2020 Chevrolet Express 3500 specs & colors

Full-size Cargo Van

Change trim

$35,600

Starting MSRP
Current listing price

Showing the 2020 Chevrolet Express 3500 RWD 3500 135"

Shop Now

Key specs

3-door

1 seat

341.0-hp, 6.0-liter, 8 Cylinder Engine (Flex Fuel Capability)

0 combined MPG

224.05" length, 84.75" height

Rear Wheel Drive

Color options

Exterior

Interior

Neutral

Medium Pewter

Jet Black / Medium Dark Pewter

Packages

Hotel Shuttle Package

$1,330

Starting MSRP

Includes (B31) front rubberized vinyl Black floor covering
(KG4) 150-amp alternator
(ZQ3) Driver Convenience Package

Driver Convenience Package

$395

Starting MSRP

includes Tilt-Wheel and (K34) cruise control

3500 Van Preferred Equipment Group

Starting MSRP

includes Standard Equipment

See all packages

Chrome Appearance Package

$355

Starting MSRP

(Includes (V37) front and rear chrome bumpers and (V22) chrome grille.

Specifications

Rear Door Type

Dual Swing-out

Front Wheel Size	16 x 6.5 in
Rear Wheel Size	16 x 6.5 in
Spare Wheel Size	16 x 6.5 in
Front Wheel Material	Steel
Rear Wheel Material	Steel
Spare Wheel Material	Steel

Cold Cranking Amps @ 0° F (Primary)	600
Maximum Alternator Capacity (amps)	105

Engine Type	Gas V6
Displacement	4.3L/-TBD-
SAE Net Horsepower @ RPM	276 @ 5200
SAE Net Torque @ RPM	298 @ 3900
Engine Oil Cooler	Yes

EPA Fuel Economy Est - Hwy	N/A MPG
Cruising Range - City	N/A mi
EPA Fuel Economy Est - City	N/A MPG
Fuel Economy Est-Combined	N/A MPG
Cruising Range - Hwy	N/A mi
Estimated Battery Range	N/A mi

Drivetrain	Rear Wheel Drive
Trans Type	8
Trans Description Cont.	Automatic
Trans Description Cont. Again	N/A
First Gear Ratio (:1)	4.56
Second Gear Ratio (:1)	2.97
Third Gear Ratio (:1)	2.08
Fourth Gear Ratio (:1)	1.69
Fifth Gear Ratio (:1)	1.27
Sixth Gear Ratio (:1)	1.00
Reverse Ratio (:1)	3.82
Trans Power Take Off	N/A
Final Drive Axle Ratio (:1)	N/A
Transfer Case Model	N/A
Transfer Case Gear Ratio (:1), High	N/A
Transfer Case Gear Ratio (:1), Low	N/A
Transfer Case Power Take Off	N/A
Seventh Gear Ratio (:1)	0.85
Eighth Gear Ratio (:1)	0.65

Suspension Type - Front	Coil Spring
Suspension Type - Rear	Hypoid Multi-Leaf
Axle Type - Front	Independent
Axle Type - Rear	Full-Floating

Frame Type

Ladder

Side Door Type

Swing-out

Brake Type	Pwr
Brake ABS System	4-Wheel
Brake ABS System (Second Line)	N/A
Disc - Front (Yes or )	Yes
Disc - Rear (Yes or )	Yes
Front Brake Rotor Diam x Thickness	12.8 x 1.5 in
Rear Brake Rotor Diam x Thickness	13.0 x 1.1 in
Drum - Rear (Yes or )	N/A

Fuel Tank Capacity, Approx	31 gal
Aux Fuel Tank Capacity, Approx	N/A gal

Steering Type	Pwr
Steering Ratio (:1), Overall	N/A
Turning Diameter - Curb to Curb	49.2 ft
Turning Diameter - Wall to Wall	N/A ft

Front Tire Size	LT245/75R16E
Rear Tire Size	LT245/75R16E
Spare Tire Size	LT245/75R16E

Dead Weight Hitch - Max Trailer Wt.	5000 lbs
Dead Weight Hitch - Max Tongue Wt.	500 lbs
Wt Distributing Hitch - Max Trailer Wt.	7400 lbs
Wt Distributing Hitch - Max Tongue Wt.	740 lbs
Fifth Wheel Hitch - Max Trailer Wt.	N/A lbs
Fifth Wheel Hitch - Max Tongue Wt.	N/A lbs
Maximum Trailering Capacity	10000 lbs

Base Curb Weight	N/A lbs
Curb Weight - Front	2890 lbs
Curb Weight - Rear	2207 lbs
Option Weight - Front	0.00 lbs
Option Weight - Rear	0.00 lbs
As Spec'd Curb Weight	5179.00 lbs
As Spec'd Payload	4421.00 lbs
Maximum Payload Capacity	4503.00 lbs
Gross Combined Wt Rating	13000 lbs
Gross Axle Weight Rating	10384.00 lbs
Curb Weight	5097.00 lbs
Total Option Weight	0.00 lbs
Gross Vehicle Weight Rating	9600.00 lbs

Passenger Capacity	2
Front Head Room	40.85 in
Front Leg Room	41.35 in
Front Shoulder Room	68.85 in
Front Hip Room	65.47 in
Second Head Room	N/A in
Second Leg Room	N/A in
Second Shoulder Room	N/A in
Second Hip Room	N/A in
Wheelbase	135.15 in
Length, Overall w/rear bumper	N/A in
Length, Overall	224.05 in
Width, Max w/o mirrors	79.25 in
Height, Overall	84.75 in
Overhang, Front	39.7 in
Overhang, Rear w/o bumper	N/A in
Cab to End of Frame	N/A in
Ground to Top of Load Floor	30.3 in
Ground Clearance, Front	9.72 in
Ground Clearance, Rear	8.62 in
Rear Door Opening Height	49.4 in
Rear Door Opening Width	53.42 in
Side Door Opening Height	N/A in
Side Door Opening Width	N/A in
Step Up Height - Front	27.67 in
Step Up Height - Side	28.25 in
Cargo Area Length @ Floor to Console	154.7 in
Cargo Area Length @ Floor to Seat 1	126.75 in
Cargo Box Width @ Top, Rear	N/A in
Cargo Area Width @ Beltline	N/A in
Cargo Box Width @ Floor	N/A in
Cargo Box Width @ Wheelhousings	52.47 in
Cargo Box (Area) Height	55.08 in
Tailgate Width	N/A in
Cargo Volume	239.4 ft³
Ext'd Cab Cargo Volume	N/A ft³

4G LTE Wi-Fi Hotspot capable (Included and only available with (UE1) OnStar. Terms and limitations apply. See onstar.com or dealer for details.)	Standard
Audio system, AM/FM stereo with MP3 player seek-and-scan, digital clock, TheftLock, random select, auxiliary jack and 2 front door speakers (STD) (Not available with (U2K) SiriusXM Radio.)	Standard

Tires, front LT245/75R16E all-season, blackwall	Standard
Tires, rear LT245/75R16E all-season, blackwall	Standard
Door, swing-out passenger-side, 60/40 split (STD)	Standard
Wheels, 4 - 16" x 6.5" (40.6 cm x 16.5 cm) steel includes Gray center caps and steel spare	Standard
License plate kit, front	Standard
Glass, Solar-Ray light-tinted, all windows	Standard
Headlamps, dual halogen composite	Standard
Wipers, front intermittent wet-arm with pulse washers	Standard
Tire, spare LT245/75R16E all-season, blackwall located at rear underbody of vehicle (STD)	Standard
Mirrors, outside manual, Black	Standard
Bumpers, front and rear painted Black with step-pad	Standard

Windows, power (Included with (ZQ2) Power Convenience Package.)	Standard
Mirror, inside rearview includes Rear Vision Camera display	Standard
Theft-deterrent system, vehicle, PASS-Key III	Standard
Warning tones, headlamp on and key-in-ignition	Standard
Oil life monitor	Standard
Floor covering, full-length Black rubberized-vinyl (Not available with (RFM) rear floor covering delete or (PCH) Hotel Shuttle Package.)	Standard
Headliner, cloth, over driver and passenger	Standard
Air conditioning, single-zone manual (STD) (Not available with (R6G) air conditioning delete.)	Standard
Defogger, side windows	Standard
Chevrolet Connected Access capable (Included and only available with (UE1) OnStar. Subject to terms. See onstar.com or dealer for details.)	Standard
Cup holders, 3 on the engine console cover	Standard
Door locks, power with lock-out protection (Included with (ZQ2) Power Convenience Package. NOTE: Does not include (ATG) Remote Keyless Entry. (ATG) Remote Keyless Entry must be ordered separately.)	Standard
Assist handles, driver and right-front passenger	Standard
Seats, front bucket with vinyl trim and outboard head restraints, includes inboard armrests. (STD) (Requires (W) interior trim.)**	Standard
Visors, driver and front passenger, vinyl	Standard
Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure	Standard
Console, engine cover with open storage bin	Standard
Lighting, interior with 4 dome lights 1 overhead and 3 LED's on cross members in cargo area, includes defeat switch and door handle-activated switches	Standard
Driver Information Center includes fuel range, average speed, oil life, tire pressure monitoring, fuel used, ice warning, engine hours, average fuel economy, tachometer, and maintenance reminders. Compass and outside temperature available if equipped.	Standard
Steering wheel, steel sleeve column with theft-deterrent locking feature, Black	Standard
Cargo tie-downs 6 D-ring attachments on cargo area floor (Not available with (Y3H) Paratransit Package or (ZP6) 5-passenger Express Crew Van.)	Standard
Trim panels, hinged rear side doors and hinged rear doors (Not available with (Y3H) Paratransit Package.)	Standard
Power outlet, 120-volt	Standard
Power outlets, 2 auxiliary on engine console cover with covers, 12-volt	Standard
Seating arrangement, driver and front passenger high-back buckets, with head restraints and vinyl or cloth trim (STD) (Not available with (AJ3) driver-side only frontal airbag.)	Standard
Tow/haul mode selector, instrument panel-mounted	Standard

GVWR, 9600 lbs. (4354 kg) (Reference the Engine/Axle page for availability.)	Standard
Engine, 4.3L V6 with Direct Injection and Variable Valve Timing, includes aluminum block construction (276 hp [206 kW] @ 5200 rpm, 298 lb-ft of torque [404 Nm] @ 3900 rpm) (STD) (Reference the Engine/Axle page for availability.)	Standard
Rear axle, 3.42 ratio (Reference the Engine/Axle page for availability.)	Standard
Transmission, 8-speed automatic, electronically controlled with overdrive and tow/haul mode, includes Cruise Grade Braking and Powertrain Grade Braking (STD) (Requires (LV1) 4.3L V6 SIDI engine.)	Standard
Brakes, 4-wheel antilock, 4-wheel disc	Standard
Cooling, external engine oil cooler (Not available with (LWN) 2.8L Duamax Turbo-Diesel engine.)	Standard
Alternator, 105 amps (Not available with (Y3H) Paratransit Package, (C69) rear air conditioning, (9L7) Wiring junction block equipment accessory or (LWN) 2.8L Duramax Turbo-Diesel engine.)	Standard
Suspension, rear hypoid drive axle with multi-leaf springs	Standard
Fuel tank capacity, mid-frame and approximately 31 gallons (117.3L)	Standard
Transmission oil cooler, external (Not available with (LWN) 2.8L Duramax Turbo-Diesel engine.)	Standard
Body, standard (STD)	Standard
Rear wheel drive	Standard
Battery, 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power	Standard
Frame, full-length box ladder-type	Standard
Exhaust, aluminized stainless-steel muffler and tailpipe	Standard
Steering, power	Standard
Suspension, front independent with coil springs and stabilizer bar	Standard

Power Convenience Package includes (A31) power windows and (AU3) power door locks

Standard

Rear Vision Camera display integrated into rearview mirror (Display included with (DRJ) inside rearview mirror.)	Standard
OnStar and Chevrolet connected services capable (Not available with (UXZ) radio provisions only. Terms and limitations apply. See onstar.com or dealer for details.)	Standard
Brake/transmission shift interlock, for automatic transmissions	Standard
Airbags, seat-mounted side-impact for driver and right-front passenger and roof-rail mounted head-curtain for 1-row coverage with (ZX1) driver only high-back bucket seat or (ZX2) driver and right-front passenger high-back bucket seats, and 2-row coverage with (ZP6) 5-passenger Express Crew Van Package (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)	Standard
Airbag deactivation switch, frontal passenger-side (Not available with (AJ3) driver only airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)	Standard
Door beams, steel-side	Standard
Airbags, frontal, front driver and right front passenger (Includes passenger-side airbag deactivation switch. Included with (ZX2) driver and front passenger high-back bucket seats or (ZP6) 5-passenger Express Crew Van Package. Not available with (ZX1) driver only high-back bucket seat or (AJ3) driver-side only frontal airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)	Standard
Tire Pressure Monitoring System (does not apply to spare tire)	Standard
Daytime Running Lamps	Standard
Hill Start Assist	Standard
StabiliTrak, traction assistance and vehicle stability enhancement system	Standard
