Change trim
MSRP
- 4dr SE FWD $30,900
- 4dr SEL FWD $33,300
- 4dr SEL AWD $35,250
- 4dr Limited FWD $39,200
- 4dr Limited AWD $41,150
- 4dr Limited AWD w/EcoBoost $43,820
2013 Ford Flex Limited specs & colors
4dr Car
Key specs
Color options
Interior
Gray
Mulberry
Medium pebble
Packages
$570
Starting MSRP
- receiver hitch
- wiring harness w/4 & 7 pin connectors
- engine oil cooler
$0
Starting MSRP
- base vehicle
$2,500
Starting MSRP
- active park assist
- adaptive cruise control w/collision mitigation & brake support
- 3rd row 50/50 split fold-flat vinyl bench w/1-touch PowerFold & tumble
301A equipment group order code
$2,500
Starting MSRP
- active park assist
- adaptive cruise control w/collision mitigation & brake support
- 3rd row 50/50 split fold-flat vinyl bench w/1-touch PowerFold & tumble
- 3rd row tailgate feature
- 10-way pwr heated/cooled driver/front passenger seats
- pwr tilt/telescoping steering column
Specifications
| EPA Classification | 4WD Sport Utility Vehicle |
| Rear Wheel Size | 19 x -TBD- in |
| Front Wheel Size | 19 x -TBD- in |
| Spare Wheel Size | Compact in |
| Spare Wheel Material | N/A |
| Rear Wheel Material | Aluminum |
| Front Wheel Material | Aluminum |
| Maximum Alternator Capacity (amps) | N/A |
| Cold Cranking Amps @ 0° F (Primary) | N/A |
| Displacement | 3.5L/213 |
| SAE Net Torque @ RPM | 254 @ 4500 |
| Engine Type | Gas V6 |
| SAE Net Horsepower @ RPM | 287 @ 6250 |
| EPA MPG Equivalent - Combined | N/A |
| Fuel Economy Est-Combined | 18 MPG |
| Cruising Range - Hwy | 427.80 mi |
| EPA MPG Equivalent - City | N/A |
| EPA MPG Equivalent - Hwy | N/A |
| EPA Fuel Economy Est - Hwy | 23 MPG |
| Estimated Battery Range | N/A mi |
| Cruising Range - City | 297.60 mi |
| EPA Fuel Economy Est - City | 16 MPG |
| Third Gear Ratio (:1) | 1.840 |
| Transfer Case Gear Ratio (:1), High | 1.000 |
| Transfer Case Gear Ratio (:1), Low | N/A |
| Trans Description Cont. Again | N/A |
| Trans Description Cont. | Automatic |
| Drivetrain | All Wheel Drive |
| Sixth Gear Ratio (:1) | 0.740 |
| Fourth Gear Ratio (:1) | 1.410 |
| Second Gear Ratio (:1) | 2.870 |
| Fifth Gear Ratio (:1) | 1.000 |
| First Gear Ratio (:1) | 4.480 |
| Final Drive Axle Ratio (:1) | 3.650 |
| Reverse Ratio (:1) | 2.880 |
| Trans Type | 6 |
| Suspension Type - Rear (Cont.) | w/Coil Springs |
| Suspension Type - Front | MacPherson strut |
| Suspension Type - Rear | Multi-link |
| Suspension Type - Front (Cont.) | w/Coil Springs |
| Drum - Rear (Yes or ) | N/A |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 12.800 x -TBD- in |
| Brake ABS System (Second Line) | N/A |
| Brake Type | Pwr |
| Rear Brake Rotor Diam x Thickness | 13.000 x -TBD- in |
| Brake ABS System | 4-Wheel |
| Aux Fuel Tank Capacity, Approx | N/A gal |
| Fuel Tank Capacity, Approx | 18.600 gal |
| Turning Diameter - Wall to Wall | N/A ft |
| Lock to Lock Turns (Steering) | N/A |
| Turning Diameter - Curb to Curb | 40.700 ft |
| Steering Ratio (:1), Overall | 17.000 |
| Steering Type | Pwr Rack & Pinion |
| Rear Tire Size | P235/55R19 |
| Front Tire Size | P235/55R19 |
| Spare Tire Size | Compact |
| Maximum Trailering Capacity | N/A lbs |
| Dead Weight Hitch - Max Trailer Wt. | 2000 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 200 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | 2000 lbs |
| Dead Weight Hitch - Max Tongue Wt. | 200 lbs |
| Curb Weight - Rear | N/A lbs |
| Curb Weight | N/A lbs |
| Base Curb Weight | 4643 lbs |
| Total Option Weight | 0.00 lbs |
| Curb Weight - Front | N/A lbs |
| Maximum Payload Capacity | N/A lbs |
| Second Leg Room | 44.300 in |
| Track Width, Front | 65.400 in |
| Min Ground Clearance | N/A in |
| Third Head Room | 38.700 in |
| Passenger Capacity | 7 |
| Second Head Room | 40.500 in |
| Cargo Volume to Seat 2 | 43.200 ft³ |
| Liftover Height | N/A in |
| Rear Door Opening Width | N/A in |
| Cargo Area Width @ Beltline | N/A in |
| Third Hip Room | 41.100 in |
| Cargo Area Length @ Floor to Seat 3 | N/A in |
| Third Leg Room | 33.300 in |
| Front Head Room | 41.800 in |
| Cargo Box (Area) Height | N/A in |
| Front Leg Room | 40.800 in |
| Height, Overall | 68.000 in |
| Front Shoulder Room | 58.400 in |
| Front Hip Room | 55.500 in |
| Rear Door Opening Height | N/A in |
| Wheelbase | 117.900 in |
| Cargo Box Width @ Wheelhousings | N/A in |
| Cargo Volume to Seat 1 | 83.200 ft³ |
| Cargo Volume to Seat 3 | 20.000 ft³ |
| Passenger Volume | 155.8 ft³ |
| Cargo Area Length @ Floor to Seat 1 | N/A in |
| Width, Max w/o mirrors | 75.900 in |
| Length, Overall | 201.800 in |
| Third Shoulder Room | 50.800 in |
| Second Hip Room | 55.000 in |
| Track Width, Rear | 65.400 in |
| Second Shoulder Room | 58.100 in |
| Cargo Area Length @ Floor to Seat 2 | N/A in |
| SYNC w/MyFord Touch -inc: (2) driver configurable 4.2" color LCD display in instrument cluster, 8" LCD touch-screen in center-stack, media hub w/(2) USB ports, SD card reader, A/V input jacks, 5-way steering wheel controls, Bluetooth capability, steering wheel audio controls, 911 assist, vehicle health report, SYNC services 3-year prepaid subscription w/GPS based turn-by-turn driving directions & traffic reports & info services | Optional |
| Voice-activated navigation -inc: in-dash screen, SIRIUS Travel Link w/6-month subscription | Optional |
| Sony AM/FM stereo w/CD player -inc: MP3 capability, 360-watt amplifier, (12) speakers, HD Radio | Optional |
| SIRIUS satellite radio *SIRIUS 6 months programming included where available* | Optional |
| P235/55R19 BSW tires | Optional |
| 19" painted aluminum wheels | Optional |
| Bright stainless steel beltline | Optional |
| Front rain sensing speed sensitive intermittent wipers | Optional |
| Satin aluminum grille | Optional |
| Pwr liftgate w/satin aluminum applique | Optional |
| Rear privacy glass | Standard |
| Lower grille w/kast silver strips | Optional |
| HID auto headlamps | Optional |
| Fog lamps w/kast silver trim ring | Optional |
| Chrome door handles | Optional |
| LED taillamps | Optional |
| Body-color heated pwr mirrors w/PowerFold -inc: security approach lamps, memory | Optional |
| Rear 2-speed wipers | Standard |
| Leather-wrapped shift knob | Standard |
| Pwr windows w/driver one-touch up/down | Standard |
| SecuriCode invisible keyless entry keypad on drivers door | Standard |
| Rear A/C vents | Standard |
| Manual tilt-adjustable/telescoping steering column | Standard |
| Cargo net | Optional |
| 4-way adjustable head restraints | Standard |
| 110V inverter | Optional |
| 1st & 2nd row carpeted floor mats | Standard |
| Cruise control w/steering wheel controls | Standard |
| Heated front perforated leather-trimmed bucket seats -inc: 10-way pwr driver seat w/pwr lumbar, 6-way pwr passenger seat w/lumbar, driver seat memory, fold-down armrest w/dual cupholders | Optional |
| Intelligent access w/push button start | Optional |
| Ambient lighting | Optional |
| Front floor console storage bin | Standard |
| Illuminated entry | Standard |
| Front seat back map pockets | Standard |
| 2nd row coat hooks | Standard |
| Overhead console w/sunglass holder -inc: map light | Standard |
| Reading lamps for 2nd & 3rd rows | Standard |
| 3rd row 50/50 fold in floor bench seat | Standard |
| SecuriLock passive anti-theft system | Standard |
| Grocery bag hooks in cargo area | Standard |
| Black scuff plates w/aluminum insert | Optional |
| 1st & 2nd row door storage pockets | Standard |
| Remote start | Optional |
| Perimeter anti-theft alarm | Standard |
| Accessory pwr delay | Standard |
| (3) roof grab handles | Standard |
| Auto-dimming rearview mirror | Standard |
| 2nd row 60/40 split bench seat -inc: autofold feature on passenger "40", center flip out armrest w/(2) cupholders | Optional |
| Locking glove box | Standard |
| (10) cup holders | Standard |
| Pwr adjustable pedals w/memory | Optional |
| Pwr locks w/autolock | Standard |
| 7-passenger seating (STD) | Optional |
| Leather-wrapped steering wheel -inc: audio controls, wood inlay | Optional |
| Universal garage door opener | Optional |
| Driver & front passenger sunvisors w/illuminated mirrors | Standard |
| Dual-zone electronic auto temp control air conditioning | Optional |
| Yoho maple wood grain appearance IP/door applique | Optional |
| (4) 12V pwr outlets | Standard |
| Remote keyless entry | Standard |
| Rear defroster | Standard |
| Easy Fuel capless fuel-filler | Standard |
| All-wheel drive | Optional |
| Battery saver | Standard |
| 6-speed SelectShift automatic transmission w/shifter-button activation (STD) | Standard |
| 3.5L Ti-VCT V6 engine (STD) | Standard |
| Battery management system | Standard |
| 3.65 axle ratio | Optional |
| Electronic pwr assisted steering (EPAS) | Standard |
| Quasi-dual exhaust w/chrome tips | Standard |
| 4-wheel anti-lock disc brakes | Standard |
| Passenger sensing system | Standard |
| SOS Post-Crash Alert System | Standard |
| 2nd/3rd row Safety Canopy w/rollover sensor | Standard |
| Rearview camera | Optional |
| Blind spot monitoring (BLIS) w/cross-traffic alert | Optional |
| Side-impact airbags | Standard |
| Reverse sensing system | Standard |
| Dual front airbags w/Personal Safety System | Standard |
| Rear child safety locks | Standard |
| MyKey system -inc: top speed limiter, audio volume limiter, early low fuel warning, programmable sound chimes, Beltminder w/audio mute | Standard |
| Rear seat lower anchors & tethers for children (LATCH) | Standard |
| Tire pressure monitoring system | Standard |
| Advance Trac w/roll stability control (RSC) | Standard |
