2005 Honda Pilot EX specs & colors
Sport Utility
MSRP
- LX AT
- $27,550
- EX AT
- $30,120
- EX-L AT
- $32,320
- EX-L AT with RES
- $33,820
- EX-L AT with NAVI
- $34,320
Key specs
-
4-door -
8 seats -
255.0-hp, 3.5-liter, V6 Cylinder Engine (Gasoline Fuel) -
0 combined MPG -
188.0" length, 70.6" height -
All Wheel Drive
Color options
Exterior
Redrock Pearl
Interior
Light Gray / Gray
Gray
Fern
Packages
Specifications
Highlights
- Engine Type
-
Gas V6
- MPG
-
17 City / 22 Hwy
- Horsepower
-
255 hp
- Seating Capacity
-
8
Brakes
- Brake Type
-
Pwr
- Brake ABS System
-
4-Wheel
- Brake ABS System (Second Line)
-
N/A
- Disc - Front (Yes or )
-
Yes
- Disc - Rear (Yes or )
-
Yes
- Front Brake Rotor Diam x Thickness
-
11.8 x -TBD- in
- Rear Brake Rotor Diam x Thickness
-
12.3 x -TBD- in
- Drum - Rear (Yes or )
-
Not Available
Electrical
- Cold Cranking Amps @ 0° F (Primary)
-
N/A
- Maximum Alternator Capacity (amps)
-
130
Engine
- Engine Type
-
Gas V6
- Displacement
-
3.5L/212
- SAE Net Horsepower @ RPM
-
255 @ 5600
- SAE Net Torque @ RPM
-
250 @ 4500
- Transmission Options
-
A/T
5-Speed A/T
- MPG
-
17 City / 22 Hwy
- Total Cooling System Capacity
-
9.6 qts
Measurements
- Passenger Capacity
-
8
- Passenger Volume
-
177 ft³
- Front Head Room
-
42 in
- Front Leg Room
-
41 in
- Front Shoulder Room
-
62 in
- Front Hip Room
-
58 in
- Second Head Room
-
41 in
- Second Leg Room
-
37 in
- Second Shoulder Room
-
61 in
- Second Hip Room
-
57 in
- Third Head Room
-
39 in
- Third Leg Room
-
30 in
- Third Shoulder Room
-
60 in
- Third Hip Room
-
49 in
- Wheelbase
-
106 in
- Length, Overall
-
188 in
- Width, Max w/o mirrors
-
77 in
- Height, Overall
-
72 in
- Track Width, Front
-
66 in
- Track Width, Rear
-
67 in
- Min Ground Clearance
-
8 in
- Rear Door Opening Height
-
N/A
- Rear Door Opening Width
-
N/A
- Cargo Area Length @ Floor to Seat 1
-
N/A
- Cargo Area Length @ Floor to Seat 2
-
N/A
- Cargo Area Length @ Floor to Seat 3
-
N/A
- Cargo Area Width @ Beltline
-
N/A
- Cargo Box Width @ Wheelhousings
-
N/A
- Cargo Box (Area) Height
-
N/A
- Liftover Height
-
N/A
- Cargo Volume to Seat 1
-
90 ft³
- Cargo Volume to Seat 2
-
49 ft³
- Cargo Volume to Seat 3
-
16 ft³
- Trunk Volume
-
N/A
Steering
- Steering Type
-
Variable Pwr
- Steering Ratio (:1), Overall
-
17
- Lock to Lock Turns (Steering)
-
3
- Turning Diameter - Curb to Curb
-
38 ft
- Turning Diameter - Wall to Wall
-
N/A
Suspension
- Suspension Type - Front
-
Independent Strut
- Suspension Type - Rear
-
Multilink
- Suspension Type - Front (Cont.)
-
Not Available
- Suspension Type - Rear (Cont.)
-
w/Trailing Arms
Tires & Wheels
- Front Tire Size
-
P235/70SR16
- Rear Tire Size
-
P235/70SR16
- Spare Tire Size
-
Compact
- Front Wheel Size
-
16 x 6.5 in
- Rear Wheel Size
-
16 x 6.5 in
- Spare Wheel Size
-
N/A
- Front Wheel Material
-
Alloy
- Spare Wheel Material
-
N/A
- Rear Wheel Material
-
Alloy
Weight & Capacity
- Base Curb Weight
-
4,431 lbs
- Dead Weight Hitch - Max Trailer Wt.
-
4,500 lbs
- Dead Weight Hitch - Max Tongue Wt.
-
450 lbs
- Wt Distributing Hitch - Max Trailer Wt.
-
N/A
- Wt Distributing Hitch - Max Tongue Wt.
-
N/A
- Fuel Tank Capacity, Approx
-
20 gal
- Aux Fuel Tank Capacity, Approx
-
N/A
