2012 GMC Sierra 1500 Hybrid 3HA specs & colors

$40,010
Starting MSRP
Current listing price

Showing the 2012 GMC Sierra 1500 Hybrid 2WD Crew Cab 143.5" 3HA

Shop Now

Key specs

Color options

Interior

Titanium w / Dark Titanium Accents


Ebony w / Ebony Accents


Cashmere


Packages

Specifications

Spare Wheel Material Steel
Spare Wheel Size 17 x -TBD- in
Front Wheel Size 18 x 8.0 in
Rear Wheel Material Aluminum
Front Wheel Material Aluminum
Rear Wheel Size 18 x 8.0 in

Maximum Alternator Capacity (amps) Not Available
Cold Cranking Amps @ 0° F (Primary) 600

Engine Oil Cooler Not Available
Engine Type Gas/Electric V8
Displacement 6.0L/366
SAE Net Torque @ RPM 367 @ 4100
SAE Net Horsepower @ RPM 332 @ 5100

Cruising Range - City 520.00 mi
Fuel Economy Est-Combined 21 MPG
Cruising Range - Hwy 598.00 mi
EPA Fuel Economy Est - Hwy 23 MPG
EPA Fuel Economy Est - City 20 MPG
Estimated Battery Range N/A mi

Transfer Case Power Take Off Not Available
Transfer Case Gear Ratio (:1), Low Not Available
Final Drive Axle Ratio (:1) N/A
Transfer Case Model MP3023/4
Second Gear Ratio (:1) 1.70
Third Gear Ratio (:1) 1.00
Drivetrain Rear Wheel Drive
First Gear Ratio (:1) 3.69
Trans Description Cont. Again Not Available
Trans Type 4
Trans Description Cont. Automatic
Transfer Case Gear Ratio (:1), High Not Available
Fourth Gear Ratio (:1) 0.73
Reverse Ratio (:1) 1.70
Trans Power Take Off Not Available

Axle Type - Rear N/A
Suspension Type - Rear 2-Stage Multi-Leaf
Axle Type - Front N/A
Suspension Type - Front Coil-Over-Shock

Frame Type Hydroformed

Disc - Rear (Yes or ) Yes
Drum - Rear (Yes or ) Not Available
Brake ABS System (Second Line) Not Available
Disc - Front (Yes or ) Yes
Brake ABS System 4-Wheel
Rear Brake Rotor Diam x Thickness 13.6 x 0.8 in
Front Brake Rotor Diam x Thickness 13.0 x 1.2 in
Brake Type Pwr

Fuel Tank Capacity, Approx 26.0 gal
Aux Fuel Tank Capacity, Approx Not Available gal

Turning Diameter - Wall to Wall N/A ft
Turning Diameter - Curb to Curb 47.2 ft
Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall N/A

Rear Tire Size P265/65R18
Spare Tire Size N/A
Front Tire Size P265/65R18

Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 915 lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Trailer Wt. 6100 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Maximum Trailering Capacity N/A lbs

Gross Vehicle Weight Rating 7100.00 lbs
Gross Combined Wt Rating 12000 lbs
Base Curb Weight N/A lbs
As Spec'd Curb Weight 5573.00 lbs
Total Option Weight 0.00 lbs
Gross Axle Weight Rating 7600.00 lbs
Curb Weight - Front 3288 lbs
As Spec'd Payload 1527.00 lbs
Maximum Payload Capacity 1527.00 lbs
Option Weight - Rear 0.00 lbs
Curb Weight - Rear 2285 lbs
Curb Weight 5573.00 lbs
Option Weight - Front 0.00 lbs

Length, Overall w/o rear bumper 229.9 in
Length, Overall N/A in
Second Leg Room 38.7 in
Front Hip Room 62.5 in
Height, Overall 73.8 in
Ground Clearance, Rear 12.3 in
Cargo Volume 53.2 ft³
Overhang, Rear w/o bumper 47.2 in
Ground Clearance, Front 9.0 in
Length, Overall w/rear bumper N/A in
Tailgate Width 61.6 in
Ground to Top of Load Floor 32.9 in
Cargo Box Width @ Top, Rear N/A in
Cargo Box Width @ Wheelhousings 50.6 in
Cargo Box Length @ Floor 69.3 in
Second Head Room 40.6 in
Cab to End of Frame N/A in
Wheelbase 143.5 in
Cargo Box (Area) Height 21.0 in
Second Shoulder Room 65.2 in
Passenger Capacity 6
Cargo Box Width @ Floor 62.5 in
Front Head Room 41.5 in
Second Hip Room 65.5 in
Overhang, Front 39.4 in
Ext'd Cab Cargo Volume Not Available ft³
Front Shoulder Room 65.2 in
Width, Max w/o mirrors 80.0 in
Front Leg Room 41.3 in

Battery, heavy-duty 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power Standard
Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger manual reclining, center fold-down armrest with storage, lockable storage compartment in seat cushion (includes auxiliary power outlet), adjustable outboard head restraints and storage pockets Standard
SiriusXM Satellite Radio is standard on nearly all 2012 GM models. Enjoy a 3-month trial to the 'XM Select' package, with over 170 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. And now add premium channels to your trial at no-cost. Welcome to the world of satellite radio. (Requires a subscription sold separately by SiriusXM after the trial period. If you decide to continue your service at the end of your subscription, service will automatically renew and bill, at the rates in effect at the time of renewal, until you call SiriusXM at 1-866-635-2349 to cancel. See our Customer Agreement for complete terms at www.siriusxm.com. Available only to those at least 18 and older in the 48 contiguous USA and D.C.) Standard
OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance including Stolen Vehicle Slowdown and Remote Ignition Block, Remote Door Unlock, Turn-by-Turn Navigation with Destination Download (requires navigation radio) and OnStar eNav (where available), OnStar Vehicle Diagnostics, Roadside Assistance, Remote Horn and Lights, and Hands Free Calling. (Visit onstar.com for details and system limitations.) Standard
Tires, P265/65R18 all-season, blackwall Standard
Seat adjuster, manual lumbar control on the driver-side Standard
Audio system, AM/FM stereo with MP3 compatible CD player seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume and TheftLock Standard
Mirrors, outside heated power-adjustable Black, manual-folding Standard
Suspension, front independent, coil over shock Standard
Engine, Vortec 6.0L Variable Valve Timing V8 SFI Hybrid, LIVC with Active Fuel Management and late intake valve closing, aluminum (332 hp [247.5 kW] @ 5100 rpm, 367 lb-ft of torque [495.4 N-m] @ 4100 rpm) Standard
Air bags, frontal, driver and right-front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your child's age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the Owner's Manual and child safety seat instructions for more safety information.) Standard
Brakes, 4-wheel antilock, 4-wheel disc electro-hydraulic power with StabiliTrak, regenerative system Standard
Tailgate, locking Standard
Bumper, front chrome (Includes body-color bumper top caps. Chrome bumper replaced with Black bumper bar when SEO (1TR) Base Appearance for Hybrid is ordered.) Standard
Wipers, front intermittent wet-arm with pulse washers. Standard
Daytime Running Lamps, with automatic exterior lamp control. Standard
StabiliTrak, stability control system with Proactive Roll Avoidance and traction control Standard
Automatic Crash Response (Deleted when (UE0) OnStar delete is ordered.) Standard
Power outlets 2 auxiliary instrument panel-mounted with covers, 12-volt Standard
Pickup box, Wideside Standard
Steering wheel, leather-wrapped with theft-deterrent locking feature Standard
Driver Information Center with odometer, trip odometer and message center (monitors numerous systems depending on vehicle equipment level including low fuel, turn signal "on", transmission temperature and oil change notification) (Includes 8-point compass and outside temperature.) Standard
Air bags, seat-mounted side-impact, driver and right-front passenger for thorax and pelvic protection (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat outboard occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your child's age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. See the Owner's Manual and child safety seat instructions for more safety information.) Standard
Visors, driver and front passenger, sliding with clip and illuminated vanity mirror on driver and passenger-side, Opal Gray-colored Standard
Bluetooth for phone personal cell phone connectivity to vehicle audio system (Requires OnStar hardware (UE1), but subscription to OnStar services not required for operation.) Standard
Hybrid Propulsion Electric, 2-mode Standard
Rear wheel drive Standard
Alternator delete Standard
Door locks, power Standard
GVWR, 7100 lbs. (3221 kg) (Requires TC10543 models.) Standard
Floor covering, color-keyed carpeting with rubberized vinyl floor mats (includes rear floor mats) Standard
Tailgate, EZ-Lift Standard
OnStar Turn-by-Turn Navigation (Deleted when (UE0) OnStar delete is ordered.) Standard
Steering wheel controls, mounted audio controls Standard
Cruise control, electronic with set and resume speed, located on steering wheel Standard
Wheels, 4 - 18" x 8" (45.7 cm x 20.3 cm) chrome-clad aluminum (spare wheel will not cosmetically match the other 4 wheels) Standard
Door locks, rear child security Standard
Air bags, head curtain side-impact front and rear outboard seating positions with rollover sensor (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat outboard occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your child's age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat in the appropriate infant, child or booster seat. See the Owner's Manual and child safety seat instructions for more safety information.) Standard
Transmission, 2-mode strong hybrid, automatic, electronic. Standard
Bumper, rear chrome, step-style with pad Standard
Steering column, Tilt-Wheel, adjustable with brake/transmission shift interlock. Standard
Stolen Vehicle Assistance (Deleted when (UE0) OnStar delete is ordered.) Standard
Grille, chrome surround (Chrome grille replaced with black surround grille when SEO (1TR) Base Appearance for Hybrid is ordered.) Standard
Spare tire lock keyed cylinder lock that utilizes same key as ignition and door Standard
LPO, Tonneau cover, soft (dealer installed) with integrated support bows that roll up with the cover and can be stowed in behind the cab Standard
Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass) (Includes rear and rear quarter windows.) Standard
Moldings, bodyside, body-colored Standard
Audio system feature, speaker system includes 6 speakers Standard
Seat trim, Premium Cloth Standard
Differential, heavy-duty automatic locking rear Standard
Wheel, 17" (43.2 cm) steel spare (spare wheel will not cosmetically match the other 4 wheels) (Requires TC10543 models.) Standard
Seat, rear full-width folding bench, 3-passenger (includes child seat top tether anchor) Standard
Suspension Package, Handling/Trailering, heavy-duty includes 46 mm piston monotube shocks and 36mm front stabilizer bar Standard
Suspension, rear 2-stage multi-leaf springs semi-elliptic Standard
Rear axle, 3.08 ratio Standard
Trailering equipment, heavy-duty includes trailering hitch platform and 2-inch receiver, 7-wire harness (harness includes wires for: park lamps, backup lamps, right turn, left turn, electric brake lead, battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector and wiring harness for aftermarket trailer brake controller (located in the instrument panel harness) Standard
Windows, power with driver Express-Down Standard
Air conditioning dual-zone automatic climate control with individual climate settings for driver and right-front passenger Standard
Remote vehicle starter prep package includes Remote Keyless Entry with 2 transmitters, panic button and content theft alarm (To enable remote start capability, new key fobs and vehicle reprogramming are required. Please see dealer for details.) Standard
Tire Pressure Monitor System (does not apply to spare tire) Standard
Mirror, inside rearview manual day/night Standard
Steering, power, rack-and-pinion Standard
