2009 Toyota Tundra LTD specs & colors

Crew Cab Pickup

Change trim

MSRP

Reg 4.0L V6 5-Spd AT (SE) $22,490
Reg 4.0L V6 5-Spd AT (GS) $22,490
Reg 4.0L V6 5-Spd AT (Natl) $22,490
Reg LB 4.0L V6 5-Spd AT (SE) $22,820
Reg LB 4.0L V6 5-Spd AT (GS) $22,820
Reg LB 4.0L V6 5-Spd AT (Natl) $22,820
Reg 4.7L V8 5-Spd AT (GS) $23,630
Reg 4.7L V8 5-Spd AT (SE) $23,630
Reg 4.7L V8 5-Spd AT (Natl) $23,630
Reg LB 4.7L V8 5-Spd AT (GS) $23,960
Reg LB 4.7L V8 5-Spd AT (SE) $23,960
Reg LB 4.7L V8 5-Spd AT (Natl) $23,960
Reg 5.7L V8 6-Spd AT (GS) $24,680
Reg 5.7L V8 6-Spd AT (SE) $24,680
Reg 5.7L V8 6-Spd AT (Natl) $24,680
Dbl 4.0L V6 5-Spd AT (GS) $24,945
Dbl 4.0L V6 5-Spd AT (SE) $24,945
Dbl 4.0L V6 5-Spd AT (Natl) $24,945
Reg LB 5.7L V8 6-Spd AT (GS) $25,010
Reg LB 5.7L V8 6-Spd AT (SE) $25,010
Reg LB 5.7L V8 6-Spd AT (Natl) $25,010
Dbl 4.7L V8 5-Spd AT (GS) $25,090
Dbl 4.7L V8 5-Spd AT (SE) $25,090
Dbl 4.7L V8 5-Spd AT (Natl) $25,090
Dbl LB 4.7L V8 5-Spd AT (GS) $26,020
Dbl LB 4.7L V8 5-Spd AT (SE) $26,020
Dbl LB 4.7L V8 5-Spd AT (Natl) $26,020
Dbl 4.0L V6 5-Spd AT SR5 (Natl) $26,305
Dbl 4.0L V6 5-Spd AT SR5 (SE) $26,305
Dbl 4.0L V6 5-Spd AT SR5 (GS) $26,305
Dbl 5.7L V8 6-Spd AT (GS) $26,390
Dbl 5.7L V8 6-Spd AT (SE) $26,390
Dbl 5.7L V8 6-Spd AT (Natl) $26,390
Reg 4.7L V8 5-Spd AT (GS) $26,680
Reg 4.7L V8 5-Spd AT (SE) $26,680
Reg 4.7L V8 5-Spd AT (Natl) $26,680
Reg LB 4.7L V8 5-Spd AT (GS) $27,010
Reg LB 4.7L V8 5-Spd AT (SE) $27,010
Reg LB 4.7L V8 5-Spd AT (Natl) $27,010
Dbl 4.7L V8 5-Spd AT SR5 (Natl) $27,050
Dbl 4.7L V8 5-Spd AT SR5 (SE) $27,050
Dbl 4.7L V8 5-Spd AT SR5 (GS) $27,050
Dbl LB 5.7L V8 6-Spd AT (GS) $27,380
Dbl LB 5.7L V8 6-Spd AT (SE) $27,380
Dbl LB 5.7L V8 6-Spd AT (Natl) $27,380
Reg 5.7L FFV V8 6-Spd AT (GS) $27,740
Reg 5.7L V8 6-Spd AT (GS) $27,740
Reg 5.7L FFV V8 6-Spd AT (SE) $27,740
Reg 5.7L V8 6-Spd AT (SE) $27,740
Reg 5.7L V8 6-Spd AT (Natl) $27,740
Reg 5.7L FFV V8 6-Spd AT (Natl) $27,740
CrewMax 4.7L V8 5-Spd AT (GS) $27,915
CrewMax 4.7L V8 5-Spd AT (SE) $27,915
CrewMax 4.7L V8 5-Spd AT (Natl) $27,915
Reg LB 5.7L V8 6-Spd AT (GS) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (SE) $28,070
Reg LB 5.7L V8 6-Spd AT (SE) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (GS) $28,070
Reg LB 5.7L V8 6-Spd AT (Natl) $28,070
Reg LB 5.7L FFV V8 6-Spd AT (Natl) $28,070
Dbl 4.7L V8 5-Spd AT (SE) $28,140
Dbl 4.7L V8 5-Spd AT (GS) $28,140
Dbl 4.7L V8 5-Spd AT (Natl) $28,140
Dbl 5.7L V8 6-Spd AT SR5 (Natl) $28,410
Dbl 5.7L V8 6-Spd AT SR5 (GS) $28,410
Dbl 5.7L V8 6-Spd AT SR5 (SE) $28,410
Dbl LB 4.7L V8 5-Spd AT (SE) $29,070
Dbl LB 4.7L V8 5-Spd AT (GS) $29,070
Dbl LB 4.7L V8 5-Spd AT (Natl) $29,070
CrewMax 5.7L V8 6-Spd AT (SE) $29,215
CrewMax 5.7L V8 6-Spd AT (GS) $29,215
CrewMax 5.7L V8 6-Spd AT (Natl) $29,215
Dbl 5.7L FFV V8 6-Spd AT (SE) $29,440
Dbl 5.7L V8 6-Spd AT (SE) $29,440
Dbl 5.7L V8 6-Spd AT (GS) $29,440
Dbl 5.7L FFV V8 6-Spd AT (GS) $29,440
Dbl 5.7L FFV V8 6-Spd AT (Natl) $29,440
Dbl 5.7L V8 6-Spd AT (Natl) $29,440
CrewMax 4.7L V8 5-Spd AT SR5 (GS) $29,875
CrewMax 4.7L V8 5-Spd AT SR5 (SE) $29,875
CrewMax 4.7L V8 5-Spd AT SR5 (Natl) $29,875
Dbl 4.7L V8 5-Spd AT SR5 (Natl) $30,100
Dbl 4.7L V8 5-Spd AT SR5 (SE) $30,100
Dbl 4.7L V8 5-Spd AT SR5 (GS) $30,100
Dbl LB 5.7L V8 6-Spd AT (GS) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (GS) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (SE) $30,430
Dbl LB 5.7L V8 6-Spd AT (SE) $30,430
Dbl LB 5.7L FFV V8 6-Spd AT (Natl) $30,430
Dbl LB 5.7L V8 6-Spd AT (Natl) $30,430
CrewMax 4.7L V8 5-Spd AT (SE) $30,965
CrewMax 4.7L V8 5-Spd AT (GS) $30,965
CrewMax 4.7L V8 5-Spd AT (Natl) $30,965
CrewMax 5.7L V8 6-Spd AT SR5 (SE) $31,235
CrewMax 5.7L V8 6-Spd AT SR5 (GS) $31,235
CrewMax 5.7L V8 6-Spd AT SR5 (Natl) $31,235
Dbl 5.7L FFV V8 6-Spd AT SR5 (Natl) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (Natl) $31,460
Dbl 5.7L FFV V8 6-Spd AT SR5 (GS) $31,460
Dbl 5.7L FFV V8 6-Spd AT SR5 (SE) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (GS) $31,460
Dbl 5.7L V8 6-Spd AT SR5 (SE) $31,460
CrewMax 5.7L V8 6-Spd AT (GS) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (GS) $32,265
CrewMax 5.7L V8 6-Spd AT (SE) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (SE) $32,265
CrewMax 5.7L V8 6-Spd AT (Natl) $32,265
CrewMax 5.7L FFV V8 6-Spd AT (Natl) $32,265
CrewMax 4.7L V8 5-Spd AT SR5 (SE) $32,925
CrewMax 4.7L V8 5-Spd AT SR5 (GS) $32,925
CrewMax 4.7L V8 5-Spd AT SR5 (Natl) $32,925
CrewMax 5.7L V8 6-Spd AT SR5 (GS) $34,285
CrewMax 5.7L V8 6-Spd AT SR5 (SE) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (SE) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (GS) $34,285
CrewMax 5.7L FFV V8 6-Spd AT SR5 (Natl) $34,285
CrewMax 5.7L V8 6-Spd AT SR5 (Natl) $34,285
Dbl 5.7L V8 6-Spd AT LTD (SE) $36,010
Dbl 5.7L V8 6-Spd AT LTD (Natl) $36,010
Dbl 5.7L V8 6-Spd AT LTD (GS) $36,010
CrewMax 5.7L V8 6-Spd AT LTD (GS) $38,545
CrewMax 5.7L V8 6-Spd AT LTD (SE) $38,545
CrewMax 5.7L V8 6-Spd AT LTD (Natl) $38,545
Dbl 5.7L FFV V8 6-Spd AT LTD (GS) $39,070
Dbl 5.7L FFV V8 6-Spd AT LTD (SE) $39,070
Dbl 5.7L V8 6-Spd AT LTD (GS) $39,070
Dbl 5.7L V8 6-Spd AT LTD (SE) $39,070
Dbl 5.7L V8 6-Spd AT LTD (Natl) $39,070
Dbl 5.7L FFV V8 6-Spd AT LTD (Natl) $39,070
CrewMax 5.7L FFV V8 6-Spd AT LTD (GS) $41,605
CrewMax 5.7L FFV V8 6-Spd AT LTD (SE) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (SE) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (GS) $41,605
CrewMax 5.7L V8 6-Spd AT LTD (Natl) $41,605
CrewMax 5.7L FFV V8 6-Spd AT LTD (Natl) $41,605

Change trim

$38,545

Starting MSRP
Current listing price

Showing the 2009 Toyota Tundra CrewMax 5.7L V8 6-Spd AT LTD (Natl)

Shop Now

Color options

Exterior

Interior

Graphite

Sand Beige

Redrock

Packages

OPTION PKG NOT DESIRED

$0

Starting MSRP

TRD OFF-ROAD PKG

$105

Starting MSRP

off-road suspension
unique 18" alloy wheels
BF Goodrich OWL all terrain tires

Specifications

Rear Wheel Size	18 x -TBD- in
Front Wheel Material	Alloy
Front Wheel Size	18 x -TBD- in
Spare Wheel Size	18 x -TBD- in
Spare Wheel Material	Steel
Rear Wheel Material	Alloy

Cruising Range - Hwy	475.20 mi
EPA Fuel Economy Est - Hwy	18 MPG
EPA Fuel Economy Est - City	14 MPG
Estimated Battery Range	N/A mi
Fuel Economy Est-Combined	16 MPG
Cruising Range - City	369.60 mi

Drivetrain	Rear Wheel Drive
Third Gear Ratio (:1)	1.35
Reverse Ratio (:1)	3.06
Second Gear Ratio (:1)	1.96
Trans Description Cont.	Automatic w/OD
First Gear Ratio (:1)	3.33
Final Drive Axle Ratio (:1)	N/A
Fifth Gear Ratio (:1)	0.73
Trans Type	6
Sixth Gear Ratio (:1)	0.59
Trans Power Take Off	N/A
Fourth Gear Ratio (:1)	1.00

Brake ABS System	4-Wheel
Disc - Front (Yes or )	Yes
Disc - Rear (Yes or )	Yes
Rear Brake Rotor Diam x Thickness	13.6 x -TBD- in
Front Brake Rotor Diam x Thickness	13.9 x -TBD- in
Brake Type	Pwr

Dead Weight Hitch - Max Tongue Wt.	500 lbs
Dead Weight Hitch - Max Trailer Wt.	5000 lbs
Wt Distributing Hitch - Max Tongue Wt.	1040 lbs
Wt Distributing Hitch - Max Trailer Wt.	10400 lbs
Maximum Trailering Capacity	N/A lbs
Fifth Wheel Hitch - Max Tongue Wt.	1040 lbs
Fifth Wheel Hitch - Max Trailer Wt.	10400 lbs

Option Weight - Rear	0.00 lbs
Curb Weight - Rear	2410 lbs
Gross Axle Weight Rating	8050.00 lbs
Maximum Payload Capacity	1585.00 lbs
Total Option Weight	0.00 lbs
As Spec'd Payload	1585.00 lbs
Option Weight - Front	0.00 lbs
Curb Weight - Front	3005 lbs
Gross Vehicle Weight Rating	7000.00 lbs
Curb Weight	5415.00 lbs
Base Curb Weight	N/A lbs
Gross Combined Wt Rating	16000 lbs
As Spec'd Curb Weight	5415.00 lbs

Height, Overall	75.6 in
Second Shoulder Room	65.4 in
Ground Clearance, Front	N/A in
Width, Max w/o mirrors	79.9 in
Passenger Capacity	5
Second Leg Room	44.5 in
Overhang, Rear w/o bumper	N/A in
Wheelbase	145.7 in
Second Hip Room	62.6 in
Cargo Volume	N/A ft³
Cargo Box (Area) Height	22.2 in
Cab to End of Frame	N/A in
Front Leg Room	42.5 in
Ground to Top of Load Floor	N/A in
Front Hip Room	63.0 in
Length, Overall w/o rear bumper	228.7 in
Length, Overall w/rear bumper	N/A in
Cargo Box Width @ Top, Rear	N/A in
Tailgate Width	66.4 in
Cargo Box Width @ Floor	N/A in
Ground Clearance, Rear	N/A in
Front Head Room	40.2 in
Cargo Box Width @ Wheelhousings	50.0 in
Length, Overall	N/A in
Cargo Box Length @ Floor	66.7 in
Ext'd Cab Cargo Volume	N/A ft³
Second Head Room	38.7 in
Front Shoulder Room	66.6 in
Overhang, Front	N/A in

Fog Lamps	Optional
Automatic limited-slip differential	Standard
HomeLink universal transceiver	Optional
Traction control	Standard
Chrome retractable pwr heated mirrors -inc: turn signals, auto-dimming, puddle lamps	Optional
Pwr vented disc brakes	Standard
Optitron gauges	Optional
Cruise control	Standard
Independent coil-spring double wishbone front suspension w/low-pressure nitrogen gas shocks, stabilizer bar	Standard
Font & rear roll-sensing side curtain airbags	Standard
7,000# GVWR	Optional
Illuminated entry system	Standard
Overhead console	Optional
Multi-information display -inc: current & average mpg, range, average speed, customizable features	Optional
Front leather heated bucket seats w/passenger-side fold flat	Optional
Center console box	Optional
Auto-dimming interior mirror -inc: compass, HomeLink, maplamps	Optional
Tire pressure monitor system	Standard
P275/65R18 all season tires	Optional
Vehicle stability control	Standard
JBL AM/FM stereo -inc: 6-disc CD changer, (12) speakers, (8) channel 440W amp, Bluetooth capability, steering wheel mounted audio controls, aux audio jack	Optional
Driver & front passenger advanced airbags w/passenger cutoff switch	Standard
Pwr locks	Standard
5.7L DOHC 32-valve i-Force V8 engine -inc: dual independent variable valve timing w/intelligence, acoustically controlled induction	Optional
Instrumentation -inc: exterior temp gauge, tachometer, tripmeter, digital clock	Standard
Carpet flooring	Standard
Tilt & telescopic steering wheel w/console shifter	Optional
2-way adjustable headrests	Standard
Rear door privacy glass	Standard
Variable intermittent windshield wipers	Standard
Hydraulic pwr rack & pinion steering	Standard
Engine immobilizer	Standard
Rear glass defroster	Standard
(2) front pwr points & (1) rear pwr point	Standard
Front & rear map lamps	Standard
Pwr sliding rear privacy glass	Standard
Dual zone automatic air conditioning w/sync mode	Optional
Anti-theft alarm system	Optional
Rear wheel drive	Standard
Driver & front passenger seat mounted side airbags	Standard
4-wheel anti-lock brakes (ABS) w/brake assist	Standard
(4) front & (2) rear cup holders	Standard
Driver & front passenger seatback pockets	Standard
Pwr windows	Standard
Deck rail system w/(4) adjustable tie-down cleats	Optional
Rear air conditioning ducts	Standard
Rear outboard seat LATCH anchors	Standard
Glove box illumination	Standard
Silver grille & chrome surround	Optional
Tow Pkg -inc: HD tow hitch receiver, 7-pin connector, trailer brake controller prewire, supplemental transmission cooler, tow & haul mode, transmission fluid temp gauge, 4.30 axle ratio	Optional
Trapezoidal multi-leaf live axle rear suspension w/staggered low-pressure nitrogen gas shocks	Standard
Cigarette lighter & ashtray w/illumination	Standard
Tailgate assist	Standard
6-speed automatic transmission -inc: electronically controlled intelligence, sequential shift mode, uphill & downhill shift logic, Tow & Haul mode	Optional
Deck rail caps	Standard
Rear armrest	Standard
Remote keyless entry system	Standard
3-point seatbelts in all seating positions w/passenger automatic & emergency locking retractors, driver & passenger pretensioners w/force limiters, driver emergency locking retractor	Standard
18" spare wheel & P255/70R18 tire	Standard
Front color-keyed resin bumper & rear chrome steel bumper w/color-keyed front upper cover	Optional
Electronic Brake-force Distribution	Standard
Child-protector rear door locks	Standard
10-way driver & 4-way front passenger pwr adjustable seats w/driver & front passenger lumbar & pwr thigh supports	Optional
Front & rear mudguards	Optional
Chrome door & black tailgate handles	Optional
Child restraint system top tether anchors for all rear seating	Standard
Double visors w/extenders, illuminated mirrors	Optional
Rear sliding & reclining fold-flat seats	Standard
18" alloy wheels	Optional

Compare trims

Wondering which trim is right for you?

Our 2009 Toyota Tundra trim comparison will help you decide.

SAE Net Torque @ RPM	401 @ 3600
Engine Type	Gas V8
SAE Net Horsepower @ RPM	381 @ 5600
Engine Oil Cooler	8.9
Displacement	5.7L/346

Steering Ratio (:1), Overall	N/A
Turning Diameter - Wall to Wall	N/A ft
Turning Diameter - Curb to Curb	44.0 ft
Steering Type	Pwr Rack & Pinion

Cold Cranking Amps @ 0° F (Primary)	N/A
Maximum Alternator Capacity (amps)	N/A

Suspension Type - Rear	Trapezoidal
Suspension Type - Front	Independent
Axle Type - Rear	N/A
Axle Type - Front	N/A

Front Tire Size	P275/65R18
Rear Tire Size	P275/65R18
Spare Tire Size	P255/70R18

2009 Toyota Tundra LTD specs & colors

Crew Cab Pickup

Key specs

Color options

Packages

Specifications

Wheels

Electrical

Engine

Mileage

Transmission

Suspension

Frame

Brakes

Fuel Tank

Steering

Tires

Trailering

Weight Information

Dimensions

Exterior

Compare trims
