2005 GMC Savana 3500 Y3G Mobility specs & colors
Full-size Cargo Van
MSRP
- 3500 135" WB RWD Y3H Paratransit
- $26,339
- 3500 135" WB RWD Y3G Mobility
- $26,339
- 3500 135" WB RWD
- $26,339
- 3500 155" WB RWD Y3H Paratransit
- $27,239
- 3500 155" WB RWD
- $27,239
- 3500 135" WB RWD
- $29,849
- 3500 155" WB RWD
- $30,819
$26,339
Starting MSRP
Current listing price
Current listing price
Showing the 2005 GMC Savana 3500 3500 135" WB RWD Y3G Mobility
Shop NowKey specs
Color options
Interior
Taupe
Dark Pewter
Packages
Specifications
Highlights
|
Gas V8
Engine Type
|
|
-
MPG
|
|
300 hp
Horsepower
|
|
1
Seating Capacity
|
Brakes
|
13 x 1.1 in
Rear Brake Rotor Diam x Thickness
|
|
Yes
Disc - Front (Yes or )
|
|
Pwr
Brake Type
|
|
4-Wheel
Brake ABS System
|
|
Not Available
Brake ABS System (Second Line)
|
|
12.8 x 1.5 in
Front Brake Rotor Diam x Thickness
|
|
Not Available
Drum - Rear (Yes or )
|
|
Yes
Disc - Rear (Yes or )
|
Electrical
|
800
Cold Cranking Amps @ 0° F (Primary)
|
|
145
Maximum Alternator Capacity (amps)
|
Engine
|
360 @ 4000
SAE Net Torque @ RPM
|
|
300 @ 4400
SAE Net Horsepower @ RPM
|
|
6.0L/364
Displacement
|
|
Gas V8
Engine Type
|
|
Transmission Overdrive Switch
A/T 4-Speed A/T Transmission Options
|
|
-
MPG
|
|
13.4 qts
Total Cooling System Capacity
|
Measurements
|
N/A
Overhang, Front
|
|
20 in
Step Up Height - Front
|
|
N/A
Overhang, Rear w/o bumper
|
|
N/A
Cargo Box Width @ Top, Rear
|
|
N/A
Cargo Box Width @ Floor
|
|
154 in
Cargo Area Length @ Floor to Console
|
|
N/A
Second Shoulder Room
|
|
52 in
Cargo Box (Area) Height
|
|
128 in
Cargo Area Length @ Floor to Seat 1
|
|
N/A
Cargo Area Width @ Beltline
|
|
N/A
Cab to End of Frame
|
|
66 in
Front Hip Room
|
|
21 in
Step Up Height - Side
|
|
48 in
Side Door Opening Height
|
|
9 in
Ground Clearance, Front
|
|
N/A
Second Hip Room
|
|
28 in
Ground to Top of Load Floor
|
|
N/A
Second Head Room
|
|
225 ft³
Cargo Volume
|
|
44 in
Side Door Opening Width
|
|
N/A
Tailgate Width
|
|
53 in
Cargo Box Width @ Wheelhousings
|
|
57 in
Rear Door Opening Width
|
|
1
Passenger Capacity
|
|
8 in
Ground Clearance, Rear
|
|
49 in
Rear Door Opening Height
|
|
41 in
Front Leg Room
|
|
N/A
Second Leg Room
|
|
N/A
Ext'd Cab Cargo Volume
|
|
N/A
Length, Overall
|
|
69 in
Front Shoulder Room
|
|
79 in
Width, Max w/o mirrors
|
|
224 in
Length, Overall w/rear bumper
|
|
40 in
Front Head Room
|
|
135 in
Wheelbase
|
|
82 in
Height, Overall
|
Steering
|
N/A
Steering Ratio (:1), Overall
|
|
49 ft
Turning Diameter - Curb to Curb
|
|
N/A
Turning Diameter - Wall to Wall
|
|
Pwr-Assisted
Steering Type
|
Suspension
|
Hypoid Multi-Leaf
Suspension Type - Rear
|
|
Full-Floating
Axle Type - Rear
|
|
Independent
Axle Type - Front
|
|
Independent Coil
Suspension Type - Front
|
Tires & Wheels
|
LT245/75R16E
Front Tire Size
|
|
16 x -TBD- in
Front Wheel Size
|
|
16 x -TBD- in
Spare Wheel Size
|
|
LT245/75R16E
Rear Tire Size
|
|
LT245/75R16E
Spare Tire Size
|
|
Steel
Rear Wheel Material
|
|
16 x -TBD- in
Rear Wheel Size
|
|
Steel
Spare Wheel Material
|
|
Steel
Front Wheel Material
|
Weight & Capacity
|
Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt.
|
|
4,000 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
Not Available gal
Aux Fuel Tank Capacity, Approx
|
|
400 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
2,358 lbs
Curb Weight - Rear
|
|
0 lbs
Option Weight - Rear
|
|
10,384 lbs
Gross Axle Weight Rating
|
|
2,956 lbs
Curb Weight - Front
|
|
9,600 lbs
Gross Vehicle Weight Rating
|
|
0 lbs
Total Option Weight
|
|
5,314 lbs
Curb Weight
|
|
Not Available lbs
Fifth Wheel Hitch - Max Trailer Wt.
|
|
8,200 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
0 lbs
Option Weight - Front
|
|
14,000 lbs
Gross Combined Wt Rating
|
|
4,286 lbs
Maximum Payload Capacity
|
|
4,286 lbs
As Spec'd Payload
|
|
N/A
Maximum Trailering Capacity
|
|
N/A
Base Curb Weight
|
|
820 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
|
5,314 lbs
As Spec'd Curb Weight
|
|
31 gal
Fuel Tank Capacity, Approx
|
