2009 Mazda Mazda6 i SV specs & colors

Starting MSRP
Current listing price
2009 Mazda Mazda6 i SV

Showing the 2009 Mazda Mazda6 4dr Sdn Man i SV

Shop Now

Key specs

Color options





EPA Classification Midsize
Front Wheel Size 16.0 x 6.5 in
Rear Wheel Size 16.0 x 6.5 in
Spare Wheel Size 16.0 x 4.0 in
Front Wheel Material Alloy
Rear Wheel Material Alloy
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) N/A
Maximum Alternator Capacity (amps) 100
Engine Type Gas I4
Displacement 2.5L/152
SAE Net Horsepower @ RPM 170 @ 6000
SAE Net Torque @ RPM 167 @ 4000
EPA Fuel Economy Est - Hwy 29 MPG
Cruising Range - City 318.00 mi
EPA Fuel Economy Est - City 20 MPG
Fuel Economy Est-Combined 23 MPG
Cruising Range - Hwy 461.10 mi
EPA MPG Equivalent - City N/A
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi
Drivetrain Front Wheel Drive
Trans Type 6
Trans Description Cont. Manual w/OD
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 3.45
Second Gear Ratio (:1) 1.84
Third Gear Ratio (:1) 1.31
Fourth Gear Ratio (:1) 1.03
Fifth Gear Ratio (:1) 0.84
Sixth Gear Ratio (:1) 0.72
Reverse Ratio (:1) 3.20
Final Drive Axle Ratio (:1) 4.39
Suspension Type - Front Independent Strut
Suspension Type - Rear Independent E-Type
Suspension Type - Front (Cont.) Double-Wishbone
Suspension Type - Rear (Cont.) Multi-Link
Brake Type Pwr
Brake ABS System 4-wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 11.8 x -TBD- in
Rear Brake Rotor Diam x Thickness 11.0 x -TBD- in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 15.9 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall 16.2
Lock to Lock Turns (Steering) 2.93
Turning Diameter - Curb to Curb 35.4 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size P205/65HR16
Rear Tire Size P205/65HR16
Spare Tire Size T115/70D16
Dead Weight Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Trailer Wt. Not Available lbs
Wt Distributing Hitch - Max Tongue Wt. Not Available lbs
Base Curb Weight 3258 lbs
Passenger Capacity 5
Passenger Volume 101.9 ft³
Front Head Room 39.4 in
Front Leg Room 42.5 in
Front Shoulder Room 57.3 in
Front Hip Room 55.1 in
Second Head Room 37.3 in
Second Leg Room 38.0 in
Second Shoulder Room 56.5 in
Second Hip Room 55.9 in
Wheelbase 109.8 in
Length, Overall 193.7 in
Width, Max w/o mirrors 72.4 in
Height, Overall 57.9 in
Track Width, Front 62.8 in
Track Width, Rear 62.8 in
Min Ground Clearance 5.1 in
Liftover Height Not Available in
Trunk Volume 16.6 ft³
Body-color sport grille Standard
Instrumentation -inc: tachometer, (2) resettable trip odometers Standard
Rear window defogger Standard
(2) 12-volt pwr outlets Standard
Remote release -inc: trunk, fuel-filler door, hood Standard
Front/rear gas shocks Standard
Pwr door locks Standard
Front map lights Standard
Rear seat heater ducts Standard
In-glass rear radio antenna Standard
Black scuff plates Standard
Front/rear side curtain air bags Standard
(3) passenger assist grips Standard
2.5L DOHC MPFI 16-valve I4 engine w/variable valve timing (VVT) Standard
Crushable brake & accelerator pedal assembly Standard
Driver/front passenger seatback storage pocket Standard
Silver trimmed rear sport type taillights Standard
P205/65HR16 all-season tires Standard
AM/FM stereo w/CD player -inc: digital clock, MP3 capability, (6) speakers Standard
Passenger airbag cutoff switch Standard
Emergency trunk release Standard
Manual day/night rearview mirror Standard
Air conditioning w/pollen filter Standard
Halogen headlights -inc: auto shutoff, clear housings Standard
Carpeted cargo mat Standard
Manual driver seat height adjustment Standard
T115/70D16 temporary spare tire Standard
Front side-impact air bags supplemental restraint system Standard
Engine immobilizer system Standard
(2) coat hooks Standard
Rear seat child safety seat lower anchors & upper tethers (LATCH) Standard
Front seat belt pretensioners w/force limiters Standard
Dark gray pwr window switch panel Standard
Center console armrest w/dual covered storage compartments Standard
Black gauges w/white lettering, red nighttime illumination Standard
Overhead sunglass holder Standard
Pwr rack & pinion steering w/engine speed-sensing variable assist Standard
Traction control system (TCS) Standard
Independent double-wishbone front suspension w/coil springs Standard
Front/rear side-impact door beams Standard
Illuminated ignition switch Standard
Sunvisors w/illuminated vanity mirrors & sliding extensions Standard
4-wheel anti-lock brake system w/electronic brakeforce distribution (EBD) Standard
3-point seat belts for all positions Standard
16" x 4.0" temporary spare wheel Standard
Independent E-type multi-link rear suspension w/coil springs Standard
Front wheel drive Standard
Warning lights -inc: air bags, battery charge, check engine, door ajar, high-beam, low fuel, oil pressure, parking brake, seat belts Standard
Pwr front ventilated & rear solid disc brakes Standard
Tire pressure monitoring system Standard
Cloth seat trim -inc: cloth door trim panels Standard
Carpeted floor mats Standard
Dynamic stability control Standard
Pwr windows -inc: front 1-touch down, cancel switch Standard
Tilt/telescopic steering wheel w/audio controls Standard
Rear seat center armrest w/(2) cupholders Standard
60/40 split bench fold-down rear seat -inc: fold-flat remote operation, headrests Standard
Delayed courtesy lighting -inc: front map, front door lights Standard
Coin holder Standard
Child safety rear door locks Standard
Front/rear body-color sport-type bumpers & side moldings Standard
Central dash panel storage -inc: mat, lid Standard
Reclining front bucket seats -inc: height adjustable active headrests Standard
Windshield w/green-tinted glass & sunshade Standard
Triple-H body construction Standard
Front/rear stabilizer bars Standard
16" x 6.5" steel wheels Standard
6-speed manual transmission w/OD Standard
Front door storage pockets w/bottle holders Standard
Body-color pwr mirrors Standard
(2) front cupholders Standard
Variable-intermittent windshield wipers Standard
Lockable illuminated glove compartment Standard
Center instrument panel display -inc: clock, audio, A/C, outside temp Standard
Dual front air bag supplemental restraint system (SRS) Standard
Sirius satellite radio compatible audio system (requires additional hardware) Standard
