2012 RAM 1500 ST specs & colors

$22,570
Starting MSRP
Current listing price
2012 RAM 1500 ST

Showing the 2012 RAM 1500 2WD Reg Cab 120.5" ST

Shop Now

Key specs

Color options

Interior

Dark slate gray


Packages

$0

Starting MSRP

  • 4.7L V8 engine
  • 6-speed auto trans

$0

Starting MSRP

  • 5.7L V8 Hemi engine
  • 6-speed auto trans

$0

Starting MSRP

  • 3.7L V6 engine
  • 4-speed auto trans

Specifications

Spare Wheel Size 17 x -TBD- in
Front Wheel Size 17 x 7.0 in
Front Wheel Material Steel
Rear Wheel Material Steel
Rear Wheel Size 17 x 7.0 in
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) 730
Maximum Alternator Capacity (amps) 160
Engine Type Gas V6
SAE Net Torque @ RPM 235 @ 4000
Displacement 3.7L/226
Engine Oil Cooler Not Available
SAE Net Horsepower @ RPM 215 @ 5200
EPA Fuel Economy Est - City 14 MPG
Fuel Economy Est-Combined 16 MPG
EPA Fuel Economy Est - Hwy 20 MPG
Cruising Range - City 364.00 mi
Cruising Range - Hwy 520.00 mi
Estimated Battery Range N/A mi
Transfer Case Gear Ratio (:1), Low Not Available
Transfer Case Power Take Off Not Available
Second Gear Ratio (:1) 1.57
First Gear Ratio (:1) 2.84
Fourth Gear Ratio (:1) 0.69
Third Gear Ratio (:1) 1.00
Reverse Ratio (:1) 2.21
Transfer Case Model Not Available
Transfer Case Gear Ratio (:1), High Not Available
Trans Power Take Off Not Available
Trans Description Cont. Again Not Available
Final Drive Axle Ratio (:1) N/A
Trans Type 4
Drivetrain Rear Wheel Drive
Trans Description Cont. Automatic
Suspension Type - Rear Multi-link coil
Axle Type - Rear Solid
Suspension Type - Front Independent
Axle Type - Front Not Available
Frame Type Ladder type
Drum - Rear (Yes or ) Not Available
Rear Brake Rotor Diam x Thickness 13.8 x 0.9 in
Brake Type Pwr
Brake ABS System (Second Line) Not Available
Disc - Front (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.2 x 1.1 in
Brake ABS System 4-Wheel
Disc - Rear (Yes or ) Yes
Fuel Tank Capacity, Approx 26.0 gal
Aux Fuel Tank Capacity, Approx Not Available gal
Turning Diameter - Wall to Wall N/A ft
Turning Diameter - Curb to Curb 39.5 ft
Steering Ratio (:1), Overall N/A
Steering Type Pwr rack & pinion
Rear Tire Size P265/70R17
Spare Tire Size Full-Size
Front Tire Size P265/70R17
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 570 lbs
Maximum Trailering Capacity N/A lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Trailer Wt. 3800 lbs
Wt Distributing Hitch - Max Trailer Wt. 3800 lbs
Dead Weight Hitch - Max Tongue Wt. 380 lbs
Gross Vehicle Weight Rating 6025.00 lbs
Base Curb Weight N/A lbs
Option Weight - Rear 0.00 lbs
As Spec'd Payload 1506.00 lbs
Curb Weight 4519.00 lbs
As Spec'd Curb Weight 4519.00 lbs
Curb Weight - Rear 2019 lbs
Gross Combined Wt Rating 8500 lbs
Total Option Weight 0.00 lbs
Maximum Payload Capacity 1506.00 lbs
Gross Axle Weight Rating 7600.00 lbs
Curb Weight - Front 2500 lbs
Option Weight - Front 0.00 lbs
Front Shoulder Room 66.0 in
Front Hip Room 62.9 in
Cargo Box (Area) Height 20.1 in
Cargo Volume 57.5 ft³
Length, Overall w/o rear bumper 209.0 in
Ground to Top of Load Floor 34.8 in
Overhang, Front 40.0 in
Length, Overall N/A in
Second Hip Room N/A in
Cab to End of Frame N/A in
Cargo Box Width @ Wheelhousings 51.0 in
Second Leg Room N/A in
Second Head Room N/A in
Front Leg Room 41.0 in
Cargo Box Width @ Floor 66.4 in
Passenger Capacity 3
Cargo Box Width @ Top, Rear 66.4 in
Ground Clearance, Front 9.7 in
Height, Overall 74.6 in
Second Shoulder Room N/A in
Width, Max w/o mirrors 79.4 in
Cargo Box Length @ Floor 76.3 in
Ext'd Cab Cargo Volume Not Available ft³
Ground Clearance, Rear 9.0 in
Front Head Room 40.3 in
Length, Overall w/rear bumper N/A in
Overhang, Rear w/o bumper N/A in
Wheelbase 120.5 in
Tailgate Width 60.4 in
P265/70R17 all-season BSW tires Standard
Gray upper front fascia Standard
Front stabilizer bar Standard
Black instrument panel bezel Standard
Trailer tow w/4-pin connector wiring Standard
Rear wheel drive Standard
Black door handles Standard
Front wheel spats Standard
Front side curtain airbags Standard
Behind the seat storage bin Standard
3.55 axle ratio Standard
Black vinyl floor covering Standard
Rear wheel spats Standard
Rear dome lamp Standard
HD front shock absorbers Standard
Pwr accessory delay Standard
Pwr rack & pinion steering Standard
Rear stabilizer bar Standard
4-speed VLP automatic transmission (REQ: EKG Engine) Standard
Dual note horn Standard
HD vinyl 40/20/40 bench seat w/manual adjusters Standard
Black grille Standard
Full-size spare tire Standard
Audio jack input for mobile devices Standard
Black rear bumper Standard
Floor tunnel insulation Standard
Aux transmission oil cooler Standard
Body color fuel filler door Standard
12V aux pwr outlet Standard
Cargo lamp Standard
Front seat side-impact airbags Standard
(6) speakers Standard
17" x 7" argent steel wheels Standard
Driver/front passenger multistage airbags Standard
Locking tailgate Standard
17" steel spare wheel Standard
Column-mounted shifter Standard
Instrument cluster w/tachometer Standard
Air conditioning Standard
Base door trim Standard
Tinted windows Standard
160-amp alternator Standard
HD rear shock absorbers Standard
Electronic stability control Standard
Auto headlamps Standard
Tire pressure monitor w/warning lamp Standard
Fixed long mast antenna Standard
Tilt steering column Standard
3.7L V6 engine (N/A w/NAS 50-State Emissions) Standard
Assist handles Standard
Manual outside mirrors Standard
Uconnect 130 -inc: AM/FM stereo, CD/MP3 player Standard
Anti-lock 4-wheel disc brakes Standard
Day/night rearview mirror Standard
Variable intermittent windshield wipers Standard
Tire carrier winch Standard
Sentry Key theft deterrent system Standard
Front seat belt height adjusters Standard
Halogen headlamps Standard
Black front bumper Standard
Front license plate bracket Standard
730-amp maintenance-free battery Standard
Front-passenger occupant-classification system Standard
Front bumper sight shields Standard
Fixed rear window Standard
7-pin wiring harness Standard
6'4" pickup box Standard
