2014 Ford F-450 Lariat specs & colors
Crew Cab Pickup
MSRP
- 4WD Crew Cab 172" XL
- $50,560
- 4WD Crew Cab 172" XLT
- $55,390
- 4WD Crew Cab 172" Lariat
- $61,445
- 4WD Crew Cab 172" King Ranch
- $66,835
- 4WD Crew Cab 172" Platinum
- $67,530
$61,445
Starting MSRP
Current listing price
Current listing price
Showing the 2014 Ford F-450 4WD Crew Cab 172" Lariat
Shop NowKey specs
Color options
Interior
Black
Adobe
Charcoal black & grabber blue accents
Light Sand
Packages
$0
Starting MSRP
Specifications
Highlights
|
Intercooled Turbo Diesel V-8
Engine Type
|
|
-
MPG
|
|
400 hp
Horsepower
|
|
6
Seating Capacity
|
Brakes
|
4-Wheel Disc
Brake Type
|
|
14 in
Front Brake Rotor Diam x Thickness
|
|
14 in
Rear Brake Rotor Diam x Thickness
|
|
Yes
Disc - Front (Yes or )
|
|
Not Available
Drum - Rear (Yes or )
|
|
4-Wheel
Brake ABS System (Second Line)
|
|
Yes
Disc - Rear (Yes or )
|
|
4-Wheel
Brake ABS System
|
Electrical
|
750
Cold Cranking Amps @ 0° F (Primary)
|
|
200
Maximum Alternator Capacity (amps)
|
Engine
|
800 @ 1600
SAE Net Torque @ RPM
|
|
6.7 L/406
Displacement
|
|
Intercooled Turbo Diesel V-8
Engine Type
|
|
400 @ 2800
SAE Net Horsepower @ RPM
|
|
6-Speed A/T
A/T Transmission w/Dual Shift Mode Transmission Options
|
|
-
MPG
|
|
N/A
Total Cooling System Capacity
|
Measurements
|
51 in
Cargo Box Width @ Wheelhousings
|
|
42 in
Second Leg Room
|
|
N/A
Cab to End of Frame
|
|
N/A
Length, Overall w/rear bumper
|
|
80 in
Height, Overall
|
|
N/A
Length, Overall w/o rear bumper
|
|
172 in
Wheelbase
|
|
5
Passenger Capacity
|
|
263 in
Length, Overall
|
|
68 in
Front Shoulder Room
|
|
68 in
Front Hip Room
|
|
N/A
Overhang, Front
|
|
96 in
Width, Max w/o mirrors
|
|
68 in
Second Hip Room
|
|
8 in
Ground Clearance, Rear
|
|
41 in
Front Head Room
|
|
98 in
Cargo Box Length @ Floor
|
|
69 in
Cargo Box Width @ Top, Rear
|
|
69 in
Cargo Box Width @ Floor
|
|
77 ft³
Cargo Volume
|
|
41 in
Second Head Room
|
|
8 in
Ground Clearance, Front
|
|
20 in
Cargo Box (Area) Height
|
|
41 in
Front Leg Room
|
|
35 in
Ground to Top of Load Floor
|
|
61 in
Tailgate Width
|
|
N/A
Overhang, Rear w/o bumper
|
|
68 in
Second Shoulder Room
|
|
N/A
Ext'd Cab Cargo Volume
|
Safety
|
Optional
Backup Camera
|
Steering
|
N/A
Turning Diameter - Wall to Wall
|
|
N/A
Steering Ratio (:1), Overall
|
|
50 ft
Turning Diameter - Curb to Curb
|
|
Re-Circulating Ball
Steering Type
|
Suspension
|
Non-Independent
Axle Type - Front
|
|
Rigid Axle
Axle Type - Rear
|
|
Other
Suspension Type - Front
|
|
Leaf
Suspension Type - Rear
|
Tires & Wheels
|
Forged Aluminum
Rear Wheel Material
|
|
Steel
Spare Wheel Material
|
|
17 X 6.5 in
Rear Wheel Size
|
|
Full-Size in
Spare Wheel Size
|
|
LT245/75SR17
Rear Tire Size
|
|
LT245/75SR17
Front Tire Size
|
|
Forged Aluminum
Front Wheel Material
|
|
Full-Size
Spare Tire Size
|
|
17 X 6.5 in
Front Wheel Size
|
Weight & Capacity
|
8,190 lbs
As Spec'd Curb Weight
|
|
0 lbs
Total Option Weight
|
|
N/A
Aux Fuel Tank Capacity, Approx
|
|
24,700 lbs
Fifth Wheel Hitch - Max Trailer Wt.
|
|
33,000 lbs
Gross Combined Wt Rating
|
|
5,810 lbs
Maximum Payload Capacity
|
|
1,850 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
|
0 lbs
Option Weight - Front
|
|
4,764 lbs
Curb Weight - Front
|
|
18,500 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
14,000 lbs
Gross Vehicle Weight Rating
|
|
0 lbs
Option Weight - Rear
|
|
8,190 lbs
Curb Weight
|
|
500 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
5,000 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
15,040 lbs
Gross Axle Weight Rating
|
|
5,810 lbs
As Spec'd Payload
|
|
38 gal
Fuel Tank Capacity, Approx
|
|
18,500 lbs
Maximum Trailering Capacity
|
|
8,190 lbs
Base Curb Weight
|
|
6,175 lbs
Fifth Wheel Hitch - Max Tongue Wt.
|
|
3,426 lbs
Curb Weight - Rear
|
