2022 GMC Canyon 4WD AT4 w/Cloth specs & colors

Crew Cab Pickup

Change trim
MSRP
2WD Ext Cab 128" Elevation Standard
$27,500
2WD Crew Cab 128" Elevation Standard
$29,400
2WD Ext Cab 128" Elevation
$32,500
4WD Ext Cab 128" Elevation Standard
$32,900
2WD Crew Cab 128" Elevation
$34,400
4WD Crew Cab 128" Elevation
$39,500
4WD Crew Cab 141" Elevation
$40,100
4WD Crew Cab 128" AT4 w/Cloth
$40,600
4WD Crew Cab 141" AT4 w/Cloth
$41,200
4WD Crew Cab 128" AT4 w/Leather
$42,400
4WD Crew Cab 141" AT4 w/Leather
$43,000
2WD Crew Cab 128" Denali
$43,400
4WD Crew Cab 128" Denali
$46,900
4WD Crew Cab 141" Denali
$47,200
$41,200
Starting MSRP
Current listing price
2022 GMC Canyon 4WD AT4 w/Cloth

Showing the 2022 GMC Canyon 4WD Crew Cab 141" AT4 w/Cloth

Shop Now

Key specs

Color options

Interior
Jet Black / Kalahari

Packages

  • $0

    Starting MSRP

    • includes standard equipment

Specifications

Highlights

Gas V6
Engine Type
17 City / 24 Hwy
MPG
308 hp
181 hp
Horsepower
5
Seating Capacity

Brakes

Pwr
Brake Type
4-Wheel
Brake ABS System
N/A
Brake ABS System (Second Line)
Yes
Disc - Front (Yes or )
Yes
Disc - Rear (Yes or )
12.2 x -TBD- in
Front Brake Rotor Diam x Thickness
12.75 x -TBD- in
Rear Brake Rotor Diam x Thickness
N/A
Drum - Rear (Yes or )

Electrical

N/A
Cold Cranking Amps @ 0° F (Primary)
N/A
Maximum Alternator Capacity (amps)

Engine

275 @ 4000
SAE Net Torque @ RPM
308 @ 6800
SAE Net Horsepower @ RPM
3.6L/222
Displacement
Gas V6
Engine Type
6-Speed A/T
Transmission Overdrive Switch
8-Speed A/T
A/T
Transmission Options
17 City / 24 Hwy
MPG
N/A
Total Cooling System Capacity

Entertainment

Standard
Bluetooth®

Measurements

5
Passenger Capacity
41 in
Front Head Room
45 in
Front Leg Room
58 in
Front Shoulder Room
55 in
Front Hip Room
38 in
Second Head Room
36 in
Second Leg Room
56 in
Second Shoulder Room
53 in
Second Hip Room
141 in
Wheelbase
N/A
Length, Overall w/o rear bumper
N/A
Length, Overall w/rear bumper
225 in
Length, Overall
74 in
Width, Max w/o mirrors
71 in
Height, Overall
37 in
Overhang, Front
47 in
Overhang, Rear w/o bumper
N/A
Cab to End of Frame
N/A
Ground to Top of Load Floor
8 in
Ground Clearance, Front
8 in
Ground Clearance, Rear
74 in
Cargo Box Length @ Floor
N/A
Cargo Box Width @ Top, Rear
58 in
Cargo Box Width @ Floor
44 in
Cargo Box Width @ Wheelhousings
N/A
Cargo Box (Area) Height
N/A
Tailgate Width
50 ft³
Cargo Volume
N/A
Ext'd Cab Cargo Volume

Safety

Optional
Navigation System
Standard
Stability Control

Steering

Electric Rack & Pinion
Steering Type
N/A
Steering Ratio (:1), Overall
45 ft
Turning Diameter - Curb to Curb
N/A
Turning Diameter - Wall to Wall

Suspension

Independent Coil
Suspension Type - Front
2-Stage Multi-Leaf
Suspension Type - Rear
Independent
Axle Type - Front
Semi-Floating
Axle Type - Rear

Tires & Wheels

265/65R17
Front Tire Size
265/65R17
Rear Tire Size
255/65R17
Spare Tire Size
17 x 8 in
Front Wheel Size
17 x 8 in
Rear Wheel Size
17 x 8 in
Spare Wheel Size
Aluminum
Front Wheel Material
Aluminum
Rear Wheel Material
Steel
Spare Wheel Material

Weight & Capacity

7,550 lbs
Maximum Trailering Capacity
N/A
Fifth Wheel Hitch - Max Tongue Wt.
N/A
Fifth Wheel Hitch - Max Trailer Wt.
700 lbs
Wt Distributing Hitch - Max Tongue Wt.
7,000 lbs
Wt Distributing Hitch - Max Trailer Wt.
500 lbs
Dead Weight Hitch - Max Tongue Wt.
5,000 lbs
Dead Weight Hitch - Max Trailer Wt.
12,000 lbs
Gross Combined Wt Rating
1,846 lbs
Maximum Payload Capacity
1,524 lbs
As Spec'd Payload
4,476 lbs
As Spec'd Curb Weight
0 lbs
Option Weight - Rear
0 lbs
Option Weight - Front
1,745 lbs
Curb Weight - Rear
2,409 lbs
Curb Weight - Front
N/A
Base Curb Weight
6,700 lbs
Gross Axle Weight Rating
4,154 lbs
Curb Weight
0 lbs
Total Option Weight
21 gal
Fuel Tank Capacity, Approx
N/A
Aux Fuel Tank Capacity, Approx
6,000 lbs
Gross Vehicle Weight Rating
