire is ordered (Requires (9F6) 12,800 lbs. GVWR, (C7J) 13,000 lbs. GVWR or (9G4) 13,400 lbs. GVWR (dual rear wheel).) Standard
Audio system, AM/FM stereo with seek-and-scan and digital clock (Not available with (U2K) SiriusXM Satellite Radio) Standard
Visors, driver and front passenger, sliding with clip and passenger side vanity mirror with cover, Opal Gray-colored Standard
Air bags, frontal, driver and right-front passenger (Always use safety belts and the correct child restraints for your child's age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual and child safety seat instructions for more safety information.) Standard
Trailering equipment, heavy-duty includes trailering hitch platform and 2.5- inch receiver with 2" adapter, 7-wire harness (harness includes wires for: park lamps, backup lamps, right turn, left turn, electric brake lead, battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector, wiring harness for after-market trailer brake controller (located in the instrument panel harness) and (JL1) integrated trailer brake controller (Will be deleted if (ZW9) pickup box delete or (VF7) rear bumper delete is ordered.) Standard
Cooling, auxiliary external transmission oil cooler heavy-duty air-to-oil Standard
Audio system feature, 4-speaker system (Requires Regular Cab models) Standard
Mirrors, outside high-visibility vertical camper-style, Black with manual folding and extension and lower convex spotter glass Standard
Tailgate protection top of tailgate protection cap Standard
Bumper, rear chrome, step-style with pad (Not available with (ZW9) pickup box delete) Standard
GVWR, 13,400 lbs. (5806 kg) with dual rear wheels (Requires T*30903 models, (L96) Vortec 6.0L V8 SFI engine and (ZW9) pickup box delete.) Standard
Transmission, 6-speed automatic, heavy-duty, electronically controlled with overdrive and tow/haul mode (Requires (L96) Vortec 6.0L V8 SFI engine.) Standard
Suspension, rear 4+1+2 multi-leaf springs for single rear wheel and 3+1+2 multi-leaf springs for dual rear wheel Standard
Instrumentation, analog with speedometer, fuel level, engine temperature, tachometer, voltmeter and oil pressure indicators Standard
Daytime Running Lamps with automatic exterior lamp control Standard
Frame, fully-boxed, hydroformed front section Standard
Air cleaner, high-capacity Standard
Wipers, front intermittent wet-arm with pulse washers Standard
Driver Information Center with odometer, trip odometer and message center (monitors numerous systems depending on vehicle equipment level including low fuel, turn signal "on", transmission temperature and oil change notification) (Driver Information Center controls are operated through the trip button unless (UK3) steering wheel mounted audio controls is ordered. On 3SA and 4SA, includes 8-point compass and outside temperature.) Standard
Cruise control, electronic with set and resume speed, located on steering wheel Standard
Floor covering, Black rubberized vinyl Standard
Lamps, dual cargo area lamps Standard
Power outlets 2 auxiliary instrument panel-mounted with covers, 12-volt Standard
Air conditioning, single-zone manual front climate control Standard
Pickup box, Wideside Standard
Assist handle, front passenger (Also includes rear assist handles in the headliner on Extended and Crew Cab models) Standard
Coat hooks, rear driver and passenger side Standard
Cup holders, front (Also includes rear cupholders on Extended and Crew Cab models) Standard
Brakes, 4-wheel antilock, 4-wheel disc with dual rear wheels Standard
Steering, power, recirculating ball Standard
Rear wheel drive Standard
Alternator, 125 amps Standard
Trailer brake controller, integrated Standard
Seat trim, Vinyl Standard
Mirror, inside rearview manual day/night Standard
Cooling, external engine oil cooler heavy-duty air-to-oil, integral to driver side of radiator tank Standard
Headlamps, dual halogen composite with automatic exterior lamp control and flash-to-pass feature Standard
Spare tire lock keyed cylinder lock that utilizes same key as ignition and door (Not included when (ZW9) pickup box delete or (VF7) rear bumper delete is ordered.) Standard
Tire carrier, outside spare, winch-type mounted under frame at rear (Orders with (ZW9) Pickup box delete will not include a Spare Tire Carrier unless a spare tire is ordered.) Standard
Steering wheel includes theft-deterrent locking feature Standard
Suspension Package, Handling/Trailering, heavy-duty includes 35mm monotube shocks and 34mm front stabilizer bar Standard
Steering column, Tilt-Wheel, adjustable with brake/transmission shift interlock Standard
Engine, Vortec 6.0L Variable Valve Timing V8 SFI E85-compatible, FlexFuel capable of running on unleaded or up to 85% ethanol (322 hp [240.1 kW] @ 4400 rpm, 380 lb-ft of torque [513.0 N-m] @ 4200 rpm) (Does not include E85 capability with (ZW9) pickup box delete.) Standard
Tires, LT235/80R17E all-season highway, blackwall (Requires (9F6) 12,800 lbs. GVWR, (C7J) 13,000 lbs. GVWR or (9G4) 13,400 lbs. GVWR (dual rear wheel). Includes 7 tires with (E63) Fleetside pickup box. Includes 6 tires with (ZW9) pickup box delete.) Standard
Suspension, front independent, torsion bar Standard
Lighting, interior with dome and reading lights, illuminated entry feature and backlit instrument panel switches Standard
Warning tones headlamp on, key-in-ignition, driver and passenger buckle up reminder and turn signal on Standard
