1997 Nissan Pathfinder XE specs & colors

$22,899
Starting MSRP
Current listing price
1997 Nissan Pathfinder XE

Showing the 1997 Nissan Pathfinder 4dr XE Manual

Shop Now

Key specs

Color options

Interior

Grey-Violet


Medium Mocha


Packages

Specifications

EPA Classification 2WD Special Purpose
Front Wheel Size 15 x 6.5 in
Spare Wheel Size 15 x 6.5 in
Rear Wheel Material Steel
Rear Wheel Size 15 x 6.5 in
Front Wheel Material Steel
Spare Wheel Material N/A
Maximum Alternator Capacity (amps) 90
Cold Cranking Amps @ 0° F (Primary) N/A
SAE Net Torque @ RPM 196 @ 2800
Displacement 3.3L/200
Engine Type Gas V6
SAE Net Horsepower @ RPM 168 @ 4800
EPA Fuel Economy Est - Hwy 20 MPG
Cruising Range - City 358.70 mi
Cruising Range - Hwy 422.00 mi
Fuel Economy Est-Combined N/A MPG
Estimated Battery Range N/A mi
EPA MPG Equivalent - Combined N/A
EPA MPG Equivalent - City N/A
EPA Fuel Economy Est - City 17 MPG
EPA MPG Equivalent - Hwy N/A
Reverse Ratio (:1) 3.64
Drivetrain Rear Wheel Drive
Trans Description Cont. Manual w/OD
Third Gear Ratio (:1) 1.36
Trans Description Cont. Again Not Available
Second Gear Ratio (:1) 2.08
Transfer Case Gear Ratio (:1), High Not Available
Trans Type 5
First Gear Ratio (:1) 3.58
Fifth Gear Ratio (:1) 0.81
Fourth Gear Ratio (:1) 1.00
Final Drive Axle Ratio (:1) 4.36
Transfer Case Gear Ratio (:1), Low Not Available
Suspension Type - Front (Cont.) w/Coil Springs
Suspension Type - Rear Rigid 5-Link
Suspension Type - Rear (Cont.) w/Coil Springs
Suspension Type - Front Independent Strut
Brake ABS System (Second Line) N/A
Drum - Rear (Yes or ) Yes
Disc - Front (Yes or ) Yes
Rear Brake Rotor Diam x Thickness Not Available in
Front Brake Rotor Diam x Thickness 11.1 x 1.10 in
Brake Type Power
Disc - Rear (Yes or ) Not Available
Brake ABS System 4-Wheel
Fuel Tank Capacity, Approx 21.1 gal
Aux Fuel Tank Capacity, Approx N/A gal
Lock to Lock Turns (Steering) 3.2
Steering Ratio (:1), Overall 18.7
Turning Diameter - Curb to Curb 35.4 ft
Turning Diameter - Wall to Wall N/A ft
Steering Type Pwr Rack & Pinion
Spare Tire Size P235/70R15
Rear Tire Size P235/70R15
Front Tire Size P235/70R15
Wt Distributing Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Tongue Wt. 350 lbs
Maximum Trailering Capacity N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 350 lbs
Base Curb Weight 3800 lbs
Maximum Payload Capacity N/A lbs
Total Option Weight 0.00 lbs
Curb Weight - Front N/A lbs
Curb Weight - Rear N/A lbs
Curb Weight N/A lbs
Cargo Area Length @ Floor to Seat 1 63.5 in
Width, Max w/o mirrors 68.7 in
Rear Door Opening Height 33.4 in
Second Leg Room 31.8 in
Cargo Area Length @ Floor to Seat 3 Not Available in
Second Shoulder Room 56.4 in
Cargo Volume to Seat 1 85.8 ft³
Cargo Volume to Seat 3 N/A ft³
Front Leg Room 41.7 in
Front Hip Room 53.2 in
Passenger Capacity 5
Cargo Volume to Seat 2 38.0 ft³
Passenger Volume 92.9 ft³
Cargo Area Width @ Beltline N/A in
Cargo Box Width @ Wheelhousings 37.7 in
Wheelbase 106.3 in
Cargo Box (Area) Height 35.6 in
Second Head Room 37.5 in
Rear Door Opening Width 50.6 in
Front Head Room 39.5 in
Front Shoulder Room 56.5 in
Cargo Area Length @ Floor to Seat 2 N/A in
Second Hip Room 53.0 in
Min Ground Clearance 5.9 in
Length, Overall 178.3 in
Liftover Height N/A in
Height, Overall 63.8 in
Track Width, Front 58.3 in
Track Width, Rear 58.5 in
Front/rear die-cut black splash guards Standard
Front/rear stabilizer bar Standard
Full size spare tire w/underbody-mount carrier Standard
Woven fabric seat material Standard
Flush-mounted halogen headlights Standard
Energy absorbing steering column Standard
21.1 gallon fuel tank Standard
Front/rear adjustable head restraints Standard
Driver & front passenger air bags (SRS) Standard
90-amp alternator Standard
Pwr vented front disc brakes Standard
Front/rear towing hooks Standard
Solid MonoFrame construction Standard
Electronic ignition system (1996) Standard
Adjustable steering column Standard
Rear wheel drive Standard
Rear window defroster w/timer Standard
Front/rear door pockets Standard
HD independent strut front suspension Standard
(4) cargo tie-downs Standard
3-point front/rear outboard seat-belts Standard
Fuel tank skid plate Standard
Driver/passenger map lamps Standard
Front/rear 12-volt DC outlets Standard
Opening rear liftgate window Standard
Diversity antenna Standard
60/40 split fold-flat rear seats w/reclining seatbacks Standard
**ALL STANDARDS ARE 1997 UNLESS OTHERWISE NOTED** Standard
Cargo area courtesy lamp Standard
Instrumentation-inc: tachometer, trip odometer, coolant temp gauge, digital clock Standard
5-speed manual transmission w/OD Standard
2-speed variable intermittent windshield wiper/washers Standard
4-wheel anti-lock brake system (ABS) Standard
City 17/hwy 20 (3.3L engine/5-speed manual trans) Standard
3500# towing capacity Standard
Multi-level center console w/armrest Standard
Steel side-door guard beams Standard
Front/rear crumple zones Standard
Black bumpers/grille Standard
4-wheel anti-lock brake system (ABS) Standard
3.3L SOHC SFI 168 HP V6 engine Standard
15" 6-spoke chrome wheels Standard
Rear window wiper/washer Standard
AM/FM stereo w/compact disc player-inc: 160-watt amp, 6-speakers Standard
60-amp HD battery Standard
Dual exterior mirrors Standard
Locking glovebox Standard
Passenger side visor w/mirror Standard
Overhead sunglasses storage compartment Standard
5-link coil spring rear suspension Standard
Front/rear assist grips Standard
Remote hood/fuel-filler door releases Standard
Adjustable front bucket seats Standard
P235/70R15 mud & snow SBR tires Standard
Child safety rear door locks Standard
Low-cut pile carpeting Standard
Tinted glass Standard
Pwr rack & pinion steering Standard
