2023 Ford F-450 XLT specs & colors

Regular Cab Pickup

Change trim

$65,695

Starting MSRP
Current listing price

Showing the 2023 Ford F-450 XLT 4WD Reg Cab 8' Box

Shop Now

Key specs

2-door
3 seats
500.0-hp, 6.7-liter, 8 Cylinder Engine (Diesel Fuel)
0 combined MPG
231.8" length, 81.7" height
Four Wheel Drive

Color options

Exterior

Rapid Red Metallic Tinted Clearcoat

Interior

Baja

Medium stone

Packages

Snow Plow/Camper Package

$305

Starting MSRP
- computer selected springs for snowplow application and heavy service front springs (1 up upgrade above the spring computer selected as a consequence of options chosen
- Not included if maximum springs have been computer selected as standard equipment)
- rear auxiliary springs and slide-in camper certification
See more detail
$305

Starting MSRP
- computer selected springs for snowplow application and heavy service front springs (1 up upgrade above the spring computer selected as a consequence of options chosen
- Not included if maximum springs have been computer selected as standard equipment)
- rear auxiliary springs and slide-in camper certification
- Note: Salesperson's Source Book or Ford RV Trailer Towing Guide should be consulted for specific trailer towing or camper limits and corresponding required equipment
- axle ratios and model availability
- Restrictions apply; see Supplemental Reference or Body Builders Layout Book for details
- Expect firmer ride when vehicle is not equipped w/snowplow and/or camper
- May result in deterioration of ride quality when vehicle is not equipped w/snowplow and/or camper
- See Body Builders Layout Book for details
- Rear Stabilizer Bar
Tow Technology Package

$1,035

Starting MSRP
- Pro Trailer Backup Assist
- trailer reverse guidance
- Pro Trailer Hitch Assist
360-Degree Camera Package

$1,150

Starting MSRP
- wired auxiliary trailer camera compatibility
- Rear Parking Sensors
- reverse sensing system w/reverse brake assist
See more detail
$1,150

Starting MSRP
- wired auxiliary trailer camera compatibility
- Rear Parking Sensors
- reverse sensing system w/reverse brake assist
- LED Center High-Mounted Stop Lamp (CHMSL) Camera
- LED center high-mounted stop lamp (CHMSL)
- 360-Degree Camera System
- picture in picture capability
- BLIS w/Cross-Traffic Alert
- trailer coverage

Order Code 673A

$0

Starting MSRP
FX4 Off-Road Package

$495

Starting MSRP
- Hill Descent Control
- Off-Road Specifically Tuned Shock Absorbers
- front/rear
See more detail
$495

Starting MSRP
- Hill Descent Control
- Off-Road Specifically Tuned Shock Absorbers
- front/rear
- Transfer Case & Fuel Tank Skid Plates
- Unique FX4 Off-Road Box Decal

Specifications

Highlights

Engine Type: Intercooled Turbo Diesel V-8
MPG: -
Horsepower: 475 hp
500 hp
Seating Capacity: 3

Brakes

Drum - Rear (Yes or ): N/A
Rear Brake Rotor Diam x Thickness: 16 in
Front Brake Rotor Diam x Thickness: 15 in
Disc - Rear (Yes or ): Yes
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes

Electrical

Cold Cranking Amps @ 0° F (Primary): 750
Maximum Alternator Capacity (amps): 190

Engine

SAE Net Torque @ RPM: 1050 @ 1600
SAE Net Horsepower @ RPM: 475 @ 2600
Displacement: 6.7 L/406
Engine Type: Intercooled Turbo Diesel V-8
Transmission Options: 10-Speed A/T
A/T
Transmission w/Dual Shift Mode
MPG: -
Total Cooling System Capacity: N/A

Entertainment

Bluetooth®: Standard

Measurements

Ext'd Cab Cargo Volume: N/A
Cargo Volume: 79 ft³
Tailgate Width: 61 in
Cargo Box (Area) Height: 21 in
Cargo Box Width @ Wheelhousings: 51 in
Cargo Box Width @ Floor: 67 in
Cargo Box Width @ Top, Rear: 67 in
Cargo Box Length @ Floor: 98 in
Ground Clearance, Rear: 9 in
Ground Clearance, Front: 9 in
Passenger Capacity: 3
Ground to Top of Load Floor: 38 in
Cab to End of Frame: N/A
Overhang, Rear w/o bumper: N/A
Overhang, Front: 38 in
Height, Overall: 82 in
Width, Max w/o mirrors: 96 in
Length, Overall: 232 in
Length, Overall w/rear bumper: N/A
Length, Overall w/o rear bumper: N/A
Wheelbase: 142 in
Second Hip Room: N/A
Second Shoulder Room: N/A
Second Leg Room: N/A
Front Head Room: 41 in
Second Head Room: N/A
Front Hip Room: 63 in
Front Shoulder Room: 67 in
Front Leg Room: 44 in

Safety

Stability Control: Standard
Backup Camera: Standard

Steering

Steering Type: Re-Circulating Ball
Steering Ratio (:1), Overall: N/A
Turning Diameter - Curb to Curb: 48 ft
Turning Diameter - Wall to Wall: N/A

Suspension

Suspension Type - Front: Other
Suspension Type - Rear: Leaf
Axle Type - Front: Non-Independent
Axle Type - Rear: Rigid Axle

Tires & Wheels

Front Tire Size: LT225/70SR19.5
Rear Tire Size: LT225/70SR19.5
Spare Tire Size: Full-Size
Front Wheel Size: 19.5 X 6 in
Rear Wheel Size: 19.5 X 6 in
Spare Wheel Size: Full-Size in
Front Wheel Material: Forged Aluminum
Rear Wheel Material: Forged Aluminum
Spare Wheel Material: Steel

Weight & Capacity

Base Curb Weight: 8,053 lbs
Curb Weight - Front: 4,562 lbs
Curb Weight - Rear: 3,491 lbs
Option Weight - Front: 0 lbs
Option Weight - Rear: 0 lbs
As Spec'd Curb Weight: 8,053 lbs
As Spec'd Payload: 5,947 lbs
Maximum Payload Capacity: 5,947 lbs
Maximum Trailering Capacity: 25,000 lbs
Fifth Wheel Hitch - Max Tongue Wt.: 8,750 lbs
Fifth Wheel Hitch - Max Trailer Wt.: 35,000 lbs
Wt Distributing Hitch - Max Tongue Wt.: 2,500 lbs
Wt Distributing Hitch - Max Trailer Wt.: 25,000 lbs
Dead Weight Hitch - Max Tongue Wt.: 500 lbs
Dead Weight Hitch - Max Trailer Wt.: 5,000 lbs
Gross Combined Wt Rating: 46,700 lbs
Gross Vehicle Weight Rating: 14,000 lbs
Total Option Weight: 0 lbs
Curb Weight: 8,053 lbs
Gross Axle Weight Rating: 15,500 lbs
Aux Fuel Tank Capacity, Approx: N/A
Fuel Tank Capacity, Approx: 29 gal
