2011 Ford Escape XLS specs & colors

Sport Utility

Change trim
MSRP
FWD 4dr XLS
$21,240
4WD 4dr XLS
$22,990
FWD 4dr XLT
$24,670
FWD 4dr Limited
$26,170
4WD 4dr XLT
$26,420
4WD 4dr Limited
$27,920
$21,240
Starting MSRP
Current listing price
2011 Ford Escape XLS

Showing the 2011 Ford Escape FWD 4dr XLS

Shop Now

Key specs

  • 4-door
  • 5 seats
  • 171.0-hp, 2.5-liter, 4 Cylinder Engine (Gasoline Fuel)
  • 23 combined MPG
  • 174.7" length, 67.7" height
  • Front Wheel Drive

Color options

Exterior

Ruby Red Metallic

Interior
Medium stone

Packages

  • 100A RAPID SPEC ORDER CODE

    $0

    Starting MSRP

    • base vehicle
  • 102A RAPID SPEC ORDER CODE

    $1,625

    Starting MSRP

    • 6-speed auto trans
    • cargo area cover
    • roof rails w/cross bars
    See more detail

    $1,625

    Starting MSRP

    • 6-speed auto trans
    • cargo area cover
    • roof rails w/cross bars
    • wet trunk bin
  • 101A RAPID SPEC ORDER CODE

    $1,230

    Starting MSRP

    • 6-speed auto trans

Specifications

Highlights

Engine Type
Gas I4
MPG
21 City / 28 Hwy
Horsepower
171 hp
Seating Capacity
5

Brakes

Brake ABS System
4-Wheel
Disc - Rear (Yes or )
Not Available
Front Brake Rotor Diam x Thickness
11.9 x 0.5 in
Brake Type
Power
Disc - Front (Yes or )
Yes
Brake ABS System (Second Line)
N/A
Drum - Rear (Yes or )
Yes
Rear Brake Rotor Diam x Thickness
Not Available in

Electrical

Maximum Alternator Capacity (amps)
110
Cold Cranking Amps @ 0° F (Primary)
550

Engine

Engine Type
Gas I4
Displacement
2.5L/152
SAE Net Torque @ RPM
171 @ 4500
SAE Net Horsepower @ RPM
171 @ 6000
Transmission Options
6-Speed A/T
M/T
A/T
5-Speed M/T
MPG
21 City / 28 Hwy
Total Cooling System Capacity
5.3 qts

Measurements

Passenger Capacity
5
Second Shoulder Room
56 in
Front Leg Room
42 in
Track Width, Rear
60 in
Height, Overall
68 in
Front Head Room
40 in
Cargo Volume to Seat 3
Not Available ft³
Cargo Area Length @ Floor to Seat 3
Not Available in
Cargo Area Width @ Beltline
N/A
Passenger Volume
100 ft³
Cargo Volume to Seat 1
67 ft³
Rear Door Opening Width
43 in
Second Hip Room
49 in
Liftover Height
30 in
Cargo Area Length @ Floor to Seat 1
67 in
Min Ground Clearance
8 in
Cargo Box Width @ Wheelhousings
41 in
Front Shoulder Room
57 in
Second Leg Room
36 in
Cargo Box (Area) Height
38 in
Rear Door Opening Height
34 in
Second Head Room
39 in
Track Width, Front
61 in
Front Hip Room
53 in
Cargo Volume to Seat 2
31 ft³
Cargo Area Length @ Floor to Seat 2
35 in
Wheelbase
103 in
Width, Max w/o mirrors
71 in
Length, Overall
175 in

Safety

Stability Control
Standard

Steering

Lock to Lock Turns (Steering)
N/A
Steering Type
Pwr
Turning Diameter - Curb to Curb
37 ft
Turning Diameter - Wall to Wall
40 ft
Steering Ratio (:1), Overall
18

Suspension

Suspension Type - Rear
Multi-link
Suspension Type - Front (Cont.)
w/Coil Springs
Suspension Type - Rear (Cont.)
w/Coil Springs
Suspension Type - Front
MacPherson Strut

Tires & Wheels

Front Wheel Size
16 x 7.0 in
Rear Tire Size
P235/70R16
Spare Tire Size
Compact
Rear Wheel Material
Aluminum
Spare Wheel Material
Steel
Rear Wheel Size
16 x 7.0 in
Front Wheel Material
Aluminum
Front Tire Size
P235/70R16
Spare Wheel Size
17 x -TBD- in

Weight & Capacity

Wt Distributing Hitch - Max Trailer Wt.
1,500 lbs
Total Option Weight
0 lbs
Curb Weight - Rear
N/A
Dead Weight Hitch - Max Trailer Wt.
1,500 lbs
Fuel Tank Capacity, Approx
18 gal
Base Curb Weight
3,268 lbs
Maximum Payload Capacity
N/A
Curb Weight - Front
N/A
Dead Weight Hitch - Max Tongue Wt.
300 lbs
Aux Fuel Tank Capacity, Approx
N/A
Curb Weight
N/A
Wt Distributing Hitch - Max Tongue Wt.
300 lbs
Maximum Trailering Capacity
N/A
