2013 Nissan Frontier PRO-4X specs & colors

Starting MSRP
Current listing price

Showing the 2013 Nissan Frontier 4WD Crew Cab SWB Manual PRO-4X

Shop Now

Key specs

Color options


Medium Prarie Tan



Front Wheel Size 16 x 7.0 in
Rear Wheel Size 16 x 7.0 in
Spare Wheel Size 16 x 7.0 in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material N/A

Cold Cranking Amps @ 0° F (Primary) 550
Maximum Alternator Capacity (amps) 130

Engine Type Gas V6
Displacement 4.0L/241
SAE Net Horsepower @ RPM 261 @ 5600
SAE Net Torque @ RPM 281 @ 4000
Engine Oil Cooler Not Available

EPA Fuel Economy Est - Hwy 21 MPG
Cruising Range - City 337.60 mi
EPA Fuel Economy Est - City 16 MPG
Fuel Economy Est-Combined 18 MPG
Cruising Range - Hwy 443.10 mi
Estimated Battery Range N/A mi

Drivetrain Four Wheel Drive
Trans Type 6
Trans Description Cont. Manual
Trans Description Cont. Again Not Available
First Gear Ratio (:1) 4.368
Second Gear Ratio (:1) 2.518
Third Gear Ratio (:1) 1.743
Fourth Gear Ratio (:1) 1.283
Fifth Gear Ratio (:1) 1.000
Sixth Gear Ratio (:1) 0.769
Reverse Ratio (:1) 3.966
Trans Power Take Off Not Available
Final Drive Axle Ratio (:1) N/A
Transfer Case Model Not Available
Transfer Case Gear Ratio (:1), High 1.000
Transfer Case Gear Ratio (:1), Low 2.625
Transfer Case Power Take Off Not Available

Suspension Type - Front Double Wishbone
Suspension Type - Rear Multi-Leaf
Axle Type - Front Not Available
Axle Type - Rear Dana

Frame Type Ladder

Brake Type Pwr
Brake ABS System 4-Wheel
Brake ABS System (Second Line) Not Available
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 11.7 x 1.1 in
Rear Brake Rotor Diam x Thickness 11.3 x 0.7 in
Drum - Rear (Yes or ) Not Available

Fuel Tank Capacity, Approx 21.1 gal
Aux Fuel Tank Capacity, Approx Not Available gal

Steering Type Pwr Rack & pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 43.3 ft
Turning Diameter - Wall to Wall N/A ft

Front Tire Size P265/75R16
Rear Tire Size P265/75R16
Spare Tire Size P265/75R16

Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Trailer Wt. 6100 lbs
Wt Distributing Hitch - Max Tongue Wt. 610 lbs
Fifth Wheel Hitch - Max Trailer Wt. Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt. Not Available lbs
Maximum Trailering Capacity N/A lbs

Base Curb Weight N/A lbs
Curb Weight - Front 2506 lbs
Curb Weight - Rear 1969 lbs
Option Weight - Front 0.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Curb Weight 4475.00 lbs
As Spec'd Payload 1125.00 lbs
Maximum Payload Capacity 1125.00 lbs
Gross Combined Wt Rating 11113 lbs
Gross Axle Weight Rating 6620.00 lbs
Curb Weight 4475.00 lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 5600.00 lbs

Passenger Capacity 5
Front Head Room 40.0 in
Front Leg Room 42.4 in
Front Shoulder Room 58.3 in
Front Hip Room 55.6 in
Second Head Room 38.7 in
Second Leg Room 33.6 in
Second Shoulder Room 58.3 in
Second Hip Room 58.0 in
Wheelbase 125.9 in
Length, Overall w/o rear bumper 205.5 in
Length, Overall w/rear bumper N/A in
Length, Overall N/A in
Width, Max w/o mirrors 72.8 in
Height, Overall 70.1 in
Overhang, Front 31.3 in
Overhang, Rear w/o bumper 48.2 in
Cab to End of Frame N/A in
Ground to Top of Load Floor N/A in
Ground Clearance, Front 8.9 in
Ground Clearance, Rear 10.1 in
Cargo Box Length @ Floor 59.5 in
Cargo Box Width @ Top, Rear 61.4 in
Cargo Box Width @ Floor 61.4 in
Cargo Box Width @ Wheelhousings 44.4 in
Cargo Box (Area) Height 18.0 in
Tailgate Width 58.8 in
Cargo Volume 27.1 ft³
Ext'd Cab Cargo Volume 38.8 ft³

Front tow hook Standard
Lower anchors & tethers for children (LATCH) Standard
Vehicle speed-sensitive pwr steering Standard
Detachable tailgate w/lock Standard
Child safety rear door locks Standard
Dual-zone automatic temp control Optional
Electronic shift-on-the-fly 4-wheel drive w/low range Standard
Rear under-seat storage bin Standard
Body-color front bumper Optional
Tinted UV-reducing solar glass Standard
Driver/front passenger assist grips Standard
Dome light Standard
Coat hook Standard
Auto-dimming rearview mirror w/compass & outside temp display Optional
Rear parking aid Optional
Manual sliding rear window Optional
Satin chrome grille Optional
Locking rear differential Optional
Variable intermittent windshield wipers Standard
Transfer case skid plate Optional
3-point seat belts for all seating positions Standard
Driver seat back pocket Optional
Pwr 4-wheel vented disc brakes Standard
Electronic Brake force Distribution (EBD) Standard
Reclining front bucket seats w/adjustable active head restraints Standard
Bed rail caps Optional
Fog lamps Optional
Cargo lamp Standard
Factory-applied spray-on bedliner Optional
Oil & volt gauges Standard
Dual glove box w/lower lockable glove box Standard
Front/rear door map pockets Standard
Remote keyless entry Optional
Overhead sunglass holder Standard
Cruise control Optional
Body-color door handles Optional
Automatic on/off headlamps Optional
Fold-flat passenger seat Standard
Driver info center Optional
60/40 split rear flip up bench seat Standard
Front seat belts w/pretensioners, load limiters, adjustable upper anchors Standard
Privacy glass Optional
Tire pressure monitoring system Standard
Dual sunvisors w/vanity mirrors Standard
Rockford Fosgate audio system -inc: AM/FM stereo w/CD/MP3 player, radio data system, aux input, SiriusXM satellite radio, (10) speakers, subwoofer, illuminated steering wheel audio controls Optional
Vehicle dynamic control (VDC) Standard
4.0L DOHC 24-valve V6 engine Standard
Nissan engine cover Optional
Utili-Track channel system w/(4) tie-down cleats Optional
Front independent suspension w/stabilizer bar Standard
Oil pan & fuel tank skid plates Optional
In-cabin microfilter Optional
Full size spare Standard
Front/rear roof-mounted curtain side impact airbags Standard
Rearview monitor Optional
Leather-wrapped shift knob w/white stitching Optional
Active brake limited slip (ABLS) Standard
Clutch start cancel switch Optional
Side door guard beams Standard
Body-color pwr outside mirrors Optional
8-way manual driver seat w/adjustable lumbar support Optional
Multi-leaf rear suspension Standard
Front center console armrest w/storage Standard
Pwr door locks w/autolock Optional
(4) full-size doors Standard
Cloth seating surfaces Standard
P265/75R16 BF Goodrich Rugged Trail OWL tires Optional
6-speed manual transmission Standard
Rear passenger assist grips Standard
Rear defroster Standard
(3) aux pwr outlets Optional
Instrumentation -inc: tachometer, trip meter, coolant temp Standard
Security alarm system Optional
Dual front/rear cup holders Standard
Dual overhead map lights Optional
Engine immobilizer system Optional
Bilstein off-road high pressure shocks Optional
Body-color rear bumper Optional
Clutch interlock Standard
First aid kit Optional
Driver & front passenger dual-stage airbags w/occupant sensor Standard
Pwr windows w/driver side auto-down Optional
Tilt steering column Standard
4-wheel anti-lock braking system (ABS) Standard
16" off-road machine-finish alloy wheels Optional
PRO-4X white gauge faces Optional
Leather-wrapped steering wheel w/white stitching Optional
Rear heater duct Standard
Front seat-mounted side impact airbags Standard
Trip computer Optional
