1997 Mitsubishi Diamante ES specs & colors

$25,900
Starting MSRP
Current listing price
1997 Mitsubishi Diamante ES

Showing the 1997 Mitsubishi Diamante 4dr Luxury Sdn ES

Shop Now

Key specs

Color options

Interior

No colors available

Packages

Specifications

EPA Classification Mid-Size
Rear Wheel Material Steel
Rear Wheel Size 15 x 6 in
Front Wheel Size 15 x 6 in
Spare Wheel Size 15 x 6 in
Spare Wheel Material N/A
Front Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) N/A
Maximum Alternator Capacity (amps) N/A
SAE Net Horsepower @ RPM 210 @ 5000
Engine Type Gas V6
SAE Net Torque @ RPM 231 @ 4000
Displacement 3.5L/213.3
Cruising Range - Hwy 494.00 mi
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - City N/A
EPA Fuel Economy Est - City 18 MPG
EPA Fuel Economy Est - Hwy 26 MPG
Cruising Range - City 342.00 mi
Fuel Economy Est-Combined N/A MPG
Reverse Ratio (:1) 2.720
Second Gear Ratio (:1) 1.495
Fourth Gear Ratio (:1) 0.731
Trans Description Cont. Automatic
Final Drive Axle Ratio (:1) 2.950
Trans Description Cont. Again Electronic
First Gear Ratio (:1) 2.842
Third Gear Ratio (:1) 1.000
Drivetrain Front Wheel Drive
Trans Type 4
Suspension Type - Front (Cont.) w/MacPherson Struts
Suspension Type - Rear Independent
Suspension Type - Front Independent
Suspension Type - Rear (Cont.) w/Coil Springs
Brake ABS System Not Available
Disc - Rear (Yes or ) Yes
Rear Brake Rotor Diam x Thickness 10.2 x -TBD- in
Brake Type Power
Front Brake Rotor Diam x Thickness 10.9 x -TBD- in
Brake ABS System (Second Line) N/A
Drum - Rear (Yes or ) Not Available
Disc - Front (Yes or ) Yes
Fuel Tank Capacity, Approx 19.0 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Ratio (:1), Overall N/A
Lock to Lock Turns (Steering) 3.1
Turning Diameter - Curb to Curb 36.7 ft
Steering Type Power Rack & Pinion
Turning Diameter - Wall to Wall N/A ft
Front Tire Size 205/65VR15
Spare Tire Size 205/65R15
Rear Tire Size 205/65VR15
Dead Weight Hitch - Max Trailer Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. Not Available lbs
Wt Distributing Hitch - Max Trailer Wt. Not Available lbs
Dead Weight Hitch - Max Tongue Wt. N/A lbs
Base Curb Weight 3363 lbs
Passenger Volume 100.9 ft³
Front Leg Room 44.3 in
Front Hip Room 58.0 in
Track Width, Rear 60.4 in
Min Ground Clearance 4.6 in
Track Width, Front 60.8 in
Wheelbase 107.1 in
Second Shoulder Room 56.1 in
Width, Max w/o mirrors 70.3 in
Height, Overall 56.5 in
Trunk Volume 14.2 ft³
Passenger Capacity 5
Second Hip Room 57.3 in
Second Head Room 37.5 in
Second Leg Room 36.6 in
Liftover Height N/A in
Length, Overall 194.1 in
Front Shoulder Room 56.0 in
Front Head Room 39.4 in
Center console w/integral armrests Standard
Diversity antenna system-inc: pwr antenna, in-glass rear antenna Standard
Door key illumination Standard
15" x 6.0" steel wheels w/full covers Standard
3.5L SOHC MFI 24-valve V6 engine Standard
Conventional spare tire Standard
Steering column-mounted controls-inc: headlamps, high/low beam, flash-to-pass, turn signals, windshield wipers, cruise control Standard
Courtesy lamps-inc: dome, trunk, glove compartment, front foot Standard
Fold-down rear center armrest Standard
Air conditioning w/automatic climate control Standard
Flush side windows w/drip channels Standard
Electric rear window defroster w/auto shutoff Standard
Front/rear door armrests Standard
Stainless steel exhaust system Standard
Prism-type headlamps Standard
Pwr windows w/driver auto-down feature Standard
Remote releases-inc: fuel door, pwr deck-lid, hood Standard
Dual instrument-panel cupholders Standard
Cut-pile carpeting Standard
Variable induction control system Standard
7-way adjustable front seats Standard
Integral front air dam Standard
Body-side molding Standard
Warning lights-inc: engine check, brake system, low oil pressure, charging system, low fuel, door/trunk ajar Standard
Velour upholstery Standard
Dual pwr-remote aero-type sideview mirrors (RH convex) Standard
Driver & front passenger air bags Standard
Full instrumentation w/120-MPH speedometer, 9000-RPM tachometer, trip meter, fuel level & coolant temp gauges Standard
Front wheel drive Standard
P205/65VR15 performance SBR tires Standard
Maintenance-free battery Standard
Key-in-ignition warning chime Standard
Variable intermittent wipers Standard
4-wheel ventilated disc brakes Standard
Digital quartz clock Standard
Rear-seat heater ducts Standard
Pwr-assisted rack & pinion steering Standard
Front/rear adjustable headrests Standard
Cruise control Standard
Front/rear crumple zones Standard
City 18/hwy 26 (3.5L engine/4-speed auto trans) Standard
Height-adjustable steering column Standard
4-speed automatic transmission w/OD Standard
Security system Standard
Carpeted cargo area Standard
Color-keyed bumpers Standard
19.0 gallon fuel tank Standard
3-point seat belts (outboard & rear center) Standard
Instrument panel controls-inc: panel lamp dimmer, trip meter reset, hazard flasher Standard
Tinted glass Standard
Height-adjustable front shoulder belts Standard
Auto transmission position indicator light Standard
Independent MacPherson strut front suspension w/coil springs, stabilizer bar Standard
Pwr door locks Standard
Independent multi-link rear suspension w/coil springs, stabilizer bar Standard
Side-impact door beams Standard
Ignition key w/delay light Standard
Upper windshield shade band Standard
AM/FM stereo w/cassette, (6) speakers Standard
