2010 Chevrolet HHR LS specs & colors

Sport Utility

Change trim

MSRP

Change trim

$18,720

Starting MSRP
Current listing price

Showing the 2010 Chevrolet HHR FWD 4dr LS

Shop Now

Color options

Exterior

Interior

Gray

Cahsmere

Ebony

Packages

Specifications

EPA MPG Equivalent - Combined	N/A
EPA Fuel Economy Est - City	22 MPG
Fuel Economy Est-Combined	26 MPG
Estimated Battery Range	N/A mi
EPA MPG Equivalent - City	N/A
EPA MPG Equivalent - Hwy	N/A
EPA Fuel Economy Est - Hwy	32 MPG
Cruising Range - City	352.00 mi
Cruising Range - Hwy	512.00 mi

Trans Description Cont.	Manual
Transfer Case Gear Ratio (:1), Low	Not Available
Fourth Gear Ratio (:1)	0.89
Drivetrain	Front Wheel Drive
Transfer Case Gear Ratio (:1), High	Not Available
First Gear Ratio (:1)	3.38
Third Gear Ratio (:1)	1.18
Final Drive Axle Ratio (:1)	4.17
Fifth Gear Ratio (:1)	0.70
Second Gear Ratio (:1)	1.76
Reverse Ratio (:1)	3.17
Trans Type	5
Trans Description Cont. Again	Not Available

Drum - Rear (Yes or )	Yes
Brake Type	Power
Disc - Front (Yes or )	Yes
Disc - Rear (Yes or )	Not Available
Rear Brake Rotor Diam x Thickness	Not Available in
Brake ABS System	4-Wheel
Front Brake Rotor Diam x Thickness	11.65 x 1.02 in
Brake ABS System (Second Line)	N/A

Dead Weight Hitch - Max Trailer Wt.	1000 lbs
Wt Distributing Hitch - Max Trailer Wt.	1000 lbs
Maximum Trailering Capacity	N/A lbs
Dead Weight Hitch - Max Tongue Wt.	100 lbs
Wt Distributing Hitch - Max Tongue Wt.	150 lbs

Width, Max w/o mirrors	69.1 in
Rear Door Opening Width	N/A in
Cargo Volume to Seat 3	Not Available ft³
Front Shoulder Room	53.5 in
Second Hip Room	50.6 in
Liftover Height	N/A in
Wheelbase	103.5 in
Length, Overall	176.2 in
Passenger Volume	97.4 ft³
Passenger Capacity	5
Cargo Area Length @ Floor to Seat 2	N/A in
Track Width, Rear	58.7 in
Min Ground Clearance	6.3 in
Front Hip Room	50.1 in
Track Width, Front	58.7 in
Second Head Room	39.0 in
Cargo Volume to Seat 1	57.7 ft³
Height, Overall	63.1 in
Cargo Box (Area) Height	N/A in
Rear Door Opening Height	N/A in
Second Leg Room	39.5 in
Front Head Room	39.6 in
Second Shoulder Room	52.7 in
Front Leg Room	40.6 in
Cargo Area Length @ Floor to Seat 3	Not Available in
Cargo Box Width @ Wheelhousings	N/A in
Cargo Area Width @ Beltline	N/A in
Cargo Volume to Seat 2	25.2 ft³
Cargo Area Length @ Floor to Seat 1	N/A in

Air bags, head curtain side-impact, front and rear outboard seating positions (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicle's Owner's Manual and child safety seat instructions for more safety information.)	Standard
Door locks, rear child security	Standard
XM Radio is standard on more than 50 2010 GM models, including three trial months of service. XM turns your world on with commercial-free music channels for virtually every music genre, all in amazing digital quality sound. Turn on your favorite sports, the biggest names in News, Talk and Comedy, family programming, exclusive concerts and original music series, wherever you go from coast to coast. Everything worth listening to is now on XM (XM service available only in the 48 contiguous United States and the District of Columbia. XM Radio subscription required and sold separately after trial period. Fees, taxes, and a one-time re-activation fee, may apply. Subscriptions governed by XM Customer Agreement available at xmradio.com. All fees and programming subject to change. Family programming Packages are available.)	Standard
Steering column, tilt	Standard
Seat adjuster, driver 6-way manual (fore/aft, height and recline) and 4-way manual front passenger (fore/aft and recline)	Standard
Door locks, power	Standard
Map pocket, driver seatback	Standard
Defogger, rear-window electric	Standard
Brakes, 4-wheel antilock, front disc/rear drum	Standard
Seat, front passenger flat-folding seatback	Standard
LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats	Standard
Transmission, 5-speed manual	Standard
Remote Keyless Entry	Standard
Daytime Running Lamps	Standard
Tires, P215/55R16, all-season, blackwall	Standard
Steering, electric power, speed-sensitive	Standard
OnStar, 1-year of Safe and Sound plan. Includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Roadside Assistance, Remote Horn and Lights, Hands Free Calling, OnStar Vehicle Diagnostics, and Low Mileage Discount (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. Vehicle Diagnostics capabilities vary by model. Remote door unlock success varies with conditions. Ability to locate stolen vehicles varies with conditions. Subscription Service Agreement required. Call 1-888-4ONSTAR (1-888-466-7827) or visit onstar.com for OnStar's Terms and Conditions, Privacy Policy and details and system limitations. Not available with a ship-to of Puerto Rico or the Virgin Islands.)	Standard
Tire Pressure Monitoring System	Standard
Mirrors, outside power-adjustable, Black	Standard
Audio system, AM/FM stereo with CD player and MP3 playback, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), automatic volume, TheftLock, auxiliary input jack and 36 cross-band presets	Standard
Tire sealant and inflator kit in place of spare tire	Standard
Suspension, Touring	Standard
Steering wheel, urethane with mounted Driver Information Center and cruise controls	Standard
Power outlets, 2 auxiliary, 1 front and 1 rear	Standard
Windows, power, include driver Express-Down	Standard
Cruise control	Standard
Seats, front bucket includes 60/40 split-folding rear seat	Standard
Battery rundown protection	Standard
Audio system feature, 6-speaker system	Standard
Glass, deep-tint second row doors, quarter windows and rear	Standard
StabiliTrak, electronic stability control system	Standard
Engine, ECOTEC 2.2L Variable Valve Timing DOHC 4-cylinder SFI (E85) includes (E85) FlexFuel (gas ethanol) capability, uses gasoline or E85 fuel (155 hp [115.6 kW] @ 6100 rpm, 150 lb-ft of torque [202.5 N-m] @ 4800 rpm)	Standard
Air bags, dual-stage, frontal, driver and front passenger with infant only suppression (Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)	Standard
Front wheel drive	Standard
Air conditioning, with air filtration	Standard
Console, floor with rear and 3 front cup holders	Standard
Wheels, 16" (40.6 cm) steel with full bolt-on wheel covers	Standard
Theft-deterrent system, vehicle, PASS-Key III+	Standard
Wiper, rear	Standard
Wipers, front intermittent, speed-sensitive	Standard
Traction control, all-speed, full function	Standard
Instrumentation with speedometer, fuel gauge, tachometer and Driver Information Center with outside temperature, warning messages and programmable menu features	Standard
Mirror, inside rearview manual day/night (Includes OnStar buttons with (UE1) OnStar. OnStar buttons deleted when (UE0) OnStar delete is ordered.)	Standard
Cloth seat trim	Standard
Glovebox, auxiliary	Standard

Compare trims

Wondering which trim is right for you?

Our 2010 Chevrolet HHR trim comparison will help you decide.

Front Wheel Size	16 x 6.5 in
Spare Wheel Material	N/A
Spare Wheel Size	N/A in
Rear Wheel Size	16 x 6.5 in
Front Wheel Material	Steel
Rear Wheel Material	Steel

SAE Net Horsepower @ RPM	155 @ 6100
SAE Net Torque @ RPM	150 @ 4800
Engine Type	Gas/Ethanol I4
Displacement	2.2L/134

Suspension Type - Rear	Semi-independent
Suspension Type - Front (Cont.)	strut-type
Suspension Type - Front	Independent
Suspension Type - Rear (Cont.)	torsion beam

Aux Fuel Tank Capacity, Approx	N/A gal
Fuel Tank Capacity, Approx	16.0 gal

Steering Type	Variable electric
Lock to Lock Turns (Steering)	3.5
Turning Diameter - Wall to Wall	N/A ft
Steering Ratio (:1), Overall	18.5
Turning Diameter - Curb to Curb	36 ft

Maximum Alternator Capacity (amps)	N/A
Cold Cranking Amps @ 0° F (Primary)	N/A

Spare Tire Size	N/A
Front Tire Size	P215/55R16
Rear Tire Size	P215/55R16

Base Curb Weight	3013 lbs
Total Option Weight	0.00 lbs
Curb Weight - Rear	N/A lbs
Maximum Payload Capacity	N/A lbs
Curb Weight	N/A lbs
Curb Weight - Front	N/A lbs
