2007 GMC Canyon Work Truck specs & colors

Regular Cab Pickup

Change trim

$14,235

Starting MSRP
Current listing price

2007 GMC Canyon Work Truck

Showing the 2007 GMC Canyon 2WD Reg Cab 111.2" Work Truck

Shop Now

No inventory available.
Shop 2007 GMC Canyon

Key specs

2-door
3 seats
185.0-hp, 2.9-liter, 4 Cylinder Engine (Gasoline Fuel)
0 combined MPG
192.4" length, 67.6" height
Rear Wheel Drive

Color options

Exterior

Copper Sunburst

Interior

Black

Charcoal

Sage

Pewter Gray

Packages

Specifications

Highlights

Engine Type: Gas I4
MPG: 17 City / 24 Hwy
Horsepower: 242 hp
185 hp
Seating Capacity: 3

Brakes

Front Brake Rotor Diam x Thickness: 11.2 x 1.1 in
Rear Brake Rotor Diam x Thickness: Not Available in
Drum - Rear (Yes or ): Yes
Brake Type: Pwr
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): Not Available
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Not Available

Electrical

Cold Cranking Amps @ 0° F (Primary): 690
Maximum Alternator Capacity (amps): 125

Engine

Engine Type: Gas I4
Displacement: 2.9L/177
SAE Net Horsepower @ RPM: 185 @ 5600
SAE Net Torque @ RPM: 190 @ 2800
Transmission Options: M/T
A/T
5-Speed M/T
4-Speed A/T
MPG: 17 City / 24 Hwy
Total Cooling System Capacity: N/A

Measurements

Passenger Capacity: 3
Front Head Room: 40 in
Front Leg Room: 42 in
Front Shoulder Room: 57 in
Front Hip Room: 53 in
Wheelbase: 111 in
Ext'd Cab Cargo Volume: Not Available ft³
Cargo Volume: 44 ft³
Tailgate Width: 52 in
Cargo Box (Area) Height: 19 in
Cargo Box Width @ Wheelhousings: 43 in
Cargo Box Width @ Floor: 57 in
Cargo Box Width @ Top, Rear: Not Available in
Cargo Box Length @ Floor: 73 in
Ground Clearance, Rear: N/A
Ground Clearance, Front: 7 in
Ground to Top of Load Floor: 28 in
Cab to End of Frame: N/A
Overhang, Rear w/o bumper: N/A
Height, Overall: 66 in
Width, Max w/o mirrors: 68 in
Length, Overall: N/A
Length, Overall w/rear bumper: N/A
Length, Overall w/o rear bumper: 192 in
Second Head Room: N/A
Second Leg Room: N/A
Second Shoulder Room: N/A
Second Hip Room: N/A
Overhang, Front: 34 in

Steering

Steering Type: Pwr
Steering Ratio (:1), Overall: N/A
Turning Diameter - Curb to Curb: 39 ft
Turning Diameter - Wall to Wall: Not Available ft

Suspension

Suspension Type - Front: Coil Springs
Suspension Type - Rear: 2-Stage Multi-Leaf
Axle Type - Front: Independent
Axle Type - Rear: Semi-Floating

Tires & Wheels

Front Wheel Size: 15 x 6 in
Rear Wheel Size: 15 x 6 in
Spare Wheel Size: Compact in
Front Wheel Material: Steel
Rear Wheel Material: Steel
Front Tire Size: P205/75R15
Rear Tire Size: P205/75R15
Spare Tire Size: Compact
Spare Wheel Material: Steel

Weight & Capacity

Maximum Payload Capacity: 1,610 lbs
As Spec'd Payload: 1,610 lbs
As Spec'd Curb Weight: 3,240 lbs
Option Weight - Rear: 0 lbs
Option Weight - Front: 0 lbs
Curb Weight - Rear: 1,393 lbs
Curb Weight - Front: 1,847 lbs
Base Curb Weight: N/A
Gross Combined Wt Rating: 6,000 lbs
Dead Weight Hitch - Max Trailer Wt.: N/A
Dead Weight Hitch - Max Tongue Wt.: N/A
Wt Distributing Hitch - Max Trailer Wt.: 2,300 lbs
Wt Distributing Hitch - Max Tongue Wt.: 345 lbs
Fifth Wheel Hitch - Max Trailer Wt.: Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt.: Not Available lbs
Maximum Trailering Capacity: N/A
Gross Vehicle Weight Rating: 4,850 lbs
Total Option Weight: 0 lbs
Curb Weight: 3,240 lbs
Gross Axle Weight Rating: 5,429 lbs
Fuel Tank Capacity, Approx: 19 gal
Aux Fuel Tank Capacity, Approx: N/A
