2009 Nissan Pathfinder S specs & colors

Starting MSRP
Current listing price

Showing the 2009 Nissan Pathfinder 2WD 4dr V6 S

Shop Now

Key specs

Color options



Medium Mocha



EPA Classification 2WD Sport Utility

Front Wheel Size 16 x 7.0 in
Rear Wheel Size 16 x 7.0 in
Spare Wheel Size 16 x 7.0 in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel

Cold Cranking Amps @ 0° F (Primary) 550
Maximum Alternator Capacity (amps) 110

Engine Type Gas V6
Displacement 4.0L/241
SAE Net Horsepower @ RPM 266 @ 5600
SAE Net Torque @ RPM 288 @ 4000

EPA Fuel Economy Est - Hwy 22 MPG
Cruising Range - City 316.50 mi
EPA Fuel Economy Est - City 15 MPG
Fuel Economy Est-Combined 17 MPG
Cruising Range - Hwy 464.20 mi
EPA MPG Equivalent - City N/A
EPA MPG Equivalent - Hwy N/A
EPA MPG Equivalent - Combined N/A
Estimated Battery Range N/A mi

Drivetrain Rear Wheel Drive
Trans Type 5
Trans Description Cont. Automatic
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 3.84
Second Gear Ratio (:1) 2.35
Third Gear Ratio (:1) 1.53
Fourth Gear Ratio (:1) 1.00
Fifth Gear Ratio (:1) 0.84
Reverse Ratio (:1) 2.76
Final Drive Axle Ratio (:1) 3.13
Transfer Case Gear Ratio (:1), High Not Available
Transfer Case Gear Ratio (:1), Low Not Available

Suspension Type - Front Independent
Suspension Type - Rear Independent
Suspension Type - Front (Cont.) Double-Wishbone
Suspension Type - Rear (Cont.) Double-Wishbone

Brake Type Power
Brake ABS System 4-Wheel
Brake ABS System (Second Line) N/A
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 11.7 x 1.1 in
Rear Brake Rotor Diam x Thickness 12.1 x 0.7 in
Drum - Rear (Yes or ) Not Available

Fuel Tank Capacity, Approx 21.1 gal
Aux Fuel Tank Capacity, Approx N/A gal

Steering Type Pwr Rack & Pinion
Steering Ratio (:1), Overall 17
Lock to Lock Turns (Steering) 3.5
Turning Diameter - Curb to Curb 39.2 ft
Turning Diameter - Wall to Wall N/A ft

Front Tire Size P245/75R16
Rear Tire Size P245/75R16
Spare Tire Size P245/75R16

Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Trailer Wt. 6000 lbs
Wt Distributing Hitch - Max Tongue Wt. 600 lbs
Maximum Trailering Capacity N/A lbs

Base Curb Weight 4446 lbs
Curb Weight - Front N/A lbs
Curb Weight - Rear N/A lbs
Maximum Payload Capacity N/A lbs
Curb Weight N/A lbs
Total Option Weight 0.00 lbs

Passenger Capacity 7
Passenger Volume 149.1 ft³
Front Head Room 40.0 in
Front Leg Room 42.4 in
Front Shoulder Room 58.3 in
Front Hip Room 55.5 in
Second Head Room 39.0 in
Second Leg Room 34.2 in
Second Shoulder Room 58.4 in
Second Hip Room 57.6 in
Third Head Room 36.7 in
Third Leg Room 28.1 in
Third Shoulder Room 57.1 in
Third Hip Room 44.0 in
Wheelbase 112.2 in
Length, Overall 192.3 in
Width, Max w/o mirrors 72.8 in
Height, Overall 72.0 in
Track Width, Front 61.8 in
Track Width, Rear 61.8 in
Min Ground Clearance 8.7 in
Rear Door Opening Height Not Available in
Rear Door Opening Width Not Available in
Cargo Area Length @ Floor to Seat 1 73.9 in
Cargo Area Length @ Floor to Seat 2 N/A in
Cargo Area Length @ Floor to Seat 3 17.4 in
Cargo Area Width @ Beltline 44.4 in
Cargo Box Width @ Wheelhousings N/A in
Cargo Box (Area) Height 34.8 in
Liftover Height 29.9 in
Cargo Volume to Seat 1 79.2 ft³
Cargo Volume to Seat 2 49.2 ft³
Cargo Volume to Seat 3 16.5 ft³

Body-color door handles Standard
Day/night rearview mirror Standard
4.0L DOHC 24-valve V6 engine Standard
Front/rear stabilizer bars Standard
Delayed accessory pwr Standard
P245/75R16 all-season tires Standard
Trip computer Standard
Front map lights Standard
Rear window fixed intermittent wiper w/washer Standard
Front air conditioning Standard
Cargo area under-floor storage Standard
Rear wheel drive Standard
4-wheel pwr vented disc brakes Standard
Driver & front passenger advanced dual stage airbags w/occupant sensor Standard
16" alloy wheels Standard
Side door guard beams Standard
Immobilizer theft-deterrent system Standard
Body-color bumpers & fender flares Standard
Variable intermittent windshield wipers Standard
Rear center console vent Standard
Vehicle dynamic control (VDC) Standard
Front/rear crumple zones Standard
Stainless steel exhaust Standard
Pwr speed-sensitive rack & pinion steering Standard
Roof rails Standard
Folding black pwr mirrors Standard
Security alarm system Standard
Electronic brake force distribution (EBD) Standard
In cabin micro filter Standard
4-wheel anti-lock braking system (ABS) Standard
Class IV tow receiver hitch w/7-pin wiring harness Standard
Dual cup holders for all rows Standard
AM/FM stereo w/CD player -inc: (6) speakers Standard
Energy absorbing steering column Standard
Overhead console w/sunglass storage Standard
Dual coat hooks for second row Standard
5-speed automatic transmission Standard
Front bucket seats -inc: 8-way manual driver seat w/manual lumbar, 4-way manual front passenger seat, adjustable active head restraints Standard
Brake-activated limited slip (ABLS) Standard
Driver seatback pocket Standard
Rear privacy glass Standard
(12) cargo hooks Standard
3rd row 50/50 fold-flat split bench seat w/adjustable head restraints Standard
Roof-mounted side-impact curtain airbags for all rows w/rollover sensor Standard
Front seat-mounted side-impact airbags Standard
Pwr door locks w/selective unlock Standard
Assist grips-inc: (3) first row, (4) second row Standard
Steering wheel mounted cruise controls Standard
Cruise control Standard
3-point front seat belts w/pretensioners, load limiters & height adjusters Standard
2nd row 40/20/40 reclining fold-flat bench seat w/adjustable head restraints Standard
Lower anchors & tethers for children (LATCH) Standard
Flip-up liftgate window Standard
In glass diversity antenna Standard
Visors w/extenders & vanity mirrors Standard
Independent double wishbone front/rear suspension Standard
Pwr windows w/front window auto up/down & safety reverse Standard
Remote keyless entry Standard
Rear window defroster w/timer Standard
Lower radiator skid plate Standard
Full size spare tire w/steel wheel Standard
Power liftgate release Standard
3-point rear height adjustable seat belts Standard
Child safety rear door locks Standard
Tilt steering column Standard
Mesh grille w/chrome surround Standard
Bottle holders in front door pockets Standard
Cloth seating surfaces Standard
Variable valve timing (CVTCS) Standard
(4) 12-volt pwr outlets Standard
Tire pressure monitor system Standard
