2003 GMC Sierra 3500 SLE specs & colors
Regular Cab Chassis-Cab
Change trim
MSRP
- Reg Cab 137.0" WB, 60.4" CA SLE $26,668
- Reg Cab 161.5" WB, 84.9" CA SLE $26,743
- Reg Cab 133" WB 4WD DRW $28,712
- Ext Cab 157.5" WB DRW $29,400
- Ext Cab 161.5" WB, 60.4" CA SLE $29,415
- Reg Cab 137.0" WB, 60.4" CA 4WD SLE $29,825
- Reg Cab 161.5" WB, 84.9" CA 4WD SLE $29,930
- Reg Cab 133" WB 4WD DRW SLE $30,730
- Crew Cab 167" WB DRW $31,400
- Ext Cab 157.5" WB DRW SLE $31,565
- Ext Cab 157.5" WB DRW SLT $31,565
- Ext Cab 157.5" WB 4WD DRW $32,452
- Ext Cab 161.5" WB, 60.4" CA 4WD SLE $32,632
- Crew Cab 167" WB DRW SLE $33,500
- Crew Cab 167" WB DRW SLT $33,500
- Crew Cab 167" WB 4WD DRW $34,452
- Ext Cab 157.5" WB 4WD DRW SLE $34,650
- Ext Cab 157.5" WB 4WD DRW SLT $34,650
- Crew Cab 167" WB 4WD DRW SLT $36,550
- Crew Cab 167" WB 4WD DRW SLE $36,550
$26,668
Starting MSRP
Current listing price
Current listing price
Showing the 2003 GMC Sierra 3500 Reg Cab 137.0" WB, 60.4" CA SLE
Shop NowKey specs
Color options
Interior
Taupe
Sage
Packages
$0
Starting MSRP
- -inc:
Specifications
| Front Wheel Size | 16 x 6.5 in |
| Spare Wheel Material | Not Available |
| Front Wheel Material | Steel |
| Spare Wheel Size | Not Available in |
| Rear Wheel Material | Steel |
| Rear Wheel Size | 16 x 6.5 in |
| Maximum Alternator Capacity (amps) | 105 |
| Cold Cranking Amps @ 0° F (Primary) | 600 |
| Engine Oil Cooler | Yes |
| SAE Net Torque @ RPM | 360 @ 4000 |
| SAE Net Horsepower @ RPM | 300 @ 4400 |
| Engine Type | Gas V8 |
| Displacement | 6.0L/366 |
| Cruising Range - City | 0.00 mi |
| Estimated Battery Range | N/A mi |
| Cruising Range - Hwy | 0.00 mi |
| Fuel Economy Est-Combined | N/A MPG |
| EPA Fuel Economy Est - Hwy | Not Available MPG |
| EPA Fuel Economy Est - City | Not Available MPG |
| Third Gear Ratio (:1) | 1.67 |
| Trans Power Take Off | RH |
| Trans Description Cont. Again | Not Available |
| Reverse Ratio (:1) | 5.61 |
| Second Gear Ratio (:1) | 3.04 |
| Final Drive Axle Ratio (:1) | N/A |
| Fourth Gear Ratio (:1) | 1.00 |
| Transfer Case Gear Ratio (:1), Low | Not Available |
| Fifth Gear Ratio (:1) | 0.75 |
| Drivetrain | Rear Wheel Drive |
| Transfer Case Gear Ratio (:1), High | Not Available |
| Trans Type | 5 |
| Trans Description Cont. | Manual w/OD |
| Transfer Case Power Take Off | Not Available |
| Transfer Case Model | Not Available |
| First Gear Ratio (:1) | 5.61 |
| Axle Type - Front | Independent |
| Suspension Type - Front | Indep Torsion Bar |
| Suspension Type - Rear | 2-Stage Multi-Leaf |
| Axle Type - Rear | Full Floating |
| Frame Type | Ladder |
| Brake ABS System | 4-Wheel |
| Brake Type | Pwr |
| Rear Brake Rotor Diam x Thickness | 12.8 x 1.2 in |
| Drum - Rear (Yes or ) | Not Available |
| Brake ABS System (Second Line) | Not Available |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 12.8 x 1.5 in |
| Disc - Front (Yes or ) | Yes |
| Fuel Tank Capacity, Approx | 27 gal |
| Aux Fuel Tank Capacity, Approx | 23 gal |
| Turning Diameter - Wall to Wall | N/A ft |
| Steering Ratio (:1), Overall | N/A |
| Steering Type | Pwr |
| Turning Diameter - Curb to Curb | 44.9 ft |
| Front Tire Size | LT215/85R16D |
| Rear Tire Size | LT215/85R16D |
| Spare Tire Size | Not Available |
| Fifth Wheel Hitch - Max Trailer Wt. | Not Available lbs |
| Wt Distributing Hitch - Max Trailer Wt. | Not Available lbs |
| Dead Weight Hitch - Max Tongue Wt. | Not Available lbs |
| Maximum Trailering Capacity | N/A lbs |
| Dead Weight Hitch - Max Trailer Wt. | Not Available lbs |
| Fifth Wheel Hitch - Max Tongue Wt. | Not Available lbs |
| Wt Distributing Hitch - Max Tongue Wt. | Not Available lbs |
| Gross Axle Weight Rating | 13050.00 lbs |
| Gross Vehicle Weight Rating | 11,400 lbs |
| Maximum Payload Capacity | N/A lbs |
| Base Curb Weight | N/A lbs |
| Curb Weight - Front | 2917 lbs |
| Gross Combined Wt Rating | 16000 lbs |
| Total Option Weight | 0.00 lbs |
| Curb Weight | 5234.00 lbs |
| Option Weight - Front | 0.00 lbs |
| As Spec'd Curb Weight | 5234.00 lbs |
| Curb Weight - Rear | 2317 lbs |
| Option Weight - Rear | 0.00 lbs |
| As Spec'd Payload | N/A lbs |
| Wheelbase | 137.0 in |
| Cargo Box (Area) Height | N/A in |
| Cargo Box Width @ Wheelhousings | N/A in |
| Length, Overall w/rear bumper | N/A in |
| Ext'd Cab Cargo Volume | N/A ft³ |
| Second Hip Room | N/A in |
| Front Head Room | 41.1 in |
| Front Shoulder Room | 65.7 in |
| Height, Overall | 76.0 in |
| Width, Max w/o mirrors | 86.0 in |
| Length, Overall | N/A in |
| Ground Clearance, Rear | N/A in |
| Length, Overall w/o rear bumper | 225.0 in |
| Second Head Room | N/A in |
| Front Hip Room | 61.5 in |
| Cargo Box Width @ Top, Rear | N/A in |
| Cab to End of Frame | 111.4 in |
| Cargo Box Width @ Floor | N/A in |
| Ground Clearance, Front | N/A in |
| Ground to Top of Load Floor | Not Available in |
| Passenger Capacity | 3 |
| Overhang, Rear w/o bumper | 51.0 in |
| Overhang, Front | 37.0 in |
| Cargo Volume | N/A ft³ |
| Second Shoulder Room | N/A in |
| Tailgate Width | N/A in |
| Front Leg Room | 41.3 in |
| Second Leg Room | N/A in |
| Wipers, intermittent, front wet-arm w/pulse washers | Standard |
| Air bags, frontal, driver & right front passenger-inc: passenger side deactivation switch | Standard |
| Warning tones, headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on | Standard |
| Front 27 gallon/rear 23 gallon fuel tanks | Standard |
| Door locks, pwr programmable, that unlock w/removal of ignition key, & lockout protection | Optional |
| Bumper, front, chrome, w/body-color lower | Optional |
| Wheel flares, front only | Standard |
| Battery, heavy-duty, 600 cold-cranking amps-inc: rundown protection & retained accessory pwr | Standard |
| Suspension, front, independent torsion bar, & stabilizer bar | Standard |
| Daytime running lamps-inc: automatic exterior lamp control | Standard |
| Cupholders, front | Standard |
| Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield, driver & front passenger) | Optional |
| Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches & door handle-activated illuminated entry | Standard |
| Headliner, Shale-colored cloth, w/matching retainer moldings | Standard |
| Defogger, rear-window, electric | Optional |
| Steering wheel, leather-wrapped rim, Black, steel sleeve-inc: theft-deterrent locking feature | Optional |
| GVWR, 11,400 lbs. (5171 kg) | Standard |
| Keyless entry, remote-inc: 2 transmitters, panic button & content theft alarm | Optional |
| Brakes, 4-wheel antilock, 4-wheel disc | Standard |
| Frame, ladder-type | Standard |
| Visors, padded, Shale-colored, driver & passenger side w/cloth trim, extenders, pocket on driver side & vanity mirror on passenger side | Standard |
| Rear axle, 66" (167.6 cm) wide | Standard |
| Theft-deterrent system, PASSLock II | Standard |
| Recovery hooks, 2 front, frame-mounted | Standard |
| Lamps, dual cargo area lamps | Standard |
| Headlamps, dual halogen composite-inc: flash-to-pass feature & automatic lamp control | Standard |
| Transmission shift interlock | Standard |
| Suspension Package, Handling/Trailering, heavy-duty | Standard |
| Floor covering, color-keyed carpeting | Standard |
| Rear wheel drive | Standard |
| Transmission, 5-speed manual, w/overdrive | Standard |
| Lamps, 5 amber roof marker | Standard |
| Body, Chassis Cab | Standard |
| Head restraints, outboard seats positions | Standard |
| Windows, pwr-inc: driver express-down | Optional |
| Instrumentation, analog-inc: speedometer, odometer w/trip odometer, fuel level, voltmeter, engine temperature, oil pressure & tachometer | Standard |
| Exhaust, aluminized stainless-steel muffler & tailpipe | Standard |
| Suspension, rear, semi-elliptic 2-stage multi-leaf springs | Standard |
| Tools, mechanical jack & wheel wrench, gloves, courtesy mat, spare tire assist hook, floor-mounted in back of cab | Standard |
| Engine, Vortec 6000 V8 SFI (300 HP [223.8 kW] @ 4400 rpm, 360 lb.-ft. [486.6 N-m] @ 4000 rpm) | Standard |
| Brakes, 4-wheel antilock, 4-wheel disc | Standard |
| Tire carrier, outside spare, winch-type mounted under frame at rear | Standard |
| Tires, LT215/85R16D, all-season, blackwall | Standard |
| Door trim, side reflectors w/lights | Optional |
| Wheels, 6 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug steel, w/bright metal rings & chrome center caps & steel spare | Standard |
| Manual lap/shoulder safety belts, outboard seat positions | Standard |
| Pwr outlets, auxiliary, covered, 2 dash-mounted, 12-volt | Standard |
| Side guard door beams | Standard |
| Floormats, front, color-keyed rubberized vinyl, removable | Standard |
| Cooling, external engine oil cooler, heavy-duty air-to-oil, integral to driver side of radiator | Standard |
| Coat hook, driver side | Standard |
| Sound system, ETR AM/FM stereo w/CD player-inc: seek-and-scan, digital clock, auto-tone control, speed-compensated volume, Radio Data System (RDS) & 4-speakers | Optional |
| Seats, front Custom Cloth 40/20/40 split-bench, 3-passenger, driver & passenger manual reclining, center fold-down armrest w/storage, adjustable outboard head restraints | Standard |
| Steering column, Tilt-Wheel, adjustable-inc: brake/transmission shift interlock | Standard |
| Rear axle, 4.10 ratio | Standard |
| Paint, solid | Standard |
| Grille, chrome surround | Optional |
| Console, overhead mini-inc: map lights | Optional |
| Transmission shift interlock | Standard |
| Air dam, Gray | Standard |
| Mirrors, outside rearview, manual folding, pwr, heated, Black | Optional |
| Cruise control, electronic w/set & resume speed-inc: telltale in instrument panel cluster | Optional |
| Steering, pwr | Standard |
| Air conditioning, dual-zone, manual, individual climate settings for driver & right front passenger | Standard |
| Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass & outside temperature indicator | Optional |
| Alternator, 105 amps | Standard |
| Cigarette lighter, on instrument panel | Standard |
| Daytime running lamps-inc: automatic exterior lamp control | Standard |
| Manual lap safety belts, center seat position | Standard |
| Assist handle, front passenger, dash-mounted | Standard |
| Driver Information Center-inc: trip odometer & message center (monitors numerous systems depending on vehicle equipment level-inc: low fuel, turn signal "on", transmission temp, low engine coolant level & oil change notification) | Standard |
