2009 Ford Expedition EL XLT specs & colors

$38,370
Starting MSRP
Current listing price
2009 Ford Expedition EL XLT

Showing the 2009 Ford Expedition EL 2WD 4dr XLT

Shop Now

Key specs

Color options

Interior

Charcoal Black


Taupe / Pearl Beige


Charcoal black


Medium light stone


Beige


Camel


Packages

$0

Starting MSRP

Specifications

Rear Door Type Liftgate
Spare Wheel Material Steel
Rear Wheel Size 17 x 8.0 in
Front Wheel Size 17 x 8.0 in
Rear Wheel Material Aluminum
Front Wheel Material Aluminum
Spare Wheel Size 17 x 8.0 in
Cold Cranking Amps @ 0° F (Primary) 650
Maximum Alternator Capacity (amps) 150
SAE Net Torque @ RPM 365 @ 3600
SAE Net Horsepower @ RPM 310 @ 5100
Engine Oil Cooler Not Available
Engine Type FFV V8
Displacement 5.4L/330
EPA Fuel Economy Est - Hwy 20 MPG
EPA Fuel Economy Est - City 14 MPG
Cruising Range - Hwy 670.00 mi
Estimated Battery Range N/A mi
Cruising Range - City 469.00 mi
Fuel Economy Est-Combined 16 MPG
Final Drive Axle Ratio (:1) N/A
Trans Type 6
First Gear Ratio (:1) 4.17
Transfer Case Power Take Off Not Available
Trans Power Take Off Not Available
Transfer Case Gear Ratio (:1), High Not Available
Fifth Gear Ratio (:1) 0.86
Reverse Ratio (:1) 3.40
Third Gear Ratio (:1) 1.52
Transfer Case Gear Ratio (:1), Low Not Available
Trans Description Cont. Again Not Available
Second Gear Ratio (:1) 2.34
Sixth Gear Ratio (:1) 0.69
Fourth Gear Ratio (:1) 1.14
Drivetrain Rear Wheel Drive
Transfer Case Model Not Available
Trans Description Cont. Automatic w/OD
Suspension Type - Rear Multi-Link
Suspension Type - Front Double Wishbone
Axle Type - Front Independent
Axle Type - Rear Independent
Frame Type Fully Boxed
Side Door Type N/A
Brake Type Pwr
Brake ABS System (Second Line) Not Available
Drum - Rear (Yes or ) Not Available
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.0 x -TBD- in
Rear Brake Rotor Diam x Thickness 13.5 x -TBD- in
Disc - Rear (Yes or ) Yes
Aux Fuel Tank Capacity, Approx Not Available gal
Fuel Tank Capacity, Approx 33.5 gal
Turning Diameter - Curb to Curb 40.83 ft
Steering Type Variable Pwr Rack & Pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Wall to Wall 42.16 ft
Rear Tire Size P265/70R17
Spare Tire Size P265/70R17
Front Tire Size P265/70R17
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Fifth Wheel Hitch - Max Tongue Wt. Not Available lbs
Maximum Trailering Capacity N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 600 lbs
Wt Distributing Hitch - Max Trailer Wt. 6000 lbs
Fifth Wheel Hitch - Max Trailer Wt. Not Available lbs
Option Weight - Front 0.00 lbs
Maximum Payload Capacity 1686.00 lbs
Curb Weight 5854.00 lbs
Gross Axle Weight Rating 7750.00 lbs
As Spec'd Curb Weight 5854.00 lbs
Gross Vehicle Weight Rating 7540.00 lbs
Option Weight - Rear 0.00 lbs
Curb Weight - Front 2912 lbs
As Spec'd Payload 1686.00 lbs
Gross Combined Wt Rating 12200 lbs
Total Option Weight 0.00 lbs
Base Curb Weight N/A lbs
Curb Weight - Rear 2942 lbs
Front Hip Room 60.2 in
Cab to End of Frame N/A in
Cargo Volume to Seat 3 Not Available ft³
Third Shoulder Room Not Available in
Wheelbase 119.0 in
Side Door Opening Width N/A in
Third Head Room Not Available in
Third Leg Room Not Available in
Third Hip Room Not Available in
Cargo Box (Area) Height N/A in
Overhang, Front 39.2 in
Second Hip Room 59.9 in
Width, Max w/o mirrors 78.8 in
Passenger Capacity 5
Cargo Area Length @ Floor to Console N/A in
Ext'd Cab Cargo Volume N/A ft³
Length, Overall w/rear bumper 206.5 in
Second Leg Room 39.1 in
Step Up Height - Front N/A in
Second Shoulder Room 63.7 in
Ground to Top of Load Floor 34.4 in
Cargo Area Length @ Floor to Seat 3 Not Available in
Rear Door Opening Height 34.6 in
Step Up Height - Side N/A in
Cargo Volume to Seat 2 55.0 ft³
Cargo Volume to Seat 4 Not Available ft³
Ground Clearance, Front 8.7 in
Second Head Room 39.8 in
Tailgate Width N/A in
Cargo Area Length @ Floor to Seat 2 44.4 in
Length, Overall N/A in
Front Shoulder Room 63.2 in
Rear Door Opening Width 56.7 in
Cargo Box Width @ Wheelhousings 49.2 in
Cargo Volume N/A ft³
Front Leg Room 41.1 in
Front Head Room 39.6 in
Cargo Box Width @ Floor N/A in
Cargo Area Width @ Beltline N/A in
Cargo Volume to Seat 1 108.3 ft³
Cargo Box Width @ Top, Rear N/A in
Overhang, Rear w/o bumper N/A in
Ground Clearance, Rear 8.7 in
Height, Overall 77.2 in
Cargo Area Length @ Floor to Seat 1 82.5 in
Side Door Opening Height N/A in
2nd & 3rd row coat hooks Standard
Engine block heater *Standard on non-fleet vehicles in AK, MN, ND, SD, MT, WI & WY* Optional
Rear liftgate w/flip-up glass Standard
Black roof rails w/crossbars Standard
Privacy glass Standard
Painted body-color bumpers Standard
Rear window defogger Standard
Color-keyed floor carpeting Optional
AdvanceTrac w/roll stability control (RSC) Standard
Cloth low back front captains chairs -inc: 6-way pwr driver seat w/adjustable lumbar, 2-way adjustable headrests Standard
Rainlamp feature Standard
LATCH system on rear outboard seats Standard
Safety Canopy Standard
Pwr windows w/driver one-touch-down Standard
Side thorax air bags Standard
Body-color lower body-side cladding Standard
Front/rear door map pockets Standard
Fog lamps Standard
Front/rear stabilizer bars Standard
Complex reflector headlamps -inc: autolamp feature Standard
3.73 Axle ratio Optional
SecuriCode keyless entry keypad Standard
Overhead console -inc: map lights, sunglass holder, conversation mirror Standard
Carpeted floor mats for 1st/2nd row Optional
Child safety locks on rear doors Standard
SecuriLock passive anti-theft system Standard
Chrome rear license plate brow Standard
Color-keyed cloth headliner Standard
Independent multi-link rear suspension Standard
Double wishbone front suspension w/coil-over shock Standard
Pwr door locks w/auto lock Standard
17" x 8.0" aluminum wheels Standard
Manual air conditioning -inc: rear aux climate controls Standard
Variable assist pwr rack & pinion steering -inc: cooler Standard
Cargo area pwr point Standard
Black running boards Optional
AM/FM stereo w/CD player -inc: (6) speakers, 160-watt amp, speed-compensated volume, Radio Data System (RDS), partitioned audio, rear seat controls, MP3 capability Standard
Concealed antenna in RH quarter glass Standard
Beltminder system Standard
Chrome grille Optional
Cargo organizer Standard
Color-keyed leather-wrapped steering wheel w/cruise controls Standard
3rd row 60/40 split bench seat -inc: fold flat feature (vinyl 3rd row when leather seating surface interior is ordered) Optional
SecuriLock remote keyless entry -inc: (2) key fobs, illum entry Standard
Rear window intermittent wiper w/washer Standard
Front skid plates Standard
Speed-sensitive intermittent windshield wipers Standard
Body-color wheel lip molding Standard
Perimeter alarm system Standard
Rear wheel drive Standard
4-wheel pwr disc brakes w/anti-lock & brake assist Standard
Cup holders -inc: (2) front/(2) rear in front console, (2) door trim panels, (3) rear quarter trim panels Optional
Rear seat heat ducts Standard
SOS Post Crash Alert System Standard
Cloth 2nd row 40/20/40 split bench seat -inc: CenterSlide, recline, fold flat feature, carpeted seatbacks Optional
Rear outboard 3-point seat belts Standard
Warning lights -inc: door/liftgate ajar, fasten seat belts, anti-lock brakes, cruise control, engine check, charge system, air bag, high beams, parking brake, TPMS, fuel cap, low fuel/washer fluid, turn signal, OD off, check gauges, suspension system, brake fluid gauge Standard
Assist handles -inc: color-keyed (2) front passengers, (2) second row Standard
Analog instrumentation -inc: voltmeter, oil pressure, water temp, tachometer Standard
Chrome door handles Optional
Pwr accessory delay Standard
Floor console -inc: storage bin, coinholder, rear passenger audio controls, headphone jacks, tissue holder, padded cover, front/rear pwr points, auxiliary HVAC controls, pen holder, auxiliary audio input jack Optional
Front 3-point seat belts -inc: adjustable shoulder harness, load limiting retractors, pretensioners, usage sensors Standard
Personal safety system -inc: crash severity sensor, dual-stage front airbags, airbag position sensor Standard
150-amp alternator Standard
Head restraints at all outboard seating positions Standard
Black instrument panel -inc: cigarette lighter, pwr point w/cap Standard
Integrated Class IV trailer towing receiver -inc: 4-pin connector Standard
Side intrusion door beams Standard
Electrochromic rearview mirror Standard
Lights -inc: glove box, front door approach, rear cargo, 2nd row map lights, illuminated entry, theater lighting Standard
Maintenance-free battery w/battery saver feature Standard
Cruise control Standard
3rd row storage bin Standard
Color-keyed cloth sunvisors -inc: aux visors, dual illuminated mirrors Standard
Tire pressure monitoring system (TPMS) Standard
Black pwr heated mirrors w/security approach lamps Standard
Body-color front/rear fascias Standard
5.4L SOHC 24-valve V8 FFV engine Standard
Tilt steering column Standard
17" spare tire w/steel wheel Standard
6-Speed automatic transmission w/OD Standard
P265/70R17 all-season BSW tires -inc: 17" all-season BSW spare Optional
