2027 GMC Yukon XL Elevation specs & colors

Sport Utility

Change trim

$73,200

Starting MSRP
Current listing price

2027 GMC Yukon XL Elevation

Showing the 2027 GMC Yukon XL 2WD 4dr Elevation

Shop Now

No inventory available.
See all cars for sale

Key specs

4-door
7 seats
305.0-hp, 3.0-liter, Straight 6 Cylinder Engine (Diesel Fuel)
17 combined MPG
225.2" length, 76.5" height
Rear Wheel Drive

Color options

Exterior

Moonstone Gray Metallic

Interior

Ebony

Gideon / Very Dark Atmosphere

Packages

Elevation Preferred Equipment Group

$0

Starting MSRP
- includes standard equipment

Specifications

Highlights

Engine Type: Gas V8
MPG: 15 City / 20 Hwy
Horsepower: 355 hp
305 hp
Seating Capacity: 7

Brakes

Rear Brake Rotor Diam x Thickness: 13.6 x 1.0 in
Brake ABS System (Second Line): N/A
Brake Type: Pwr
Brake ABS System: 4-Wheel
Front Brake Rotor Diam x Thickness: 13.5 x 1.2 in
Disc - Rear (Yes or ): Yes
Drum - Rear (Yes or ): N/A
Disc - Front (Yes or ): Yes

Electrical

Cold Cranking Amps @ 0° F (Primary): 730
Maximum Alternator Capacity (amps): 220

Engine

SAE Net Horsepower @ RPM: 355 @ 5600
SAE Net Torque @ RPM: 383 @ 4100
Engine Type: Gas V8
Displacement: 5.3L/-TBD-
Transmission Options: 10-Speed A/T
A/T
MPG: 15 City / 20 Hwy
Total Cooling System Capacity: N/A

Measurements

Cargo Area Length @ Floor to Seat 1: N/A
Rear Door Opening Height: N/A
Third Hip Room: 49 in
Side Door Opening Height: N/A
Cargo Box Width @ Top, Rear: N/A
Front Head Room: 42 in
Step Up Height - Front: N/A
Cargo Area Length @ Floor to Console: N/A
Rear Door Opening Width: N/A
Ground Clearance, Front: N/A
Width, Max w/o mirrors: 81 in
Height, Overall: 77 in
Third Shoulder Room: 63 in
Passenger Capacity: 8
Cargo Area Width @ Beltline: N/A
Front Hip Room: 62 in
Cargo Volume to Seat 2: 94 ft³
Second Leg Room: 42 in
Cargo Area Length @ Floor to Seat 3: N/A
Front Shoulder Room: 66 in
Cargo Area Length @ Floor to Seat 2: N/A
Tailgate Width: N/A
Cargo Box Width @ Wheelhousings: 50 in
Cargo Volume: N/A
Cargo Box (Area) Height: N/A
Second Shoulder Room: 65 in
Wheelbase: 134 in
Third Leg Room: 37 in
Length, Overall w/rear bumper: N/A
Cargo Volume to Seat 1: 145 ft³
Second Hip Room: 61 in
Cargo Volume to Seat 4: N/A
Ground Clearance, Rear: N/A
Ground to Top of Load Floor: N/A
Side Door Opening Width: N/A
Cargo Volume to Seat 3: 42 ft³
Second Head Room: 39 in
Front Leg Room: 45 in
Overhang, Rear w/o bumper: N/A
Overhang, Front: N/A
Ext'd Cab Cargo Volume: N/A
Step Up Height - Side: N/A
Third Head Room: 38 in
Length, Overall: 225 in
Cab to End of Frame: N/A
Cargo Box Width @ Floor: N/A

Safety

Brake Assist: Standard
Automatic Parking: Standard
Navigation System: Standard
Third Row Seating: Standard
Lane Departure Warning: Standard
Rear Cross Traffic Alert: Standard

Steering

Steering Type: Pwr Rack & Pinion
Turning Diameter - Curb to Curb: 43 ft
Turning Diameter - Wall to Wall: N/A
Steering Ratio (:1), Overall: N/A

Suspension

Suspension Type - Front: Coil-Over Shock
Axle Type - Rear: Semi-Floating
Suspension Type - Rear: Multi-Link
Axle Type - Front: Independent

Tires & Wheels

Front Wheel Size: 20 x 9 in
Front Tire Size: 275/60R20SL
Spare Wheel Size: 17 x -TBD- in
Rear Wheel Size: 20 x 9 in
Spare Tire Size: P265/70R17
Front Wheel Material: Aluminum
Rear Tire Size: 275/60R20SL
Spare Wheel Material: Steel
Rear Wheel Material: Aluminum

Weight & Capacity

Wt Distributing Hitch - Max Trailer Wt.: 7,700 lbs
Base Curb Weight: N/A
Fifth Wheel Hitch - Max Trailer Wt.: N/A
Curb Weight: 5,530 lbs
Wt Distributing Hitch - Max Tongue Wt.: 770 lbs
Dead Weight Hitch - Max Trailer Wt.: 5,000 lbs
Fuel Tank Capacity, Approx: 28 gal
Option Weight - Front: 0 lbs
Maximum Trailering Capacity: 8,200 lbs
As Spec'd Curb Weight: 5,530 lbs
Total Option Weight: 0 lbs
Gross Vehicle Weight Rating: 7,600 lbs
Option Weight - Rear: 0 lbs
Fifth Wheel Hitch - Max Tongue Wt.: N/A
As Spec'd Payload: 2,070 lbs
Gross Axle Weight Rating: 8,000 lbs
Aux Fuel Tank Capacity, Approx: N/A
Curb Weight - Rear: 2,696 lbs
Curb Weight - Front: 2,834 lbs
Maximum Payload Capacity: 2,070 lbs
Dead Weight Hitch - Max Tongue Wt.: 500 lbs
Gross Combined Wt Rating: 14,000 lbs
