2002 Chevrolet Silverado 3500 LS

Showing the 2002 Chevrolet Silverado 3500 Ext Cab 157.5" WB 4WD DRW LS

Shop Now

Key specs

Color options

Interior
Taupe
Graphite
Pewter Gray

Packages

Specifications

Highlights

Gas V8
Engine Type
-
MPG
300 hp
300 hp
340 hp
Horsepower
5
Seating Capacity

Brakes

Pwr
Brake Type
Four-Wheel
Brake ABS System
Not Available
Brake ABS System (Second Line)
Yes
Disc - Front (Yes or )
Yes
Disc - Rear (Yes or )
12.8 x 1.5 in
Front Brake Rotor Diam x Thickness
12.8 x 1.2 in
Rear Brake Rotor Diam x Thickness
Not Available
Drum - Rear (Yes or )

Electrical

600
Cold Cranking Amps @ 0° F (Primary)
105
Maximum Alternator Capacity (amps)

Engine

Gas V8
Engine Type
6.0L/364
Displacement
300 @ 4400
SAE Net Horsepower @ RPM
360 @ 4000
SAE Net Torque @ RPM
M/T
6-Speed M/T
A/T
5-Speed A/T
5-Speed M/T
4-Speed A/T
Transmission Options
-
MPG
N/A
Total Cooling System Capacity

Measurements

6
Passenger Capacity
41 in
Front Head Room
41 in
Front Leg Room
65 in
Front Shoulder Room
61 in
Front Hip Room
38 in
Second Head Room
34 in
Second Leg Room
66 in
Second Shoulder Room
62 in
Second Hip Room
158 in
Wheelbase
247 in
Length, Overall w/o rear bumper
N/A
Length, Overall w/rear bumper
N/A
Length, Overall
80 in
Width, Max w/o mirrors
76 in
Height, Overall
37 in
Overhang, Front
47 in
Overhang, Rear w/o bumper
N/A
Cab to End of Frame
N/A
Ground to Top of Load Floor
11 in
Ground Clearance, Front
14 in
Ground Clearance, Rear
98 in
Cargo Box Length @ Floor
62 in
Cargo Box Width @ Top, Rear
65 in
Cargo Box Width @ Floor
50 in
Cargo Box Width @ Wheelhousings
20 in
Cargo Box (Area) Height
62 in
Tailgate Width
71 ft³
Cargo Volume
N/A
Ext'd Cab Cargo Volume

Steering

Pwr
Steering Type
N/A
Steering Ratio (:1), Overall
52 ft
Turning Diameter - Curb to Curb
N/A
Turning Diameter - Wall to Wall

Suspension

Torsion Bar
Suspension Type - Front
2-Stage Multi-Leaf
Suspension Type - Rear
N/A
Axle Type - Front
Full-Floating
Axle Type - Rear

Tires & Wheels

LT215/85R16
Front Tire Size
LT215/85R16
Rear Tire Size
LT215/85R16
Spare Tire Size
16 x 6.5 in
Front Wheel Size
16 x 6.5 in
Rear Wheel Size
16 x 6.5 in
Spare Wheel Size
Steel
Front Wheel Material
Steel
Rear Wheel Material
Steel
Spare Wheel Material

Weight & Capacity

N/A
Base Curb Weight
3,345 lbs
Curb Weight - Front
2,688 lbs
Curb Weight - Rear
0 lbs
Option Weight - Front
0 lbs
Option Weight - Rear
6,033 lbs
As Spec'd Curb Weight
N/A
As Spec'd Payload
N/A
Maximum Payload Capacity
16,000 lbs
Gross Combined Wt Rating
7,500 lbs
Dead Weight Hitch - Max Trailer Wt.
1,000 lbs
Dead Weight Hitch - Max Tongue Wt.
9,800 lbs
Wt Distributing Hitch - Max Trailer Wt.
1,500 lbs
Wt Distributing Hitch - Max Tongue Wt.
9,800 lbs
Fifth Wheel Hitch - Max Trailer Wt.
3,500 lbs
Fifth Wheel Hitch - Max Tongue Wt.
N/A
Maximum Trailering Capacity
34 gal
Fuel Tank Capacity, Approx
Not Available gal
Aux Fuel Tank Capacity, Approx
13,350 lbs
Gross Axle Weight Rating
6,033 lbs
Curb Weight
0 lbs
Total Option Weight
11,400 lbs
Gross Vehicle Weight Rating
