2017 Nissan Titan S specs & colors

$29,580
Starting MSRP
Current listing price

Showing the 2017 Nissan Titan 4x2 Single Cab S

Shop Now

Key specs

Color options

Interior

Medium Grey


Packages

$800

Starting MSRP

  • Receiver Hitch
  • 4/7-pin wiring harness
  • Front Overhead Console

[K01] S Convenience & Utility Package

Specifications

Front Wheel Size 18 X 8 in
Spare Wheel Material Steel
Rear Wheel Size 18 X 8 in
Spare Wheel Size Full-Size in
Front Wheel Material Styled Steel
Rear Wheel Material Styled Steel

Maximum Alternator Capacity (amps) 200
Cold Cranking Amps @ 0° F (Primary) 710

Displacement 5.6 L/339
SAE Net Torque @ RPM 394 @ 4000
Engine Oil Cooler Regular Duty
SAE Net Horsepower @ RPM 390 @ 5800
Engine Type Regular Unleaded V-8

Fuel Economy Est-Combined 18 MPG
Cruising Range - Hwy 546.00 mi
EPA Fuel Economy Est - Hwy 21 MPG
Cruising Range - City 390.00 mi
EPA Fuel Economy Est - City 15 MPG
Estimated Battery Range N/A mi

Second Gear Ratio (:1) 3.17
Final Drive Axle Ratio (:1) N/A
Trans Type 7
Trans Description Cont. Automatic w/OD
Fifth Gear Ratio (:1) 1.00
Trans Description Cont. Again N/A
Transfer Case Gear Ratio (:1), Low N/A
Transfer Case Gear Ratio (:1), High N/A
Drivetrain Rear Wheel Drive
Reverse Ratio (:1) 4.04
First Gear Ratio (:1) 4.89
Transfer Case Model None
Sixth Gear Ratio (:1) 0.86
Trans Power Take Off N/A
Fourth Gear Ratio (:1) 1.41
Transfer Case Power Take Off No
Seventh Gear Ratio (:1) 0.77
Third Gear Ratio (:1) 2.03

Suspension Type - Front Double Wishbone
Suspension Type - Rear Leaf
Axle Type - Rear Rigid Axle
Axle Type - Front Independent

Frame Type N/A

Disc - Rear (Yes or ) Yes
Brake Type 4-Wheel Disc
Front Brake Rotor Diam x Thickness 13.8 in
Disc - Front (Yes or ) Yes
Drum - Rear (Yes or ) N/A
Brake ABS System (Second Line) 4-Wheel
Rear Brake Rotor Diam x Thickness 13.6 in
Brake ABS System 4-Wheel

Fuel Tank Capacity, Approx 26 gal
Aux Fuel Tank Capacity, Approx N/A gal

Steering Type Rack-Pinion
Turning Diameter - Wall to Wall N/A ft
Turning Diameter - Curb to Curb 48 ft
Steering Ratio (:1), Overall N/A

Front Tire Size P265/70SR18
Rear Tire Size P265/70SR18
Spare Tire Size Full-Size

Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Trailer Wt. 9740 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Maximum Trailering Capacity 9740 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Wt Distributing Hitch - Max Tongue Wt. 974 lbs

Curb Weight 5170.00 lbs
As Spec'd Payload 1930.00 lbs
Curb Weight - Front 3085 lbs
As Spec'd Curb Weight 5170.00 lbs
Total Option Weight 0.00 lbs
Gross Vehicle Weight Rating 7100.00 lbs
Gross Axle Weight Rating 7812.00 lbs
Curb Weight - Rear 2085 lbs
Option Weight - Rear 0.00 lbs
Base Curb Weight 5170 lbs
Maximum Payload Capacity 1930.00 lbs
Gross Combined Wt Rating N/A lbs
Option Weight - Front 0.00 lbs

Cargo Box Width @ Top, Rear 63.8 in
Front Shoulder Room 63.3 in
Second Shoulder Room N/A in
Cargo Box Width @ Wheelhousings 50 in
Ground Clearance, Rear 8.3 in
Front Hip Room 60.8 in
Length, Overall w/rear bumper N/A in
Cargo Volume N/A ft³
Cargo Box Length @ Floor 97.7 in
Ground Clearance, Front 8.3 in
Tailgate Width N/A in
Cab to End of Frame N/A in
Overhang, Front N/A in
Overhang, Rear w/o bumper N/A in
Ext'd Cab Cargo Volume N/A ft³
Front Leg Room 41.8 in
Length, Overall 228.1 in
Second Leg Room N/A in
Second Hip Room N/A in
Length, Overall w/o rear bumper N/A in
Ground to Top of Load Floor N/A in
Passenger Capacity 3
Cargo Box (Area) Height 20.8 in
Width, Max w/o mirrors 79.5 in
Height, Overall 74.5 in
Front Head Room 41 in
Wheelbase 139.8 in
Cargo Box Width @ Floor 63.8 in
Second Head Room N/A in

2 LCD Monitors In The Front Standard
Fixed Antenna Standard
Radio: NissanConnect w/Mobile Apps -inc: 5" color display, streaming audio via Bluetooth, USB connection port for iPod interface and other compatible devices, Bluetooth hands-free phone system, hands-free text messaging assistant and 4 speakers Standard
Radio w/Seek-Scan, MP3 Player, Clock, Speed Compensated Volume Control, Aux Audio Input Jack, Steering Wheel Controls, Radio Data System and External Memory Control Standard

Cargo Lamp w/High Mount Stop Light Standard
Aero-Composite Halogen Headlamps Standard
Black Side Windows Trim, Black Front Windshield Trim and Black Rear Window Trim Standard
Steel Spare Wheel Standard
Deep Tinted Glass Standard
Black Grille Standard
Sliding Rear Window w/Defroster Standard
Black Door Handles Standard
Black Front Bumper Standard
Full-Size Spare Tire Stored Underbody w/Crankdown Standard
Black Rear Step Bumper Standard
Tires: P265/70R18 AS BSW Standard
Galvanized Steel/Aluminum Panels Standard
Speed Sensitive Variable Intermittent Wipers Standard
Wheels w/Hub Covers Standard
Tailgate Rear Cargo Access Standard
Black Manual Side Mirrors w/Manual Folding Standard
Regular Box Style Standard
Manual Tailgate/Rear Door Lock Standard
Wheels: 18" x 8" Silver Metallic Styled Steel Standard

Proximity Key For Push Button Start Only Standard
Power Door Locks w/Autolock Feature Standard
Cloth Seat Trim w/Vinyl Bolsters Standard
Full Cloth Headliner Standard
Driver Information Center Standard
Cruise Control w/Steering Wheel Controls Standard
Dashboard Storage, Driver And Passenger Door Bins Standard
Pickup Cargo Box Lights Standard
2 12V DC Power Outlets Standard
Immobilizer Standard
Air Filtration Standard
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry, Illuminated Ignition Switch and Panic Button Standard
Passenger Visor Vanity Mirror w/Driver And Passenger Auxiliary Mirror Standard
Analog Appearance Standard
Armrests w/Storage Standard
Manual Adjustable Front Head Restraints Standard
Valet Function Standard
Urethane Gear Shifter Material Standard
FOB Controls -inc: Windows Standard
4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement Standard
Fade-To-Off Interior Lighting Standard
Manual Tilt/Telescoping Steering Column Standard
Interior Trim -inc: Metal-Look Interior Accents Standard
Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Tachometer, Trip Odometer and Trip Computer Standard
Full Vinyl/Rubber Floor Covering Standard
Perimeter Alarm Standard
Driver Foot Rest Standard
Trip Computer Standard
Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down Standard
Day-Night Rearview Mirror Standard
Manual Air Conditioning Standard
Seats w/Cloth Back Material Standard
Locking Glove Box Standard
Outside Temp Gauge Standard
4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement Standard
Front Manual Split Bench Seat (40/20/40) -inc: flip down center seat w/armrest, dual cupholders and storage (in seat-back and seat-bottom) Standard

2.937 Axle Ratio Standard
1920# Maximum Payload Standard
Gas-Pressurized Shock Absorbers Standard
Solid Axle Rear Suspension w/Leaf Springs Standard
Front And Rear Anti-Roll Bars Standard
Hydraulic Power-Assist Speed-Sensing Steering Standard
Double Wishbone Front Suspension w/Coil Springs Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist and Hill Hold Control Standard
Engine Oil Cooler Standard
Engine: 5.6L V8 Standard
Single Stainless Steel Exhaust Standard
Transmission w/Driver Selectable Mode and Sequential Shift Control Standard
200 Amp Alternator Standard
80-Amp/Hr 710CCA Maintenance-Free Battery w/Run Down Protection Standard
Rear-Wheel Drive Standard
26 Gal. Fuel Tank Standard
GVWR: 7,100 lbs Standard
Transmission: 7-Speed Automatic Standard

Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Tire Specific Low Tire Pressure Warning Standard
ABS And Driveline Traction Control Standard
Dual Stage Driver And Passenger Front Airbags Standard
Electronic Stability Control (ESC) Standard
Curtain 1st Row Airbags Standard
Airbag Occupancy Sensor Standard
Side Impact Beams Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners Standard
