2024 Jeep Wrangler Rubicon 392 specs & colors

Starting MSRP
Current listing price
2024 Jeep Wrangler Rubicon 392

Showing the 2024 Jeep Wrangler Rubicon 392 4 Door 4x4 *Ltd Avail*

Shop Now

Key specs

Color options


Red / Black



Starting MSRP

  • Cigar Lighter
  • Removable Ash Tray


Starting MSRP

  • Premium Black Sunrider Soft Top


Front Wheel Material Aluminum
Spare Wheel Size Full-Size in
Front Wheel Size 17 X 8 in
Rear Wheel Material Aluminum
Rear Wheel Size 17 X 8 in
Spare Wheel Material Aluminum
Maximum Alternator Capacity (amps) 220
Cold Cranking Amps @ 0° F (Primary) 700
SAE Net Torque @ RPM 470 @ 4300
Engine Oil Cooler Regular Duty
Engine Type Premium Unleaded V-8
Displacement 6.4 L/392
SAE Net Horsepower @ RPM 470 @ 6000
EPA Fuel Economy Est - Hwy 16 MPG
Cruising Range - City 279.50 mi
Fuel Economy Est-Combined 14 MPG
EPA Fuel Economy Est - City 13 MPG
Estimated Battery Range N/A mi
Cruising Range - Hwy 344.00 mi
Seventh Gear Ratio (:1) 0.84
Transfer Case Gear Ratio (:1), High N/A
Fourth Gear Ratio (:1) 1.67
Second Gear Ratio (:1) 3.14
Eighth Gear Ratio (:1) 0.67
Trans Description Cont. Automatic w/OD
Trans Type 8
Drivetrain Four Wheel Drive
Transfer Case Gear Ratio (:1), Low N/A
Reverse Ratio (:1) 3.29
Transfer Case Model Manual
Fifth Gear Ratio (:1) 1.28
Trans Power Take Off N/A
Final Drive Axle Ratio (:1) N/A
Sixth Gear Ratio (:1) 1.00
First Gear Ratio (:1) 4.71
Trans Description Cont. Again N/A
Third Gear Ratio (:1) 2.11
Transfer Case Power Take Off No
Axle Type - Rear Rigid Axle
Axle Type - Front Non-Independent
Suspension Type - Rear Trailing Arm
Suspension Type - Front Leading Link
Frame Type N/A
Front Brake Rotor Diam x Thickness 12.9 in
Disc - Rear (Yes or ) Yes
Brake ABS System 4-Wheel
Brake ABS System (Second Line) 4-Wheel
Brake Type 4-Wheel Disc
Rear Brake Rotor Diam x Thickness 14 in
Drum - Rear (Yes or ) N/A
Disc - Front (Yes or ) Yes
Fuel Tank Capacity, Approx 21.5 gal
Aux Fuel Tank Capacity, Approx N/A gal
Turning Diameter - Wall to Wall N/A ft
Turning Diameter - Curb to Curb 38.8 ft
Steering Ratio (:1), Overall N/A
Steering Type Re-Circulating Ball
Rear Tire Size LT315/70SR17
Spare Tire Size Full-Size
Front Tire Size LT315/70SR17
Wt Distributing Hitch - Max Tongue Wt. 350 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Tongue Wt. 350 lbs
Wt Distributing Hitch - Max Trailer Wt. 3500 lbs
Dead Weight Hitch - Max Trailer Wt. 3500 lbs
Maximum Trailering Capacity 3500 lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Option Weight - Rear 0.00 lbs
Gross Vehicle Weight Rating 6400.00 lbs
Maximum Payload Capacity 1132.00 lbs
Curb Weight - Front 2797 lbs
Total Option Weight 0.00 lbs
Option Weight - Front 0.00 lbs
As Spec'd Payload 1132.00 lbs
Curb Weight 5268.00 lbs
Base Curb Weight 5268 lbs
Gross Axle Weight Rating 6950.00 lbs
As Spec'd Curb Weight 5268.00 lbs
Gross Combined Wt Rating 9400 lbs
Curb Weight - Rear 2471 lbs
Cargo Volume to Seat 3 27.7 ft³
Track Width, Rear 64.4 in
Cab to End of Frame N/A in
Height, Overall 74.5 in
Cargo Box Width @ Top, Rear N/A in
Cargo Box Width @ Wheelhousings 41.5 in
Min Ground Clearance 11.1 in
Rear Door Opening Width N/A in
Tailgate Width N/A in
Length, Overall w/rear bumper N/A in
Ext'd Cab Cargo Volume N/A ft³
Front Shoulder Room 55.8 in
Front Head Room 40.8 in
Front Leg Room 40.8 in
Ground to Top of Load Floor N/A in
Cargo Area Width @ Beltline 47.9 in
Cargo Area Length @ Floor to Seat 3 N/A in
Overhang, Rear w/o bumper N/A in
Cargo Box Width @ Floor N/A in
Wheelbase 118.4 in
Second Shoulder Room 55.8 in
Cargo Volume to Seat 2 27.7 ft³
Second Leg Room 38.2 in
Ground Clearance, Rear N/A in
Width, Max w/o mirrors 73.9 in
Rear Door Opening Height N/A in
Cargo Volume N/A ft³
Cargo Area Length @ Floor to Seat 2 N/A in
Cargo Volume to Seat 1 67.4 ft³
Overhang, Front N/A in
Liftover Height 30.8 in
Cargo Area Length @ Floor to Seat 1 N/A in
Front Hip Room 53.9 in
Length, Overall 188.4 in
Track Width, Front 64.4 in
Ground Clearance, Front N/A in
Second Hip Room 55.9 in
Second Head Room 40.3 in
Cargo Box (Area) Height 35.7 in
Passenger Capacity 5
Radio: Uconnect 5 Nav w/12.3" Display Optional
Streaming Audio Standard
Connected Travel & Traffic Services Real-Time Traffic Display Optional
Window Grid Antenna Standard
9 Alpine Speakers Optional
2 LCD Monitors In The Front Optional
AM/FM/HD/Satellite w/Seek-Scan, Clock, Speed Compensated Volume Control, Aux Audio Input Jack, Steering Wheel Controls, Voice Activation, Radio Data System and Uconnect External Memory Control Optional
552w Premium Amplifier Optional
Swing-Out Rear Cargo Access Standard
Auto On/Off Reflector Led Low/High Beam Daytime Running Auto High-Beam Headlamps w/Delay-Off Optional
Black Rear Bumper w/1 Tow Hook Standard
Body-Color Grille w/Colored Accents Standard
Variable Intermittent Wipers Standard
Black Wheel Well Trim and Body-Colored Fender Flares Optional
Rear Window Defroster Optional
Flip-Up Rear Window Optional
Full-Size Spare Tire Mounted Outside Rear Standard
Tires: LT315/70R17C 113/110S Optional
Clearcoat Paint w/Badging Optional
Freedom Panel Storage Bag Optional
Black Door Handles Standard
Black Side Windows Trim Standard
Tailgate/Rear Door Lock Included w/Power Door Locks Optional
Black Front Bumper w/2 Tow Hooks Standard
Rear Window Wiper/Washer Optional
LED Brakelights Optional
Black Power Heated Side Mirrors w/Manual Folding Optional
Headlights-Automatic Highbeams Optional
Aluminum Spare Wheel Optional
Deep Tinted Glass Optional
Manual Convertible Hard Top w/Glass Rear Window and Fixed Roll-Over Protection Optional
Laminated Glass Optional
Front Fog Lamps Standard
Galvanized Steel/Aluminum/Magnesium Panels Standard
Manual Targa Composite 1st Row Sunroof Optional
Perimeter Alarm Optional
Smart Device Integration Standard
Voice Activated Dual Zone Front Automatic Air Conditioning Optional
Power Door Locks w/Autolock Feature Optional
Front And Rear Map Lights Standard
Driver And Passenger Visor Vanity Mirrors w/Driver And Passenger Illumination Optional
Trip Computer Standard
Instrument Panel Bin, Dashboard Storage, Driver / Passenger And Rear Door Bins Standard
60-40 Folding Split-Bench Front Facing Fold Forward Seatback Leather Rear Seat Optional
Carpet Floor Trim, Carpet And Rubber Mat Standard
Outside Temp Gauge Standard
Tracker System Optional
Compass Standard
Fade-To-Off Interior Lighting Standard
Power 1st Row Windows w/Driver And Passenger 1-Touch Down Optional
Cargo Space Lights Standard
Proximity Key For Doors And Push Button Start Optional
Manual Tilt/Telescoping Steering Column Standard
Front Center Armrest w/Storage and Rear Center Armrest Optional
Smart Device Remote Engine Start Optional
Illuminated Front Cupholder Standard
Day-Night Auto-Dimming Rearview Mirror Optional
Full Cloth Headliner Optional
Locking Cargo Area Concealed Storage Standard
Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Tachometer, Inclinometer, Altimeter, Oil Temperature, Transmission Fluid Temp, Engine Hour Meter, Trip Odometer and Trip Computer Optional
2 12V DC Power Outlets Standard
Driver Information Center Standard
Leather Gear Shifter Material Optional
Illuminated Rear Cupholder Standard
Air Filtration Optional
Sentry Key Immobilizer Standard
Cruise Control w/Steering Wheel Controls Standard
Manual Adjustable Front Head Restraints and Foldable Rear Head Restraints Standard
Power Rear Windows and Fixed 3rd Row Windows Optional
2 12V DC Power Outlets and 1 120V AC Power Outlet Optional
2 Seatback Storage Pockets Standard
Heated Leather Steering Wheel Optional
12-Way Power Driver Seat -inc: Power Recline, Height Adjustment, Fore/Aft Movement, Cushion Tilt and Power 4-Way Lumbar Support Optional
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button Optional
Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats Standard
Driver And Passenger Heated-Cushion, Driver And Passenger Heated-Seatback Optional
Interior Trim -inc: Deluxe Sound Insulation, Metal-Look Instrument Panel Insert, Metal-Look Door Panel Insert, Metal-Look Console Insert and Metal-Look Interior Accents Optional
HVAC -inc: Console Ducts Standard
Front Seats w/Power 4-Way Driver Lumbar Optional
Locking Glove Box Standard
Analog Appearance Standard
12-Way Power Passenger Seat -inc: Power Recline, Height Adjustment, Fore/Aft Movement, Cushion Tilt and Power 4-Way Lumbar Support Optional
4G LTE Wi-Fi Hot Spot Mobile Hotspot Internet Access Standard
FOB Controls -inc: Remote Start Optional
Full Floor Console w/Locking Storage, 2 12V DC Power Outlets and 1 120V AC Power Outlet Optional
Garage Door Transmitter Optional
Redundant Digital Speedometer Standard
Adaptive w/Traffic Stop-Go Optional
4.56 Rear Axle Ratio Optional
220 Amp Alternator Optional
Driver Selectable Front Locking Differential Optional
Electro-Hydraulic Power Assist Steering Standard
Class II Towing Equipment -inc: Hitch and Trailer Sway Control Optional
Engine: 6.4L V8 SRT HEMI MDS (STD) Optional
6400# Gvwr 1088# Maximum Payload Optional
Transmission w/Sequential Shift Control w/Steering Wheel Controls Optional
Upfitter Switches Optional
GVWR: 6,400 lbs (STD) Optional
Leading Link Front Suspension w/Coil Springs Standard
Part And Full-Time Four-Wheel Drive Optional
Fox Brand Name Shock Absorbers Optional
Solid Axle Rear Suspension w/Coil Springs Standard
Dual Stainless Steel Exhaust Optional
4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist, Hill Descent Control and Hill Hold Control Optional
21.5 Gal. Fuel Tank Standard
Manual Transfer Case Standard
Driver Selectable Rear Locking Differential Optional
Front Active w/Driver Control Anti-Roll and Rear Anti-Roll Optional
Federal Emissions Optional
Auto Locking Hubs Standard
Transmission: 8-Speed Automatic (8HP75) (STD) Optional
Engine Oil Cooler Standard
700CCA Maintenance-Free Battery w/Run Down Protection Standard
Brake Actuated Limited Slip Differential Optional
Trailer Wiring Harness Optional
5 Skid Plates Optional
Collision Mitigation-Front Optional
Side Impact Beams Standard
Airbag Occupancy Sensor Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Rear Child Safety Locks Standard
ParkSense Rear Parking Sensors Optional
ParkView Back-Up Camera Standard
Full Speed Forward Collision Warning Plus and Cross Path Detection Optional
Blind Spot Detection Blind Spot Optional
Curtain 1st And 2nd Row Airbags Standard
Electronic Stability Control (ESC) And Roll Stability Control (RSC) Standard
Dual Stage Driver And Passenger Front Airbags Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners Standard
Tire Specific Low Tire Pressure Warning Standard
ABS And Driveline Traction Control Standard
