2026 Chrysler Pacifica Limited specs & colors
Mini-van, Passenger
MSRP
- Select FWD
- $43,945
- Select AWD
- $47,290
- Limited FWD
- $49,105
- Limited AWD
- $52,450
- Pinnacle FWD
- $55,595
- Pinnacle AWD
- $58,940
Key specs
Color options
Interior
Black / Black / Black
Packages
$0
Starting MSRP
- Engine: 3.6L V6 24V VVT UPG I w/ESS
- Transmission: 9-Speed 948TE Automatic
$1,495
Starting MSRP
- ParkSense Front/Rear Park Assist w/Stop
- 360 Surround View Camera System
$1,195
Starting MSRP
- Hitch w/2" Receiver
- Trailer Sway Damping
- 7 & 4 Pin Trailer Tow Wiring Harness
$995
Starting MSRP
- Cargo Area Liner
- Bright Door Sills
- All Weather Cargo Floor Mats
See more detail $995
Starting MSRP
- Cargo Area Liner
- Bright Door Sills
- All Weather Cargo Floor Mats
- All Weather Floor Mats - Stow 'N Go
- Rear Cargo Bin Stow 'N Go Storage
$225
Starting MSRP
- First Aid Kit
- Reflecting Triangle
- Tool Kit
$3,325
Starting MSRP
- Video USB Port
- Blu-Ray/DVD Player/USB Port
- Hands Free Sliding Doors
See more detail $3,325
Starting MSRP
- Video USB Port
- Blu-Ray/DVD Player/USB Port
- Hands Free Sliding Doors
- 19 harman/kardon Speakers w/Subwoofer
- High Definition Multimedia Interface
- Stow N Vac Integrated Vacuum
- 3-Channel Video Remote Control
- 2nd & 3rd Row Window Shades
- Seatback Video Screens
- 115V Auxiliary Power Outlet
- 760 Watt Amplifier
- FamCAM Interior Camera
- Amazon Fire TV Built-In
$1,795
Starting MSRP
- Black Day Light Opening Moldings
- Premium Fascia Upper/Lower Grille w/Black Surround
- Tires: 245/50R20 BSW AS Self-Sealing
See more detail $1,795
Starting MSRP
- Black Day Light Opening Moldings
- Premium Fascia Upper/Lower Grille w/Black Surround
- Tires: 245/50R20 BSW AS Self-Sealing
- Black Stow 'N Place Roof Rack
- Premium Rear Fascia Black
- Wheels: 20" x 7.5" S-Model Aluminum Design 1
- Anodized Ink Badging
- S Badge
Specifications
Highlights
|
Regular Unleaded V-6
Engine Type
|
|
17 City / 25 Hwy
MPG
|
|
287 hp
Horsepower
|
|
7
Seating Capacity
|
Brakes
|
N/A
Drum - Rear (Yes or )
|
|
14 in
Front Brake Rotor Diam x Thickness
|
|
Yes
Disc - Front (Yes or )
|
|
4-Wheel
Brake ABS System
|
|
4-Wheel Disc
Brake Type
|
|
Yes
Disc - Rear (Yes or )
|
|
13 in
Rear Brake Rotor Diam x Thickness
|
|
N/A
Brake ABS System (Second Line)
|
Electrical
|
220
Maximum Alternator Capacity (amps)
|
|
650
Cold Cranking Amps @ 0° F (Primary)
|
Engine
|
3.6 L/220
Displacement
|
|
Regular Unleaded V-6
Engine Type
|
|
287 @ 6400
SAE Net Horsepower @ RPM
|
|
262 @ 4000
SAE Net Torque @ RPM
|
|
9-Speed A/T
A/T Transmission Options
|
|
17 City / 25 Hwy
MPG
|
|
N/A
Total Cooling System Capacity
|
Entertainment
|
Standard
Bluetooth®
|
Measurements
|
165 ft³
Passenger Volume
|
|
5 in
Min Ground Clearance
|
|
69 in
Track Width, Front
|
|
122 in
Wheelbase
|
|
N/A
Cargo Area Length @ Floor to Seat 2
|
|
N/A
Cargo Area Length @ Floor to Seat 3
|
|
63 in
Second Shoulder Room
|
|
37 in
Third Leg Room
|
|
N/A
Rear Door Opening Height
|
|
204 in
Length, Overall
|
|
N/A
Cargo Area Length @ Floor to Seat 1
|
|
N/A
Trunk Volume
|
|
65 in
Second Hip Room
|
|
38 in
Front Head Room
|
|
71 in
Height, Overall
|
|
49 in
Cargo Box Width @ Wheelhousings
|
|
39 in
Third Head Room
|
|
48 in
Cargo Box (Area) Height
|
|
88 ft³
Cargo Volume to Seat 2
|
|
N/A
Cargo Area Width @ Beltline
|
|
59 in
Front Hip Room
|
|
80 in
Width, Max w/o mirrors
|
|
38 in
Second Head Room
|
|
N/A
Rear Door Opening Width
|
|
61 in
Third Shoulder Room
|
|
N/A
Liftover Height
|
|
50 in
Third Hip Room
|
|
39 in
Second Leg Room
|
|
64 in
Front Shoulder Room
|
|
41 in
Front Leg Room
|
|
7
Passenger Capacity
|
|
69 in
Track Width, Rear
|
|
141 ft³
Cargo Volume to Seat 1
|
|
32 ft³
Cargo Volume to Seat 3
|
Safety
|
Standard
Blind Spot Monitor
|
|
Standard
Rear Cross Traffic Alert
|
|
Standard
Lane Departure Warning
|
|
Standard
Backup Camera
|
|
Standard
Stability Control
|
Steering
|
N/A
Turning Diameter - Wall to Wall
|
|
N/A
Steering Ratio (:1), Overall
|
|
40 ft
Turning Diameter - Curb to Curb
|
|
N/A
Lock to Lock Turns (Steering)
|
|
Rack-Pinion
Steering Type
|
Suspension
|
Trailing Arm
Suspension Type - Rear
|
|
Strut
Suspension Type - Front
|
|
Strut
Suspension Type - Front (Cont.)
|
|
Trailing Arm
Suspension Type - Rear (Cont.)
|
Tires & Wheels
|
N/A
Spare Wheel Size
|
|
Aluminum
Rear Wheel Material
|
|
18 X 7.5 in
Front Wheel Size
|
|
P245/60HR18
Rear Tire Size
|
|
18 X 7.5 in
Rear Wheel Size
|
|
N/A
Spare Wheel Material
|
|
Aluminum
Front Wheel Material
|
|
N/A
Spare Tire Size
|
|
P245/60HR18
Front Tire Size
|
Weight & Capacity
|
19 gal
Fuel Tank Capacity, Approx
|
|
N/A
Aux Fuel Tank Capacity, Approx
|
|
3,600 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
4,883 lbs
Base Curb Weight
|
|
360 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
3,600 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
360 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
