Compare
$22,035
$22,425
Highlights
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Starting MSRP |
$22,035
|
$22,425
|
| Engine Type |
Gas I4
|
Gas I4
|
| MPG |
21 City / 27 Hwy
|
21 City / 27 Hwy
|
| Horsepower |
136 hp
|
136 hp
|
| Drive Type |
Front Wheel Drive
|
Front Wheel Drive
|
| Seating Capacity |
2
|
2
|
| Basic Warranty |
3 yr / 36,000 mi
|
3 yr / 36,000 mi
|
Engine
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Engine Type |
Gas I4
|
Gas I4
|
| SAE Net Horsepower @ RPM |
136 @ 6300
|
136 @ 6300
|
| Displacement |
2.0L/121
|
2.0L/121
|
| SAE Net Torque @ RPM |
128 @ 4750
|
128 @ 4750
|
| Transmission Options |
|
|
| MPG |
21 City / 27 Hwy
|
21 City / 27 Hwy
|
| Total Cooling System Capacity |
N/A
|
N/A
|
Tires & Wheels
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Rear Wheel Size |
15 x -TBD- in
|
15 x -TBD- in
|
| Front Tire Size |
P205/65R15
|
P205/65R15
|
| Spare Wheel Size |
15 x -TBD- in
|
15 x -TBD- in
|
| Rear Tire Size |
P205/65R15
|
P205/65R15
|
| Front Wheel Material |
Steel
|
Steel
|
| Spare Tire Size |
P205/65R15
|
P205/65R15
|
| Spare Wheel Material |
Steel
|
Steel
|
| Front Wheel Size |
15 x -TBD- in
|
15 x -TBD- in
|
| Rear Wheel Material |
Steel
|
Steel
|
Suspension
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Suspension Type - Front |
MacPherson Strut
|
MacPherson Strut
|
| Axle Type - Front |
N/A
|
N/A
|
| Suspension Type - Rear |
Multi-Leaf Spring
|
Beam Axle
|
| Axle Type - Rear |
Not Available
|
N/A
|
Steering
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Steering Ratio (:1), Overall |
N/A
|
N/A
|
| Turning Diameter - Curb to Curb |
39 ft
|
39 ft
|
| Turning Diameter - Wall to Wall |
N/A
|
N/A
|
| Steering Type |
Pwr Rack & Pinion
|
Pwr Rack & Pinion
|
Measurements
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Cargo Area Length @ Floor to Seat 1 |
81 in
|
81 in
|
| Overhang, Rear w/o bumper |
N/A
|
N/A
|
| Second Leg Room |
N/A
|
N/A
|
| Front Leg Room |
41 in
|
41 in
|
| Cargo Area Length @ Floor to Console |
N/A
|
N/A
|
| Cargo Box Width @ Floor |
N/A
|
N/A
|
| Length, Overall w/rear bumper |
181 in
|
181 in
|
| Step Up Height - Side |
Not Available in
|
Not Available in
|
| Front Hip Room |
51 in
|
51 in
|
| Cargo Box Width @ Top, Rear |
N/A
|
N/A
|
| Side Door Opening Width |
Not Available in
|
Not Available in
|
| Rear Door Opening Height |
52 in
|
52 in
|
| Step Up Height - Front |
N/A
|
N/A
|
| Ground Clearance, Front |
8 in
|
8 in
|
| Second Hip Room |
N/A
|
N/A
|
| Wheelbase |
115 in
|
115 in
|
| Tailgate Width |
N/A
|
N/A
|
| Side Door Opening Height |
Not Available in
|
Not Available in
|
| Ext'd Cab Cargo Volume |
N/A
|
N/A
|
| Front Head Room |
51 in
|
51 in
|
| Ground Clearance, Rear |
7 in
|
7 in
|
| Overhang, Front |
37 in
|
37 in
|
| Second Head Room |
N/A
|
N/A
|
| Front Shoulder Room |
54 in
|
54 in
|
| Width, Max w/o mirrors |
71 in
|
71 in
|
| Cargo Box (Area) Height |
54 in
|
54 in
|
| Height, Overall |
79 in
|
79 in
|
| Ground to Top of Load Floor |
23 in
|
23 in
|
| Cargo Area Width @ Beltline |
60 in
|
60 in
|
| Length, Overall |
N/A
|
N/A
|
| Second Shoulder Room |
N/A
|
N/A
|
| Cargo Volume |
130 ft³
|
130 ft³
|
| Passenger Capacity |
2
|
2
|
| Rear Door Opening Width |
50 in
|
50 in
|
| Cab to End of Frame |
N/A
|
N/A
|
| Cargo Box Width @ Wheelhousings |
48 in
|
48 in
|
Weight & Capacity
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Total Option Weight |
0 lbs
|
0 lbs
|
| Wt Distributing Hitch - Max Tongue Wt. |
Not Available lbs
|
Not Available lbs
|
| As Spec'd Curb Weight |
3,360 lbs
|
3,360 lbs
|
| Curb Weight |
3,360 lbs
|
3,360 lbs
|
| Option Weight - Rear |
0 lbs
|
0 lbs
|
| Fifth Wheel Hitch - Max Trailer Wt. |
Not Available lbs
|
Not Available lbs
|
| Curb Weight - Rear |
1,464 lbs
|
1,464 lbs
|
| Maximum Trailering Capacity |
N/A
|
N/A
|
| As Spec'd Payload |
1,645 lbs
|
1,645 lbs
|
| Fuel Tank Capacity, Approx |
15 gal
|
15 gal
|
| Gross Combined Wt Rating |
N/A
|
N/A
|
| Fifth Wheel Hitch - Max Tongue Wt. |
Not Available lbs
|
Not Available lbs
|
| Dead Weight Hitch - Max Trailer Wt. |
Not Available lbs
|
Not Available lbs
|
| Wt Distributing Hitch - Max Trailer Wt. |
Not Available lbs
|
Not Available lbs
|
| Base Curb Weight |
N/A
|
N/A
|
| Option Weight - Front |
0 lbs
|
0 lbs
|
| Gross Axle Weight Rating |
5,231 lbs
|
5,231 lbs
|
| Dead Weight Hitch - Max Tongue Wt. |
Not Available lbs
|
Not Available lbs
|
| Gross Vehicle Weight Rating |
5,005 lbs
|
5,005 lbs
|
| Curb Weight - Front |
1,896 lbs
|
1,896 lbs
|
| Maximum Payload Capacity |
1,645 lbs
|
1,645 lbs
|
| Aux Fuel Tank Capacity, Approx |
Not Available gal
|
Not Available gal
|
Safety
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Stability Control |
Standard
|
Standard
|
Electrical
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Maximum Alternator Capacity (amps) |
150
|
150
|
| Cold Cranking Amps @ 0° F (Primary) |
500
|
500
|
Brakes
| 2012 Ford Transit Connect | 2013 Ford Transit Connect | |
|---|---|---|
| Disc - Rear (Yes or ) |
Not Available
|
Not Available
|
| Brake ABS System (Second Line) |
Not Available
|
Not Available
|
| Drum - Rear (Yes or ) |
Yes
|
Yes
|
| Brake ABS System |
4-Wheel
|
4-Wheel
|
| Brake Type |
Pwr
|
Pwr
|
| Disc - Front (Yes or ) |
Yes
|
Yes
|
| Rear Brake Rotor Diam x Thickness |
Not Available in
|
Not Available in
|
| Front Brake Rotor Diam x Thickness |
N/A
|
N/A
|
