2011 GMC Sierra 3500 SRW Work Truck specs & colors

Regular Cab Pickup

Change trim

MSRP
Change trim
$29,255
Starting MSRP
Current listing price
2011 GMC Sierra 3500 SRW Work Truck

Showing the 2011 GMC Sierra 3500 2WD Reg Cab 133.7" SRW Work Truck

Shop Now

Key specs

Color options

Interior

Dark Titanium

Packages

Specifications

Front Wheel Size 17 x 6.5 in
Rear Wheel Size 17 x 6.5 in
Spare Wheel Size 17 x -TBD- in
Front Wheel Material Steel
Rear Wheel Material Steel
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) 600
Maximum Alternator Capacity (amps) 125
Engine Type Gas V8
Displacement 6.0L/366
SAE Net Horsepower @ RPM 322 @ 4400
SAE Net Torque @ RPM 380 @ 4200
Engine Oil Cooler Yes
EPA Fuel Economy Est - Hwy Not Available MPG
Cruising Range - City 0.00 mi
EPA Fuel Economy Est - City Not Available MPG
Fuel Economy Est-Combined Not Available MPG
Cruising Range - Hwy 0.00 mi
Estimated Battery Range N/A mi
Drivetrain Rear Wheel Drive
Trans Type 6
Trans Description Cont. HD Automatic w/OD
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 4.03
Second Gear Ratio (:1) 2.36
Third Gear Ratio (:1) 1.53
Fourth Gear Ratio (:1) 1.15
Fifth Gear Ratio (:1) 0.85
Sixth Gear Ratio (:1) 0.67
Reverse Ratio (:1) 3.06
Trans Power Take Off Not Available
Final Drive Axle Ratio (:1) N/A
Transfer Case Model Not Available
Transfer Case Gear Ratio (:1), High Not Available
Transfer Case Gear Ratio (:1), Low Not Available
Transfer Case Power Take Off Not Available
Suspension Type - Front Independent
Suspension Type - Rear Multi-Leaf
Axle Type - Front Independent
Axle Type - Rear Full-Floating
Frame Type Hydroformed
Brake Type Pwr
Brake ABS System 4-Wheel
Brake ABS System (Second Line) Not Available
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.98 x 1.57 in
Rear Brake Rotor Diam x Thickness 13.98 x 1.57 in
Drum - Rear (Yes or ) Not Available
Fuel Tank Capacity, Approx 36 gal
Aux Fuel Tank Capacity, Approx Not Available gal
Steering Type Pwr Recirculating Ball
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 44.9 ft
Turning Diameter - Wall to Wall N/A ft
Front Tire Size LT235/80R17E
Rear Tire Size LT235/80R17E
Spare Tire Size Not Available
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Trailer Wt. 10000 lbs
Wt Distributing Hitch - Max Tongue Wt. 1500 lbs
Fifth Wheel Hitch - Max Trailer Wt. 10000 lbs
Fifth Wheel Hitch - Max Tongue Wt. 2500 lbs
Maximum Trailering Capacity 14500 lbs
Base Curb Weight N/A lbs
Curb Weight - Front 3141 lbs
Curb Weight - Rear 2627 lbs
Option Weight - Front 0.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Curb Weight 5768.00 lbs
As Spec'd Payload 7032.00 lbs
Maximum Payload Capacity 7032.00 lbs
Gross Combined Wt Rating 16000 lbs
Gross Axle Weight Rating 13775.00 lbs
Curb Weight 5768.00 lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 12800.00 lbs
Passenger Capacity 3
Front Head Room 41.3 in
Front Leg Room 41.3 in
Front Shoulder Room 65.2 in
Front Hip Room 60.3 in
Second Head Room N/A in
Second Leg Room N/A in
Second Shoulder Room N/A in
Second Hip Room N/A in
Wheelbase 133.7 in
Length, Overall w/o rear bumper 225.0 in
Length, Overall w/rear bumper N/A in
Length, Overall N/A in
Width, Max w/o mirrors 95.9 in
Height, Overall 77.4 in
Overhang, Front 38.8 in
Overhang, Rear w/o bumper 52.6 in
Cab to End of Frame N/A in
Ground to Top of Load Floor 37.9 in
Ground Clearance, Front 10.0 in
Ground Clearance, Rear 8.8 in
Cargo Box Length @ Floor 97.8 in
Cargo Box Width @ Top, Rear N/A in
Cargo Box Width @ Floor 62.5 in
Cargo Box Width @ Wheelhousings 50.6 in
Cargo Box (Area) Height 21.0 in
Tailgate Width 61.6 in
Cargo Volume 75.5 ft³
Ext'd Cab Cargo Volume Not Available ft³
Warning tones headlamp on, key-in-ignition, driver and passenger buckle up reminder and turn signal on Standard
Differential, heavy-duty automatic locking rear (Included with (Z82) trailering equipment on Retail Orders only. Standard with single rear wheel GVWR.) Standard
Battery, heavy-duty 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power Standard
Audio system, AM/FM stereo with seek-and-scan and digital clock (Not available with (U2K) XM Radio) Standard
Seats, front 40/20/40 split-bench, 3-passenger, driver and front passenger manual reclining with outboard head restraints and center fold-down armrest with storage Standard
Tailgate protection top of tailgate protection cap Standard
Coat hooks, rear driver and passenger side Standard
Recovery hooks, front, frame-mounted Standard
Engine, Vortec 6.0L Variable Valve Timing V8 SFI (322 hp [240.1 kW] @ 4400 rpm, 380 lb-ft of torque [513.0 N-m] @ 4200 rpm) Standard
Tire carrier, outside spare, winch-type mounted under frame at rear (Orders with (ZW9) Pickup box delete will not include a Spare Tire Carrier unless a spare tire is ordered) Standard
Steering, power, recirculating ball Standard
Daytime Running Lamps with automatic exterior lamp control Standard
Frame, fully-boxed, hydroformed front section Standard
Air bags, frontal, driver and right-front passenger (Always use safety belts and the correct child restraints for your child's age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicle's Owners Manual and child safety seat instructions for more safety information) Standard
Suspension Package, Handling/Trailering, heavy-duty includes 35mm monotube shocks and 34mm front stabilizer bar Standard
Cup holders, front (Also includes rear cupholders on Extended and Crew Cab models) Standard
Seat trim, Vinyl Standard
Suspension, front independent, torsion bar with increased front GAWR Standard
Air cleaner, high-capacity Standard
Mirror, inside rearview manual day/night Standard
StabiliTrak, stability control system includes electronic trailer sway control, intelligent brake assist and hill start assist (Standard on single rear wheel GVWR only.) Standard
Wheels, 18" (45.7 cm) painted steel includes painted center caps and a steel spare. Spare not included with (ZW9) pickup box delete unless a spare tire is ordered (Included with (L96) Vortec 6.0L V8 SFI engine. Available with (LML/LGH) Duramax 6.6L Turbo Diesel V8 engine. Not available with (9F6) 12,800 lbs. GVWR or (C7J) 13,000 lbs. GVWR (dual rear wheel).) Standard
Driver Information Center with odometer, trip odometer and message center (monitors numerous systems depending on vehicle equipment level including low fuel, turn signal "on", transmission temperature and oil change notification) (Driver Information Center controls are operated through the trip button unless (UK3) steering wheel mounted audio controls is ordered. On 3SA and 4SA, includes 8-point compass and outside temperature.) Standard
Glass, Solar-Ray light-tinted, all windows Standard
Steering wheel includes theft-deterrent locking feature Standard
Rear wheel drive Standard
Suspension, rear 4+1+2 multi-leaf springs for single rear wheel and 3+1+2 multi-leaf springs for dual rear wheel Standard
Exhaust aluminized stainless-steel muffler and tailpipe Standard
Lighting, interior with dome and reading lights, illuminated entry feature and backlit instrument panel switches Standard
Bumper, front chrome includes body-color bumper top caps Standard
Alternator, 125 amps Standard
Transmission, 6-speed automatic, heavy-duty electronically controlled with overdrive and tow/haul mode (Requires (L96) Vortec 6.0L V8 SFI engine.) Standard
Air conditioning, single-zone manual front climate control Standard
Tires, LT265/70R18E all-season, blackwall (Not available with (9F6) 12,800 lbs. GVWR or (C7J) 13,000 lbs. GVWR (dual rear wheel). Included with (PYT) 18" (45.7 cm) painted steel wheels.) Standard
Steering column, Tilt-Wheel, adjustable with brake/transmission shift interlock Standard
Wipers, front intermittent wet-arm with pulse washers Standard
Cooling, external engine oil cooler heavy-duty air-to-oil, integral to driver side of radiator tank Standard
Headliner, Opal Gray-colored cloth with matching retainer moldings Standard
Audio system feature, 4-speaker system (Requires Regular Cab models) Standard
Floor covering, Black rubberized vinyl Standard
Pickup box, Wideside Standard
Instrumentation, analog with speedometer, fuel level, engine temperature, tachometer, voltmeter and oil pressure indicators Standard
Grille, chrome surround Standard
Visors, driver and front passenger, sliding with clip and passenger side vanity mirror with cover, Opal Gray-colored Standard
Lamps, dual cargo area lamps Standard
Power outlets 2 auxiliary instrument panel-mounted with covers, 12-volt Standard
Bumper, rear chrome, step-style with pad (Not available with (ZW9) pickup box delete) Standard
Assist handle, front passenger (Also includes rear assist handles in the headliner on Extended and Crew Cab models) Standard
XM Radio, delete Standard
Brakes, 4-wheel antilock, 4-wheel disc with single rear wheels Standard
Mirrors, outside manual, Black, manual-folding Standard
Headlamps, dual halogen composite with automatic exterior lamp control and flash-to-pass feature Standard
Cooling, auxiliary external transmission oil cooler heavy-duty air-to-oil Standard
OnStar, delete Standard
