2026 GMC Terrain FWD Elevation specs & colors
Sport Utility
MSRP
- FWD 4dr Elevation
- $30,200
- AWD 4dr Elevation
- $32,200
- AWD 4dr AT4
- $39,400
- AWD 4dr Denali
- $41,900
Key specs
-
4-door -
5 seats -
175.0-hp, 1.5-liter, 4 Cylinder Engine (Gasoline Fuel) -
27 combined MPG -
181" length, - TBD -" height -
Front Wheel Drive
Color options
Exterior
Moonstone Gray Metallic
Interior
Black
Gideon Gray / After Dark
Jet Black
Packages
- Elevation Preferred Equipment Group
$0
Starting MSRP
- includes standard equipment
Specifications
Highlights
- Engine Type
-
Turbocharged Gas I4
- MPG
-
26 City / 28 Hwy
- Horsepower
-
175 hp
- Seating Capacity
-
5
Brakes
- Disc - Rear (Yes or )
-
Yes
- Rear Brake Rotor Diam x Thickness
-
16 x -TBD- in
- Drum - Rear (Yes or )
-
N/A
- Disc - Front (Yes or )
-
Yes
- Front Brake Rotor Diam x Thickness
-
16 x -TBD- in
- Brake Type
-
Pwr
- Brake ABS System
-
4-Wheel
- Brake ABS System (Second Line)
-
N/A
Electrical
- Cold Cranking Amps @ 0° F (Primary)
-
760
- Maximum Alternator Capacity (amps)
-
130
Engine
- SAE Net Horsepower @ RPM
-
175 @ 5600
- Displacement
-
1.5L/90
- SAE Net Torque @ RPM
-
184 @ 1750-4800
- Engine Type
-
Turbocharged Gas I4
- Transmission Options
-
CVT Transmission
A/T
- MPG
-
26 City / 28 Hwy
- Total Cooling System Capacity
-
N/A
Measurements
- Track Width, Front
-
64 in
- Rear Door Opening Height
-
N/A
- Liftover Height
-
N/A
- Passenger Volume
-
N/A
- Cargo Volume to Seat 1
-
64 ft³
- Passenger Capacity
-
5
- Cargo Volume to Seat 3
-
N/A
- Second Leg Room
-
40 in
- Wheelbase
-
107 in
- Cargo Area Width @ Beltline
-
N/A
- Front Head Room
-
41 in
- Cargo Area Length @ Floor to Seat 2
-
N/A
- Width, Max w/o mirrors
-
75 in
- Height, Overall
-
66 in
- Rear Door Opening Width
-
N/A
- Length, Overall
-
181 in
- Front Hip Room
-
55 in
- Track Width, Rear
-
64 in
- Cargo Box Width @ Wheelhousings
-
N/A
- Front Shoulder Room
-
58 in
- Cargo Area Length @ Floor to Seat 1
-
N/A
- Second Head Room
-
39 in
- Second Shoulder Room
-
56 in
- Second Hip Room
-
51 in
- Front Leg Room
-
44 in
- Min Ground Clearance
-
6 in
- Cargo Volume to Seat 2
-
30 ft³
- Cargo Box (Area) Height
-
N/A
- Cargo Area Length @ Floor to Seat 3
-
N/A
Safety
- Navigation System
-
Standard
- Rear Cross Traffic Alert
-
Standard
- Backup Camera
-
Standard
- Lane Departure Warning
-
Standard
Steering
- Lock to Lock Turns (Steering)
-
N/A
- Steering Type
-
Electric Rack & Pinion
- Turning Diameter - Wall to Wall
-
N/A
- Turning Diameter - Curb to Curb
-
37 ft
- Steering Ratio (:1), Overall
-
N/A
Suspension
- Suspension Type - Rear (Cont.)
-
N/A
- Suspension Type - Rear
-
4-Link
- Suspension Type - Front (Cont.)
-
N/A
- Suspension Type - Front
-
McPherson Strut
Tires & Wheels
- Front Tire Size
-
235/65R17
- Front Wheel Material
-
Aluminum
- Spare Wheel Material
-
Steel
- Rear Wheel Size
-
17 x -TBD- in
- Rear Wheel Material
-
Aluminum
- Spare Tire Size
-
T125/70R17
- Spare Wheel Size
-
17 x -TBD- in
- Front Wheel Size
-
17 x -TBD- in
- Rear Tire Size
-
235/65R17
Weight & Capacity
- Curb Weight
-
N/A
- Dead Weight Hitch - Max Trailer Wt.
-
800 lbs
- Dead Weight Hitch - Max Tongue Wt.
-
80 lbs
- Base Curb Weight
-
3,446 lbs
- Aux Fuel Tank Capacity, Approx
-
N/A
- Wt Distributing Hitch - Max Tongue Wt.
-
80 lbs
- Fuel Tank Capacity, Approx
-
15 gal
- Wt Distributing Hitch - Max Trailer Wt.
-
800 lbs
- Maximum Trailering Capacity
-
N/A
- Curb Weight - Rear
-
N/A
- Maximum Payload Capacity
-
N/A
- Curb Weight - Front
-
N/A
- Total Option Weight
-
0 lbs
