2010 Nissan Frontier LE specs & colors

Extended Cab Pickup

Change trim
$27,620
Starting MSRP
Current listing price

Showing the 2010 Nissan Frontier 4WD King Cab Auto LE

Shop Now

Key specs

Color options

Interior

Grey-Violet

Medium Mocha

Packages

Specifications

Front Wheel Material Alloy
Rear Wheel Material Alloy
Spare Wheel Material Alloy
Front Wheel Size 18 x 7.5 in
Rear Wheel Size 18 x 7.5 in
Spare Wheel Size 18 x 7.5 in

Maximum Alternator Capacity (amps) 110
Cold Cranking Amps @ 0° F (Primary) 550

Displacement 4.0L/-TBD-
Engine Type Gas V6
Engine Oil Cooler Not Available
SAE Net Horsepower @ RPM 261 @ 5600
SAE Net Torque @ RPM 281 @ 4000

Fuel Economy Est-Combined 16 MPG
Estimated Battery Range N/A mi
EPA Fuel Economy Est - Hwy 19 MPG
Cruising Range - City 295.40 mi
Cruising Range - Hwy 400.90 mi
EPA Fuel Economy Est - City 14 MPG

Fourth Gear Ratio (:1) 1.00
Transfer Case Gear Ratio (:1), High 1.0
Trans Description Cont. Again w/OD
Drivetrain 4-Wheel Drive
Fifth Gear Ratio (:1) 0.84
Transfer Case Model Not Available
Transfer Case Power Take Off Not Available
Second Gear Ratio (:1) 2.35
First Gear Ratio (:1) 3.84
Trans Type 5
Trans Description Cont. Automatic
Reverse Ratio (:1) 2.76
Transfer Case Gear Ratio (:1), Low 2.63
Third Gear Ratio (:1) 1.53
Trans Power Take Off Not Available
Final Drive Axle Ratio (:1) N/A

Suspension Type - Rear Multi-Leaf
Axle Type - Front Not Available
Axle Type - Rear Not Available
Suspension Type - Front Independent

Frame Type Ladder Type

Rear Brake Rotor Diam x Thickness 11.3 x 0.7 in
Disc - Front (Yes or ) Yes
Brake Type Pwr
Disc - Rear (Yes or ) Yes
Drum - Rear (Yes or ) Not Available
Brake ABS System 4-Wheel
Brake ABS System (Second Line) Not Available
Front Brake Rotor Diam x Thickness 11.7 x 1.1 in

Aux Fuel Tank Capacity, Approx Not Available gal
Fuel Tank Capacity, Approx 21.1 gal

Turning Diameter - Wall to Wall Not Available ft
Steering Type Pwr Rack & pinion
Turning Diameter - Curb to Curb N/A ft
Steering Ratio (:1), Overall N/A

Rear Tire Size P265/60R18
Front Tire Size P265/60R18
Spare Tire Size P265/60R18

Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Maximum Trailering Capacity N/A lbs
Fifth Wheel Hitch - Max Trailer Wt. Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt. Not Available lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Tongue Wt. 630 lbs
Wt Distributing Hitch - Max Trailer Wt. 6300 lbs

As Spec'd Curb Weight 4352.00 lbs
Curb Weight - Rear 1828 lbs
Curb Weight - Front 2524 lbs
Gross Axle Weight Rating 6620.00 lbs
Option Weight - Rear 0.00 lbs
Maximum Payload Capacity 1338.00 lbs
Option Weight - Front 0.00 lbs
Curb Weight 4352.00 lbs
Gross Vehicle Weight Rating 5690.00 lbs
Gross Combined Wt Rating 11133 lbs
Total Option Weight 0.00 lbs
Base Curb Weight N/A lbs
As Spec'd Payload 1338.00 lbs

Second Hip Room 55.0 in
Cargo Box Width @ Wheelhousings 44.4 in
Front Leg Room 42.4 in
Ground Clearance, Rear 10.1 in
Overhang, Front 31.3 in
Length, Overall w/rear bumper N/A in
Tailgate Width 58.8 in
Ground Clearance, Front 10.1 in
Second Leg Room 25.4 in
Height, Overall 69.7 in
Front Shoulder Room 58.3 in
Length, Overall N/A in
Cargo Box (Area) Height 18.0 in
Wheelbase 125.9 in
Passenger Capacity 4
Cargo Volume 33.5 ft³
Front Hip Room 55.8 in
Second Head Room 38.3 in
Cargo Box Width @ Floor 61.4 in
Width, Max w/o mirrors 72.8 in
Ext'd Cab Cargo Volume 30.9 ft³
Ground to Top of Load Floor N/A in
Overhang, Rear w/o bumper 48.2 in
Front Head Room 39.7 in
Cargo Box Length @ Floor 73.3 in
Cab to End of Frame N/A in
Second Shoulder Room 54.9 in
Cargo Box Width @ Top, Rear N/A in
Length, Overall w/o rear bumper 205.5 in

Variable intermittent windshield wipers Standard
Remote keyless entry Optional
Reminders -inc: low fuel, fasten seat belts Standard
Chrome rear bumper Standard
Driver seat back pocket Optional
(2) auxiliary pwr outlets Standard
Active brake limited slip (ABLS) Standard
(2) bottle holders Standard
Front seat belts w/pretensioners, load limiters, adjustable upper anchors Standard
Roof-mounted curtain side impact airbags Standard
Dome light Standard
Fold-flat passenger seat Standard
Cargo lamp Standard
Body-color side molding Optional
Front/rear splash guards Standard
Forward facing rear jump seats w/flip-up seat cushions Standard
Multi-leaf rear suspension Standard
Chrome inside door handles Standard
4.0L DOHC 24-valve V6 engine Standard
Tire pressure monitoring system Standard
Tubular step rails Optional
Driver seat height adjuster & lumbar support Optional
Pwr windows w/driver side auto-down Optional
Pwr door locks Optional
Sliding rear window Standard
Coat hook Standard
Cell phone storage Optional
18" machined finish alloy wheels Optional
Overhead sunglass holder Optional
Chrome front grille Standard
Fog lamps Optional
Chrome door handles Optional
Dual sunvisors w/illum vanity mirrors Optional
3-point seat belts for all seating positions Standard
(4) tie-down cleats Optional
Full size spare tire w/alloy wheel Optional
First aid kit Optional
Bed rail caps Optional
Unique cloth seating surfaces Standard
Tinted UV-reducing solar glass Standard
Tilt steering column Standard
Illuminated ignition switch Optional
Part-time transfer case w/rotary switch Standard
Trip computer Optional
Pwr rack & pinion steering Standard
Dual glove box w/lower lockable glove box Standard
Leather-wrapped steering wheel Optional
Instrumentation -inc: tachometer, trip meter, coolant temp Standard
(1) rear passenger top tether child restraint anchor Standard
Chrome front bumper Standard
Oil & volt gauges Standard
Vehicle dynamic control (VDC) Standard
2nd row LH removable under seat storage Standard
Satin gauges & chrome vent accents Optional
P265/60R18 all-season tires Optional
Reclining front bucket seats w/adjustable active head restraints Standard
Cruise control Optional
Air conditioning Standard
Side door guard beams Standard
5-speed automatic transmission w/OD Optional
4-wheel anti-lock braking system (ABS) Standard
Driver & front passenger dual stage airbags -inc: front passenger occupancy sensor Standard
(2) front/(2) rear cup holders Standard
4-wheel drive Standard
Detachable tailgate w/lock Standard
Chrome pwr outside mirrors Optional
Front independent suspension Standard
Privacy glass Standard
Nissan engine cover Standard
Spray-on bed liner Optional
Driver/front passenger assist grips Standard
Front/rear door map pockets Standard
AM/FM stereo w/CD player -inc: (4) speakers, aux input jack Standard
Pwr 4-wheel vented disc brakes Standard
Utili-Track channel system Optional
Dual-level center console w/storage & armrest style lid Standard
Hill start assist & hill descent control Optional
Rear access doors Standard
Front seat-mounted side impact airbags Standard
Front map lights Standard
Front tow hook Standard
