2004 Hummer H2 specs & colors
Sport Utility
MSRP
- 4dr Wgn
- $49,395
Key specs
Color options
Interior
Light Beige
Packages
Specifications
Highlights
|
Gas V8
Engine Type
|
|
-
MPG
|
|
316 hp
Horsepower
|
|
7
Seating Capacity
|
Brakes
|
Yes
Disc - Rear (Yes or )
|
|
12.8 x 1.5 in
Front Brake Rotor Diam x Thickness
|
|
13.0 x 1.1 in
Rear Brake Rotor Diam x Thickness
|
|
Power
Brake Type
|
|
Yes
Disc - Front (Yes or )
|
|
4-Wheel
Brake ABS System
|
|
Not Available
Brake ABS System (Second Line)
|
|
Not Available
Drum - Rear (Yes or )
|
Electrical
|
N/A
Cold Cranking Amps @ 0° F (Primary)
|
|
145
Maximum Alternator Capacity (amps)
|
Engine
|
Gas V8
Engine Type
|
|
360 @ 4000
SAE Net Torque @ RPM
|
|
6.0L/364
Displacement
|
|
316 @ 5200
SAE Net Horsepower @ RPM
|
|
A/T
4-Speed A/T Transmission Options
|
|
-
MPG
|
|
16.8 qts
Total Cooling System Capacity
|
Measurements
|
Not Available in
Third Hip Room
|
|
52 in
Rear Door Opening Width
|
|
Not Available in
Third Shoulder Room
|
|
Not Available in
Side Door Opening Width
|
|
123 in
Wheelbase
|
|
N/A
Cargo Box Width @ Top, Rear
|
|
N/A
Tailgate Width
|
|
62 in
Second Hip Room
|
|
N/A
Ext'd Cab Cargo Volume
|
|
31 in
Ground to Top of Load Floor
|
|
87 ft³
Cargo Volume to Seat 1
|
|
66 in
Front Shoulder Room
|
|
Not Available in
Cargo Area Length @ Floor to Seat 3
|
|
Not Available ft³
Cargo Volume to Seat 4
|
|
39 in
Second Leg Room
|
|
26 in
Step Up Height - Front
|
|
81 in
Width, Max w/o mirrors
|
|
40 ft³
Cargo Volume to Seat 2
|
|
63 in
Front Hip Room
|
|
Not Available ft³
Cargo Volume to Seat 3
|
|
10 in
Ground Clearance, Front
|
|
N/A
Overhang, Rear w/o bumper
|
|
33 in
Overhang, Front
|
|
N/A
Cab to End of Frame
|
|
37 in
Cargo Area Length @ Floor to Seat 2
|
|
35 in
Rear Door Opening Height
|
|
72 in
Cargo Area Length @ Floor to Seat 1
|
|
41 in
Front Leg Room
|
|
9 in
Ground Clearance, Rear
|
|
N/A
Length, Overall
|
|
N/A
Cargo Volume
|
|
190 in
Length, Overall w/rear bumper
|
|
N/A
Cargo Box (Area) Height
|
|
N/A
Cargo Area Width @ Beltline
|
|
5
Passenger Capacity
|
|
78 in
Height, Overall
|
|
68 in
Cargo Box Width @ Wheelhousings
|
|
Not Available in
Third Leg Room
|
|
40 in
Second Head Room
|
|
Not Available in
Side Door Opening Height
|
|
N/A
Cargo Box Width @ Floor
|
|
Not Available in
Third Head Room
|
|
N/A
Cargo Area Length @ Floor to Console
|
|
26 in
Step Up Height - Side
|
|
41 in
Front Head Room
|
|
66 in
Second Shoulder Room
|
Steering
|
Pwr recirculating ball
Steering Type
|
|
N/A
Turning Diameter - Wall to Wall
|
|
N/A
Steering Ratio (:1), Overall
|
|
44 ft
Turning Diameter - Curb to Curb
|
Suspension
|
N/A
Axle Type - Front
|
|
Multi-link coil
Suspension Type - Rear
|
|
Rigid
Axle Type - Rear
|
|
Torsion bar
Suspension Type - Front
|
Tires & Wheels
|
Aluminum
Spare Wheel Material
|
|
Aluminum
Rear Wheel Material
|
|
LT315/70R17
Rear Tire Size
|
|
17 x 8.5 in
Rear Wheel Size
|
|
17 x 8.5 in
Spare Wheel Size
|
|
17 x 8.5 in
Front Wheel Size
|
|
LT315/70R17
Spare Tire Size
|
|
LT315/70R17
Front Tire Size
|
|
Aluminum
Front Wheel Material
|
Weight & Capacity
|
6,700 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
N/A
Fifth Wheel Hitch - Max Trailer Wt.
|
|
N/A
Maximum Trailering Capacity
|
|
0 lbs
Option Weight - Rear
|
|
6,400 lbs
As Spec'd Curb Weight
|
|
8,600 lbs
Gross Vehicle Weight Rating
|
|
32 gal
Fuel Tank Capacity, Approx
|
|
2,200 lbs
Maximum Payload Capacity
|
|
0 lbs
Total Option Weight
|
|
N/A
Fifth Wheel Hitch - Max Tongue Wt.
|
|
14,000 lbs
Gross Combined Wt Rating
|
|
Not Available gal
Aux Fuel Tank Capacity, Approx
|
|
2,200 lbs
As Spec'd Payload
|
|
5,000 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
670 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
|
6,400 lbs
Curb Weight
|
|
500 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
9,000 lbs
Gross Axle Weight Rating
|
|
0 lbs
Option Weight - Front
|
|
2,880 lbs
Curb Weight - Rear
|
|
N/A
Base Curb Weight
|
|
3,520 lbs
Curb Weight - Front
|
