Change trim
MSRP
- 4dr Sdn Manual $14,749
- 4dr Sdn Auto $15,549
- 4dr Sdn GL Auto $16,349
- 4dr Sdn GL Auto V6 $17,349
- 4dr Sdn GLS Auto V6 $18,549
Interior
No colors available
EPA Classification | Mid-Size |
Front Wheel Size | 14 x 5 in |
Rear Wheel Size | 14 x 5 in |
Spare Wheel Size | Compact in |
Front Wheel Material | Steel |
Rear Wheel Material | Steel |
Spare Wheel Material | Steel |
Cold Cranking Amps @ 0° F (Primary) | 550 |
Maximum Alternator Capacity (amps) | 75 |
Engine Type | Gas I4 |
Displacement | 2.0L/122 |
SAE Net Horsepower @ RPM | 137 @ 6000 |
SAE Net Torque @ RPM | 129 @ 4000 |
EPA Fuel Economy Est - Hwy | 28 MPG |
Cruising Range - City | 361.20 mi |
EPA Fuel Economy Est - City | 21 MPG |
Fuel Economy Est-Combined | N/A MPG |
Cruising Range - Hwy | 481.60 mi |
EPA MPG Equivalent - City | N/A |
EPA MPG Equivalent - Hwy | N/A |
EPA MPG Equivalent - Combined | N/A |
Estimated Battery Range | N/A mi |
Drivetrain | Front Wheel Drive |
Trans Type | 5 |
Trans Description Cont. | Manual w/OD |
Trans Description Cont. Again | Not Available |
First Gear Ratio (:1) | 3.083 |
Second Gear Ratio (:1) | 1.947 |
Third Gear Ratio (:1) | 1.285 |
Fourth Gear Ratio (:1) | 0.939 |
Fifth Gear Ratio (:1) | 0.756 |
Reverse Ratio (:1) | 3.083 |
Final Drive Axle Ratio (:1) | 4.322 |
Suspension Type - Front | Independent |
Suspension Type - Rear | Independent |
Suspension Type - Front (Cont.) | Macpherson Strut |
Suspension Type - Rear (Cont.) | Multi-Link |
Brake Type | Pwr-Assisted |
Brake ABS System | Not Available |
Brake ABS System (Second Line) | N/A |
Disc - Front (Yes or ) | Yes |
Disc - Rear (Yes or ) | Not Available |
Front Brake Rotor Diam x Thickness | 10.12 x .87 in |
Rear Brake Rotor Diam x Thickness | Not Available in |
Drum - Rear (Yes or ) | Yes |
Fuel Tank Capacity, Approx | 17.2 gal |
Aux Fuel Tank Capacity, Approx | N/A gal |
Steering Type | Pwr Rack & Pinion |
Steering Ratio (:1), Overall | 15.7 |
Lock to Lock Turns (Steering) | 3.06 |
Turning Diameter - Curb to Curb | 34.6 ft |
Turning Diameter - Wall to Wall | N/A ft |
Front Tire Size | P195/70R14 |
Rear Tire Size | P195/70R14 |
Spare Tire Size | Compact |
Dead Weight Hitch - Max Trailer Wt. | N/A lbs |
Dead Weight Hitch - Max Tongue Wt. | N/A lbs |
Wt Distributing Hitch - Max Trailer Wt. | N/A lbs |
Wt Distributing Hitch - Max Tongue Wt. | N/A lbs |
Base Curb Weight | 2935 lbs |
Passenger Capacity | 5 |
Passenger Volume | 101.3 ft³ |
Front Head Room | 38.5 in |
Front Leg Room | 43.3 in |
Front Shoulder Room | 58.2 in |
Front Hip Room | 57.9 in |
Second Head Room | 37.7 in |
Second Leg Room | 36.6 in |
Second Shoulder Room | 56.4 in |
Second Hip Room | 57.1 in |
Wheelbase | 106.3 in |
Length, Overall | 185.0 in |
Width, Max w/o mirrors | 69.7 in |
Height, Overall | 55.3 in |
Track Width, Front | 59.6 in |
Track Width, Rear | 59.1 in |
Min Ground Clearance | 6.3 in |
Liftover Height | 27.1 in |
Trunk Volume | 13.2 ft³ |
5-speed manual transmission w/OD | Standard |
Variable intermittent windshield wipers | Standard |
Cargo area floor carpeting | Standard |
Dual cupholder | Standard |
Fully independent multi-link rear suspension | Standard |
Rotary climate control | Standard |
Low fuel/door/trunk ajar warning lights | Standard |
Aerodynamic halogen headlamps | Standard |
Fixed mast antenna | Standard |
Digital quartz clock | Standard |
60-amp/hr maintenance-free battery | Standard |
Cut pile carpeting | Standard |
Remote hood/fuel-filler door release | Standard |
17.2 Gallon fuel tank | Standard |
Pwr-assisted dual diagonal ventilated front disc/self-adjusting rear drum brakes | Standard |
Full center console w/coin holder/storage box | Standard |
3-point color-keyed outboard rear seat belts | Standard |
Color-keyed 4-spoke soft grip steering wheel w/tilt column | Standard |
Full roll-down rear windows | Standard |
ETR AM/FM stereo w/cassette/4-speakers | Standard |
Body-color door handles | Standard |
Cargo area illumination | Standard |
Overhead courtesy dome lamp | Standard |
Independent front MacPherson struts suspension | Standard |
Lockable illuminated glove box | Standard |
75-amp alternator | Standard |
Body-color grille | Standard |
City 21/hwy 28 (2.0L engine/5-speed manual trans) | Standard |
2.0L DOHC MFI 4 cyl engine w/dual balance shafts | Standard |
Electronic ignition | Standard |
Front wheel drive | Standard |
Dual black remote-control mirrors | Standard |
2-point color-keyed center rear lap belt | Standard |
Remote trunk release w/lock-out feature | Standard |
Compact spare tire | Standard |
Rear window defroster w/timer | Standard |
60/40 split fold-down rear seatback | Standard |
3-point color-keyed non-passive front seat belts w/height adjuster | Standard |
Tinted glass | Standard |
Pwr rack & pinion steering | Standard |
Body-color body-side moldings | Standard |
Black front/rear window moldings | Standard |
Delay-out interior lighting w/illuminated ignition | Standard |
14" X 5.0 steel wheels w/full wheel covers | Standard |
Front/rear assist grips (3) | Standard |
Driver & front passenger dual airbag supplemental restraint system | Standard |
Full cloth seat trim | Standard |
Dual visor vanity mirrors | Standard |
Rear seat heater ducts | Standard |
Illuminated cigarette lighter | Standard |
Front side window defoggers | Standard |
Rear child safety door locks | Standard |
Bright side window accents | Standard |
Front illuminated/single rear ashtray | Standard |
Front/rear coil springs/stabilizer bars | Standard |
Front door map pockets | Standard |
Body-color bumpers w/body-color inserts | Standard |
Air conditioning | Standard |
Reclining front bucket seats w/4-way adjustable driver's seat | Standard |
Integral rear headrests | Standard |
P195/70R14 all-season SBR tires | Standard |
Tachometer, trip odometer, water temp gauge | Standard |
Unitized body construction | Standard |
