2026 Ford F-350 XL specs & colors

Regular Cab Chassis-Cab

Change trim

$52,030

Starting MSRP
Current listing price

2026 Ford F-350 XL

Showing the 2026 Ford F-350 XL 2WD Reg Cab 145" WB 60" CA

Shop Now

Key specs

2-door
2 seats
335.0-hp, 7.3-liter, 8 Cylinder Engine (Gasoline Fuel)
0 combined MPG
230.7" length, 79.3" height
Rear Wheel Drive

Color options

Exterior

Cypress Green

Interior

Laguna Seca

Medium stone

Black

Packages

Order Code 640A

$0

Starting MSRP
XL Chrome Package

$425

Starting MSRP
- Halogen Fog Lamps
- Bright Grille
- Remote Start
See more detail
$425

Starting MSRP
- Halogen Fog Lamps
- Bright Grille
- Remote Start
- Chrome Front Bumper

Specifications

Highlights

Engine Type: Regular Gasoline V-8
MPG: -
Horsepower: 330 hp
335 hp
Seating Capacity: 2

Brakes

Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness: 14 in
Rear Brake Rotor Diam x Thickness: 14 in
Drum - Rear (Yes or ): N/A

Electrical

Cold Cranking Amps @ 0° F (Primary): 750
Maximum Alternator Capacity (amps): 190

Engine

Engine Type: Regular Gasoline V-8
Displacement: 7.3 L/445
SAE Net Horsepower @ RPM: 335 @ 3750
SAE Net Torque @ RPM: 468 @ 3750
Transmission Options: 10-Speed A/T
A/T
Transmission w/Dual Shift Mode
MPG: -
Total Cooling System Capacity: N/A

Measurements

Passenger Capacity: 3
Cargo Box Width @ Floor: N/A
Cargo Box Width @ Wheelhousings: N/A
Cargo Box (Area) Height: N/A
Tailgate Width: N/A
Cargo Volume: N/A
Ext'd Cab Cargo Volume: N/A
Ground Clearance, Front: 8 in
Ground Clearance, Rear: 8 in
Cargo Box Width @ Top, Rear: N/A
Wheelbase: 145 in
Length, Overall w/o rear bumper: N/A
Length, Overall w/rear bumper: N/A
Length, Overall: 231 in
Width, Max w/o mirrors: 80 in
Height, Overall: 79 in
Overhang, Front: 38 in
Front Head Room: 41 in
Front Leg Room: 44 in
Front Shoulder Room: 67 in
Front Hip Room: 63 in
Second Head Room: N/A
Second Leg Room: N/A
Second Shoulder Room: N/A
Second Hip Room: N/A
Overhang, Rear w/o bumper: 47 in
Cab to End of Frame: 107 in
Ground to Top of Load Floor: N/A

Safety

Lane Departure Warning: Standard

Steering

Turning Diameter - Curb to Curb: 50 ft
Turning Diameter - Wall to Wall: N/A
Steering Ratio (:1), Overall: N/A
Steering Type: Re-Circulating Ball

Suspension

Suspension Type - Front: Other
Suspension Type - Rear: Leaf
Axle Type - Front: Independent
Axle Type - Rear: Rigid Axle

Tires & Wheels

Front Tire Size: LT245/75SR17
Rear Tire Size: LT245/75SR17
Spare Tire Size: N/A
Front Wheel Size: 17 X 6.5 in
Rear Wheel Size: 17 X 6.5 in
Spare Wheel Size: N/A
Front Wheel Material: Steel
Rear Wheel Material: Steel
Spare Wheel Material: N/A

Weight & Capacity

Base Curb Weight: 5,893 lbs
Curb Weight - Front: 3,290 lbs
Curb Weight - Rear: 2,603 lbs
Option Weight - Front: 0 lbs
Option Weight - Rear: 0 lbs
As Spec'd Curb Weight: 5,893 lbs
Gross Axle Weight Rating: 14,400 lbs
Curb Weight: 5,893 lbs
Total Option Weight: 0 lbs
Gross Vehicle Weight Rating: 14,000 lbs
Fuel Tank Capacity, Approx: 40 gal
Aux Fuel Tank Capacity, Approx: N/A
As Spec'd Payload: 8,107 lbs
Maximum Payload Capacity: 8,107 lbs
Gross Combined Wt Rating: 23,500 lbs
Dead Weight Hitch - Max Trailer Wt.: 5,000 lbs
Dead Weight Hitch - Max Tongue Wt.: 500 lbs
Wt Distributing Hitch - Max Trailer Wt.: 16,400 lbs
Wt Distributing Hitch - Max Tongue Wt.: 1,640 lbs
Fifth Wheel Hitch - Max Trailer Wt.: 16,200 lbs
Fifth Wheel Hitch - Max Tongue Wt.: 4,050 lbs
Maximum Trailering Capacity: 16,400 lbs
