2004 Ford Ranger XLT Appearance specs & colors
Extended Cab Pickup
MSRP
- Reg Cab 2.3L XL
- $14,575
- Reg Cab 3.0L XL
- $14,965
- Reg Cab LWB 3.0L XL
- $15,745
- Reg Cab 2.3L XLT
- $16,085
- Reg Cab 3.0L Edge
- $16,450
- Reg Cab 3.0L XLT
- $16,800
- 2dr Supercab 3.0L XL
- $17,965
- 2dr Supercab 3.0L XLT
- $18,120
- Reg Cab LWB 3.0L XLT
- $18,430
- 2dr Supercab 3.0L Edge
- $18,520
- 2dr Supercab 4.0L Edge
- $19,240
- Reg Cab 3.0L Edge Plus 4WD
- $20,515
- 2dr Supercab 4.0L XLT Value 4WD
- $20,540
- 2dr Supercab 3.0L Tremor
- $20,580
- 4dr Supercab 3.0L XLT Appearance
- $21,160
- 4dr Supercab 3.0L Edge Deluxe
- $21,805
- 2dr Supercab 4.0L XLT 4WD
- $21,945
- 4dr Supercab 4.0L XLT Appearance
- $22,245
- 4dr Supercab 3.0L Tremor Plus
- $22,555
- 4dr Supercab 4.0L Edge 4WD
- $22,760
- 4dr Supercab 4.0L XLT 4WD
- $23,605
- 4dr Supercab 4.0L Tremor Plus 4WD
- $24,620
- 4dr Supercb 4.0L XLT FX4 Off-Rd 4WD
- $24,760
- 4dr Supercb 4.0L XLT FX4 Lvl II 4WD
- $26,015
$22,245
Starting MSRP
Current listing price
Current listing price
Showing the 2004 Ford Ranger 4dr Supercab 4.0L XLT Appearance
Shop 2004 Ford Ranger
Key specs
Color options
Interior
Gray
Mocha
Packages
$0
Starting MSRP
Specifications
Highlights
|
Gas V6
Engine Type
|
|
17 City / 22 Hwy
MPG
|
|
207 hp
Horsepower
|
|
4
Seating Capacity
|
Brakes
|
11.28 x 1.02 in
Front Brake Rotor Diam x Thickness
|
|
Yes
Drum - Rear (Yes or )
|
|
Not Available in
Rear Brake Rotor Diam x Thickness
|
|
Not Available
Disc - Rear (Yes or )
|
|
Yes
Disc - Front (Yes or )
|
|
Not Available
Brake ABS System (Second Line)
|
|
4-Wheel
Brake ABS System
|
|
Power
Brake Type
|
Electrical
|
95
Maximum Alternator Capacity (amps)
|
|
540
Cold Cranking Amps @ 0° F (Primary)
|
Engine
|
238 @ 3000
SAE Net Torque @ RPM
|
|
207 @ 5250
SAE Net Horsepower @ RPM
|
|
4.0L/245
Displacement
|
|
Gas V6
Engine Type
|
|
A/T
5-Speed A/T Transmission Options
|
|
17 City / 22 Hwy
MPG
|
|
7.8 qts
Total Cooling System Capacity
|
Measurements
|
42 in
Front Leg Room
|
|
39 in
Front Head Room
|
|
54 in
Front Shoulder Room
|
|
5
Passenger Capacity
|
|
126 in
Wheelbase
|
|
203 in
Length, Overall w/o rear bumper
|
|
N/A
Length, Overall w/rear bumper
|
|
N/A
Length, Overall
|
|
69 in
Width, Max w/o mirrors
|
|
65 in
Height, Overall
|
|
33 in
Overhang, Front
|
|
44 in
Overhang, Rear w/o bumper
|
|
N/A
Cab to End of Frame
|
|
28 in
Ground to Top of Load Floor
|
|
N/A
Ground Clearance, Front
|
|
7 in
Ground Clearance, Rear
|
|
72 in
Cargo Box Length @ Floor
|
|
N/A
Cargo Box Width @ Top, Rear
|
|
52 in
Cargo Box Width @ Floor
|
|
40 in
Cargo Box Width @ Wheelhousings
|
|
17 in
Cargo Box (Area) Height
|
|
52 in
Tailgate Width
|
|
37 ft³
Cargo Volume
|
|
N/A
Ext'd Cab Cargo Volume
|
|
53 in
Front Hip Room
|
|
36 in
Second Head Room
|
|
40 in
Second Leg Room
|
|
15 in
Second Shoulder Room
|
|
20 in
Second Hip Room
|
Steering
|
45 ft
Turning Diameter - Wall to Wall
|
|
43 ft
Turning Diameter - Curb to Curb
|
|
N/A
Steering Ratio (:1), Overall
|
|
Pwr Rack & Pinion
Steering Type
|
Suspension
|
Ford Semi-Floating
Axle Type - Rear
|
|
Independent SLA
Axle Type - Front
|
|
2-Stage Multi-Leaf
Suspension Type - Rear
|
|
Coil Spring
Suspension Type - Front
|
Tires & Wheels
|
Steel
Spare Wheel Material
|
|
Steel
Rear Wheel Material
|
|
Steel
Front Wheel Material
|
|
Compact in
Spare Wheel Size
|
|
15 x 6.0 in
Rear Wheel Size
|
|
15 x 6.0 in
Front Wheel Size
|
|
Compact
Spare Tire Size
|
|
P225/70R15
Rear Tire Size
|
|
P225/70R15
Front Tire Size
|
Weight & Capacity
|
Not Available gal
Aux Fuel Tank Capacity, Approx
|
|
20 gal
Fuel Tank Capacity, Approx
|
|
900 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
|
6,000 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
200 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
2,000 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
9,500 lbs
Gross Combined Wt Rating
|
|
1,614 lbs
Maximum Payload Capacity
|
|
1,614 lbs
As Spec'd Payload
|
|
3,166 lbs
As Spec'd Curb Weight
|
|
0 lbs
Option Weight - Rear
|
|
0 lbs
Option Weight - Front
|
|
1,364 lbs
Curb Weight - Rear
|
|
1,802 lbs
Curb Weight - Front
|
|
N/A
Base Curb Weight
|
|
N/A
Maximum Trailering Capacity
|
|
Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt.
|
|
Not Available lbs
Fifth Wheel Hitch - Max Trailer Wt.
|
|
5,350 lbs
Gross Axle Weight Rating
|
|
3,166 lbs
Curb Weight
|
|
0 lbs
Total Option Weight
|
|
4,780 lbs
Gross Vehicle Weight Rating
|
