2009 Toyota Tundra SR5 specs & colors

Crew Cab Pickup

Change trim

MSRP

Reg 4.0L V6 5-Spd AT (SE) $22,490
Reg 4.0L V6 5-Spd AT (GS) $22,490
Reg 4.0L V6 5-Spd AT (Natl) $22,490
Reg LB 4.0L V6 5-Spd AT (SE) $22,820
Reg LB 4.0L V6 5-Spd AT (GS) $22,820
Reg LB 4.0L V6 5-Spd AT (Natl) $22,820
Reg 4.7L V8 5-Spd AT (GS) $23,630
Reg 4.7L V8 5-Spd AT (SE) $23,630
Reg 4.7L V8 5-Spd AT (Natl) $23,630
Reg LB 4.7L V8 5-Spd AT (GS) $23,960
Reg LB 4.7L V8 5-Spd AT (SE) $23,960
Reg LB 4.7L V8 5-Spd AT (Natl) $23,960
Reg 5.7L V8 6-Spd AT (GS) $24,680
Reg 5.7L V8 6-Spd AT (SE) $24,680
Reg 5.7L V8 6-Spd AT (Natl) $24,680
Dbl 4.0L V6 5-Spd AT (GS) $24,945
Dbl 4.0L V6 5-Spd AT (SE) $24,945
Dbl 4.0L V6 5-Spd AT (Natl) $24,945
Reg LB 5.7L V8 6-Spd AT (GS) $25,010
Reg LB 5.7L V8 6-Spd AT (SE) $25,010
Reg LB 5.7L V8 6-Spd AT (Natl) $25,010
Dbl 4.7L V8 5-Spd AT (GS) $25,090
Dbl 4.7L V8 5-Spd AT (SE) $25,090
Dbl 4.7L V8 5-Spd AT (Natl) $25,090
Dbl LB 4.7L V8 5-Spd AT (GS) $26,020
Dbl LB 4.7L V8 5-Spd AT (SE) $26,020
Dbl LB 4.7L V8 5-Spd AT (Natl) $26,020
Dbl 4.0L V6 5-Spd AT SR5 (Natl) $26,305
Dbl 4.0L V6 5-Spd AT SR5 (SE) $26,305
Dbl 4.0L V6 5-Spd AT SR5 (GS) $26,305
Dbl 5.7L V8 6-Spd AT (GS) $26,390
Dbl 5.7L V8 6-Spd AT (SE) $26,390
Dbl 5.7L V8 6-Spd AT (Natl) $26,390
Reg 4.7L V8 5-Spd AT (GS) $26,680
Reg 4.7L V8 5-Spd AT (SE) $26,680
Reg 4.7L V8 5-Spd AT (Natl) $26,680
Reg LB 4.7L V8 5-Spd AT (GS) $27,010
Reg LB 4.7L V8 5-Spd AT (SE) $27,010
Reg LB 4.7L V8 5-Spd AT (Natl) $27,010
Dbl 4.7L V8 5-Spd AT SR5 (Natl) $27,050
Dbl 4.7L V8 5-Spd AT SR5 (SE) $27,050
Dbl 4.7L V8 5-Spd AT SR5 (GS) $27,050
Dbl LB 5.7L V8 6-Spd AT (GS) $27,380
Dbl LB 5.7L V8 6-Spd AT (SE) $27,380
Dbl LB 5.7L V8 6-Spd AT (Natl) $27,380
Reg 5.7L FFV V8 6-Spd AT (GS) $27,740
Reg 5.7L V8 6-Spd AT (GS) $27,740
Reg 5.7L FFV V8 6-Spd AT (SE) $27,740
Reg 5.7L V8 6-Spd AT (SE) $27,740
Reg 5.7L V8 6-Spd AT (Natl) $27,740
Reg 5.7L FFV V8 6-Spd AT (Natl) $27,740
CrewMax 4.7L V8 5-Spd AT (GS) $27,915
CrewMax 4.7L V8 5-Spd AT (SE) $27,915
CrewMax 4.7L V8 5-Spd AT (Natl) $27,915
Reg LB 5.7L V8 6-Spd AT (GS) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (SE) $28,070
Reg LB 5.7L V8 6-Spd AT (SE) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (GS) $28,070
Reg LB 5.7L V8 6-Spd AT (Natl) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (Natl) $28,070
Dbl 4.7L V8 5-Spd AT (SE) $28,140
Dbl 4.7L V8 5-Spd AT (GS) $28,140
Dbl 4.7L V8 5-Spd AT (Natl) $28,140
Dbl 5.7L V8 6-Spd AT SR5 (Natl) $28,410
Dbl 5.7L V8 6-Spd AT SR5 (GS) $28,410
Dbl 5.7L V8 6-Spd AT SR5 (SE) $28,410
Dbl LB 4.7L V8 5-Spd AT (SE) $29,070
Dbl LB 4.7L V8 5-Spd AT (GS) $29,070
Dbl LB 4.7L V8 5-Spd AT (Natl) $29,070
CrewMax 5.7L V8 6-Spd AT (SE) $29,215
CrewMax 5.7L V8 6-Spd AT (GS) $29,215
CrewMax 5.7L V8 6-Spd AT (Natl) $29,215
Dbl 5.7L FFV V8 6-Spd AT (SE) $29,440
Dbl 5.7L V8 6-Spd AT (SE) $29,440
Dbl 5.7L V8 6-Spd AT (GS) $29,440
Dbl 5.7L FFV V8 6-Spd AT (GS) $29,440
Dbl 5.7L FFV V8 6-Spd AT (Natl) $29,440
Dbl 5.7L V8 6-Spd AT (Natl) $29,440
CrewMax 4.7L V8 5-Spd AT SR5 (GS) $29,875
CrewMax 4.7L V8 5-Spd AT SR5 (SE) $29,875
CrewMax 4.7L V8 5-Spd AT SR5 (Natl) $29,875
Dbl 4.7L V8 5-Spd AT SR5 (Natl) $30,100
Dbl 4.7L V8 5-Spd AT SR5 (SE) $30,100
Dbl 4.7L V8 5-Spd AT SR5 (GS) $30,100
Dbl LB 5.7L V8 6-Spd AT (GS) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (GS) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (SE) $30,430
Dbl LB 5.7L V8 6-Spd AT (SE) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (Natl) $30,430
Dbl LB 5.7L V8 6-Spd AT (Natl) $30,430
CrewMax 4.7L V8 5-Spd AT (SE) $30,965
CrewMax 4.7L V8 5-Spd AT (GS) $30,965
CrewMax 4.7L V8 5-Spd AT (Natl) $30,965
CrewMax 5.7L V8 6-Spd AT SR5 (SE) $31,235
CrewMax 5.7L V8 6-Spd AT SR5 (GS) $31,235
CrewMax 5.7L V8 6-Spd AT SR5 (Natl) $31,235
Dbl 5.7L FFV V8 6-Spd AT SR5 (Natl) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (Natl) $31,460
Dbl 5.7L FFV V8 6-Spd AT SR5 (GS) $31,460
Dbl 5.7L FFV V8 6-Spd AT SR5 (SE) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (GS) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (SE) $31,460
CrewMax 5.7L V8 6-Spd AT (GS) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (GS) $32,265
CrewMax 5.7L V8 6-Spd AT (SE) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (SE) $32,265
CrewMax 5.7L V8 6-Spd AT (Natl) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (Natl) $32,265
CrewMax 4.7L V8 5-Spd AT SR5 (SE) $32,925
CrewMax 4.7L V8 5-Spd AT SR5 (GS) $32,925
CrewMax 4.7L V8 5-Spd AT SR5 (Natl) $32,925
CrewMax 5.7L V8 6-Spd AT SR5 (GS) $34,285
CrewMax 5.7L V8 6-Spd AT SR5 (SE) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (SE) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (GS) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (Natl) $34,285
CrewMax 5.7L V8 6-Spd AT SR5 (Natl) $34,285
Dbl 5.7L V8 6-Spd AT LTD (SE) $36,010
Dbl 5.7L V8 6-Spd AT LTD (Natl) $36,010
Dbl 5.7L V8 6-Spd AT LTD (GS) $36,010
CrewMax 5.7L V8 6-Spd AT LTD (GS) $38,545
CrewMax 5.7L V8 6-Spd AT LTD (SE) $38,545
CrewMax 5.7L V8 6-Spd AT LTD (Natl) $38,545
Dbl 5.7L FFV V8 6-Spd AT LTD (GS) $39,070
Dbl 5.7L FFV V8 6-Spd AT LTD (SE) $39,070
Dbl 5.7L V8 6-Spd AT LTD (GS) $39,070
Dbl 5.7L V8 6-Spd AT LTD (SE) $39,070
Dbl 5.7L V8 6-Spd AT LTD (Natl) $39,070
Dbl 5.7L FFV V8 6-Spd AT LTD (Natl) $39,070
CrewMax 5.7L FFV V8 6-Spd AT LTD (GS) $41,605
CrewMax 5.7L FFV V8 6-Spd AT LTD (SE) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (SE) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (GS) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (Natl) $41,605
CrewMax 5.7L FFV V8 6-Spd AT LTD (Natl) $41,605

Change trim

$29,875

Starting MSRP
Current listing price

Showing the 2009 Toyota Tundra CrewMax 4.7L V8 5-Spd AT SR5 (Natl)

Shop Now

Color options

Exterior

Interior

Sand Beige

Black

Graphite

Stone

Packages

TRD OFF-ROAD PKG

$2,180

Starting MSRP

off-road suspension
unique 18" alloy wheels
P275/65R18 BF Goodrich OWL all terrain tires

OPTION PKG NOT DESIRED

$0

Starting MSRP

Specifications

Spare Wheel Size	18 x -TBD- in
Front Wheel Material	Steel
Rear Wheel Size	18 x -TBD- in
Rear Wheel Material	Steel
Front Wheel Size	18 x -TBD- in
Spare Wheel Material	Steel

EPA Fuel Economy Est - City	14 MPG
Estimated Battery Range	N/A mi
Fuel Economy Est-Combined	15 MPG
Cruising Range - Hwy	448.80 mi
Cruising Range - City	369.60 mi
EPA Fuel Economy Est - Hwy	17 MPG

Fourth Gear Ratio (:1)	1.00
Second Gear Ratio (:1)	2.04
Trans Description Cont.	Automatic w/OD
Trans Type	5
Reverse Ratio (:1)	3.22
Drivetrain	Rear Wheel Drive
First Gear Ratio (:1)	3.52
Third Gear Ratio (:1)	1.40
Trans Power Take Off	N/A
Final Drive Axle Ratio (:1)	N/A
Fifth Gear Ratio (:1)	0.72

Disc - Front (Yes or )	Yes
Brake Type	Pwr
Disc - Rear (Yes or )	Yes
Brake ABS System	4-Wheel
Front Brake Rotor Diam x Thickness	13.9 x -TBD- in
Rear Brake Rotor Diam x Thickness	13.6 x -TBD- in

Dead Weight Hitch - Max Trailer Wt.	5000 lbs
Wt Distributing Hitch - Max Tongue Wt.	800 lbs
Fifth Wheel Hitch - Max Tongue Wt.	800 lbs
Dead Weight Hitch - Max Tongue Wt.	500 lbs
Maximum Trailering Capacity	N/A lbs
Fifth Wheel Hitch - Max Trailer Wt.	8000 lbs
Wt Distributing Hitch - Max Trailer Wt.	8000 lbs

As Spec'd Payload	1470.00 lbs
Curb Weight - Rear	2360 lbs
Gross Axle Weight Rating	7950.00 lbs
Total Option Weight	0.00 lbs
As Spec'd Curb Weight	5330.00 lbs
Option Weight - Rear	0.00 lbs
Gross Vehicle Weight Rating	6800.00 lbs
Base Curb Weight	N/A lbs
Gross Combined Wt Rating	13500 lbs
Curb Weight	5330.00 lbs
Curb Weight - Front	2970 lbs
Option Weight - Front	0.00 lbs
Maximum Payload Capacity	1470.00 lbs

Length, Overall	N/A in
Ext'd Cab Cargo Volume	N/A ft³
Cargo Box Length @ Floor	66.7 in
Wheelbase	145.7 in
Second Hip Room	62.6 in
Length, Overall w/rear bumper	N/A in
Second Leg Room	44.5 in
Front Shoulder Room	66.6 in
Length, Overall w/o rear bumper	228.7 in
Cargo Volume	N/A ft³
Height, Overall	75.6 in
Front Head Room	40.2 in
Overhang, Front	N/A in
Overhang, Rear w/o bumper	N/A in
Ground Clearance, Rear	N/A in
Cab to End of Frame	N/A in
Ground Clearance, Front	N/A in
Second Shoulder Room	65.4 in
Cargo Box Width @ Top, Rear	N/A in
Front Leg Room	42.5 in
Cargo Box (Area) Height	22.2 in
Passenger Capacity	5
Second Head Room	38.7 in
Tailgate Width	66.4 in
Cargo Box Width @ Wheelhousings	50.0 in
Cargo Box Width @ Floor	N/A in
Ground to Top of Load Floor	N/A in
Front Hip Room	63.0 in
Width, Max w/o mirrors	79.9 in

18" styled steel wheels	Optional
Front & rear mudguards	Optional
Electronic Brake-force Distribution	Standard
Cruise control	Standard
Chrome steel bumpers w/color-keyed front upper cover	Standard
Vehicle stability control	Standard
Pwr windows	Standard
Independent coil-spring double wishbone front suspension w/low-pressure nitrogen gas shocks, stabilizer bar	Standard
2-way adjustable headrests	Standard
Trapezoidal multi-leaf live axle rear suspension w/staggered low-pressure nitrogen gas shocks	Standard
6,800# GVWR	Standard
18" spare wheel & P255/70R18 tire	Standard
5-speed automatic transmission -inc: electronically controlled intelligence, sequential shift mode, uphill & downhill shift logic	Standard
Driver & front passenger advanced airbags w/passenger cutoff switch	Standard
8-way driver & 4-way front passenger pwr adjustable seats	Optional
3-point seatbelts in all seating positions w/passenger automatic & emergency locking retractors, driver & passenger pretensioners w/force limiters, driver emergency locking retractor	Standard
Driver & front passenger seatback pockets	Standard
Overhead console	Optional
Rear glass defroster	Standard
Rear armrest	Standard
Front fabric bucket seats w/front passenger fold-flat seat	Optional
(4) front & (2) rear cup holders	Standard
Instrumentation -inc: exterior temp gauge, tachometer, tripmeter, digital clock, trip computer	Optional
Front & rear map lamps	Standard
Illuminated entry system	Standard
Rear door privacy glass	Standard
Tailgate assist	Standard
AM/FM stereo -inc: 6-disc CD changer, (6) speakers, aux audio jack	Optional
(2) front pwr points & (1) rear pwr point	Standard
Rear outboard seat LATCH anchors	Standard
Center console box	Optional
Cigarette lighter & ashtray w/illumination	Standard
Pwr vented disc brakes	Standard
Rear air conditioning ducts	Standard
Carpet flooring	Standard
Black grille & chrome surround	Standard
Dual zone air conditioning w/sync mode	Standard
Visor mirrors w/extenders	Standard
Pwr sliding rear privacy glass	Standard
Hydraulic pwr rack & pinion steering	Standard
Font & rear roll-sensing side curtain airbags	Standard
Engine immobilizer	Standard
Pwr locks	Standard
Rear sliding & reclining fold-flat seats	Standard
4-wheel anti-lock brakes (ABS) w/brake assist	Standard
Driver & front passenger seat mounted side airbags	Standard
Variable intermittent windshield wipers	Standard
Child-protector rear door locks	Standard
Rear wheel drive	Standard
Tilt & telescopic steering wheel w/console shifter	Optional
Deck rail caps	Standard
Tire pressure monitor system	Standard
Remote keyless entry system	Standard
Traction control	Standard
Glove box illumination	Standard
4.7L DOHC 32-valve i-Force V8 engine -inc: variable valve timing w/intelligence, acoustically controlled induction	Standard
Tow Pkg -inc: HD tow hitch receiver, 7-pin connector, trailer brake controller prewire, supplemental transmission cooler, transmission fluid temp gauge, 4.10 axle ratio	Optional
Automatic limited-slip differential	Standard
Black door & tailgate handles	Standard
P255/70R18 all season tires	Standard
Black pwr heated mirrors	Optional
Child restraint system top tether anchors for all rear seating	Standard

Compare trims

Wondering which trim is right for you?

Our 2009 Toyota Tundra trim comparison will help you decide.

Engine Oil Cooler	7.5
Engine Type	Gas V8
SAE Net Torque @ RPM	313 @ 3400
SAE Net Horsepower @ RPM	276 @ 5400
Displacement	4.7L/285

Turning Diameter - Wall to Wall	N/A ft
Turning Diameter - Curb to Curb	44.0 ft
Steering Ratio (:1), Overall	N/A
Steering Type	Pwr Rack & Pinion

Cold Cranking Amps @ 0° F (Primary)	N/A
Maximum Alternator Capacity (amps)	N/A

Suspension Type - Rear	Trapezoidal
Axle Type - Front	N/A
Suspension Type - Front	Independent
Axle Type - Rear	N/A

Front Tire Size	P255/70R18
Spare Tire Size	P255/70R18
Rear Tire Size	P255/70R18

2009 Toyota Tundra SR5 specs & colors

Crew Cab Pickup

Key specs

Color options

Packages

Specifications

Wheels

Electrical

Engine

Mileage

Transmission

Suspension

Frame

Brakes

Fuel Tank

Steering

Tires

Trailering

Weight Information

Dimensions

Exterior

Compare trims
