2009 Toyota Tundra LTD specs & colors

Crew Cab Pickup

Change trim

MSRP
Change trim
$36,010
Starting MSRP
Current listing price
2009 Toyota Tundra LTD

Showing the 2009 Toyota Tundra Dbl 5.7L V8 6-Spd AT LTD (Natl)

Shop Now

Key specs

Color options

Interior

Redrock

Graphite

Sand Beige

Sand beige

Packages

$0

Starting MSRP

$105

Starting MSRP

  • off-road suspension
  • unique 18" alloy wheels
  • BF Goodrich OWL all terrain tires

TRD OFF-ROAD PKG

$105

Starting MSRP

  • off-road suspension
  • unique 18" alloy wheels
  • BF Goodrich OWL all terrain tires
  • front tow hooks
  • TRD graphic

Specifications

Front Wheel Material Alloy
Front Wheel Size 18 x -TBD- in
Spare Wheel Size 18 x -TBD- in
Rear Wheel Size 18 x -TBD- in
Rear Wheel Material Alloy
Spare Wheel Material Steel
Maximum Alternator Capacity (amps) N/A
Cold Cranking Amps @ 0° F (Primary) N/A
SAE Net Torque @ RPM 401 @ 3600
SAE Net Horsepower @ RPM 381 @ 5600
Engine Oil Cooler 8.9
Displacement 5.7L/346
Engine Type Gas V8
Cruising Range - Hwy 475.20 mi
Fuel Economy Est-Combined 16 MPG
Cruising Range - City 369.60 mi
EPA Fuel Economy Est - Hwy 18 MPG
Estimated Battery Range N/A mi
EPA Fuel Economy Est - City 14 MPG
Transfer Case Gear Ratio (:1), High Not Available
Drivetrain Rear Wheel Drive
Transfer Case Model Not Available
Trans Power Take Off N/A
Reverse Ratio (:1) 3.06
Fifth Gear Ratio (:1) 0.73
Trans Type 6
First Gear Ratio (:1) 3.33
Final Drive Axle Ratio (:1) N/A
Second Gear Ratio (:1) 1.96
Transfer Case Gear Ratio (:1), Low Not Available
Sixth Gear Ratio (:1) 0.59
Third Gear Ratio (:1) 1.35
Fourth Gear Ratio (:1) 1.00
Trans Description Cont. Automatic w/OD
Trans Description Cont. Again Not Available
Transfer Case Power Take Off Not Available
Suspension Type - Front Independent
Axle Type - Rear N/A
Suspension Type - Rear Trapezoidal
Axle Type - Front N/A
Frame Type N/A
Brake ABS System (Second Line) Not Available
Brake ABS System 4-Wheel
Drum - Rear (Yes or ) Not Available
Brake Type Pwr
Front Brake Rotor Diam x Thickness 13.9 x -TBD- in
Rear Brake Rotor Diam x Thickness 13.6 x -TBD- in
Disc - Rear (Yes or ) Yes
Disc - Front (Yes or ) Yes
Aux Fuel Tank Capacity, Approx Not Available gal
Fuel Tank Capacity, Approx 26.4 gal
Turning Diameter - Wall to Wall N/A ft
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 44.0 ft
Steering Type Pwr Rack & Pinion
Spare Tire Size P255/70R18
Rear Tire Size P275/65R18
Front Tire Size P275/65R18
Fifth Wheel Hitch - Max Trailer Wt. 10600 lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Fifth Wheel Hitch - Max Tongue Wt. 1060 lbs
Wt Distributing Hitch - Max Tongue Wt. 1060 lbs
Maximum Trailering Capacity N/A lbs
Wt Distributing Hitch - Max Trailer Wt. 10600 lbs
Gross Axle Weight Rating 8000.00 lbs
Gross Combined Wt Rating 16000 lbs
Gross Vehicle Weight Rating 6900.00 lbs
As Spec'd Curb Weight 5235.00 lbs
Curb Weight - Rear 2270 lbs
Maximum Payload Capacity 1665.00 lbs
As Spec'd Payload 1665.00 lbs
Curb Weight 5235.00 lbs
Base Curb Weight N/A lbs
Total Option Weight 0.00 lbs
Option Weight - Rear 0.00 lbs
Curb Weight - Front 2965 lbs
Option Weight - Front 0.00 lbs
Front Shoulder Room 66.6 in
Height, Overall 75.8 in
Cargo Box Width @ Floor N/A in
Passenger Capacity 5
Cargo Box Width @ Wheelhousings 50.0 in
Length, Overall w/o rear bumper 228.7 in
Cargo Box Width @ Top, Rear N/A in
Cargo Box Length @ Floor 78.7 in
Width, Max w/o mirrors 79.9 in
Tailgate Width 66.4 in
Second Hip Room 62.6 in
Second Leg Room 34.7 in
Wheelbase 145.7 in
Second Shoulder Room 65.7 in
Cab to End of Frame N/A in
Ground Clearance, Front N/A in
Ground Clearance, Rear N/A in
Overhang, Rear w/o bumper N/A in
Cargo Volume N/A ft³
Length, Overall N/A in
Ground to Top of Load Floor N/A in
Front Head Room 40.2 in
Overhang, Front N/A in
Second Head Room 38.7 in
Ext'd Cab Cargo Volume N/A ft³
Front Hip Room 63.0 in
Cargo Box (Area) Height 22.2 in
Front Leg Room 42.5 in
Length, Overall w/rear bumper N/A in
Rear outboard seat LATCH anchors Standard
6-speed automatic transmission -inc: electronically controlled intelligence, sequential shift mode, uphill & downhill shift logic, Tow & Haul mode Optional
Chrome retractable pwr heated mirrors w/turn signals, auto-dimming Optional
Vehicle stability control Standard
Front & rear mudguards Optional
Variable intermittent windshield wipers Standard
Tow Pkg -inc: HD tow hitch receiver, 7-pin connector, trailer brake controller prewire, supplemental transmission cooler, tow & haul mode, transmission fluid temp gauge, 4.30 axle ratio Optional
Driver & front passenger seatback pockets Standard
4-wheel anti-lock brakes (ABS) w/brake assist Standard
Tailgate assist Standard
Deck rail caps Standard
Pwr locks Standard
Rear air conditioning ducts Standard
6,800# GVWR Optional
Center console box Optional
Dual zone automatic air conditioning w/sync mode Optional
(2) front pwr points & (1) rear pwr point Standard
Tire pressure monitor system Standard
Sliding rear window w/privacy glass Optional
3-point seatbelts in all seating positions w/passenger automatic & emergency locking retractors, driver & passenger pretensioners w/force limiters, driver emergency locking retractor Standard
Driver & front passenger advanced airbags w/passenger cutoff switch Standard
P275/65R18 all season tires Optional
Traction control Standard
HomeLink universal transceiver Optional
Double visors w/extenders, illuminated mirrors Optional
5.7L DOHC 32-valve i-Force V8 engine -inc: dual independent variable valve timing w/intelligence, acoustically controlled induction Optional
Rear armrest Standard
Pwr windows Standard
(4) front & (2) rear cup holders Standard
18" spare wheel & P255/70R18 tire Standard
10-way driver & 4-way front passenger pwr adjustable seats w/driver & front passenger lumbar & pwr thigh supports Optional
Font & rear roll-sensing side curtain airbags Standard
Child restraint system top tether anchors for all rear seating Standard
Pwr vented disc brakes Standard
Auto-dimming interior mirror -inc: compass, HomeLink, maplamps Optional
Multi-information display -inc: current & average mpg, range, average speed, customizable features Optional
Cigarette lighter & ashtray w/illumination Standard
Child-protector rear door locks Standard
Front & rear map lamps Standard
JBL AM/FM stereo -inc: 6-disc CD changer, (10) speakers, (8) channel 440W amp, Bluetooth capability, steering wheel mounted audio controls, aux audio jack Optional
Front color-keyed resin bumper & rear chrome steel bumper w/color-keyed front upper cover Optional
Deck rail system w/(4) adjustable tie-down cleats Optional
Optitron gauges Optional
Anti-theft alarm system Optional
18" alloy wheels Optional
Rear wheel drive Standard
Overhead console Optional
Rear door privacy glass Optional
Carpet flooring Standard
Hydraulic pwr rack & pinion steering Standard
Instrumentation -inc: exterior temp gauge, tachometer, tripmeter, digital clock Optional
Front leather heated bucket seats w/passenger-side fold flat Optional
Illuminated entry system Standard
Glove box illumination Standard
Automatic limited-slip differential Standard
Silver grille & chrome surround Optional
2-way adjustable headrests Standard
Driver & front passenger seat mounted side airbags Standard
Cruise control Standard
Remote keyless entry system Standard
Tilt & telescopic steering wheel w/console shifter Optional
Chrome door & black tailgate handles Optional
Fog Lamps Optional
Engine immobilizer Optional
Electronic Brake-force Distribution Standard
Independent coil-spring double wishbone front suspension w/low-pressure nitrogen gas shocks, stabilizer bar Standard
Trapezoidal multi-leaf live axle rear suspension w/staggered low-pressure nitrogen gas shocks Standard
