2009 Honda Odyssey LX specs & colors
Mini-van, Passenger
Change trim
MSRP
- 5dr LX $26,355
- 5dr EX $29,455
- 5dr EX-L $33,155
- 5dr EX-L w/RES $34,755
- 5dr EX-L w/RES & Navi $36,955
- 5dr Touring $40,505
- 5dr Touring w/PAX $41,105
Key specs
Color options
Interior
Gray
Ivory
Packages
Specifications
| EPA Classification | 2WD Minivan |
| Front Wheel Size | 16 x -TBD- in |
| Rear Wheel Size | 16 x -TBD- in |
| Spare Wheel Size | Compact in |
| Front Wheel Material | Steel |
| Rear Wheel Material | Steel |
| Spare Wheel Material | Steel |
| Cold Cranking Amps @ 0° F (Primary) | N/A |
| Maximum Alternator Capacity (amps) | N/A |
| Engine Type | Gas V6 |
| Displacement | 3.5L/212 |
| SAE Net Horsepower @ RPM | 244 @ 5750 |
| SAE Net Torque @ RPM | 240 @ 5000 |
| EPA Fuel Economy Est - Hwy | 23 MPG |
| Cruising Range - City | 336.00 mi |
| EPA Fuel Economy Est - City | 16 MPG |
| Fuel Economy Est-Combined | 18 MPG |
| Cruising Range - Hwy | 483.00 mi |
| EPA MPG Equivalent - City | N/A |
| EPA MPG Equivalent - Hwy | N/A |
| EPA MPG Equivalent - Combined | N/A |
| Estimated Battery Range | N/A mi |
| Drivetrain | Front Wheel Drive |
| Trans Type | 5 |
| Trans Description Cont. | Automatic |
| Trans Description Cont. Again | Not Available |
| First Gear Ratio (:1) | 2.70 |
| Second Gear Ratio (:1) | 1.61 |
| Third Gear Ratio (:1) | 1.07 |
| Fourth Gear Ratio (:1) | 0.77 |
| Fifth Gear Ratio (:1) | 0.54 |
| Reverse Ratio (:1) | 1.89 |
| Final Drive Axle Ratio (:1) | 4.31 |
| Suspension Type - Front | MacPherson Strut |
| Suspension Type - Rear | Double Wishbone |
| Suspension Type - Front (Cont.) | Not Available |
| Suspension Type - Rear (Cont.) | Multi-link |
| Brake Type | Pwr |
| Brake ABS System | 4-Wheel |
| Brake ABS System (Second Line) | N/A |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Front Brake Rotor Diam x Thickness | 11.7 x -TBD- in |
| Rear Brake Rotor Diam x Thickness | 12.3 x -TBD- in |
| Drum - Rear (Yes or ) | Not Available |
| Fuel Tank Capacity, Approx | 21.0 gal |
| Aux Fuel Tank Capacity, Approx | N/A gal |
| Steering Type | Pwr Rack & Pinion |
| Steering Ratio (:1), Overall | 16.2 |
| Lock to Lock Turns (Steering) | 3.44 |
| Turning Diameter - Curb to Curb | 36.7 ft |
| Turning Diameter - Wall to Wall | N/A ft |
| Front Tire Size | P235/65TR16 |
| Rear Tire Size | P235/6T5R16 |
| Spare Tire Size | Compact |
| Dead Weight Hitch - Max Trailer Wt. | 3500 lbs |
| Dead Weight Hitch - Max Tongue Wt. | 350 lbs |
| Wt Distributing Hitch - Max Trailer Wt. | 3500 lbs |
| Wt Distributing Hitch - Max Tongue Wt. | 350 lbs |
| Base Curb Weight | 4387 lbs |
| Passenger Capacity | 7 |
| Passenger Volume | 171.4 ft³ |
| Front Head Room | 40.9 in |
| Front Leg Room | 40.8 in |
| Front Shoulder Room | 63.5 in |
| Front Hip Room | 57.0 in |
| Second Head Room | 40.0 in |
| Second Leg Room | 40.0 in |
| Second Shoulder Room | 63.1 in |
| Second Hip Room | 64.4 in |
| Third Head Room | 38.4 in |
| Third Leg Room | 41.1 in |
| Third Shoulder Room | 61.2 in |
| Third Hip Room | 48.5 in |
| Wheelbase | 118.1 in |
| Length, Overall | 202.1 in |
| Width, Max w/o mirrors | 77.1 in |
| Height, Overall | 68.8 in |
| Track Width, Front | 66.7 in |
| Track Width, Rear | 66.8 in |
| Min Ground Clearance | N/A in |
| Rear Door Opening Height | N/A in |
| Rear Door Opening Width | N/A in |
| Cargo Area Length @ Floor to Seat 1 | N/A in |
| Cargo Area Length @ Floor to Seat 2 | N/A in |
| Cargo Area Length @ Floor to Seat 3 | N/A in |
| Cargo Area Width @ Beltline | N/A in |
| Cargo Box Width @ Wheelhousings | N/A in |
| Cargo Box (Area) Height | N/A in |
| Liftover Height | N/A in |
| Cargo Volume to Seat 1 | 147.4 ft³ |
| Cargo Volume to Seat 2 | 91.1 ft³ |
| Cargo Volume to Seat 3 | 38.4 ft³ |
| Trunk Volume | N/A ft³ |
| Child-proof rear door locks | Standard |
| 2nd row pwr windows | Standard |
| Front & rear 12V pwr outlets | Standard |
| Maintenance Minder system | Standard |
| Rear privacy glass | Standard |
| Sunglasses holder | Standard |
| 2nd row in-floor storage | Standard |
| Instrument panel-mounted shifter | Standard |
| P235/65TR16 all-season tires | Standard |
| Tachometer | Standard |
| Upper & lower glove boxes | Standard |
| Programmable pwr door/tailgate locks | Standard |
| 16" steel wheels w/full wheel covers | Standard |
| Variable pwr rack & pinion steering | Standard |
| 3-point seat belts in all seating positions -inc: front automatic tensioning system, front & 2nd row outboard adjustable seatbelt anchors | Standard |
| Cargo area light | Standard |
| Black rear roofline spoiler w/integrated brakelight | Standard |
| Rear window defroster | Standard |
| Dual sliding doors | Standard |
| 7-passenger seating | Standard |
| Body-colored tailgate garnish | Standard |
| Front/2nd/3rd row side curtain airbags w/rollover sensor | Standard |
| Direct ignition system | Standard |
| Rear seat heater ducts | Standard |
| Remote keyless entry | Standard |
| Cruise control | Standard |
| Brake assist | Standard |
| Vehicle Stability Assist (VSA) w/traction control | Standard |
| Front passenger-side seatback pocket | Standard |
| Pwr mirrors | Standard |
| 2-speed variable intermittent windshield wipers | Standard |
| Intermittent rear window wiper w/washer | Standard |
| Remote fuel filler door release | Standard |
| 5-speed automatic transmission | Standard |
| 120-watt AM/FM stereo w/CD player -inc: (4) speakers, MP3/WMA playback, auxiliary input jack | Standard |
| Retractable center tray table w/bag hooks | Standard |
| Integrated glass antenna | Standard |
| Side-impact door beams | Standard |
| Front stabilizer bar | Standard |
| Multi-link double wishbone rear suspension | Standard |
| 3rd row outboard tether anchors | Standard |
| Tilt & telescopic steering column | Standard |
| Heat-rejecting glass | Standard |
| Rear storage well | Standard |
| 3.5L SOHC MPFI 24-valve VTEC V6 engine | Standard |
| 2nd row outboard/3rd row middle lower anchors & tethers for children (LATCH) | Standard |
| (13) cup holders | Standard |
| Daytime running lights | Standard |
| Dual illuminated visor vanity mirrors | Standard |
| Front cloth captains chairs -inc: active adjustable head restraints | Standard |
| Warning lights -inc: low-fuel, low-oil pressure, door/tailgate open, passenger-side airbag-off | Standard |
| Dual front side-impact airbags w/passenger-side occupant position detection system | Standard |
| Front wheel drive | Standard |
| Adjustable 2nd row captains chairs w/armrests -inc: "walk-in" feature, head restraints | Standard |
| Compact spare tire | Standard |
| MacPherson strut front suspension | Standard |
| Drive-By-Wire throttle | Standard |
| Advanced Compatibility Engineering (ACE) body structure | Standard |
| Pwr ventilated front disc brakes, solid rear disc brakes | Standard |
| 3rd row 60/40 Magic Seat -inc: one-motion stowing feature, head restraints | Standard |
| Multi-reflector halogen headlights | Standard |
| Front/2nd/3rd row passenger assist grips -inc: 2nd row garment hooks | Standard |
| Dual-stage, dual-threshold front airbags | Standard |
| Front pwr windows w/driver auto-up/down | Standard |
| Front/2nd/3rd row map lights | Standard |
| Floor mats | Standard |
| Immobilizer theft-deterrent system | Standard |
| 4-wheel anti-lock braking system (ABS) w/electronic brake distribution (EBD) | Standard |
| Tire pressure monitoring system | Standard |
| Coin holder | Standard |
| (8) cargo area tie-down anchors | Standard |
| (6) cargo area bag hooks | Standard |
| Front & rear air conditioning | Standard |
| Body-colored bumpers | Standard |
