2009 Honda Pilot LX specs & colors

Starting MSRP
Current listing price
2009 Honda Pilot LX

Showing the 2009 Honda Pilot 2WD 4dr LX

Shop Now

Key specs

Color options


Vanilla / Blue






EPA Classification 2WD Sport Utility Vehicle
Front Wheel Size 17 x -TBD- in
Rear Wheel Size 17 x -TBD- in
Spare Wheel Size Compact in
Rear Wheel Material Steel
Spare Wheel Material Steel
Front Wheel Material Steel
Maximum Alternator Capacity (amps) N/A
Cold Cranking Amps @ 0° F (Primary) N/A
Displacement 3.5L/212
Engine Type Gas V6
SAE Net Horsepower @ RPM 250 @ 5700
SAE Net Torque @ RPM 253 @ 4800
EPA MPG Equivalent - City N/A
EPA Fuel Economy Est - City 17 MPG
Estimated Battery Range N/A mi
Cruising Range - City 357.00 mi
EPA Fuel Economy Est - Hwy 23 MPG
EPA MPG Equivalent - Combined N/A
Fuel Economy Est-Combined 19 MPG
Cruising Range - Hwy 483.00 mi
EPA MPG Equivalent - Hwy N/A
Fifth Gear Ratio (:1) 0.61
Drivetrain Front Wheel Drive
Trans Description Cont. Automatic w/OD
Final Drive Axle Ratio (:1) 4.31
Reverse Ratio (:1) 1.89
Fourth Gear Ratio (:1) 0.77
Third Gear Ratio (:1) 1.07
First Gear Ratio (:1) 2.70
Second Gear Ratio (:1) 1.61
Trans Description Cont. Again Not Available
Trans Type 5
Suspension Type - Rear Multi-link
Suspension Type - Rear (Cont.) w/Trailing Arms
Suspension Type - Front (Cont.) Not Available
Suspension Type - Front MacPherson Strut
Brake ABS System (Second Line) N/A
Front Brake Rotor Diam x Thickness 13.0 x -TBD- in
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Brake ABS System 4-Wheel
Brake Type Pwr
Rear Brake Rotor Diam x Thickness 13.1 x -TBD- in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 21.0 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Pwr Rack & Pinion
Turning Diameter - Curb to Curb 38.6 ft
Turning Diameter - Wall to Wall N/A ft
Steering Ratio (:1), Overall 19.0
Lock to Lock Turns (Steering) 3.69
Front Tire Size P245/65R17
Rear Tire Size P245/65R17
Spare Tire Size Compact
Dead Weight Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Tongue Wt. 350 lbs
Wt Distributing Hitch - Max Trailer Wt. 3500 lbs
Wt Distributing Hitch - Max Tongue Wt. 350 lbs
Base Curb Weight 4319 lbs
Width, Max w/o mirrors 78.5 in
Third Hip Room 48.4 in
Trunk Volume N/A ft³
Passenger Volume 153.7 ft³
Wheelbase 109.2 in
Second Hip Room 56.9 in
Second Shoulder Room 62.2 in
Rear Door Opening Width N/A in
Cargo Volume to Seat 2 47.7 ft³
Third Head Room 38.2 in
Passenger Capacity 8
Third Shoulder Room 58.9 in
Front Hip Room 58.6 in
Cargo Area Width @ Beltline N/A in
Cargo Box (Area) Height Not Available in
Cargo Volume to Seat 1 87.0 ft³
Liftover Height Not Available in
Min Ground Clearance 8.0 in
Second Head Room 39.8 in
Cargo Area Length @ Floor to Seat 2 N/A in
Cargo Area Length @ Floor to Seat 1 N/A in
Height, Overall 71.0 in
Cargo Box Width @ Wheelhousings Not Available in
Front Head Room 40.0 in
Second Leg Room 38.5 in
Track Width, Rear 67.5 in
Length, Overall 190.9 in
Rear Door Opening Height N/A in
Track Width, Front 67.7 in
Cargo Volume to Seat 3 18.0 ft³
Front Leg Room 41.4 in
Front Shoulder Room 61.5 in
Cargo Area Length @ Floor to Seat 3 N/A in
Third Leg Room 32.1 in
Maintenance Minder system Standard
3rd row child seat tether anchors Standard
Steering wheel-mounted illuminated cruise controls Standard
(12) cup holders Standard
Pwr ventilated front/solid rear disc brakes Standard
3rd row 60/40 split flat-folding bench seat Standard
Child-proof rear door locks Standard
8-passenger seating Standard
Multifunctional center console Standard
Side curtain airbags on all rows w/rollover sensor Standard
Integrated glass antenna Standard
Intermittent rear window wiper/washer Standard
Front & rear splash guards Standard
Remote keyless entry Standard
Rear window defroster w/timer Standard
Unit-body construction Standard
Drive-by-wire throttle Standard
MacPherson strut front suspension Standard
Heavy duty pwr steering fluid cooler Standard
Brake assist Standard
Upper & lower front row seatback pockets Standard
Variable intermittent windshield wipers Standard
Map lights on all rows Standard
Rear seat heater ducts Standard
Daytime running lights Standard
2nd & 3rd row 3-point seat belts Standard
Tailgate w/lift-up glass hatch Standard
Sunglasses holder Standard
AM/FM stereo w/CD player -inc: (6) speakers, subwoofer, MP3/WMA playback, auxiliary input jack, radio data system, speed-sensitive volume control Standard
3.5L SOHC MPFI 24-valve i-VTEC V6 engine Standard
Front & rear stabilizer bars Standard
Front 3-point seat belts -inc: automatic tensioning system, adjustable anchors Standard
2nd & 3rd row lower anchors & tethers for children (LATCH) Standard
P245/65R17 all-season tires Standard
Pwr door & tailgate locks Standard
Dual illuminated visor vanity mirrors Standard
Tilt & telescoping steering column Standard
Black body side molding Standard
Multi-reflector halogen headlights w/auto-on/off Standard
Compact spare tire Standard
Variable pwr rack & pinion steering Standard
Tire pressure monitoring system w/location indicators Standard
Hill start assist Standard
2nd row 60/40 split reclining, sliding, flat-folding bench seat Standard
Dual front dual-stage, dual-threshold airbags Standard
Variable Cylinder Management (VCM) Standard
Heavy-duty automatic transmission fluid cooler Standard
Immobilizer theft-deterrent system Standard
Pwr mirrors Standard
Front seat adjustable active head restraints Standard
Courtesy door lights Standard
Front wheel drive Standard
4-wheel anti-lock braking system (ABS) w/electronic brake distribution (EBD) Standard
Vehicle Stability Assist (VSA) w/traction control Standard
Floor mats Standard
(3) 12V auxiliary pwr outlets Standard
Instrumentation -inc: digital odometer, (2) digital trip meters, trip computer, miles-to-empty indicator, compass Standard
Integrated class III trailer hitch w/trailer harness pre-wiring Standard
Multi-link rear suspension w/trailing arms Standard
Pwr windows w/dual front auto-up/down Standard
Warning lights -inc: low-fuel, low-oil pressure, door/tailgate open, passenger airbags status, vehicle stability assist Standard
Advanced Compatibility Engineering (ACE) body structure Standard
Heat-rejecting green-tinted glass Standard
Active Noise Cancellation (ANC) Standard
5-speed automatic transmission w/OD Standard
Front & rear air conditioning w/air-filtration system Standard
Side-impact door beams Standard
Cruise control Standard
Dual front side-impact airbags w/passenger-side occupant position detection system Standard
Cloth front bucket seats -inc: 6-way manual seat adjusters Standard
17" steel wheels Standard
Sliding sunvisor extensions Standard
Rear privacy glass Standard
Head restraints at all seating positions Standard
Remote fuel filler door release Standard
Ambient console lighting Standard
Active control engine mount system (ACM) Standard
Rear hidden storage compartment Standard
Cargo area -inc: cargo net, cargo light, (4) tie-down anchors, bag hooks Standard
