2012 Chevrolet Silverado 3500 Work Truck specs & colors

Crew Cab Pickup

Change trim

$36,030

Starting MSRP
Current listing price

2012 Chevrolet Silverado 3500 Work Truck

Showing the 2012 Chevrolet Silverado 3500 2WD Crew Cab 167.7" Work Truck

Shop Now

Key specs

4-door
6 seats
335.0-hp, 6.6-liter, 8 Cylinder Engine (Diesel Fuel)
0 combined MPG
229.5" length, 77.3" height
Rear Wheel Drive

Color options

Exterior

Sapphire

Interior

Dark Titanium

Packages

Specifications

Highlights

Engine Type: Gas/Ethanol V8
MPG: -
Horsepower: 397 hp
322 hp
335 hp
Seating Capacity: 6

Brakes

Drum - Rear (Yes or ): Not Available
Rear Brake Rotor Diam x Thickness: 13.98 x 1.57 in
Front Brake Rotor Diam x Thickness: 13.98 x 1.57 in
Disc - Rear (Yes or ): Yes
Disc - Front (Yes or ): Yes
Brake ABS System (Second Line): Not Available
Brake ABS System: 4-Wheel
Brake Type: Pwr

Electrical

Maximum Alternator Capacity (amps): 125
Cold Cranking Amps @ 0° F (Primary): 600

Engine

SAE Net Torque @ RPM: 380 @ 4200
SAE Net Horsepower @ RPM: 322 @ 4400
Displacement: 6.0L/366
Engine Type: Gas/Ethanol V8
Transmission Options: 6-Speed A/T
Transmission Overdrive Switch
A/T
MPG: -
Total Cooling System Capacity: 16.4 qts

Measurements

Front Hip Room: 60 in
Front Shoulder Room: 65 in
Front Leg Room: 41 in
Front Head Room: 41 in
Passenger Capacity: 6
Second Head Room: 41 in
Ext'd Cab Cargo Volume: N/A
Second Leg Room: 39 in
Second Shoulder Room: 65 in
Second Hip Room: 66 in
Wheelbase: 168 in
Length, Overall w/o rear bumper: 259 in
Length, Overall w/rear bumper: N/A
Length, Overall: N/A
Width, Max w/o mirrors: 96 in
Height, Overall: 78 in
Overhang, Front: 39 in
Overhang, Rear w/o bumper: 53 in
Cab to End of Frame: N/A
Ground to Top of Load Floor: 38 in
Ground Clearance, Front: 10 in
Ground Clearance, Rear: 9 in
Cargo Box Length @ Floor: 98 in
Cargo Box Width @ Top, Rear: N/A
Cargo Box Width @ Floor: 63 in
Cargo Box Width @ Wheelhousings: 51 in
Cargo Box (Area) Height: 21 in
Tailgate Width: 62 in
Cargo Volume: 76 ft³

Steering

Turning Diameter - Wall to Wall: N/A
Turning Diameter - Curb to Curb: 51 ft
Steering Ratio (:1), Overall: N/A
Steering Type: Pwr Recirculating Ball

Suspension

Axle Type - Rear: Full-Floating
Axle Type - Front: Independent
Suspension Type - Rear: Multi-Leaf
Suspension Type - Front: Independent

Tires & Wheels

Spare Wheel Material: Steel
Rear Wheel Material: Steel
Front Wheel Material: Steel
Spare Wheel Size: 17 x 6.5 in
Rear Wheel Size: 17 x 6.5 in
Front Wheel Size: 17 x 6.5 in
Spare Tire Size: Not Available
Rear Tire Size: LT235/80R17E
Front Tire Size: LT235/80R17E

Weight & Capacity

Aux Fuel Tank Capacity, Approx: Not Available gal
Fuel Tank Capacity, Approx: 36 gal
Maximum Trailering Capacity: 22,800 lbs
Fifth Wheel Hitch - Max Tongue Wt.: 2,275 lbs
Fifth Wheel Hitch - Max Trailer Wt.: 9,000 lbs
Wt Distributing Hitch - Max Tongue Wt.: 1,350 lbs
Wt Distributing Hitch - Max Trailer Wt.: 9,000 lbs
Dead Weight Hitch - Max Tongue Wt.: 500 lbs
Dead Weight Hitch - Max Trailer Wt.: 5,000 lbs
Gross Combined Wt Rating: 16,000 lbs
Maximum Payload Capacity: 6,608 lbs
As Spec'd Payload: 6,608 lbs
As Spec'd Curb Weight: 6,392 lbs
Option Weight - Rear: 0 lbs
Option Weight - Front: 0 lbs
Curb Weight - Rear: 3,004 lbs
Curb Weight - Front: 3,388 lbs
Base Curb Weight: N/A
Gross Axle Weight Rating: 14,175 lbs
Curb Weight: 6,392 lbs
Total Option Weight: 0 lbs
Gross Vehicle Weight Rating: 13,000 lbs
