2003 Hummer H1 specs & colors
Sport Utility
$105,160
Starting MSRP
Current listing price
Current listing price
Showing the 2003 Hummer H1 4-Passenger Open Top Hard Doors
Shop NowKey specs
Color options
Interior
Cloud Gray
Packages
Specifications
| Rear Door Type | N/A |
| Spare Wheel Material | Not Available |
| Rear Wheel Material | Aluminum |
| Spare Wheel Size | Not Available in |
| Front Wheel Material | Aluminum |
| Rear Wheel Size | 17 x -TBD- in |
| Front Wheel Size | 17 x -TBD- in |
| Maximum Alternator Capacity (amps) | 124 |
| Cold Cranking Amps @ 0° F (Primary) | 600 |
| Displacement | 6.5L/396 |
| SAE Net Torque @ RPM | 430 @ 1800 |
| Engine Oil Cooler | Yes |
| SAE Net Horsepower @ RPM | 195 @ 3400 |
| Engine Type | Turbo Diesel V8 |
| EPA Fuel Economy Est - Hwy | N/A MPG |
| Cruising Range - City | N/A mi |
| Estimated Battery Range | N/A mi |
| EPA Fuel Economy Est - City | N/A MPG |
| Cruising Range - Hwy | N/A mi |
| Fuel Economy Est-Combined | N/A MPG |
| Drivetrain | 4-Wheel Drive |
| Trans Power Take Off | Not Available |
| First Gear Ratio (:1) | 2.48 |
| Transfer Case Power Take Off | Not Available |
| Fourth Gear Ratio (:1) | 0.75 |
| Transfer Case Model | New Venture #242 |
| Second Gear Ratio (:1) | 1.48 |
| Trans Description Cont. | HD Automatic w/OD |
| Final Drive Axle Ratio (:1) | N/A |
| Transfer Case Gear Ratio (:1), Low | 2.72 |
| Trans Type | 4 |
| Transfer Case Gear Ratio (:1), High | 1.00 |
| Trans Description Cont. Again | Not Available |
| Reverse Ratio (:1) | 2.08 |
| Third Gear Ratio (:1) | 1.00 |
| Suspension Type - Rear | Coil Spring |
| Axle Type - Front | Indep Dbl A-Frame |
| Suspension Type - Front | Coil Spring |
| Axle Type - Rear | Indep Dbl A-Frame |
| Frame Type | Box Ladder |
| Side Door Type | N/A |
| Brake ABS System (Second Line) | Not Available |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 10.5 x -TBD- in |
| Disc - Front (Yes or ) | Yes |
| Drum - Rear (Yes or ) | Not Available |
| Rear Brake Rotor Diam x Thickness | 10.5 x -TBD- in |
| Brake ABS System | Yes |
| Brake Type | Pwr |
| Fuel Tank Capacity, Approx | 25 gal |
| Aux Fuel Tank Capacity, Approx | 17 gal |
| Steering Type | Power Variable Ratio |
| Turning Diameter - Curb to Curb | N/A ft |
| Steering Ratio (:1), Overall | N/A |
| Turning Diameter - Wall to Wall | N/A ft |
| Rear Tire Size | 37X12.5R17 |
| Spare Tire Size | Not Available |
| Front Tire Size | 37X12.5R17 |
| Wt Distributing Hitch - Max Tongue Wt. | Not Available lbs |
| Fifth Wheel Hitch - Max Tongue Wt. | N/A lbs |
| Dead Weight Hitch - Max Trailer Wt. | 5000 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | Not Available lbs |
| Maximum Trailering Capacity | N/A lbs |
| Fifth Wheel Hitch - Max Trailer Wt. | N/A lbs |
| Dead Weight Hitch - Max Tongue Wt. | 500 lbs |
| Gross Combined Wt Rating | 15,300 lbs |
| Gross Axle Weight Rating | 10900.00 lbs |
| Total Option Weight | 0.00 lbs |
| Maximum Payload Capacity | N/A lbs |
| Curb Weight - Front | 3748 lbs |
| Option Weight - Rear | 0.00 lbs |
| Option Weight - Front | 0.00 lbs |
| As Spec'd Curb Weight | 6814.00 lbs |
| As Spec'd Payload | N/A lbs |
| Curb Weight | 6814.00 lbs |
| Gross Vehicle Weight Rating | 10,300 lbs |
| Base Curb Weight | N/A lbs |
| Curb Weight - Rear | 3066 lbs |
| Cargo Volume to Seat 3 | N/A ft³ |
| Length, Overall w/rear bumper | 184.5 in |
| Cargo Area Length @ Floor to Seat 2 | 44.0 in |
| Cargo Area Length @ Floor to Console | N/A in |
| Tailgate Width | N/A in |
| Second Leg Room | 29.9 in |
| Length, Overall | N/A in |
| Rear Door Opening Height | N/A in |
| Cargo Box Width @ Top, Rear | N/A in |
| Front Leg Room | 44.1 in |
| Cargo Area Length @ Floor to Seat 1 | 76.5 in |
| Step Up Height - Front | N/A in |
| Cargo Volume | N/A ft³ |
| Width, Max w/o mirrors | 86.5 in |
| Passenger Capacity | 4 |
| Overhang, Rear w/o bumper | N/A in |
| Cargo Area Length @ Floor to Seat 3 | Not Available in |
| Second Hip Room | 22.4 in |
| Height, Overall | 77.0 in |
| Cargo Box (Area) Height | N/A in |
| Ext'd Cab Cargo Volume | N/A ft³ |
| Cargo Volume to Seat 2 | N/A ft³ |
| Step Up Height - Side | N/A in |
| Ground to Top of Load Floor | N/A in |
| Side Door Opening Height | N/A in |
| Cargo Box Width @ Floor | N/A in |
| Second Head Room | 42.9 in |
| Cargo Box Width @ Wheelhousings | N/A in |
| Cargo Volume to Seat 4 | N/A ft³ |
| Wheelbase | 130.0 in |
| Cargo Area Width @ Beltline | N/A in |
| Front Shoulder Room | 77.1 in |
| Cab to End of Frame | N/A in |
| Front Head Room | 44.4 in |
| Ground Clearance, Rear | 16.0 in |
| Overhang, Front | N/A in |
| Second Shoulder Room | 77.1 in |
| Rear Door Opening Width | N/A in |
| Side Door Opening Width | N/A in |
| Front Hip Room | 23.1 in |
| Ground Clearance, Front | 16.0 in |
| Cargo Volume to Seat 1 | N/A ft³ |
| 130" WB | Standard |
| Utility lighting pkg | Standard |
| Halogen headlamps | Standard |
| Heat-treated/corrosion-resistant aluminum alloy body | Standard |
| Central Tire Inflation System (CTIS)-inc: on-board air compressor, in-dash tire pressure gauge | Standard |
| Helicopter lift hooks | Standard |
| Trailer towing pkg-inc: heavy duty bumper towing shackles, wiring harness | Standard |
| AM/FM stereo radio w/cassette/in-dash 6-disc CD changer-inc: Monsoon premium audio system | Standard |
| 124 amp alternator | Standard |
| Welded steel box-section frame w/5 crossmembers | Standard |
| Padded interior | Standard |
| 4-wheel independent double A-frame suspension w/HD open-end coil springs | Standard |
| 10,300# GVW | Standard |
| 6.5L (396) turbo-diesel V8 engine | Standard |
| H1 badging | Standard |
| Black door lock bezels | Standard |
| Windshield wiper/washer system | Standard |
| TT4 traction control system | Standard |
| Dual pwr heated mirrors | Standard |
| Serpentine drive belt | Standard |
| Canvas top | Standard |
| Side door impact beams | Standard |
| Rocker panel protection-inc: dual aluminum plates | Standard |
| 17" one-piece forged aluminum wheels w/beadlock system | Standard |
| Torque-biasing differentials | Standard |
| Galvanized steel doors | Standard |
| TT4 traction control system | Standard |
| 4100# capacity front/6800# capacity rear GAWR | Standard |
| Tonneau cover | Standard |
| 2-speed transfer case | Standard |
| Air conditioning w/auxiliary air/heat | Standard |
| 3486# payload | Standard |
| 4-passenger seating-inc: (4) high-back bucket seats | Standard |
| 4-wheel anti-lock brakes | Standard |
| Instrumentation-inc: speedometer, odometer, tachometer, fuel level, engine coolant temp, oil pressure, voltmeter | Standard |
| Sealed central venting system | Standard |
| Dual fuel tanks (25 gallon main/17 gallon auxiliary) | Standard |
| Air compressor-inc: air line w/quick connects | Standard |
| Remote keyless entry-inc: pwr door locks | Standard |
| Dura-wall runflat tire system | Standard |
| Full-time four wheel drive | Standard |
| 4-wheel anti-lock brakes | Standard |
| HD hydraulic shock absorbers | Standard |
| Brush guard | Standard |
| HD 4-speed automatic transmission w/OD | Standard |
| HD rear bumper | Standard |
| HD multiple-cooling systems-inc: engine coolant, engine oil, transmission oil, transfer case oil, pwr steering fluid | Standard |
| Driveline protection-inc: three tubular steel cages | Standard |
| 3-point seat belts for all seating positions | Standard |
| Glove box | Standard |
| LT37/12.50R17 SBR BSW Goodyear Wrangler GS-A tires | Standard |
| Driver/front passenger armrests | Standard |
| Cruise control | Standard |
| Pwr-assisted variable-ratio steering | Standard |
| Sliding rear window | Standard |
| 4-wheel hydraulic inboard-mounted pwr disc brakes | Standard |
| Flow-through ventilation | Standard |
| Heat & sound insulation | Standard |
| Deluxe rearview mirror | Standard |
| Pwr windows w/driver-side express down feature | Standard |
