2014 RAM 1500 Lone Star specs & colors

Crew Cab Pickup

Change trim

MSRP
Change trim
$37,645
Starting MSRP
Current listing price

Showing the 2014 RAM 1500 2WD Crew Cab 149" Lone Star

Shop Now

Key specs

Color options

Interior

Canyon Brown / Light Frost Beige Interior

Black / Diesel Gray Interior

Packages

$1,295

Starting MSRP

$560

Starting MSRP

  • Leather Wrapped Steering Wheel
  • Exterior Mirrors w/Supplemental Signals
  • Rear Dome w/On/Off Switch Lamp

Luxury Group

$560

Starting MSRP

  • Leather Wrapped Steering Wheel
  • Exterior Mirrors w/Supplemental Signals
  • Rear Dome w/On/Off Switch Lamp
  • Underhood Lamp
  • Steering Wheel Mounted Audio Controls
  • Exterior Mirrors Courtesy Lamps
  • Glove Box Lamp
  • Ash Tray Lamp
  • Rear View Auto Dim Mirror w/Microphone
  • Auto Dim Exterior Mirror
  • Power Folding Mirrors
  • Power Heated Fold-Away Mirrors
  • Auto Dim Exterior Passenger Mirror
  • Sun Visors w/Illuminated Vanity Mirrors
  • Electroluminescent Instrument Cluster
  • Overhead Console w/Garage Door Opener
  • Universal Garage Door Opener

$595

Starting MSRP

  • ParkView Rear Back-Up Camera
  • ParkSense Front/Rear Park Assist System
See all packages

$805

Starting MSRP

  • Engine: 5.7L V8 HEMI MDS VVT
  • Transmission: 8-Speed Automatic (8HP70)
  • Full Size Temporary Use Spare Tire

Quick Order Package 26Y Lone Star

$805

Starting MSRP

  • Engine: 5.7L V8 HEMI MDS VVT
  • Transmission: 8-Speed Automatic (8HP70)
  • Full Size Temporary Use Spare Tire
  • Leather Wrapped Steering Wheel
  • Fog Lamps
  • Steering Wheel Mounted Audio Controls
  • Bright/Bright Billets Grille
  • Locking Lug Nuts
  • Lonestar Badge
  • Class IV Receiver Hitch
  • Power Black Trailer Tow Mirrors
  • Exterior Mirrors w/Supplemental Signals
  • Exterior Mirrors Courtesy Lamps

$350

Starting MSRP

  • Remote Start System
  • Security Alarm

$395

Starting MSRP

  • Heated Steering Wheel
  • Heated Front Seats

$805

Starting MSRP

  • Engine: 3.0L V6 Ecodiesel
  • Transmission: 8-Speed Automatic (8HP70)
  • Full Size Temporary Use Spare Tire

Quick Order Package 28Y Lone Star

$805

Starting MSRP

  • Engine: 3.0L V6 Ecodiesel
  • Transmission: 8-Speed Automatic (8HP70)
  • Full Size Temporary Use Spare Tire
  • Leather Wrapped Steering Wheel
  • Fog Lamps
  • Steering Wheel Mounted Audio Controls
  • Bright/Bright Billets Grille
  • Locking Lug Nuts
  • Lonestar Badge
  • Class IV Receiver Hitch
  • Power Black Trailer Tow Mirrors
  • Exterior Mirrors w/Supplemental Signals
  • Exterior Mirrors Courtesy Lamps

$610

Starting MSRP

  • Leather Wrapped Steering Wheel
  • 6 Mo
  • Trial (Registration Required)

Lone Star Premium Group

$610

Starting MSRP

  • Leather Wrapped Steering Wheel
  • 6 Mo
  • Trial (Registration Required)
  • Rear Dome w/On/Off Switch Lamp
  • Underhood Lamp
  • Glove Box Lamp
  • Ash Tray Lamp
  • Auto Dim Exterior Mirror
  • Security Alarm
  • Power Heated Fold-Away Mirrors
  • Electroluminescent Instrument Cluster
  • Overhead Console w/Garage Door Opener
  • Universal Garage Door Opener
  • Remote Start System
  • 6 Month Trial (Reg
  • Required)
  • Radio: Uconnect 8.4A AM/FM/SXM/BT
  • Remote SD Card Slot
  • SIRIUSXM Satellite Radio
  • No satellite coverage in Hawaii or Alaska
  • Media Hub (SD
  • USB
  • AUX)
  • For Details Go To DriveUconnect.com
  • Uconnect Access
  • 8.4" Touchscreen Display
  • Nav-Capable! See Dealer for Details
  • Uconnect Voice Command w/Bluetooth
  • Exterior Mirrors w/Supplemental Signals
  • Steering Wheel Mounted Audio Controls
  • Exterior Mirrors Courtesy Lamps
  • Rear View Auto Dim Mirror w/Microphone
  • Roadside Assistance & 9-1-1 Call
  • Power Folding Mirrors
  • ParkView Rear Back-Up Camera
  • Auto Dim Exterior Passenger Mirror,Sun Visors w/Illuminated Vanity Mirrors
  • Wheel to Wheel Side Steps
  • ParkSense Front/Rear Park Assist System

$410

Starting MSRP

  • Trailer Brake Control

Specifications

Rear Wheel Size 20 X 8 in
Spare Wheel Material Steel
Spare Wheel Size Full-Size in
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Front Wheel Size 20 X 8 in

Maximum Alternator Capacity (amps) 180
Cold Cranking Amps @ 0° F (Primary) 730

SAE Net Torque @ RPM 410 @ 3950
Engine Oil Cooler None
Displacement 5.7 L/345
Engine Type Regular Unleaded V-8
SAE Net Horsepower @ RPM 395 @ 5600

Cruising Range - City 390.00 mi
Cruising Range - Hwy 572.00 mi
Fuel Economy Est-Combined 17 (Est) MPG
EPA Fuel Economy Est - City 15 (Est) MPG
Estimated Battery Range N/A mi
EPA Fuel Economy Est - Hwy 22 (Est) MPG

Drivetrain Rear Wheel Drive
Trans Type 8
Seventh Gear Ratio (:1) 0.84
First Gear Ratio (:1) 4.71
Transfer Case Gear Ratio (:1), Low N/A
Fifth Gear Ratio (:1) 1.29
Transfer Case Gear Ratio (:1), High N/A
Trans Description Cont. Again N/A
Transfer Case Model None
Fourth Gear Ratio (:1) 1.67
Third Gear Ratio (:1) 2.10
Second Gear Ratio (:1) 3.14
Eighth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) N/A
Trans Power Take Off N/A
Reverse Ratio (:1) 3.30
Transfer Case Power Take Off No
Sixth Gear Ratio (:1) 1.00
Trans Description Cont. Automatic w/OD

Axle Type - Front Independent
Suspension Type - Front Short And Long Arm
Suspension Type - Rear Multi-Link
Axle Type - Rear Rigid Axle

Frame Type N/A

Brake Type 4-Wheel Disc
Rear Brake Rotor Diam x Thickness 13.8 in
Disc - Rear (Yes or ) Yes
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.2 in
Drum - Rear (Yes or ) N/A
Brake ABS System (Second Line) 4-Wheel

Fuel Tank Capacity, Approx 26 gal
Aux Fuel Tank Capacity, Approx N/A gal

Turning Diameter - Wall to Wall N/A ft
Steering Type Rack-Pinion
Steering Ratio (:1), Overall N/A
Turning Diameter - Curb to Curb 47.6 ft

Spare Tire Size Full-Size
Rear Tire Size P275/60SR20
Front Tire Size P275/60SR20

Wt Distributing Hitch - Max Trailer Wt. 8100 lbs
Dead Weight Hitch - Max Tongue Wt. 500 lbs
Maximum Trailering Capacity 8100 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Dead Weight Hitch - Max Trailer Wt. 5000 lbs
Wt Distributing Hitch - Max Tongue Wt. 810 lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs

Base Curb Weight 5223 lbs
Gross Axle Weight Rating 7600.00 lbs
Maximum Payload Capacity 1677.00 lbs
Option Weight - Rear 0.00 lbs
As Spec'd Payload 1677.00 lbs
As Spec'd Curb Weight 5223.00 lbs
Curb Weight - Front 2975 lbs
Gross Combined Wt Rating 13500 lbs
Option Weight - Front 0.00 lbs
Total Option Weight 0.00 lbs
Curb Weight 5223.00 lbs
Gross Vehicle Weight Rating 6900.00 lbs
Curb Weight - Rear 2248 lbs

Front Leg Room 41 in
Ground Clearance, Rear 7.7 in
Front Hip Room 63.2 in
Second Shoulder Room 65.7 in
Ground Clearance, Front 7.7 in
Overhang, Front 40 in
Front Shoulder Room 66 in
Cargo Volume 57.5 ft³
Overhang, Rear w/o bumper 48.4 in
Ground to Top of Load Floor 34.4 in
Cargo Box Length @ Floor 76.3 in
Front Head Room 41 in
Height, Overall 77.5 in
Length, Overall w/o rear bumper N/A in
Wheelbase 149 in
Passenger Capacity 6
Cab to End of Frame N/A in
Second Head Room 39.9 in
Length, Overall 237.9 in
Length, Overall w/rear bumper N/A in
Cargo Box Width @ Floor 66.4 in
Cargo Box Width @ Wheelhousings 51 in
Ext'd Cab Cargo Volume N/A ft³
Second Hip Room 63.2 in
Cargo Box Width @ Top, Rear 66.4 in
Width, Max w/o mirrors 79.4 in
Cargo Box (Area) Height 20 in
Tailgate Width 60.4 in
Second Leg Room 40.3 in

Fixed Antenna Standard
Media Hub (USB, AUX) Standard
6 Speakers Standard
Integrated Voice Command w/Bluetooth Optional
Radio w/Clock Optional
Charge Only Remote USB Port Optional
Streaming Audio Optional
Radio: Uconnect 5.0 AM/FM/BT Optional

Regular Box Style Standard
Wheels: 20" x 8" Aluminum Chrome Clad (STD) Optional
Steel Spare Wheel Standard
Exterior Mirrors w/Heating Element Standard
Spare Tire Stored Underbody w/Crankdown Optional
Power Rear Window Optional
Tailgate Rear Cargo Access Standard
Cargo Lamp w/High Mount Stop Light Standard
Black Exterior Mirrors Standard
Auto On/Off Aero-Composite Halogen Headlamps w/Delay-Off Standard
Goodyear Brand Tires Optional
Deep Tinted Glass Standard
Chrome Rear Step Bumper Optional
Galvanized Steel/Aluminum Panels Standard
Variable Intermittent Wipers Standard
Tires: P275/60R20 BSW AS (STD) Optional
Chrome Front Bumper w/Body-Colored Rub Strip/Fascia Accent Optional
Tailgate/Rear Door Lock Included w/Power Door Locks Optional
Chrome Door Handles Optional
Black Side Windows Trim and Black Front Windshield Trim Standard
Front License Plate Bracket Standard

Passenger Visor Vanity Mirror Optional
Mini Overhead Console Optional
Full Cloth Headliner Standard
Full Folding Bench Front Facing Fold-Up Cushion Rear Seat Optional
Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats Optional
Sentry Key Immobilizer Standard
Cargo Area Concealed Storage Standard
Urethane Gear Shifter Material Standard
Valet Function Optional
Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Tachometer, Oil Temperature, Transmission Fluid Temp, Engine Hour Meter, Trip Odometer and Trip Computer Optional
Storage Tray Standard
Rear Cupholder Standard
40/20/40 Split Bench Seat Standard
HVAC -inc: Underseat Ducts and Console Ducts Standard
Power Rear Windows Standard
Front Map Lights Optional
FOB Controls -inc: Cargo Access Optional
Manual Air Conditioning Standard
Compass Optional
Manual Adjustable Front Head Restraints and Manual Adjustable Rear Head Restraints Standard
Interior Trim -inc: Deluxe Sound Insulation, Metal-Look Instrument Panel Insert, Metal-Look Door Panel Insert and Chrome/Metal-Look Interior Accents Optional
Vinyl Door Trim Insert Optional
Rear View Mirror w/Microphone Optional
Trip Computer Optional
Driver Information Center Standard
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button Optional
4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement Standard
Fade-To-Off Interior Lighting Standard
Analog Appearance Standard
Front Armrest w/3 Cupholders Standard
Outside Temp Gauge Optional
Pickup Cargo Box Lights Standard
Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down Standard
5.0" Touchscreen Display Optional
Armrests w/Storage and Rear Center Armrest Optional
Power Door Locks w/Autolock Feature Optional
Instrument Panel Bin, Dashboard Storage, Driver / Passenger And Rear Door Bins and 2nd Row Underseat Storage Standard
4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement Standard
Manual Tilt Steering Column Standard
Cruise Control w/Steering Wheel Controls Standard
Redundant Digital Speedometer Optional

Quasi-Dual Stainless Steel Exhaust w/Chrome Tailpipe Finisher Optional
Short And Long Arm Front Suspension w/Coil Springs Standard
Front And Rear Anti-Roll Bars Standard
HD Shock Absorbers Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control Standard
180 Amp Alternator Optional
730CCA Maintenance-Free Battery Standard
3.21 Rear Axle Ratio (STD) Standard
Electric Power-Assist Steering Standard
26 Gal. Fuel Tank Standard
Trailer Wiring Harness Standard
1600# Maximum Payload Optional
Engine: 5.7L V8 HEMI MDS VVT (STD) Standard
GVWR: 6,900 lbs (STD) Optional
Towing Equipment -inc: Trailer Sway Control Optional
Solid Axle Rear Suspension w/Coil Springs Standard
Transmission: 8-Speed Automatic (8HP70) (STD) Optional
Rear-Wheel Drive Standard
Transmission w/Driver Selectable Mode, Sequential Shift Control w/Steering Wheel Controls and HD Oil Cooler Optional

Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners Standard
ABS And Driveline Traction Control Standard
Airbag Occupancy Sensor Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
Side Impact Beams Standard
Electronic Stability Control (ESC) Standard
Curtain 1st And 2nd Row Airbags Standard
Dual Stage Driver And Passenger Front Airbags Standard
Rear Child Safety Locks Standard
Tire Specific Low Tire Pressure Warning Standard

Compare trims

Wondering which trim is right for you?

Our 2014 RAM 1500 trim comparison will help you decide.
