1997 Chevrolet Express 3500 specs & colors
Mini-van, Passenger
MSRP
- 3dr Reg WB
- $19,925
- 3dr Ext WB
- $21,090
- 4dr Reg WB
- $21,869
- 4dr Ext WB
- $22,699
- 3500 135" WB
- $24,956
- 3500 155" WB
- $25,856
$19,925
Starting MSRP
Current listing price
Current listing price
Showing the 1997 Chevrolet Express 3500 3dr Reg WB
Shop NowKey specs
Color options
Interior
Light Gray
Taupe
Jadestone
Packages
Specifications
Highlights
|
Gas V6
Engine Type
|
|
18 City / 25 Hwy
MPG
|
|
180 hp
Horsepower
|
|
7
Seating Capacity
|
Brakes
|
Not Available in
Rear Brake Rotor Diam x Thickness
|
|
Not Available
Disc - Rear (Yes or )
|
|
N/A
Brake ABS System (Second Line)
|
|
4-Wheel
Brake ABS System
|
|
Yes
Drum - Rear (Yes or )
|
|
10.94 X 1.27 in
Front Brake Rotor Diam x Thickness
|
|
Power
Brake Type
|
|
Yes
Disc - Front (Yes or )
|
Electrical
|
105
Maximum Alternator Capacity (amps)
|
|
600
Cold Cranking Amps @ 0° F (Primary)
|
Engine
|
Gas V6
Engine Type
|
|
205 @ 4000
SAE Net Torque @ RPM
|
|
180 @ 5200
SAE Net Horsepower @ RPM
|
|
3.4L/207
Displacement
|
|
A/T
4-Speed A/T Transmission Options
|
|
18 City / 25 Hwy
MPG
|
|
11.23 qts
Total Cooling System Capacity
|
Measurements
|
39 in
Second Head Room
|
|
N/A
Trunk Volume
|
|
60 in
Front Shoulder Room
|
|
48 in
Third Hip Room
|
|
187 in
Length, Overall
|
|
60 in
Third Shoulder Room
|
|
18 in
Cargo Area Length @ Floor to Seat 3
|
|
48 in
Cargo Box Width @ Wheelhousings
|
|
8 in
Min Ground Clearance
|
|
41 in
Rear Door Opening Height
|
|
37 in
Second Leg Room
|
|
63 in
Track Width, Rear
|
|
N/A
Passenger Volume
|
|
62 in
Second Shoulder Room
|
|
60 in
Second Hip Room
|
|
86 in
Cargo Area Length @ Floor to Seat 1
|
|
46 in
Cargo Box (Area) Height
|
|
67 in
Height, Overall
|
|
127 ft³
Cargo Volume to Seat 1
|
|
40 in
Front Head Room
|
|
39 in
Third Head Room
|
|
24 in
Liftover Height
|
|
7
Passenger Capacity
|
|
34 in
Third Leg Room
|
|
16 ft³
Cargo Volume to Seat 3
|
|
112 in
Wheelbase
|
|
40 in
Front Leg Room
|
|
43 ft³
Cargo Volume to Seat 2
|
|
56 in
Front Hip Room
|
|
62 in
Track Width, Front
|
|
72 in
Width, Max w/o mirrors
|
|
51 in
Cargo Area Length @ Floor to Seat 2
|
|
51 in
Rear Door Opening Width
|
|
51 in
Cargo Area Width @ Beltline
|
Steering
|
39 ft
Turning Diameter - Curb to Curb
|
|
Power w/Reduced Effort
Steering Type
|
|
41 ft
Turning Diameter - Wall to Wall
|
|
17
Steering Ratio (:1), Overall
|
|
3
Lock to Lock Turns (Steering)
|
Suspension
|
w/Coil Springs
Suspension Type - Rear (Cont.)
|
|
w/Coil Springs
Suspension Type - Front (Cont.)
|
|
MacPherson Strut
Suspension Type - Front
|
|
Trailing Arm
Suspension Type - Rear
|
Tires & Wheels
|
15 x 6.0 in
Front Wheel Size
|
|
T125/70R15
Spare Tire Size
|
|
15 x 6.0 in
Rear Wheel Size
|
|
15 x 4.0 in
Spare Wheel Size
|
|
Steel
Front Wheel Material
|
|
P205/70R15
Front Tire Size
|
|
P205/70R15
Rear Tire Size
|
|
Steel
Spare Wheel Material
|
|
Steel
Rear Wheel Material
|
Weight & Capacity
|
200 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
N/A
Wt Distributing Hitch - Max Trailer Wt.
|
|
N/A
Wt Distributing Hitch - Max Tongue Wt.
|
|
3,671 lbs
Base Curb Weight
|
|
20 gal
Fuel Tank Capacity, Approx
|
|
2,000 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
N/A
Aux Fuel Tank Capacity, Approx
|
