2024 Ford Bronco Big Bend specs & colors

$39,630
Starting MSRP
Current listing price
2024 Ford Bronco Big Bend

Showing the 2024 Ford Bronco Big Bend 2 Door 4x4

Shop Now

Key specs

Color options

Interior

Black / Silver


Palm Tree Green


Packages

$0

Starting MSRP

$9,455

Starting MSRP

  • Advanced 4x4 w/automatic on demand engagement
  • Wheels: 17" Black High Gloss-Painted Aluminum
  • warm alloy beauty ring and beadlock capable wheels

Sasquatch Package

$1,645

Starting MSRP

  • Rear Parking Sensors
  • Power Outlet - Back Side of Center Floor Console
  • Dual Smart Charging USB Ports

Equipment Group 222A Mid Package

See all packages

$8,460

Starting MSRP

  • Advanced 4x4 w/automatic on demand engagement
  • High Clearance Fender Flares
  • High Clearance Suspension

Sasquatch Package w/Non Beadlock Capable Wheels

Specifications

Front Wheel Size 17 X 7.5 in
Rear Wheel Size 17 X 7.5 in
Spare Wheel Size Full-Size in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Aluminum
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 250
Engine Type Intercooled Turbo Regular Unleaded I-4
Displacement 2.3 L/140
SAE Net Horsepower @ RPM 275 @ 5700
SAE Net Torque @ RPM 315 @ 3400
Engine Oil Cooler None
EPA Fuel Economy Est - Hwy 21 (2023) MPG
Cruising Range - City 338.00 mi
EPA Fuel Economy Est - City 20 (2023) MPG
Fuel Economy Est-Combined 20 (2023) MPG
Cruising Range - Hwy 354.90 mi
Estimated Battery Range N/A mi
Drivetrain Four Wheel Drive
Trans Type 7
Trans Description Cont. Manual w/OD
Trans Description Cont. Again N/A
First Gear Ratio (:1) 4.28
Second Gear Ratio (:1) 2.37
Third Gear Ratio (:1) 1.45
Fourth Gear Ratio (:1) 1.00
Fifth Gear Ratio (:1) 0.78
Sixth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 5.62
Trans Power Take Off N/A
Final Drive Axle Ratio (:1) N/A
Transfer Case Model Electronic
Transfer Case Gear Ratio (:1), High N/A
Transfer Case Gear Ratio (:1), Low N/A
Transfer Case Power Take Off No
Seventh Gear Ratio (:1) N/A
Suspension Type - Front Short And Long Arm
Suspension Type - Rear Multi-Link
Axle Type - Front Independent
Axle Type - Rear Rigid Axle
Frame Type N/A
Brake Type 4-Wheel Disc
Brake ABS System 4-Wheel
Brake ABS System (Second Line) 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 12.2 in
Rear Brake Rotor Diam x Thickness 12.1 in
Drum - Rear (Yes or ) N/A
Fuel Tank Capacity, Approx 16.9 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Rack-Pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb N/A ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P255/75SR17
Rear Tire Size P255/75SR17
Spare Tire Size Full-Size
Dead Weight Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Tongue Wt. 350 lbs
Wt Distributing Hitch - Max Trailer Wt. 3500 lbs
Wt Distributing Hitch - Max Tongue Wt. 350 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Maximum Trailering Capacity 3500 lbs
Base Curb Weight 4297 lbs
Curb Weight - Front 2349 lbs
Curb Weight - Rear 1948 lbs
Option Weight - Front 0.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Curb Weight 4297.00 lbs
As Spec'd Payload 1243.00 lbs
Maximum Payload Capacity 1243.00 lbs
Gross Combined Wt Rating 8780 lbs
Gross Axle Weight Rating 5900.00 lbs
Curb Weight 4297.00 lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 5540.00 lbs
Passenger Capacity 4
Front Head Room 41 in
Front Leg Room 43.1 in
Front Shoulder Room 57.1 in
Front Hip Room 56.3 in
Second Head Room 39.8 in
Second Leg Room 35.7 in
Second Shoulder Room 51.8 in
Second Hip Room 43.3 in
Wheelbase 100.4 in
Length, Overall w/rear bumper N/A in
Length, Overall 173.7 in
Width, Max w/o mirrors 75.9 in
Height, Overall 72.9 in
Track Width, Front 65 in
Track Width, Rear 65 in
Overhang, Front N/A in
Overhang, Rear w/o bumper N/A in
Cab to End of Frame N/A in
Ground to Top of Load Floor N/A in
Ground Clearance, Front N/A in
Ground Clearance, Rear N/A in
Min Ground Clearance 8.4 in
Rear Door Opening Height N/A in
Rear Door Opening Width N/A in
Cargo Area Length @ Floor to Seat 1 N/A in
Cargo Area Length @ Floor to Seat 2 N/A in
Cargo Area Length @ Floor to Seat 3 N/A in
Cargo Box Width @ Top, Rear N/A in
Cargo Area Width @ Beltline N/A in
Cargo Box Width @ Floor N/A in
Cargo Box Width @ Wheelhousings N/A in
Cargo Box (Area) Height N/A in
Liftover Height N/A in
Tailgate Width N/A in
Cargo Volume N/A ft³
Cargo Volume to Seat 1 52.3 ft³
Cargo Volume to Seat 2 22.4 ft³
Cargo Volume to Seat 3 22.4 ft³
Ext'd Cab Cargo Volume N/A ft³
Wireless Phone Connectivity Standard
Streaming Audio Standard
2 LCD Monitors In The Front Standard
SYNC 4 -inc: 12" LCD capacitive touchscreen w/swipe capability, wireless phone connection, cloud connected, AppLink w/app catalog, 911 Assist, wireless Apple CarPlay and Android Auto compatibility, digital owner's manual and conversational voice command recognition Standard
SiriusXM Radio w/360L -inc: super categories/live sports categories, for you recommendations and SiriusXM listener profiles, a 3-month prepaid subscription, Service is not available in Alaska and Hawaii, Trial length and service availability may vary by model, model year or trim, SiriusXM audio and data services each require a subscription sold separately, or as a package, by SiriusXM radio inc, Your SiriusXM service will automatically stop at the end of your trial unless you decide to subscribe, If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your chosen payment method at then-current rates, Fees and taxes apply, To cancel you must call SiriusXM at 1-866-635-2349, See SiriusXM customer agreement for complete terms at www.siriusxm.com, All fees and programming subject to change, Not all vehicles or devices are capable of receiving all services offered by SiriusXM, Current information and features may not be available in all locations, or on all receivers, Satellite and streaming lineups vary slightly, 2020 SiriusXM radio inc Sirius, XM, SiriusXM and all related marks and logos are trademarks of Sirius XM Radio Inc Standard
Radio: AM/FM Stereo -inc: 7 speakers including subwoofer Standard
AM/FM/Satellite w/Seek-Scan, Clock, Speed Compensated Volume Control, Steering Wheel Controls and Radio Data System Standard
Fixed Antenna Standard
Flip-Up Rear Window w/Fixed Interval Wiper and Defroster Standard
Deep Tinted Glass Standard
Variable Intermittent Wipers Standard
Headlights-Automatic Highbeams Standard
Manual Targa Composite 1st Row Sunroof Standard
Gray Grille Standard
Tires: P255/75R17 A/T -inc: full size spare tire w/TPMS Standard
Front Fog Lamps Standard
Full-Size Spare Tire Mounted Outside Rear Standard
Black Door Handles Standard
Tailgate/Rear Door Lock Included w/Power Door Locks Standard
Black Power Heated Side Mirrors w/Convex Spotter and Manual Folding Standard
Black Rear Step Bumper w/1 Tow Hook Standard
Aluminum Spare Wheel Standard
Ford Co-Pilot360 - Autolamp Auto On/Off Reflector Led Low/High Beam Auto High-Beam Daytime Running Lights Preference Setting Headlamps w/Delay-Off Standard
Wheels: 17" Carbonized Gray-Painted Aluminum Standard
Manual Convertible Hard Top w/Lining, Glass Rear Window and Fixed Roll-Over Protection Standard
Black Fender Flares Standard
Black Front Bumper w/2 Tow Hooks Standard
Black Side Windows Trim Standard
Swing-Out Rear Cargo Access Standard
Fully Galvanized Steel Panels Standard
Front Center Armrest Standard
Manual Adjustable Front Head Restraints and Foldable Rear Head Restraints Standard
Interior Trim -inc: Metal-Look Interior Accents Standard
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry, Illuminated Ignition Switch and Panic Button Standard
Proximity Key For Push Button Start Only Standard
Carpet Floor Trim Standard
Smart Device Remote Engine Start Standard
Outside Temp Gauge Standard
Rear Cupholder Standard
Tracker System Standard
Trip Computer Standard
Driver Information Center Standard
Air Filtration Standard
Immobilizer Standard
Power Door Locks w/Autolock Feature Standard
Driver And Passenger Visor Vanity Mirrors w/Driver And Passenger Auxiliary Mirror Standard
Driver Foot Rest Standard
Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Tachometer, Inclinometer, Trip Odometer and Trip Computer Standard
Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down Standard
Full Vinyl/Rubber Floor Covering -inc: Carpet Front Floor Mats Standard
Leather/Metal-Look Gear Shifter Material Standard
Digital/Analog Appearance Standard
Driver Seat -inc: Manual Rear Seat Easy Entry Standard
Fade-To-Off Interior Lighting Standard
Manual Tilt/Telescoping Steering Column Standard
Compass Standard
Marine Grade Vinyl Bucket Seats -inc: 6-way manual driver and passenger including fore/aft, up/down and recline and front driver/passenger seat back MOLLE strap system Standard
Dashboard Storage, Driver And Passenger Door Bins Standard
Cargo Space Lights Standard
Leather/Metal-Look Steering Wheel Standard
50-50 Folding Split-Bench Front Facing Fold Forward Seatback Vinyl Rear Seat Standard
Locking Glove Box Standard
Redundant Digital Speedometer Standard
Perimeter Alarm Standard
Front Cupholder Standard
Smart Device Integration Standard
Full Floor Console w/Locking Storage, Mini Overhead Console w/Storage and 2 12V DC Power Outlets Standard
HVAC -inc: Underseat Ducts Standard
2 12V DC Power Outlets Standard
Mobile Hotspot Internet Access Standard
Cruise Control w/Steering Wheel Controls Standard
Manual Air Conditioning Standard
Removable Rear Windows Standard
Passenger Seat -inc: Manual Rear Seat Easy Entry Standard
Front Map Lights Standard
Day-Night Rearview Mirror Standard
2 Seatback Storage Pockets Standard
Transmission: 7-Speed Manual -inc: granny gear and crank in gear function and Hill Descent Control (STD) Standard
16.9 Gal. Fuel Tank Standard
4.46 Axle Ratio (STD) Standard
Solid Axle Rear Suspension w/Coil Springs Standard
Regenerative 250 Amp Alternator Standard
Short And Long Arm Front Suspension w/Coil Springs Standard
Gas-Pressurized Shock Absorbers Standard
80-Amp/Hr 800CCA Maintenance-Free Battery w/Run Down Protection Standard
Part And Full-Time Four-Wheel Drive Standard
Towing Equipment -inc: Trailer Sway Control Standard
Front Anti-Roll Standard
1242# Maximum Payload Standard
Off-Road Suspension Standard
50 State Emissions System Standard
Engine: 2.3L EcoBoost I-4 (STD) Standard
Single Stainless Steel Exhaust Standard
GVWR: 5,540 lbs Standard
Electric Power-Assist Steering Standard
Electronic Transfer Case Standard
Engine Auto Stop-Start Feature Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist, Hill Descent Control, Hill Hold Control and Electric Parking Brake Standard
Auto Locking Hubs Standard
AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC) Standard
Back-Up Camera Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Pre-Collision Assist with Pedestrian Detection Standard
Emergency Sos Standard
Safety Canopy System Curtain 1st And 2nd Row Airbags Standard
Mykey System -inc: Top Speed Limiter, Audio Volume Limiter, Early Low Fuel Warning, Programmable Sound Chimes and Beltminder w/Audio Mute Standard
Dual Stage Driver And Passenger Front Airbags Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Pretensioners Standard
ABS And Driveline Traction Control Standard
Personal Safety System Airbag Occupancy Sensor Standard
Collision Mitigation-Front Standard
Tire Specific Low Tire Pressure Warning Standard
Side Impact Beams Standard
