2016 RAM 1500 Big Horn specs & colors

$31,795
Starting MSRP
Current listing price
2016 RAM 1500 Big Horn

Showing the 2016 RAM 1500 2WD Reg Cab 140.5" Big Horn

Shop Now

Key specs

Color options

Interior

Canyon Brown / Light Frost Beige Interior


Black / Diesel Gray Interior


Packages

$235

Starting MSRP

  • Engine Block Heater
  • Winter Front Grille Cover

$460

Starting MSRP

  • Trailer Brake Control
  • Power Black Trailer Tow Mirrors
  • Exterior Mirrors w/Supplemental Signals

Trailer Tow Mirrors & Brake Group

$405

Starting MSRP

  • Heated Steering Wheel
  • Heated Front Seats
See all packages

$2,265

Starting MSRP

  • Engine: 5.7L V8 HEMI MDS VVT
  • Transmission: 8-Speed Automatic (8HP70)
  • Remote Start System

Quick Order Package 26S Big Horn

$2,265

Starting MSRP

  • Engine: 3.6L V6 24V VVT
  • Transmission: 8-Speed Automatic (845RE)
  • Remote Start System

Quick Order Package 22S Big Horn

$2,265

Starting MSRP

  • Engine: 3.0L V6 Turbo Diesel
  • Transmission: 8-Speed Automatic (8HP70) (DFD)
  • Remote Start System

Quick Order Package 28S Big Horn

Specifications

Spare Wheel Size Full-Size in
Rear Wheel Size 20 X 8 in
Front Wheel Material Aluminum
Front Wheel Size 20 X 8 in
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Cold Cranking Amps @ 0° F (Primary) 730
Maximum Alternator Capacity (amps) 160
Displacement 3.6 L/220
Engine Type Regular Unleaded V-6
SAE Net Horsepower @ RPM 305 @ 6400
SAE Net Torque @ RPM 269 @ 4175
Engine Oil Cooler Regular Duty
Estimated Battery Range N/A mi
Cruising Range - Hwy 800.00 mi
EPA Fuel Economy Est - Hwy 25 MPG
Fuel Economy Est-Combined 20 MPG
EPA Fuel Economy Est - City 17 MPG
Cruising Range - City 544.00 mi
Fifth Gear Ratio (:1) 1.28
Trans Description Cont. Automatic w/OD
Trans Type 8
Drivetrain Rear Wheel Drive
Seventh Gear Ratio (:1) 0.84
Trans Power Take Off N/A
Transfer Case Gear Ratio (:1), Low N/A
Fourth Gear Ratio (:1) 1.67
Transfer Case Model None
Sixth Gear Ratio (:1) 1.00
Transfer Case Gear Ratio (:1), High N/A
Reverse Ratio (:1) 3.29
Transfer Case Power Take Off No
Second Gear Ratio (:1) 3.14
Eighth Gear Ratio (:1) 0.67
Final Drive Axle Ratio (:1) N/A
First Gear Ratio (:1) 4.71
Trans Description Cont. Again N/A
Third Gear Ratio (:1) 2.11
Suspension Type - Front Short And Long Arm
Axle Type - Rear Rigid Axle
Suspension Type - Rear Multi-Link
Axle Type - Front Independent
Frame Type N/A
Rear Brake Rotor Diam x Thickness 13.8 in
Disc - Rear (Yes or ) Yes
Brake ABS System 4-Wheel
Drum - Rear (Yes or ) N/A
Brake Type 4-Wheel Disc
Front Brake Rotor Diam x Thickness 13.2 in
Disc - Front (Yes or ) Yes
Brake ABS System (Second Line) 4-Wheel
Fuel Tank Capacity, Approx 32 gal
Aux Fuel Tank Capacity, Approx N/A gal
Steering Type Rack-Pinion
Turning Diameter - Curb to Curb 45.1 ft
Turning Diameter - Wall to Wall N/A ft
Steering Ratio (:1), Overall N/A
Spare Tire Size Full-Size
Front Tire Size P275/60SR20
Rear Tire Size P275/60SR20
Wt Distributing Hitch - Max Trailer Wt. 4820 lbs
Maximum Trailering Capacity 4820 lbs
Dead Weight Hitch - Max Tongue Wt. 482 lbs
Fifth Wheel Hitch - Max Trailer Wt. N/A lbs
Fifth Wheel Hitch - Max Tongue Wt. N/A lbs
Wt Distributing Hitch - Max Tongue Wt. 482 lbs
Dead Weight Hitch - Max Trailer Wt. 4820 lbs
As Spec'd Curb Weight 4765.00 lbs
Gross Combined Wt Rating 9850 lbs
Base Curb Weight 4765 lbs
Curb Weight 4765.00 lbs
Curb Weight - Rear 2083 lbs
Option Weight - Rear 0.00 lbs
Gross Axle Weight Rating 7600.00 lbs
Curb Weight - Front 2682 lbs
Gross Vehicle Weight Rating 6600.00 lbs
As Spec'd Payload 1835.00 lbs
Maximum Payload Capacity 1835.00 lbs
Option Weight - Front 0.00 lbs
Total Option Weight 0.00 lbs
Ground Clearance, Rear 8.7 in
Cargo Box (Area) Height 20.2 in
Width, Max w/o mirrors 79.4 in
Front Head Room 39.9 in
Passenger Capacity 3
Tailgate Width 60.4 in
Cargo Box Width @ Floor 66.4 in
Front Leg Room 41 in
Front Hip Room 62.9 in
Cargo Box Width @ Wheelhousings 51 in
Ground to Top of Load Floor 34.6 in
Overhang, Rear w/o bumper 50.4 in
Second Hip Room N/A in
Height, Overall 74.4 in
Cargo Box Width @ Top, Rear 66.4 in
Ext'd Cab Cargo Volume N/A ft³
Length, Overall w/rear bumper N/A in
Length, Overall w/o rear bumper N/A in
Ground Clearance, Front 8.7 in
Second Shoulder Room N/A in
Cargo Volume 74.7 ft³
Front Shoulder Room 66 in
Wheelbase 140 in
Overhang, Front N/A in
Cab to End of Frame N/A in
Cargo Box Length @ Floor 98.3 in
Second Head Room N/A in
Second Leg Room N/A in
Length, Overall 231 in
6 Speakers Standard
Charge Only Remote USB Port Optional
Streaming Audio Optional
SIRIUSXM Satellite Radio Optional
Integrated Voice Command w/Bluetooth Optional
AM/FM/Satellite w/Seek-Scan, Clock, Aux Audio Input Jack, Voice Activation and Radio Data System Optional
Radio: Uconnect 8.4 -inc: 6 Month Trial (Reg, Required), Media Hub (SD, USB, AUX), For Details Visit DriveUconnect.com, 6 Month Trial (Registration Required), Remote SD Card Slot, Harman Radio Manufacturer, Uconnect Access, 8.4" Touchscreen Display, Nav-Capable! See Dealer for Details Optional
Fixed Antenna Standard
Chrome Rear Step Bumper Optional
Auto On/Off Reflector Halogen Headlamps w/Delay-Off Standard
Regular Box Style Standard
Galvanized Steel/Aluminum Panels Standard
Steel Spare Wheel Standard
Tires: P275/60R20 BSW AS (STD) Optional
Variable Intermittent Wipers Standard
Black Side Windows Trim and Black Front Windshield Trim Standard
Tailgate/Rear Door Lock Included w/Power Door Locks Optional
Tailgate Rear Cargo Access Standard
Chrome Door Handles Optional
Exterior Mirrors w/Heating Element Optional
Fog Lamps Optional
Active Grille Shutters Standard
Black Exterior Mirrors Optional
Chrome Front Bumper w/Body-Colored Rub Strip/Fascia Accent Optional
Wheels: 20" x 8" Aluminum Chrome Clad (STD) Optional
Light Tinted Glass Standard
Goodyear Brand Tires Standard
Front License Plate Bracket Standard
Fixed Rear Window Standard
Instrument Panel Bin, Dashboard Storage, Driver And Passenger Door Bins Standard
Manual Air Conditioning Standard
Power 1st Row Windows w/Driver And Passenger 1-Touch Down Optional
Valet Function Optional
Redundant Digital Speedometer Optional
Manual Adjustable Front Head Restraints Standard
GPS Antenna Input Optional
Sentry Key Immobilizer Standard
Outside Temp Gauge Optional
Mini Overhead Console and 2 12V DC Power Outlets Optional
Trip Computer Optional
Front Map Lights Optional
2 12V DC Power Outlets Standard
Fade-To-Off Interior Lighting Standard
Urethane Gear Shifter Material Standard
Compass Optional
Power Door Locks w/Autolock Feature Optional
Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button Optional
Electronic Shift Standard
Manual Tilt Steering Column Standard
Full Cloth Headliner Standard
FOB Controls -inc: Cargo Access Optional
Interior Trim -inc: Deluxe Sound Insulation, Metal-Look Instrument Panel Insert, Metal-Look Door Panel Insert and Chrome/Metal-Look Interior Accents Optional
Full Carpet Floor Covering -inc: Carpet Front Floor Mats Optional
ParkView Rear Back-Up Camera Optional
Armrests w/Storage Optional
Cruise Control w/Steering Wheel Controls Standard
Day-Night Rearview Mirror Standard
Driver Information Center Standard
Front Armrest w/3 Cupholders Standard
4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement Standard
40/20/40 Split Bench Seat Standard
Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Tachometer, Oil Temperature, Transmission Fluid Temp, Engine Hour Meter, Trip Odometer and Trip Computer Optional
Vinyl Door Trim Insert Optional
Front Cupholder Standard
Analog Appearance Standard
4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement Standard
Class IV Receiver Hitch Optional
Single Stainless Steel Exhaust Standard
Solid Axle Rear Suspension w/Coil Springs Standard
32 Gal. Fuel Tank Standard
Engine Oil Cooler Standard
3.21 Rear Axle Ratio (STD) Standard
HD Shock Absorbers Standard
Rear-Wheel Drive Standard
Electric Power-Assist Steering Standard
160 Amp Alternator Standard
Towing Equipment -inc: Trailer Sway Control Optional
Engine: 3.6L V6 24V VVT -inc: Flex fuel capable (STD) Standard
Transmission w/Driver Selectable Mode and Oil Cooler Standard
1880# Maximum Payload Optional
Transmission: 8-Speed Automatic (845RE) (STD) Standard
Short And Long Arm Front Suspension w/Coil Springs Standard
GVWR: 6,600 lbs Standard
730CCA Maintenance-Free Battery Standard
Trailer Wiring Harness Standard
4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control Standard
Front Anti-Roll Standard
Luxury Group -inc: Leather Wrapped Steering Wheel, Exterior Mirrors w/Supplemental Signals, Rear Dome w/On/Off Switch Lamp, Underhood Lamp, LED Bed Lighting, Steering Wheel Mounted Audio Controls, Exterior Mirrors Courtesy Lamps, Glove Box Lamp, Ash Tray Lamp, Rear View Auto Dim Mirror w/Microphone, Auto Dim Exterior Mirrors, Power Folding Mirrors, Power Heated Fold-Away Mirrors, Sun Visors w/Illuminated Vanity Mirrors, Electroluminescent Instrument Cluster, Overhead Console w/Garage Door Opener, Universal Garage Door Opener Optional
Electronic Stability Control (ESC) Standard
ABS And Driveline Traction Control Standard
Curtain 1st Row Airbags Standard
Dual Stage Driver And Passenger Front Airbags Standard
Tire Specific Low Tire Pressure Warning Standard
Airbag Occupancy Sensor Standard
Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners Standard
Side Impact Beams Standard
Dual Stage Driver And Passenger Seat-Mounted Side Airbags Standard
