2025 Ford Transit-150 specs & colors

Mini-van, Cargo

Change trim
MSRP
T-150 130" Low Rf 8670 GVWR RWD
$47,400
T-150 148" Low Rf 8670 GVWR RWD
$48,800
T-150 148" Med Rf 8670 GVWR RWD
$49,800
T-150 130" Low Rf 8670 GVWR AWD
$51,300
T-250 148" Hi Rf 9070 GVWR RWD
$51,800
T-150 148" Low Rf 8670 GVWR AWD
$52,700
T-250 148" EL Hi Rf 9070 GVWR RWD
$53,000
T-150 148" Med Rf 8670 GVWR AWD
$53,700
$47,400
Starting MSRP
Current listing price
2025 Ford Transit-150

Showing the 2025 Ford Transit-150 T-150 130" Low Rf 8670 GVWR RWD

Shop Now

Key specs

Color options

Interior
Anthracite
Graphite Grey
Red

Packages

  • $535

    Starting MSRP

    • Wiper Activated Headlamps
    • Honeycomb Mesh Grille w/Chrome Surround
    • Wheels: 16" Steel w/Full Silver Cover
    See more detail

    $535

    Starting MSRP

    • Wiper Activated Headlamps
    • Honeycomb Mesh Grille w/Chrome Surround
    • Wheels: 16" Steel w/Full Silver Cover
    • Black HID Lamps

  • $0

    Starting MSRP

  • $4,665

    Starting MSRP

    • Rear speakers are shipped in dunnage box
    • Front Only Carpet Floor Covering
    • Deletes all rear floor covering
    See more detail

    $4,665

    Starting MSRP

    • Rear speakers are shipped in dunnage box
    • Front Only Carpet Floor Covering
    • Deletes all rear floor covering
    • Lane Keeping System
    • Lane keeping system combines Blind Spot Information System (BLIS) w/lane keeping system to provide a visual warning and resistive steering torque to prevent a collision should an object be recognized in the vehicles blind spot while changing lanes
    • Short-Arm Pwr-Folding Heated Pwr Adjusting Mirrors
    • turn signals
    • Radio: AM/FM Stereo w/SYNC 4/SiriusXM w/360L/Nav/iACC
    • HD Radio
    • 12" multi-function display
    • Bluetooth
    • dual USB ports
    • embedded voice recognition
    • connected built-in navigation (1 year of service) and 4 speakers (front)
    • Traffic Sign Recognition (TSR)
    • Intersection Assist
    • Intelligent Adaptive Cruise Control
    • Electronic Air Temperature Control
    • Intelligent Speed Assist (ISA)
    • 8 Speakers (4 Front/4 Rear)
    • Illuminated Sun Visors
    • Side Sensing System
    • Works similar to the reverse sensing system,as it sounds a tone when the vehicle gets close to surrounding vehicles and other objects
    • Front Sensing System
    • Front Fog Lamps
    • Auxiliary lamps that are generally integrated into the front fascia and designed to help illuminate the roadway during poor visibility
    • Reverse Sensing System
    • Body Colored Front Bumper
    • Body colored front bumpers are offered in every exterior color
    • The front bumper will match the exterior color
    • High Resolution Digital Camera
    • Wiper Activated Headlamps
    • Modified Vehicle Wiring System
    • modified vehicle connections for customized wiring harness provisions

  • $1,435

    Starting MSRP

    • full-height polypropylene cargo area panels
    • Front & Rear Vinyl Floor Covering
    • wheel well liners
    See more detail

    $1,435

    Starting MSRP

    • full-height polypropylene cargo area panels
    • Front & Rear Vinyl Floor Covering
    • wheel well liners
    • Illuminated Sun Visors

  • $485

    Starting MSRP

    • Deletes rear tow hook
    • 4/7 pin connector assembly and rear jumper and relay system for backup/B+/running lights
    • This package does not include a Trailer Brake Controller (TBC) (67D)
    See more detail

    $485

    Starting MSRP

    • Deletes rear tow hook
    • 4/7 pin connector assembly and rear jumper and relay system for backup/B+/running lights
    • This package does not include a Trailer Brake Controller (TBC) (67D)
    • Frame Mounted Hitch Receiver
    • Tow/Haul Mode w/Trailering Wiring Provisions

Specifications

Highlights

Regular Unleaded V-6
Engine Type
-
MPG
275 hp
Horsepower
1
Seating Capacity

Brakes

Yes
Disc - Front (Yes or )
Yes
Disc - Rear (Yes or )
N/A
Drum - Rear (Yes or )
4-Wheel
Brake ABS System
12 in
Front Brake Rotor Diam x Thickness
4-Wheel Disc
Brake Type
4-Wheel
Brake ABS System (Second Line)
12 in
Rear Brake Rotor Diam x Thickness

Electrical

250
Maximum Alternator Capacity (amps)
N/A
Cold Cranking Amps @ 0° F (Primary)

Engine

Regular Unleaded V-6
Engine Type
3.5 L/213
Displacement
275 @ 6250
SAE Net Horsepower @ RPM
260 @ 4000
SAE Net Torque @ RPM
10-Speed A/T
A/T
Transmission w/Dual Shift Mode
Transmission Options
-
MPG
N/A
Total Cooling System Capacity

Entertainment

Standard
Bluetooth®

Measurements

N/A
Side Door Opening Height
N/A
Cargo Box Width @ Floor
126 in
Cargo Area Length @ Floor to Seat 1
40 in
Overhang, Front
247 ft³
Cargo Volume
N/A
Cargo Box Width @ Top, Rear
68 in
Front Shoulder Room
81 in
Width, Max w/o mirrors
57 in
Cargo Box (Area) Height
N/A
Step Up Height - Front
130 in
Wheelbase
61 in
Front Hip Room
N/A
Rear Door Opening Width
41 in
Front Head Room
220 in
Length, Overall
N/A
Ground Clearance, Rear
N/A
Ext'd Cab Cargo Volume
N/A
Second Shoulder Room
N/A
Step Up Height - Side
82 in
Height, Overall
N/A
Tailgate Width
29 in
Ground to Top of Load Floor
55 in
Cargo Box Width @ Wheelhousings
70 in
Cargo Area Width @ Beltline
N/A
Cargo Area Length @ Floor to Console
N/A
Second Hip Room
41 in
Front Leg Room
N/A
Overhang, Rear w/o bumper
N/A
Second Leg Room
N/A
Side Door Opening Width
N/A
Second Head Room
N/A
Cab to End of Frame
N/A
Length, Overall w/rear bumper
N/A
Ground Clearance, Front
2
Passenger Capacity
N/A
Rear Door Opening Height

Safety

Standard
Backup Camera
Standard
Blind Spot Monitor
Standard
Lane Departure Warning

Steering

Rack-Pinion
Steering Type
43 ft
Turning Diameter - Curb to Curb
N/A
Steering Ratio (:1), Overall
N/A
Turning Diameter - Wall to Wall

Suspension

Strut
Suspension Type - Front
Leaf
Suspension Type - Rear
Rigid Axle
Axle Type - Rear
Independent
Axle Type - Front

Tires & Wheels

Full-Size in
Spare Wheel Size
Steel
Spare Wheel Material
Full-Size
Spare Tire Size
Steel
Rear Wheel Material
LT235/65SR16
Front Tire Size
Steel
Front Wheel Material
16 X 6.5 in
Rear Wheel Size
16 X 6.5 in
Front Wheel Size
LT235/65SR16
Rear Tire Size

Weight & Capacity

5,200 lbs
Wt Distributing Hitch - Max Trailer Wt.
0 lbs
Option Weight - Front
3,815 lbs
As Spec'd Payload
4,985 lbs
Curb Weight
8,800 lbs
Gross Vehicle Weight Rating
N/A
Fifth Wheel Hitch - Max Tongue Wt.
5,000 lbs
Dead Weight Hitch - Max Trailer Wt.
N/A
Aux Fuel Tank Capacity, Approx
4,985 lbs
As Spec'd Curb Weight
N/A
Fifth Wheel Hitch - Max Trailer Wt.
520 lbs
Wt Distributing Hitch - Max Tongue Wt.
10,800 lbs
Gross Combined Wt Rating
0 lbs
Total Option Weight
5,200 lbs
Maximum Trailering Capacity
9,200 lbs
Gross Axle Weight Rating
4,985 lbs
Base Curb Weight
3,815 lbs
Maximum Payload Capacity
25 gal
Fuel Tank Capacity, Approx
2,062 lbs
Curb Weight - Rear
0 lbs
Option Weight - Rear
500 lbs
Dead Weight Hitch - Max Tongue Wt.
2,923 lbs
Curb Weight - Front
